Hanskamp MultiFrame User manual

MultiFrame
EN
Installaon instrucon
Arkelnumber: 010-243-000
Date: March 2020
Version 1.6 - Translaon of original instrucons
In parlour feeding
075-000-000
Doenchem,
The Netherlands
www.hanskamp.nl/en

2 - 8
Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en
MulFrame
EN 075-000-000
Montage MulFrame
1. Decide for mounng the MulFrame, where the MulFrame should
hang. The distance between the MulFrames is dependent on the
type of milking parlour. The posion measurements are, therefor, to
nd in the drawing of the milking parlour.
2. When the distance is determined, the holes can be drilled according
to the dimensions as shown in the drawing.
3. Now install the MulFrame on the wall. (Mounng material not in-
cluded).
X ≈ 2000mm - 2300mm
X1 = depending on the size of the animal, measure this.
Mounng Feedtrough
1. Install the feedtrough in the MulFrame. The feedtrough is easy to place in the
frame by sliding it obliquely below the 2 vercal tubes which are welded to the
ring. When the edge of the feedtrough is placed under the vercal tubes, the
feedtrough can be placed on the ring. The feedtrough
is now secured on one side.
2. Secure now the other side of the feedtrough with sup-
plied mounng material as shown in Figure 3.
1
2
34
007-522-000 007-522-001
There are two types of feedthroughs available. The perfora-
ted feedtrough (art.nr.: 007-522-000) and the tradional
feedtrough with one hole. (art.nr.: 007-522-001).
XX1

3 - 8
Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en
MulFrame
EN 075-000-000
Mounng PipeFeeder
1. Mount the PipeFeeder to the MulFrame with included mounng material
as shown in Figure 5.
2. Make sure the boom of the PipeFeeder is level with the top of the feed-
trough
3. In order to let the PipeFeeder dosing nicely into the feedtrough, it is desira-
ble to rotate the tube of the PipeFeeder 45° so that the discharging secon
is hung above the feedtrough.
Please note! If the stainless steel tube of the PipeFeeder is rotated with pertaining
to the plasc part make sure that de PipeFeeder is re-adjusted in order to maintain
the an-spill funcon. For adjusng the PipeFeeder see manual 001-847-000
Adjust the PipeFeeder not to the MulFrame by a truss structure or similar. Then
the PipeFeeder can also be mounted on the wall. The distance between the wall
and the PipeFeeder remains unchanged from mounng on the MulFrame. For
example, all PipeFeeders remain perfectly straight line in order to keep the parlour
ght.
MulFrame degree posions
The MulFrame 30° is the complete MulFrame as described above. These will be
delivered without sidefence. 40°, 50° & 60° parlours can be made with a short side
fence (art.nr.: 007-504-000). 70° & 80° parlours can be made with a long side fence
(art.nr.: 007-505-000).
40° & 50° 60° 70° 80°
5
6
007-504-000 007-505-000

4 - 8
Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en
MulFrame
EN 075-000-000
Right Le
Aachment; Right / Le
Grounding MulFrame
It is recommended to ground all MulFrames.
To ground, there is a tube lug (art.no.: 001-302-000) provided it could be mount bet-
ween any bolt and nut of the MulFrame.
Maintenance MulFrame
Clean the feedtrough regurlarly and make sure the feedtrough stays
clean. Let the water out of the feedtrough aer cleaning it.

5 - 8
Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en
MulFrame
EN 075-000-000
Mounng Reader/Antenna mount (individual stall recognion)
It is possible to mount various types of antennas on the MulFrame.
One suited for DeLaval (art. no. 007-524-000) and one suited for Hanskamp,
Nedap & Fullwood antennas (Art.nr.: 007-525-000) (g. 7).
In gures 8-11 is displayed how to reader mount 007-525-000. mount 007-
524-000 is mounted in the same way.
To shield the antenna cable, a guide tube can be placed (g. 12-14). This is
available at Hanskamp as a set : Art.nr.: 007-530-000 for neck collar tag read-
ers, art.nr.: 007-531-000 for leg tag readers.
7
8910
11
12 13 14

6 - 8
Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en
MulFrame
EN 075-000-000
FAQ
Occurring problem Possible cause Soluon
Side fence does not t,
mounng holes do not match
Fence is posioned the wrong way. Turn fence 180° and try again.
No mounng for stand-place
recognion
No antenna mounng plate ordered or
delivered.
Order for Delaval antenne 007-524-
000
Order for Nedap antenna 007-525-
000
List of included amendments in this installaon- and operang instrucon
No. Release date Chapter comments
1.0 01/2016 First edion
1.1 02/2016 Aachment & Arcle structure Arcle names are changed & grounding added
1.2 01/2017 Aachment FAQ added
1.3 01/2018 Mounng Picture PF to low added
1.4 01/2018 Antenna mounng Added antenna mounng instrucons.
1.5 06/2019 Front page, images 1 & 2 Changed to most recent version MulFrame
1.6 03/2020 Pag. 2 and 4 Image added pag. 2, comment added pag. 4

7 - 8
Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en
MulFrame
EN 075-000-000
Art.no.: Descripon QTY.
007-501-000 MulFrame right 1
007-502-000 MulFrame le 1
007-504-000 Side fence short 1
007-505-000 Side fence long 1
Art.no.: Descripon QTY
007-522-000 Perforated feedtrough 1
007-522-001 Feedtrough with hole Ø20 1
Art.no.: Descripon QTY
001-037-000 Washer M8 r9.0 a2 DIN440R 2
001-302-000 Tube cable lug M10 4,5mm² 1
001-382-000 Minigrip packaging sachets 100x150mm 1
001-531-000 Bolt M10x60 DIN931 a2 4
001-532-000 Washer M10 a2 DIN125/ A1 8
001-707-001 Washer M10x34x3 DIN440 8.8ev 2
001-707-002 Curved washer M10x34x3 DIN440 8.8ev 6
001-741-000 Bolt M8x55 a2 DIN933 2
001-769-000 Sloed retaining nut M8 a2 DIN985 coat 2
001-774-000 Washer M8 DIN 9021 a2 2
001-805-000 Bolt M10x70 DIN 931 8.8ev 2
001-857-000 Sloed retaining M10 a2 DIN 985 coat GL 4
001-866-000 Sloed retaining moer M10 DIN 985 8.8ev 4
011-124-000 Bolt M10x105 DIN931 8.8ev 2
MulFrame parts
Type feedtrough
007-506-000 Mounng material
Art.no.: Descripon QTY
007-524-000 Mount for Reader 3mm incl. (DeLaval) 1
007-525-000 Mount for Antenne 3mm AISI304 (Hanskamp, Nedap, Fullwood) 1
007-530-000 Cable guide tube set (Neck collar antenna) 1
007-531-000 Cable guide tube set (Leg tag antenna) 1
Antenna mount incl. mounng material

8 - 8
Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en
MulFrame
EN 075-000-000
