H-KING GLUE-N-GO F-4 PP KIT User manual

1
PACKING LISTPACKING LIST
TOOLS & ELECTRONIC EQUIPMENTTOOLS & ELECTRONIC EQUIPMENT
1: PP F-4 fuselage x 1 pc
2: Carbon tube x 1 pc
3: Carbon strip x 2 pcs
4: Pull rod 1.2mm x 3 pcs
5: Motor mount x 1 pc
6: 2mm Quick rod adjuster x 3 pcs
7: Hinge x 3 pcs
8: Hook and loop tape x 1 pc
9: M3 screws x 4 pcs
1: 1.5mm allen wrench
2: Phillips screwdriver
3: Modelling knife
4: Wire cutters
5: Hot melt glue gun and glue sticks
6: Foam safe glue
7: Foam safe instant glue
(Recommended)
Motor：2208 or 2200 kv x 1 pc
Prop：6 × 4 x 1 pc
ESC：30A BEC x 1 pc
Servo：9g x 3 pcs
Battery：1500 mah 3S x 1 pc
20cm Y cord x 1 pc
30cm extension x 1 pc
50cm Motor extension x 3 pcs

2
Insert a supplied carbon strip into the wing’s groove near the wing’s leading edge and insert the other carbon strip
near the trailing edge of the wing. Use foam safe CA glue to secure the strips on the wing.
Apply foam safe glue on the vertical tail area.
Note: Just to apply enough glue to the area as shown.
Glue the aileron and elevator to the wing and horizontal tail respectively by using some foam safe
glue. Notice: Do not use fiber tape or other kinds of tape for this purpose. In fact, the foam safe
glue will make a good hinge material for the purpose.

3
Apply some foam safe glue on the wing as shown in the
picture below.
Apply foam glue to the rear top part of the fuselage as
shown.
Then install the wing onto the fuselage.
Then assemble the rear part of the top fuselage and
bottom fuselage on vertical fuselage.
Put the fuselage together and hold it by using some
clamps.
Apply foam glue on the nose of the fuselage as shown.
Then assemble the top nose fuselage on the side of the
fuselage.

4
Then hold the nose shape by using a clamp.
Apply foam glue on Y board using foam glue as shown.
Assemble the fuselage by using some clamps.
Apply foam glue to the middle part of the horizontal tail
and do it on both sides
Assemble the Y board into fuselage. Trail-fit the plastic motor mount on the tail (Don’t glue the
motor mount at this moment.

5
Apply foam glue on the slot of the vertical tail and the centre part of the horizontal tail (both sides).
Then insert the horizontal tail into the slot of the vertical tail.
Ensure the fin and the stabiliser are perpendicular to
each other and true to the wing, then wait for the glue to
dry.
After the glue thoroughly dried, you may remove all the
clamps at this moment. Cut the canopy by using a model-
ling knife. Don’t cut the front! The front part will act like a
hinge.
Remove the motor mount and install motor and prop. Assemble the quick rod adjusters and install it on the
control surfaces, apply loctite glue on all the bolts.

6
When installing the servos, just to make sure that all the servo arms are perpendicular to the
servo case.
Install all the push rods on quick rod adjuster and servo
arms as shown.
Then trim the excessive push rod as shown. Anchor the servo lead on the wing by using some hot
glue.

7
Total flying weight of the F-4 is about 415 grams.
Insert the carbon rod through the hole under the canopy
by using some hot glue stick.
Stick the hook and loop tape into the cockpit by using
some foam glue. Then install battery, ESC and receiver
into the compartment.

C of G is behind 1cm of carbon strip’s peak as shown picture below.
