Hachette PACK 3 Manual

ALIEN
BUILD THE
TERRIFYING
XENOMORPH
FROM
ALIEN
EASY
ASSEMBLY
PACK 3
KITS 13 - 20
Non contractual visual
spectacular
1:2
scale

Hachette Partworks Ltd, 4 t h F l o o r , J o r d a n H o u s e ,
47 Brunswick Place, London N1 6EB
www.hachettepartworks.com
© 2023/2024 Hachette Partworks Ltd.
© 2023 20th Century Studios.
ALL RIGHTS RESERVED
All parts belong to a kit. Collectors item for adults.
Not suitable for children under 14.
PACK 3 | BUILD INSTRUCTIONS
ALIEN
WARNING: Some parts are assembled using magnets. These magnets can cause serious
injury if they are swallowed. Keep away from children. If you suspect a magnet has been
swallowed, seek medical help straight away.
Some parts may have sharp edges, please handle them with care.
The installation of electronic parts must always be carried out by an adult. When replacing batteries,
use the same type of batteries.
Please ensure that the battery compartment is securely fastened before you use the model.
Used batteries should be recycled.
Please make sure to check with your local council how batteries should be disposed of in your area.
Batteries can present a choking danger to small children and may cause serious harm if ingested. Do
not leave them lying around and keep any spare batteries locked away at all times.
KIT 13
THE HEAD & THE SKULL (II)
KIT 14
THE SKULL & THE
RIGHT LEG (I)
KIT 15
THE SKULL & THE
RIGHT LEG (II)
KIT 16
THE SKULL & THE
RIGHT LEG (III)
KIT 17
THE RIGHT LEG (I)
STEPS & TIPS ONLINE
KIT 18
THE RIGHT LEG (II)
KIT 19
THE RIGHT RIBS
KIT 20
THE RIGHT RIBS &
THE LEG (I)

PB 1
ASSEMBLY GUIDE
In this kit you will continue to assemble different parts of the
Xenomorph’s head and skull.
KIT 13: THE HEAD AND
THE SKULL (II)
13-1 13-2
13-4
13-3
13-5
PARTS SUPPLIED
Ref. Name Qty.
13-1 L ower B ack P art of the H ead 1
13-2 P ip e R1 1
13-3 P ip e R2 1
Ref. Name Qty.
13-4 P ip e R3 1
13-5 2.3x6mm screws 3*
*A spare screw is supplied in case of loss or damage.

23
KIT 13: THE HEAD AND THE SKULL (II)
1
Take the Lower Back Part
of the Head 13-1 and
Pipe R1 13-2. Test-fit
the pipe before glueing in
place, as shown.
13-2 (R1)
13-1
EXPERT ADVICE
From this kit onwards, the Pipes provided will be attached to small numbered tabs which will allow for quick identication.
Before adding them to the assembly, gently twist the tab to remove it from the piece.

23
KIT 13: THE HEAD AND THE SKULL (II)
2
3
13-5
13-1
13-3
(R2)
1-1
7-1
9-1
Take the head assembly you
worked on in pack 2 - kit 12 and
orientate Head part 13-1, as
shown. The tabs on Head part
13-1 (circled) fit over raised
screw sockets on parts 7-1
and 9-1. Fix in place with two
2.3x6mm screws 13-5.
Next, take the skull
assembly which was also
worked on in the last kit.
After test-fitting the tabs
of Pipe R2 13-3 into the
slots on the right-hand
side of the skull 1-1,
glue in place.

KIT 13 IS COMPLETE
4
1-1
13-3
(R2)
3-1
13-4 (R3)
Further parts have been
fitted to the head and
skull.
To finish, test-fit the tabs
on Pipe R3 13-4 into the
next three slots and glue
in place.
KIT 13: THE HEAD AND THE SKULL (II)
4

PB 1
ASSEMBLY GUIDE
In this kit you will continue to add appendages to the skull as well as
working on parts of the right calf.
KIT 14: THE SKULL &
THE RIGHT LEG (I)
14-1
14-2 14-3
14-4 14-5
PARTS SUPPLIED
Ref. Name Qty.
14-1 S k in ( right cal f) 1 1
14-2 P ip e A 1 ( sk u l l ) 1
14-3 P ip e A 2 ( sk u l l ) 1
Ref. Name Qty.
14-4 P ip e A 3 ( sk u l l ) 1
14-5 M agnets 4

23
KIT 14: THE SKULL & THE RIGHT LEG (I)
1
2
3
14-2 (A1)
14-3 (A2)
14-4
(A3)
5-1
14-2 (A1)
5-1
3-1
Finish the line of pipes
along the right side of the
skull by fitting Pipe A3
14-4. Check the fit and
glue firmly in place.
Repeat the previous step
to secure Pipe A2 14-3
as a continuation of Pipe
A1 14-2.
Take the skull assembly which
was worked on in the last kit and
continue fitting the pipes on the
right-hand side. Check the fit of
Pipe A1 14-2 and glue firmly in
place on skull part 3-1.

