Harmar Mobility AL030 Operating instructions

Read and understand this manual thoroughly before
attempting to install or operate the lift. If you have any
questions, please contact your Authorized Harmar Dealer or
Harmar’s Technical Service Department.
Dealer Name & Contact Information:
Serial # of Your Lift:
Outside Lifts
Installation & Owner’s Manual www.harmar.com | 800-833-0478
AL030 Power Tote Folding
Manual Wheelchair Lift
Capacity: 100 lbs
AL010/050 Micro
Power Chair / Scooter Lift
Capacity: 135 lbs
AL015 Micro Scooter Lift
Capacity: 100 lbs
AL100 Universal Lift
Capacity: 350 lbs
AL160 Low Prole
Universal Scooter Lift
Capacity: 350 lbs
AL300 Universal
Scooter/Power Chair Lift
Capacity: 350 lbs
AL300RV RV Lift
Scooter/Power Chair Lift
Capacity: 350 lbs
AL500
Universal Power Chair Lift
Capacity: 350 lbs
AL301XL Extra Wide
Universal Power Chair Lift
Capacity: 350 lbs
AL560 Auto Hold Down
Power Chair Lift
Capacity: 350 lbs
AL560XL Automatic
Extra Large Power
Chair Lift
Capacity: 350 lbs
AL570 Auto
Power Chair Lift
Capacity: 350 lbs
AL570 Extra Large
Power Chair Lift
Capacity: 350 lbs
AL580 Power Chair Lift
Capacity: 350 lbs
AL580XL Extra Large
Power Chair Lift
Capacity: 350 lbs
AL585-SEL
Power Chair Lift
Capacity: 250 lbs
AL585-SS
Power Chair Lift
Capacity: 250 lbs
AL100HD Heavy Duty
Scooter Lift
Capacity: 400lbs
AL300HD Heavy Duty Scooter/
Power Chair Lift
Capacity: 400 lbs
AL500HD Heavy Duty
Power Chair Lift
Capacity: 400 lbs
AL301XLHD Extra Wide
Heavy Duty Power Chair Lift
Capacity: 400 lbs

2
Contents
NOTE: The following symbols indicate areas where you should take
special care to avoid danger to individuals or property.
Section 1: Owner
OPERATING YOUR LIFT
General Operation.................................3
AL010/050 and AL030 Micro Lifts .....6
AL570 & AL570XL Lifts..........................7
Using a Swing-Away..............................8
Manual Override.................................. 10
SAFETY & MAINTENANCE 11
Section 2: Installer
PREPARATION
Tools Required............................................13
Unpacking the Lift.....................................14
Installation Overview ...............................15
INSTALLATION
Wiring the Vehicle .....................................17
Vehicle Hitch................................................19
Hitch Adapters........................................... 20
Lift Installation
Hitch Post Mount ................................ 22
AL030 Bumper Mount...................... 23
Swing-Away .......................................... 24
AL030 Power Tote Ball Mount......... 26
CHAIR PREPARATION 27
Anchor Plate ......................................... 27
U-Bolt Kit................................................ 28
LIFT ADJUSTMENTS
AL015 / AL100 / AL100HD / AL160.. 29
AL010/050 and AL030 .........................31
AL560 & AL560XL................................ 32
AL560 & AL580 Hold-Down Arm... 33
AL570 & AL570XL Chair Plow .......... 34
Dock ‘N’ Lock: AL570 & AL570 XL...35
TROUBLESHOOTING 37
EXPLODED VIEWS
AL030 ...................................................... 39
AL010/050 .............................................. 40
AL015 ........................................................41
AL100 ....................................................... 42
AL160 ....................................................... 43
AL300 ......................................................44
AL300RV................................................. 45
AL301XL .................................................. 46
AL500 ...................................................... 47
AL560 ...................................................... 48
AL560XL ................................................. 49
AL570 ...................................................... 50
AL570XL.................................................. 51
AL580 ...................................................... 52
AL580XL ................................................. 53
AL585SEL................................................ 54
AL585SS.................................................. 55
AL100HD ................................................ 56
AL300HD................................................ 57
AL301XLHD............................................ 58
AL500HD................................................ 59
ELECTRICAL HARDWARE 60
WARRANTY 63
WARNING
Hazardous situation. If not avoided,
could result in serious injury to
installer or user.
CAUTION!
Hazardous situation. If not
avoided, could result in serious
damage to property.

