Harmar Mobility AL055 Operating instructions

INSTALLATION & OWNER’S MANUAL
Read manual thoroughly before attempting to install or operate lift.
Serial Number:
Dealer:
AL 055
MICRO INSIDE LIFT
CAPACITYY: 200 lbs
AL 055 AL 065
MICRO INSIDE-OUTSIDE LIFT
CAPACITY: 200 lbs
AL 065
This manual has been provided to assist you
with lift installation and operation.
For further assistance please contact your
authorized Harmar Mobility dealer or
Harmar’s Technical Service Department.
Fax: [phone]
Tech: 866-378-6648
Email: [email protected]
Harmar
2075 47th ST
Sarasota, FL 34234
Tel: [phone]
P/N: 999-3B05-AA Rev B

TABLE of CONTENTS
TECHNICAL INFORMATION
PREPARATION
INSTALLATION
OPERATION
TOOLS RECOMMENDED .................................................p 2
UN-PACKING THE LIFT .....................................................p 3
WIRING THE VEHICLE ......................................................p 4
TRIAL FIT PROCEDURE .....................................................p 5
INSTALLATION .................................................................p 6-7
DOCKING DEVICES ........................................................p 8
OPERATION ......................................................................p 9-10
SAFETY & MAINTENANCE ..................................................p 11
TROUBLE-SHOOTING .........................................................p 12
EXPLODED VIEWS / PARTS BREAKOUT .................................p 13-15
ELECTRICAL......................................................................p 16
SERVICE NOTES.................................................................p 17-18
1

TOOLS RECOMMENDED
THE FOLLOWING IS A SUGGESTION OF BASIC TOOLS RECOMMENDED TO HAVE ON HAND DURING INSTALLATION
AS WELL AS A GUIDE TO PORTRAY COMPLEXITY OF THIS TYPE OF INSTALLATION
THIS IS, BY NO MEANS, MEANT TO REPRESENT THE REQUIREMENTS AS A WHOLE, AS EACH INSTALLATION WILL
VARY TO SOME DEGREE. HARMAR LIFTS ARE DESIGNED TO INSTALL WITH AS LITTLE ASSEMBLY AS POSSIBLE.
SAE SOCKET SAE WRENCH
7/16”
1/2”
9/16”
3/4”
7/16”
1/2”
9/16”
3/4”
SAE ALLEN WRENCH
5/32”
1/8”
3/16”
5/16”
38”
#2 FLAT HEAD
SCREWDRIVER
#2 PHILLIPS HEAD
SCREWDRIVER
SMALL HACKSAW ELECTRIC DRILL
WIRE CUTTERS
NEEDLE NOSE
PLIERS
MARKING
IMPLEMENT TAPE MEASURE DRILL BITS METAL FILE
PILOT DRILL BIT
3/8” DRILL BIT
9/16” DRILL BIT
As always, if you have any questions, concerns or comments, please feel free to contact
Harmar's Technical Service Department at 866-378-6648 or "[email protected]"
2