23
KIT 14: THE SKULL & THE RIGHT LEG (I)
4
14-5
14-1
14-5
14-5
14-5
KIT 14 IS COMPLETE
MORE PIPES HAVE BEEN SECURED
TO THE SKULL AND MAGNETS
FITTED TO THE RIGHT CALF SKIN.
Finally, take the Calf Skin 14-1
and fit the four Magnets 14-5
into the circular recesses as
shown on the left. Secure them in
place with a little glue. This time,
it doesn’t matter which way round
the magnets are fitted.
EXPERT TIP: As some of
the skin parts look quite similar,
it may help to label the inside
of the part. This could be done
by writing the part number on a
small piece of masking tape.

PB 1
ASSEMBLY GUIDE
In this kit you will continue to add appendages to the skull as well as
working on parts of the right calf.
KIT 15: THE SKULL &
THE RIGHT LEG (II)
15-1
15-4
15-6 15-7
15-5
15-2 15-3
PARTS SUPPLIED
Ref. Name Qty.
15-1 Right Tibia 1 1
15-2 Connector 1
15-3 P ip e R4 1
15-4 P ip e R5 1
Ref. Name Qty.
15-5 P ip e R7 1
15-6 P ip e R6 1
15-7 2.3x6mm screws 2*
*A spare screw of each type is supplied in case of loss or damage.

23
KIT 15: THE SKULL & THE RIGHT LEG (II)
1
2
3
15-3 (R4)
15-4 (R5) 15-3 (R4)
1-1
5-1 3-1
15-7
15-2
15-1
3-1 Take the skull assembly you worked
on in the previous kit. Check that the
tabs on Pipe R4 15-3 fit correctly
into the notches underneath the
Skull 1-1 and 3-1, then fix in place
with a little glue. The pipe may need
to be stretched slightly to fit.
Repeat the previous step to fit
Pipe R5 15-4 into the notches
underneath parts 3-1 and 5-1 so
that it continues Pipe R4 15-3. A
peg at the end of Pipe 15-4 fits
into a hole in part 5-1. Again, the
pipe may need to be stretched
slightly to fit.
Take the Right Tibia 15-1 and the
Connector 15-2. The Connector
is fitted, as shown on the left and
secured in place with a 2.3x6mm
screw 15-7. Put the part aside until
it is needed in the next kit.

23
KIT 15: THE SKULL & THE RIGHT LEG (II)
45
14-1
15-5 (R7) 15-6 (R6)
14-1
15-5 (R7)
KIT 15 IS COMPLETE
MORE PIPES HAVE BEEN FITTED TO
THE SKULL AND CALF SKIN ALONG
WITH A CONNECTOR ON THE TIBIA.
Take the right Calf Skin 14-1,
supplied with the previous kit, along
with the pipe R7 15-5. Before fixing
in place with a little glue, check
that the tabs on Pipe R7 15-5 fit
properly into the slots on the Calf
Skin 14-1. Hold in place until the
glue has set.
Repeat the previous step to attach
Pipe R6 15-6 to the Calf Skin 14-
1. Pipe R6 15-6 is a continuation
of Pipe R7 15-5. Again, hold the
pipe in place until the glue has set.

PB 1
ASSEMBLY GUIDE
In this kit you will continue to add appendages to the skull as
well as starting work on building the right tibia.
KIT 16: THE SKULL AND
THE RIGHT LEG (III)
16-1 16-2
16-616-516-416-3
PARTS SUPPLIED
Ref. Name Qty.
16-1 Right Tibia 1
16-2 P ip e R8 ( sk u l l ) 1
16-3 P ip e R9 ( sk u l l ) 1
Ref. Name Qty.
16-4 P ip e R10 ( sk u l l ) 1
16-5 M agnets 4
16-6 2.3x6 mm screws 2*
*A spare screw is supplied in case of loss or damage.