Outside Lifts - Installation & Owner’s Manual 2013
3
Section 1 : owner Operating Your Lift
GENERAL OPERATION
1. LOWERING THE LIFT
Insert key and switch to ‘ON’ position.Press
‘DOWN’ on toggle switch. The platform will
unfold. Continue to lower until platform reaches
the ground and becomes level. [Figure 3-1]
DO NOT over-lower to the point where the
vehicle begins to rise. This will damage the lift.
IMPORTANT
Positioning the chair properly on the platform is
critical to ensure it is properly locked onto the lift.
Always verify wheels are captured by cradles
or bars. Please consult your dealer on the specics
of your application.
Figure 3-1
Figure 3-2
2. DRIVE CHAIR ONTO PLATFORM.
Drive slowly, stopping when the drive wheels fall
between the platform bars on the side or center
depending on the lift and chair model. [Figure 3-2]

4
Section 1 : owner
Operating Your Lift
3. SECURING THE CHAIR
Depending on your lift model and the type of securement device it uses, you may
wish to raise the platform halfway, using the ‘UP’ toggle switch, in order to avoid
having to bend over while you attach straps or ip the chair’s armrest out of the way
of the hold-down arm. [Figure 4-1]
x2x2
Figure 4-1
Figure 4-2
4. RAISING THE LIFT
When the chair is secure, use the ‘UP’ toggle
switch to continue raising the lift. Stop when
it reaches the top of travel when you hear the
clutch sound. Twist the key to remove.
[Figure 4-2]

Outside Lifts - Installation & Owner’s Manual 2013
5
Section 1 : owner Operating Your Lift
Figure 5-1
CAUTION
These are general
instructions. Specics may
vary based on your chair
model and lift combination.
Please follow the specic
instruction suggested by
your dealer.
CAUTION
Always verify the chair or
scooter is held rmly in place
prior to transport.
•Always run the lift fully to the top
for transport. The lift will make a
ratcheting sound which indicates
that all mechanisms are locked and
prepared for travel.
•Never attempt to move the vehicle
without the lift being in the full up or
stowed position. This may damage the lift.
•Drive slowly over rough terrain such as
pot holes, unpaved roads, railroad tracks.
Excessive loads from rough driving will
damage your lift and is not covered by
the warranty.
•If you notice any damage, stop using
the lift immediately. Do not attempt
to transport a chair or scooter with a
compromised lift. Damage to your chair,
lift, vehicle may occur. Take the lift to
your nearest dealer and have it evaluated
prior to further use.
5. UNLOADING THE CHAIR
Insert the key and switch to ‘ON’ position.
Press ‘DOWN’ to lower the lift. Do NOT
continue travel to the point where the
vehicle rises; that will damage the lift.
[Figure 5-1]
Drive the chair o the platform carefully.
When the chair is unloaded, press ‘UP’ and
the platform will automatically fold. (Except
AL010/050 and AL030).

KEEPER PLATE
PIN
KEEPER PLATE
PIN
KEEPER
PLATE
PIN
KEEPER
PLATE
PIN
6
Section 1 : owner
Operating Your Lift
AL010/050 AND AL030
MICRO LIFTS
Figure 6-2
Figure 6-1
MICRO LIFTS / FOLDING
AL010/050 and AL030 models require the
platform to be folded and unfolded manually.
The locking mechanism consists of a pin and
keeper plate, which must be disengaged before
unfolding. Simply hold the platform rmly and
lower it approximately 2” to allow the platform to
disengage and unfold. [Figure 6-1]
WARNING
Hold platform rmly
while lowering the lift
to its down position.
To lock in the upright position, lift platform
up before the pin engages the keeper plate.
[Figure 6-2]
WARNING
Hold platform rmly while
raising the lift until the pin has
engaged the keeper plate.

