Hans Grohe PHARO DP Prestige M20 26 10 1 Series User manual

Shower Panel Prestige
Installation Instructions
DP Prestige M20 26 10x xx1
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

2
Contents
Packing List 3
Dimensions / Wall Installation Dimensions Diagram 4
Corner Installation Dimensions Diagram 5
Panel Dimensions 6
Fittings / Technical Data / Safety Instructions 7
Fitting Items / Water Connections Overview 8
Fitting the Canopy / Hand Shower Hose 9
Fitting the Protective Profile, Connecting the Water 10
Fastening the Panel 11
Fitting the Tray / Hand Shower 12
Thermostat Setting 13
Service Information 14
Spare Parts 15
Addresses 16
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

3
Packing List
g
f
e
d
c
b
a
Fitting items
a Fastening piece (corner installation)
b Fastening bracket (wall installation + corner installation)
c Screws with nuts and washers (fastening piece/
fastening bracket)
d Screws (wall installation + corner installation)
e Clamping bracket (wall installation)
f Bottom fitting set with bottom clamping brackets
(corner installation)
g Water connection elbow (wall installation + corner
installation)
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

4
Dimensions / Wall Installation Dimensions Diagram
Check for required minimum height
of 85½" from shower tray floor
before starting installation
Wall installation dimensions diagram
Dimensions
The installation dimensions stated in this
installation instructions are ideal for people of
approximately 70“ in body height.
The dimensions can be altered if required. In this
case you will have to attend to the minimum height
of 85½" from shower tray floor, and alter all the
required measurements as necessary.
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

5
Corner Installation Dimensions Diagram
Check for required minimum height of 85½" from shower tray floor
before starting installation
Corner installation dimensions diagram
Connections on the left side
Corner installation dimensions diagram
Connections on the right side
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

6
Panel Dimensions
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

7
Fittings / Technical Data / Safety Instructions
Technical Data
Minimum flow pressure 22 psi
Operating pressure max. 147 psi *
Recommended operating pressure 29,4 - 73,5 psi
Test pressure 235,2 psi
Hot water temperature max. 158 °F *
Temperature scale 68 – 140°F
Safety stop 100°F
Flow capacity at 3 bar
Hand shower 4 gpm
Body showers, 6 jets 4,8 gpm
Overhead shower 3,7 gpm
Overhead shower + Body showers 4,8 gpm
Hand shower + Overhead shower 4,5 gpm
* Check applicable codes
The flow rates are limited to 2.5 gpm.
These are the maximum flow rates
permitted by the Energy Policy Act of
1992.
Flow heater:
Applicable for flow heaters at min. 24 kW and 22 psi
flow pressure before the Shower panel. Only one
consumer possible, not two simul-taneously.
Pressure differences:
The pressures of the cold and hot water connections must
be balanced.
Maintenance
The non return valves must be checked regularly
according with national or regional regulations (at
least once a year)!.
non return valves
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

8
Fitting Items/Water Connections Overview
Fitting items/water connections
Wall installation
Fitting items/water connections
Corner installation
Seal all drill holes with silicone free from acetic acid (not in scope of delivery)
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

9
Fitting the Canopy/Hand Shower Hose
1Fasten canopy with 4 fastening screws.
2Join overhead shower hoses.
1Join hand shower hose to panel.
2Push hose end through, screw tight.
Fit canopy Fit hand shower hose
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

10
Fitting the Protective Profile, Connecting the Water
2Hang panel on, connect water, open wall connection
angle and test for soundness (The fitting must installed,
flushed and tested after the valid norms!).
Corner installation: Press seal in.
Wall installation: Press protective profile in.
Wall installation
Corner installation
Wall installation
Corner installation