23
KIT 16: THE SKULL & THE RIGHT LEG (III)
1
2
1-1
1-2
16-2 (R8)
16-3 (R9)
Check that the tabs on
Pipe R9 16-3 fit correctly
into the slots in the
underside of the left part
of the Jaw 1-2. Once
happy with the fit, glue the
pipe in place.
Take the skull assembly that you
worked on in the previous kit.
Check that the Pipe R8 16-2 fits
correctly in place at the front of the
Skull 1-1. Study the ends of the
pipe closely and note that there is
a hole at each end that fits over a
peg each side of the skull part 1-1.
When sure of a good fit, apply a
little glue to the tabs on Pipe R8
16-2 and the pegs on skull part
1-1 and secure the pipe in place.

23
KIT 16: THE SKULL & THE RIGHT LEG (III)
3
4
1-2
16-4 (R10)
16-6
15-1
16-1
15-2
Repeat the previous step
to fit the Pipe R10 16-4
underneath the other side
of the Jaw 1-2.
Taking the Tibia 15-1 from the last kit
along with Tibia 16-1, join the parts
together using the connector which has
previously been fitted to Tibia 15-1.
Secure the connector to part 16-1 with a
2.3x6mm screw 16-6.

KIT 16 IS COMPLETE
5
6
15-1
16-1
14-1
16-5
15-1
16-1
More pipes have been fitted to the skull and
work has continued on the right leg.
Put the head safely aside until it is needed
in a later kit.
Take the Right Calf Skin 14-1
which was worked on in kit 14 and
the Tibia parts 15-1/16-1. Place
the Tibia 15-1/16-1 on top of the
Right Calf Skin 14-1, as shown.
To hold the skin to the tibia, Magnets
16-5 will now be tted to the assembly
15-1/16-1. To do this, slot a Magnet
16-5 into the rst recess on the left. The
magnetic pole is automatically attracted
towards the magnet already tted below on
the Calf Skin 14-1. If tted incorrectly, the
poles will repel and the magnet may even
jump out of the recess.
In a similar manner, t the remaining
magnets. Again, the magnets already in
place below will attract the magnets to be
tted. When you are happy with the polarity
of the Magnets 16-5, glue in place.
KIT 16: THE SKULL & THE RIGHT LEG (III)
4

PB 1
ASSEMBLY GUIDE
In this kit you will continue to assemble parts of the right tibia and leg.
KIT 17: THE RIGHT
LEG(I)
17-1
17-2 17-3 17-4
PARTS SUPPLIED
Ref. Name Qty.
17 -1 Right Tibia 1 1
17 -2 Connector 1
Ref. Name Qty.
17 -3 M agnets 4
17 -4 2.3x6mm screws 2*
*A spare screw is supplied in case of loss or damage.

23
KIT 17: THE RIGHT LEG (I)
1
2
3
17-2
17-4
17-2
17-1
17-1
17-3
4-4
17-3
Place the Right Tibia 17-1
on the work surface and
note from the diagram how
Connector 17-2 fits into the
oval recess on part 17-1.
Take the right calf assembly
4-4 which was last worked
on in kit 4. Fit two Magnets
17-3 into the circular
recesses, as shown, and
secure in place with a little
glue. It doesn’t matter which
way up the magnets are
fitted.
Use a 2.3x6mm
screw 17-4 to fix the
Connector 17-2 in place.

23
KIT 17: THE RIGHT LEG (I)
4
17-3
4-4
17-3
KIT 17 IS COMPLETE
WORK HAS CONTINUED ON THE
RIGHT LEG WITH A CONNECTOR AND
MAGNETS BEING ADDED.
Repeat the previous step
to add the remaining two
Magnets 17-3 to part 4-4,
as shown. Again, it doesn’t
matter which way up the
magnets are tted.

PB 1
ASSEMBLY GUIDE
In this kit you will continue to assemble parts of the right leg.
KIT 18: THE RIGHT
LEG (II)
18-1
18-4
18-2
18-3
PARTS SUPPLIED
Ref. Name Qty.
18 -1 Right Tibia 1
18 -2 Connectors 4
Ref. Name Qty.
18 -3 M agnets 4
18 -4 2.3x6 mm screws 10*
*A spare screw is supplied in case of loss or damage.