Raise lift 2-3”
to close
Dock ‘N’ Lock
Dock ‘N’ Lock
Plow
CLICK
Continueto drive chair
forward until...
Raise lift 2-3”
to close
Dock ‘N’ Lock
Dock ‘N’ Lock
Plow
CLICK
Continueto drive chair
forward until...
TESTTEST
SLOWSLOW
Outside Lifts - Installation & Owner’s Manual 2013
7
Section 1 : owner Operating Your Lift
Figure 7-2
Figure 7-3
Figure 7-1
AL570 & AL570XL
LOADING THE CHAIR
Set chair speed to SLOW. Drive chair forward
carefully until the chair plow engages with the
Dock 'N' Lock [Figure 7-1]
CAUTION
Set chair speed to SLOW and use
extra caution while driving on and
o the platform.
Raise lift 2”-3” to close the Dock
'N' Lock. [Figure 7-2]
TEST SECUREMENT
Raise the lift platform 3”-6” o the
ground. Set the chair speed controller
to slow and attempt to move the chair
in reverse. If successfully locked, the
chair will not move in reverse.
[Figure 7-3]
WARNING
The Dock 'N' Lock MUST be tested
EVERY time you load the chair for
transport. DO NOT attempt to travel
with the chair until you verify that the
chair is fully engaged on the platform.
Failure to do so could result in serious
injury or property damage.

Remove
Safety
Pin
Pull
T-Handle
AL105 AL105L
Remove
Safety
Pin
Pull
T-Handle
AL105 AL105L
8
Section 1 : owner
Operating Your Lift
SWINGAWAY
The Swing-Away allows you to easily swing the
installed auto lift away from the back of the
vehicle for convenient access to the trunk or lift
gate. The Swing-Away option can be purchased
from an authorized dealer and added at any time.
NOTE: Two Swing-Away models are available,
a standard AL105 and the lightweight
AL105L . They work basically the same way
but the parts dier slightly as noted in
[Figure 8-3].
Figure 8-2
Figure 8-1
WARNING
NEVER open the Swing-Away
with the chair on the lift.
You will damage the Swing-
Away and the lift. It will
potentially damage the vehicle
and the chair. Any of these
actions will VOID your warranty.
Figure 8-4
Remove
Safety
Pin
Pull
T-Handle
AL105 AL105L
Remove
Safety
Pin
Pull
T-Handle
AL105 AL105L
Figure 8-3
Figure 8-5
OPENING THE SWINGAWAY
1. Remove Safety Pin [Figure 8-3]
2. Pull T-Handle [Figure 8-4]
• Grasp the lift rmly and swing it out, away
from the vehicle. The Swing-Away can be
opened up to 180 degrees from the closed
position to allow full access to the vehicle’s
cargo area. [Figure 8-5]
WARNING
Open ONLY on Level Ground
Failure to open on level
ground may result in losing
control of the lift, resulting in
personal injury or damage to
property.

Outside Lifts - Installation & Owner’s Manual 2013
9
Section 1 : owner Operating Your Lift
CLOSING THE SWING AWAY
Close the Swing-Away unit as you would a
car door.
WARNING
Stay clear of the latching
mechanism
Figure 9-1
Figure 9-4
SAFELY CLOSED WRONG SAFELY CLOSED WRONG
Figure 9-2
Figure 9-3
WARNING
Always install the safety pin.
CAUTION
Verify that the T handle has
fully retracted.

VEHICLE HARNESS
LIFT HARNESS
VEHICLE HARNESS
LIFT HARNESS
REMOVEREMOVE
3/8”3/8”
Turn COUNTER -
CLOCKWISE
to LOWER platform.
Turn CLOCKWISE
to RAISE platform.
Turn COUNTER -
CLOCKWISE
to LOWER platform.
Turn CLOCKWISE
to RAISE platform.
10
Section 1 : owner
Operating Your Lift
Figure 10-1
Figure 10-2
Figure 10-3
MANUAL OVERRIDE
IMPORTANT!
You MUST unplug the two-connector plug BEFORE
any attempt to use the Manual Override. Failure to
do so result in serious injury.
WARNING
Disconnect power from lift
BEFORE attempting manual
override.
1. Unplug Power to the Lift. [Figure 10-1]
2. Remove the cap on top of the motor cover,
using a coin or key. [Figure 10-2]
3. Insert a 3/8” socket wrench into the
actuator and rotate the Hex Shaft. [Figure 10-3]
Figure 10-4
In the event of a power failure, for example
if your car battery dies, your lift can still
operate using the Manual Override system.
4. Turn COUNTER-CLOCKWISE to LOWER
the platform. [Figure 10-4]
5. Turn CLOCKWISE to RAISE the platform.
[Figure 10-4]

