LP50 & LP50H
Item no.:
LP50 Vertical lifting platform: 13013-xxx
LP50H Cantilever vertical lifting platform: 13012-xxx

3
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
1.00 Purpose and use
1.01 Manufacturer
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
Denmark
Tlf. [phone]
Fax [phone]
1.02 Purpose and use
Purpose
LP50 / LP50H is a oor mounted lifting platform which can be used by per-
sons with impaired mobility (e.g. walking-impaired, wheelchair users, persons
with pushchairs and sack trucks) to meet the demand for negotiating minor
height differences of up to 830 mm.
The LP50 is a vertical lifting platform. LP50H is a lifting platform with a com-
bined vertical and horizontal movement.
Use
The LP50/LP50H is recessed into the oor in front of the stairs/landing and is
designed for permanent installation indoors. The lifting platform may be used
in temperatures from -10 to +40 degrees. In temperatures of less than -10
degrees, the application of suitable heating beneath the platform is recom-
mended.
When the lifting platform is activated, the four safety edges go up automa-
tically and ensure that the user does not roll over the edge when the platform
is in motion. When the platform is level with the landing, the platform stops
and the safety edge in the front goes down automatically so the user can
drive onto the landing.
LP50 is designed and produced in accordance with current standards for nego-
tiating height differences from 0-500 mm.
LP50H is designed and produced in accordance with current standards for
negotiating height differences (stairs) from 0-830 mm. Be aware of local regula-
tions in relation to lifting height.
Great importance is attached to the design and implementation to achieve an
attractive and harmonious installation in different environments, private and pub-
lic. Public environments are institutions, public buildings, etc., where the lifting
platform is subject to a certain amount of supervision. In these environments, the
lifting platform should be locked, protecting it against unintentional use or games.
When the lifting platform is in use, it is understood that the user has been
instructed on its use, or that a skilled personnel is present to assist.

4
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
1.03 Important / warnings
• All of the operating instructions must be read before the product is used.
• The LP50 / LP50H must be assembled by the Guldmann Service Team, or by
an engineer approved by Guldmann.
• The lifting platform is controlled by a microprocessor print which can be dam-
aged by static electricity if touched without the necessary precautions. The
electronics must therefore be serviced by trained technicians only.
• The accompanying safety chain must be used when the service engineer
moves around beneath the lifting platform.
• The max. load must not be exceeded.
• The lifting platform must be swept clean of gravel, fallen leaves, snow, etc.
before use.
• The lifting platform is to be used to transport people only, and must be used
in accordance with the descriptions in this manual.
• The brakes of the user’s wheelchair or similar must be applied.
• All playing by and with the lifting platform is forbidden.
• A simple and usable “Emergency procedure” must be described and agreed
between the user and the helper. This must ensure that the user does not
become trapped on the platform in the event of an electrical or a mechanical
failure.
• The lifting platform must not be used during re.
• Safety equipment must only be reset by qualied assistance.
• Make sure that the area in front of the lifting platform is free.
• After use ensure that the lifting platform is in its lowest position and check
that the safety edges are completely down before leaving the lifting platform.
1.04 Safety rules
When working beneath the platform, there is a risk of becoming trapped
between the moving parts of the platform. The following safety rules must
therefore be observed:
1. The safety chain/strap must always be used while working beneath the platform.
2 The lifting platform must NOT be raised/lowered while work is going on beneath
the lifting platform. This applies even if the safety equipment is installed.
3 When the lifting platform is assembled and connected so that it can be raised/
lowered, only one person may work on it.
Safety equipment
When working beneath the platform, the
safety chain/-strap MUST be used.
The safety chain/strap is tted between
the safety eyelets on the scissors or the
two central tubes of the scissors as illus-
trated on the picture.
When the chain/strap has been tted,
lower the platform until the chain is taut,
i.e. until the traction wheel ”releases”
the curve.

5
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
1.05 Assembly
The lifting platform must be assembled by the Guldmann Service Team or an
engineer approved by Guldmann according to Guldmann’s
instructions.
As the noise level of the lifting platform is minimal, no steps should be taken
to reduce the noise level further during the installation.
1.06 Recessing the platform
The platform is designed to be recessed in front of the stairs/landing so
access without changing levels is provided.
Guldmann has documentation with measurements and exact data about the
recessing of the individual platform.
A: According to the dimension sketch from
Guldmann
B: According to the dimension sketch from
Guldmann
C: 155 mm (+20, −0)
D: The distance between the pit and the
stairs / landing must be as short as
possible (according to the dimension
sketch from Guldmann).
1.07 Electrical connection
• Input: 100- 240V AC, 50-60Hz
• Maximum consumption: 0,35A
Connect the platform to the mains network via the tted rubber cable.
• Brown lead: Phase lead
• Blue lead: 0 lead
• Green/yellow lead: Earth clamp
Important!
For safety reasons, the lifting platform must always be earthed.
Remote control (accessory) uses 9 V.
2
A
B
C