CAUTION
!
CAUTION
!
Outside Lifts - Installation & Owner’s Manual 2013
11
Section 1 : owner Safety & Maintenance
SPECIAL CAUTIONS
• Return hold-down arm to a side
position before folding platform.
Failure to do so will damage your lift.
• Beware of pinch points. These
are areas of mechanical objects
with moving parts than can catch
extremities or clothing. Do not place
ngers, extremities or allow clothing
near such points.
• Keep hands, feet and objects away
from Platform as it Lowers.
• Keep chair tires properly inated.
Improper ination will change how the
chair ts and secures on the platform,
and changes the clamping pressure.
• Secure chair rmly before driving.
Double-check that is it secured
properly to the platform before you
transport it.
• Inspect the lift condition often. If
ANY parts are worn or damaged, DO
NOT USE THE LIFT. Immediately contact
the dealer you purchased the lift from
for repairs.
• Do Not Enter Steep Driveways
Straight On. Enter and leave at an
angle to the street so that the lift does
not drag on the ground.
• Do Not Move the Vehicle with
Platform Down. If you move with the
platform in the down position, you will
damage the lift mechanism.
• Hand Wash or Use Touchless
Automatic Car Wash only. To
prevent lift damage do NOT use
automatic wash systems.
Figure 11-1
SAFETY & MAINTENANCE
WARNING!
This lift is NOT meant for human transport. The chair or
scooter MUST be unoccupied before operating the lift. Each
lift is designed to transport a specic chair only. DO NOT
attempt to move any mobility devices, objects, people, or
materials other than those for which the lift was designed.
CAUTION!
Drive with EXTREME CARE while transporting your chair or
scooter on the lift. DRIVE SLOWLY over rough terrain such as
pot holes, unpaved roads, railroad tracks. Excessive bumping
creates stress on the lift and vehicle and can badly damage
your lift, vehicle, and mobility device.

ESAERG ESAERG
ESAERG
ESAERG ESAERG
ESAERG
12
Section 2 : inStaller
Safety & Maintenance
NOTES FOR AL015,
AL100 AND AL160
MODELS
WARNING!
On some scooters, it
may be necessary to
temporarily move the
steering tiller forward to
clear the hold-down arm
as it lowers into the lock-
down position.
WARNING!
Some scooters have
pneumatic (air inated)
tires. If your scooter has
this type tire, be sure the
tires are properly inated.
Improper ination will
change the deck height of
the scooter and therefore
change the amount of
clamping force the hold-
down arm places on
the scooter. The scooter
can fall o the lift if not
properly secured.
CAUTION!
Drive the scooter o
in REVERSE. When the
scooter is clear of the
platform, raise the
platform by pushing up
on the UP/DOWN switch.
MAINTENANCE
This Outside Lift is designed to be as trouble free as possible;
however, some basic maintenance will ensure that it continues
to oer reliable use for years to come.
Oil pivot points on all moving parts every 30 days.
Re-grease the inside vertical square tube every 30 days in
winter or in dirty or dusty conditions. Just lower the platform
to the ground and clean the tube with mineral spirits, WD-40,
or a good solvent. When clean, grease the square vertical tube
shaft with high grade water-resistant grease such as boat trailer
wheel bearing grease. [Figure 12-1]
Check for paint chips and touch up bare metal. Use a good
gloss black enamel or lacquer to inhibit rust. You may need to
do this more frequently if your lift is subject to salt air or road
salt in the winter.
Figure 12-1

SOCKET SET
Specifically
WRENCH SET
Specifically
3/8”
7/16”
1/2"
9/16"
3/4"
7/16”
1/2"
9/16”
3/4"
ALLENWRENCH
Specifically
1/8”
3/16”
5/16”
#2 FLAT HEAD
SCREWDRIVER
#2 PHILLIPS HEAD
SCREWDRIVER
WIRE CUTTERS
NEEDLE NOSE
PLIERS
MARKING
IMPLEMENT TAPE MEASURE
Outside Lifts - Installation & Owner’s Manual 2013
13
Section 2 : inStaller Preparation
TOOLS REQUIRED
PROFESSIONAL INSTALLATION RECOMMENDED
Installations may vary to some degree, but below are the basic tools to have on hand for an
Outside Lift installation.
If you have any questions, concerns or comments, please contact our Technical Service
Department at 800-378-6648 or [e-mail]
If you do not understand any portion of installation or
operation, please consult our technical service department or
authorized mobility dealer. Do not attempt to install or use this
NOTE: The following section is designed for the professional
installer. We strongly recommend that a certied dealer
install the lift, congure the docking device, and instruct the
user on correct operation as well as establish a Safety and
Maintenance Schedule.
lift with any hesitation or question.
Serious injury or damage can result if
proper procedures are not followed.
Read & Understand this Manual
Prior to Installation or Operation.
Having an overall understanding
of the lift and proper installation
techniques will help you save time,
energy and avoid possible injury.

14
Section 2 : inStaller
Preparation
UNPACKING THE LIFT
Check the box contents. Review each part against the packaging
checklist to ensure that all parts have been included.
If any parts are missing or damaged, immediately contact the dealer
who sold the lift. Do not attempt to install or use a lift that has missing
or damaged parts.

X4X4
Outside Lifts - Installation & Owner’s Manual 2013
15
Section 2 : inStaller Preparation
INSTALLATION OVERVIEW
Read & understand this Manual prior
to installation or operation.
Knowing the lift’s adjustments and the tips on proper installation
techniques will save time, energy and avoid possible injury. If you
do not understand any portion of installation or operation, please
consult our technical service department or authorized mobility
dealer.
Quick Reference – Installation Procedure
1. Wire the Vehicle. See page 17.
Installing the wiring harness first will ensure you have power
to the lift during installation. This allows the motor to do the
lifting for you. (If you skip this step, use a shop battery.)
2. Position the
open box behind
the vehicle. Slice
the corner seams.
[Figure 15-1]
3. Determine / Install Hitch Height / Adapter. Measure the
hitch to ground distance so you can save time by selecting
components that fit between lift and vehicle so as to maintain
proper ground clearance. [Figure 15-2] Install Hitch Adapter
that fits the application. See pages 21 to 25.
Figure 15-2
Figure 15-1
Never attempt to pick up the lift from the box,
ground or on/off a vehicle alone.
If you follow the proper installation procedure, no
heavy lifting will be needed, and the lift practically
installs itself.

Vehicle Harness
Lift Harness
Connect power
to the lift
Vehicle Harness
Lift Harness
Connect power
to the lift
3” or
more
3” or
more
PUSHPUSH
16
Section 2 : inStaller
Preparation
4. Connect power to the lift. [Figure 16-1] Insert and turn key.
Press ‘DOWN’ to extend the lift. [Figure 16-2]
5. When extended 3” or more ip up to
vertical. [Figure 16-3]
Figure 16-1
Figure 16-3
Figure 16-2
Figure 16-4
6. Align the hitch adapter, using the
power of the lift. The lift will slide on the
cardboard box. [Figure 16-4]