6
1
4
3
21
3
4
2
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
2.00 Description of functions
2.01 Labels
A label with the max. load and serial number is placed on the safety edge of
the platform. Two extra labels are included which can be placed in an appro-
priate place on the upper/lower level.
LP50 / LP50H
max 375 kg/825 lbs
LP50 LP50H
Part no. 13013-xxx
Serial no. xxxxxxxxxx
230V, 0.5A
Internally powered
equipment 24V DC
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
Made in Denmark
yyyy-mm-dd
Lifting Platform LP50
Part no. 13012-xxx
Serial no. xxxxxxxxxx
230V, 0.5A
Internally powered
equipment 24V DC
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
Made in Denmark
yyyy-mm-dd
Lifting Platform LP50H
A Stepless label and an overload label are placed on the operating panel on
the platform (if an operating panel is ordered).
On the LP50H there are 2 ”do not step on” labels with a
footprint, which indicate that it is NOT allowed to step on the
under plate during horizontal movement.
2.02 Operation
The lifting platform is activated by means of the
operating panel on the platform or on the possible
external operating panels on the upper and lower
landing or by wireless operation (option).
The lifting platform is logical and unproblematic to
operate and use, even with no prior knowledge.
1. Up
2. Overload signal
3. Emergency stop
4. Down

7
1
4
3
21
3
4
2
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
Operation of the lifting platform
1. When the lifting platform is at the lowest level, the
user can freely drive up on to the lifting platform.
2. The platform is activated by pressing the up button on the operating panel (1)
or on the up button on the wireless hand sender. Hereby the 4 safety edges
automatically go up. The button is active as for as long as it is held down.
3. When all 4 safety edges are up, the platform will start to rise.
4. When the platform is level with the landing, the platform stops and the safety
edge in the front goes down automatically so the user can freely drive onto
the landing.
5. After use the lifting platform must always be lowered to its lowest level.
Activate the down button and keep it active until the platform has reached its
lowest level. Make sure that the safety edges are completely down before
leaving the lifting platform.
The lifting platform can be equipped with an overload indicator. If the lifting
platform is overloaded, the lifting platform will not lift or lower. After the over-
load has been removed, the platform can operate again.
2.03 Safety functions
Important!
Individual and specic consideration must be given to how an emergency
summoning system must work. One or more responsible people should be
appointed to help with the correct use of the lifting platform. It should always be
possible to call those responsible in any emergency situation. The users must
be informed of who holds this responsibility.
Description of the emergency stop
The emergency stop must be used
in emergencies only. If the emer-
gency stop is activated owing
to a malfunction, the dealer
must be contacted before the
lifting platform is used again.
The emergency stop (3) is
positioned in the centre of the
control panel. It stops all
movement when activated.
Important!
Pull out the emergency stop and briey press the control button twice to
restart the lifting platform.
Safety curtain
The safety curtain ensures that nobody can move in beneath the platform
when it is at its highest level and thereby risk getting caught when the lifting
platform is lowered. The safety curtain is tted upon delivery.

8
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
Safety list
If anyone or anything gets caught beneath the platforms edge, the oor or the
steps, when it is lowered, the descent will stop as soon as the safety list is
activated.
Reset the safety function by pressing the »« button and removing the
object that activated the safety list.
2.04 Accessories
Extra control panel
Extra control panels with function buttons »« »« for
mounting on walls and similar. The control panel is available
with a lock.
Wireless operation
Use this when there are one or more independent users.
This allows users to control the lifting platform without being
dependent on a helper.
Important!
If the user is independent, the remote control must be
fastened to him/her in such a way that it is always within
the user’s reach.
3.00 Maintenance
3.01 Cleaning
The lifting platform is cleaned with a sponge or brush and soapy water. The
lifting platform can be sprayed or rinsed at ordinary water pressure; it must
not be rinsed under high pressure.
Never use acids, bases or solvents for cleaning.
3.02 Storage and keeping
No special requirements.
The lifting platform contains electronics that must be disposed of according to
current rules.
3.03 How is corrosion avoided?
The lifting platform is made of corrosion-resistant materials and requires no
further corrosion prevention.
3.04 What maintenance is required by the owner?
Cleaning as required.