TO BATTERY
TO LIFT
20 AMP SELF
RESETTING
CIRCUIT
BREAKER
TO BATTERY
TO LIFT
20 AMP SELF
RESETTING
CIRCUIT
BREAKER
YLNOERIWKCALB
SIDE MOUNT
BLACK WIRE
ONLY
OR
TOPMOUNT
YLNOERIWKCALB
SIDE MOUNT
BLACK WIRE
ONLY
OR
TOPMOUNT
Outside Lifts - Installation & Owner’s Manual 2013
17
Section 2 : inStaller Installation
WIRING THE VEHICLE
Improper wiring is the #1 cause of problems in the operation
of a vehicle lift. Follow the wiring instructions carefully
The vehicle wiring harness is located in the hardware pack.
The harness is manufactured to comply with SAE J1128
requirements. It is approximately 23 feet long and will
accommodate most vehicles.
1. Unwind the wiring harness and lay it at.
The harness end with the black connector is
the lift end. It goes to the trailer hitch area
where the lift will mount. [Figure 17-1]
WARNING!
DO NOT connect
the red wire
until LAST.
2. Begin routing the wiring harness at the vehicle
battery. Attach the black wire to the negative terminal on
the battery. Do NOT attach the red wire until the very end
of installation. [Figure 17-2]
CAUTION!
NEVER attempt to connect the harness to
a secondary power source. Always connect
both leads directly to the battery.
3. Run the vehicle harness under and, when possible,
through the vehicle back to the bumper/trailer hitch area.
• DO NOT run wiring near the gas tank.
• If you wish to run the harness under the
vehicle, use the supplied wire ties to
secure the wire against the frame, avoiding
moving parts / hot parts such as exhaust.
• Run the wire under and through the
vehicle whenever possible, gaining
entry into the vehicle through the
firewall
• DO NOT run wiring where it can be
snagged by road debris.
Figure 17-1
Figure 17-2
continued

COIL ANY EXCESS
WIREHERE
DO CUT
OR SHORTEN
NOT
COIL ANY EXCESS
WIREHERE
DO CUT
OR SHORTEN
NOT
18
Section 2 : inStaller
Installation
CAUTION!
DO NOT cut or shorten the harness.
4. Once harness is run into the vehicle,
remove the pin's protective tubing.
5. Inspect the pin's retaining anges.
They may have become deformed while
run through the vehicle. These are critical to
secure the pins inside the connector. Adjust
as needed.
6. Flip open end connector's jigned
retainer, insert pins as shown. [Figure 18-2]
Verify the wires can not be pulled out by
moderately pulling on the wires.
Be sure rubber seals are inside back of
connector and close the hinged retainer.
7. Plug connector into the lift.
8. LAST…attach red wire to the positive
terminal on the battery. [Figure 18-3]
• If the harness is too long, coil the
excess wire and secure it to the vehicle
frame/bumper with the supplied wire
ties. [Figure 18-1]
RED WIRE
RED WIRE
OR
LAST
SIDE MOUNT
TOPMOUNT
RED WIRE
RED WIRE
OR
LAST
SIDE MOUNT
TOPMOUNT
Figure 18-3
B=BLACK,A=R ED
LETTERSARE
MOLDED INTO
PLASTIC
HINGED
RETAINER
A
B
BLACK WIRE
ERIWDER
Protective
tubing
CORRECT
ADJUST BY
PRYING OUT
SLIGHTLY
IF NEEDED
SEALS
3
4
5
B=BLACK,A=R ED
LETTERSARE
MOLDED INTO
PLASTIC
HINGED
RETAINER
A
B
BLACK WIRE
ERIWDER
Protective
tubing
CORRECT
ADJUST BY
PRYING OUT
SLIGHTLY
IF NEEDED
SEALS
3
4
5
Figure 18-2
Figure 18-1

Outside Lifts - Installation & Owner’s Manual 2013
19
Section 2 : inStaller Installation
BROWN WIRE
VEHICLE SIDE
OR
SPLICE +12VTail ParkingLight wire
or any+12V source HOT when
vehicle'slightsare turned on,
or ignitionisin"ACC" mode.
Ground for Lamp
is tied intothe
Main Power 2 Pin
Connector
LIFT SIDE
BROWN WIRE
VEHICLE SIDE
OR
SPLICE +12VTail ParkingLight wire
or any+12V source HOT when
vehicle'slightsare turned on,
or ignitionisin"ACC" mode.
Ground for Lamp
is tied intothe
Main Power 2 Pin
Connector
LIFT SIDE
IMPORTANT!
If the installation requires the wiring harness to run on
the underside of the vehicle, route the harness away
from the exhaust system, brake lines, fuel lines and gas
tank. Avoid pinch points and sharp edges. Avoid locating
the harness where it can be snagged by road debris.
NOTE: A standard two-contact trailer connector is
included with the lift. This is for the license plate lamp. If
your vehicle is not equipped with the proper connector,
you can use the BROWN WIRE to make a wire splice and
achieve the same result. [Figure 19-3]
TECH NOTE: MOTOR TESTING
Troubleshooting with a test light
or voltage meter may give a false
indication.
When you probe for 12 volts, the
reading may indicate a connection,
even if the connection is not
necessarily sufficient. The lift’s motor
can draw up to 20 amps at some
points, requiring all of the available
wire to flow proper current. Poor
connections are the #1 problem
associated with a slow, intermittent,
warm, poorly performing motor which
will also deteriorate prematurely.
If a single strand of a multi-strand wire
is making contact, 12V will appear on
a meter or test light, but it will not
allow the motor to operate. It is always
best to test both current and voltage,
or run the motor with known good
shop battery or power source when
troubleshooting.
Figure 19-3

PRODUCT: WEIGHT:
IF
USED
CHAIR/
SCOOTER
lbs
Manufacturer's
MaxTongue
Weight
=
++
Must
Exceed Hitch
NOT
""lbsx
OR
HITCH
CLASS:
AL003......ball,1,2, or 3...........25 lbs
AL010/050......1,2or 3............71/67
AL015.............1,2, or 3...........62 lbs
AL030......ball,1,2, or 3...........49 lbs
AL580................2 or 3............63 lbs
AL580XL............2 or 3............63 lbs
AL300HD...........3 or 5............82 lbs
AL500HD...........3 or 5...........77 lbs
AL301XL HD......3 or 5..........102 lbs
AL100................2 or 3............83 lbs
AL160.............1,2, or 3...........74 lbs
AL300................2 or 3............80 lbs
AL301XL............2 or 3..........100lbs
AL500................2 or 3............75 lbs
AL560................2 or 3............89 lbs
AL560XL........... 2or 3..........101 lbs
AL570................ 2or3............69 lbs
AL570XL........... 2or 3............79 lbs
OR
24 lbs
AL105L
AL105
40 lbs
20
Section 2 : inStaller
Installation
VEHICLE HITCH
Outside Lifts require a vehicle that can accept a
Class 1, 2 or 3 hitch. The vehicle should be wired
with a standard 4 connector trailer wiring.
If you are not sure about the vehicle and
hitch capability, contact a local hitch installer
or you can visit web sites of a hitch company.
For example: www.hitch-web.com;
www.reeseprod.com; www.draw-tite.com
Be sure to use a hitch installer that is reputable,
insured, and capable. Their work reflects directly
on the customer’s perception of your mobility
lift installation.
1. Calculate the weights of the lift,
mobility device, and, where applicable,
the Swing-Away option. Be certain that
the total weight does not exceed the hitch’s
recommended tongue weight. A range of
hitches are available, capable of bearing
different amounts of weight.
The lift manufacturer suggests the installer
observe the vehicle’s Gross Vehicle Weight Rating
restrictions.
Some states have strict license plate
obstruction laws. Familiarize yourself with
local and state laws.
2. Ensure the receiver tube of the hitch is
installed parallel to the ground. This is a
requirement, not merely a recommendation.
If the hitch is not installed properly it affects
the lift’s functionality.
Some vehicles will require that the rear
suspension be supplemented. The manufacturer
recommends the installer contact a suspension
specialist for additional technical support.
A vehicle with a Class 2 hitch requires optional
accessories.
A vehicle with a Class 3 hitch and standard 4
connector wiring is ready for installation.
NOTE: Not every vehicle is capable of
having a hitch installed.
adapters. Hitch Expanders
and Extenders are strictly
prohibited – using them or any
other aftermarket accessory
may result in damage to the
vehicle, lift, and/or personal
injury to the user.