9
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
4.00 Servicing and useful life
4.01 Useful life and servicing
The lifting platform must be inspected in accordance with the national law and
at least once a year.
The lifting platform has an expected life span of 15 years with regular daily use.
The lifting actuator must be replaced after 10 000 lifts.
The life span is based on correct usage, cleaning, and maintenance, as well
as annual inspection and maintenance by qualied personnel or the Guld-
mann Service Team. After this period, the lifting platform must be assessed
by qualied personnel before future use.
4.02 General inspection
Important!
The accompanying safety chain/
strap MUST be used when a service
engineer is working under the lifting
platform.
During the service inspection, a
report must be kept of what has been
inspected and replaced. Parts that
are worn out or defective must be
replaced with new spare parts from
Guldmann.
1. Visually checking the product
• Check the product for signs of wear and tear.
• Check the product for any faults.
• Check that there is no other form of damage to the product.
2. Testing of the product as for normal use
• Check all the product’s functions, loaded and unloaded.
3. Checking the electrical state of the product
• Check electrical functions and signals.
• Check the wiring for faults and defects.
• Check the cable bushings.
• Check connection options, connectors, etc.
• Check the seal on the control box.
4. Checking the mechanical state of the product
• Clean dirt and other impurities from the product.
• Inspect and assess vital parts of the product.
• Replace any parts of the product that are defective or worn out.
• Check and tighten vital parts.
• Lubricate the product.

10
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
5. Go through point 2 again, to check that everything works.
6. Did any new problems arise/were new problems noted in point 5?
• If new problems arose, go back to point 2.
• If no new problems were noted, nish the inspection.
4.03 Troubleshooting
1. Is the emergency stop activated?
• The emergency stop is released by turning the button until it pops out.
2. Is the platform turned on?
• Turn on the socket.
• If the platform has been disabled, wait for around 3 hours until the batteries
are charged.
3. Is there power in the socket; could the fuse have blown?
• Check the fuses and change the fuse if necessary.
4. Can the lifting platform go up but not down?
• Clean any impurities from the safety list underneath the platform.
• Check the safety list underneath the platform for other blockages.
5. Is the platform overloaded?
• Remove some of the load from the lifting platform.
• Observe the maximum load indication of the platform.
If the points above do not solve the problem, please contact the Guldmann
Service Team or your distributor.

11
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
5.00 Technical specications
Functions
Lifting height. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0-830 mm
Lifting capacity ............................................375 kg
Cantilever LP50H.........................................900 mm
Dimensions
Exterior dimensions LxW ............................ 1550 x 1150 mm
Interior dimensions LxW ............................ 1500 x 1100 mm
Pit depth................................................155 mm
Covering depth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 mm
Lifting speed .........................................13 mm/sec
Electrical connection ....................................230V/115V
Power consumption on stand-by ................................ 3 W
Power consumption ........................................14,7 W
Batteries ......................................... 2 x 12 V/7.0 Ah
Gastight and maintenance-free
Noise level ..............................................64 dB(A)
Permissible connection time/intermittence factor
(Work/Break ratio in per cent) ................................10/90
6.00 EC-declaration of conformity
The product is manufactured in compliance with the Council Directive
2006/42/EC of May 17th 2006, including amendments.

12
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
USA and countries outside the EU
A. Users guide
Before using the product, read the entire operation manual
including warranty.
B. WARRANTY
Guldmann warrants its equipment is free from material defects under normal
use, and will perform substantially in accordance with the specications set
forth in documentation provided with the equipment.
This express warranty shall be in effect for one year from the date of original
purchase and installation (the “Warranty Period”). If a valid claim is made
during the Warranty Period for malfunction or equipment defect, Guldmann will
repair or replace the equipment at no additional cost to you. Guldmann retains
sole discretion as to whether the equipment will be repaired or replaced.
This warranty shall be null and void if the equipment is operated and main-
tained in any manner inconsistent with its intended use or the instructions
provided with the product. Further, in order for the warranty to remain in effect
for the full Warranty Period, all service to the equipment must be provided
by a Guldmann designated technician. Any parts or components repaired or
replaced by a Guldmann designated technician will be guaranteed for the
remainder of the Warranty Period.
The warranty does not cover any part of the equipment which has been sub-
ject to damage or abuse by the user or others. The warranty does not cover
any part of the equipment which has been altered or changed in any way by
the user or others. Guldmann does not warrant that the lifting device functions
will meet your requirements, be uninterrupted or error free.
The warranty set forth is in lieu of all other express and implied warranties,
whether oral, written or implied, and the remedies set forth above are your
sole and exclusive remedies. Only an authorized ofcer of Guldmann may
make modications to this warranty, or additional warranties binding on Guld-
mann. Accordingly, additional statements such as advertising or presentati-
ons, whether oral or written, do not constitute warranties by Guldmann.
Service or Repair
Contact Guldmann Repair for an authorization to return any defective item
during the Warranty Period. You will be provided with a return authorization
number and address for returning the item for warranty service or replace-
ment. Do not return items to Guldmann under warranty without receiving a
Return Authorization Number.
If mailing the item, pack it carefully in a sturdy carton to prevent damage. Include
your Return Authorization Number, a brief description of the problem and your
return address and phone number. Guldmann does not assume the risk of loss
or damage while in transit, so it is recommended you insure the package.

13
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752

14
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752

15
© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752

© Guldmann GB-1559/01/2018 • # 551752 © Guldmann GB-1559/01/2018 • # 551752
V. Guldmann A/S
Tlf. [phone]
Fax [phone]
E-mail [email protected]
www.stepless.com