UNPACKING THE LIFT
AL-055
AL-065
BE SURE TO CHECK THE CONTENTS OF THE BOX
AGAINST THE PACKAGE CHECK LIST TO BE SURE
THAT ALL THE PARTS ARE INCLUDED WITH THE LIFT
THAT ARE REQUIRED FOR PROPER INSTALLATION
IF ANY PARTS ARE MISSING OR IF ANY DAMAGE IS NOTED,
IMMEDIATELY CONTACT THE DISTRIBUTOR FROM WHICH
YOU PURCHASED YOUR LIFT. DO NOT ATTEMPT TO INSTALL
OR USE THE LIFT WITH ANY MISSING OR DAMAGED PARTS
VEHICLE
HARNESS
INSTALLATION
WASHERS
3x
1 - HHCS, 1/4-28 x 3.00”L, ZP STEEL G5
3 - HHTB, 3/8-16 x 3-1/2”L, ZP STEEL G5
1 - NUT, NYLOC, 1/4-28, ZP STEEL
3 - NUT, NYLOC, 3/8-16, ZP STEEL
3 - WASHER, FLAT, 3/8”, ZP STEEL
10 - 14” CABLE TIES
4 - 4-1/2” CABLE TIES
1 - INSTALLATION & OWNER’S MANUAL
w/ WARRANTY SHEET
1 - RUBBER GROMMET
1 - WIRE HARNESS INSTRUCTION
1 - 4” Velcro
END
CONNECTOR
HARDWARE PACK
FLANGE BUSHING
BUSHING
COLLAR
POST
HAND
CONTROL
HARNESS
BASE
ARM ASSEMBLY
ARM ASSEMBLY
HAND
CONTROL
HARNESS
FLANGE
BUSHING
(X2)
POST
SHAFT
COLLAR
MOUNTING FLANGE
MOUNTING ARM
1 - VEHICLE HARNESS
1 - WIRE CONNECTOR
1 - ROCKER STOPPER
2- HHCS, 1/4-20 x 4.00”L, ZP STEEL G5
1 - HHCS, 1/4-28 x 3.00”L, ZP STEEL G5
2 - NUT, NYLOC, 1/4-20, ZP STEEL
1 - NUT, NYLOC, 1/4-28, ZP STEEL
10 - 14” CABLE TIES
4 - 4” CABLE TIES
4 - CORD CLIPS
1 - INSTALLATION & OWNER’S MANUAL
w/ WARRANTY SHEET
1 - RUBBER GROMMET
1 - WIRE HARNESS INSTRUCTION
1 - 6” Velcro
HARDWARE PACK
STANDARD CLASS 3
HITCH ADAPTER
33

B=BLACK, A=RED
IMPROPER WIRING IS THE #1 CAUSE OF PROBLEMS IN THE OPERATION OF A VEHICLE LIFT.
FOLLOW THE WIRING INSTRUCTIONS CAREFULLY
BLACK WIRE ONLY
SIDE MOUNT
BLACK WIRE
ONLY
OR
TOP MOUNT
LETTERS ARE
MOLDED INTO
PLASTIC
HINGED
RETAINER
A
B
BLACK WIRE
RED WIRE
Protective
tubing
CORRECT
ADJUST BY
PRYING OUT
SLIGHTLY
IF NEEDED
PROBING FOR 12 VOLTS MAY INDICATE
A CONNECTION, BUT NOT NECESSARILY
A SUFFICIENT CONNECTION.
THE LIFT’S MOTOR CAN DRAW UP TO
30 AMPS AT SOME POINTS, REQUIRING
ALL OF THE AVAILABLE TO FLOW
PROPER CURRENT. POOR CONNECTIONS
ARE THE #1 PROBLEM ASSOCIATED WITH
A SLOW, INTERMITTENT, WARM,
POORLY PERFORMING MOTOR.
NOT ONLY WILL THE MOTOR PERFORM POORLY,
BUT WILL PREMATURELY DETERIORATE.
IF A SINGLE STRAND OF A MULTI-
STRAND WIRE IS MAKING CONTACT,
12V WILL APPEAR ON THE METER, OR TEST LIGHT,
BUT WILL NOT ALLOW THE MOTOR TO OPERATE.
IT IS ALWAYS BEST TO TEST BOTH
CURRENT AND VOLTAGE, OR RUN THE MOTOR
WITH KNOWN GOOD SHOP BATTERY OR POWER
SOURCE WHEN TESTING FOR POWER.
WIRE
WHEN THE INSTALLATION
REQUIRES THE WIRING
HARNESS BE RUN ON THE
UNDERSIDE OF THE VEHICLE,
ROUTE THE HARNESS AWAY
FROM THE EXHAUST SYSTEM,
BRAKE LINES, FUEL LINES< GAS
TANK, PINCH POINTS, AND SHARP
EDGES. LOCATE THE WIRING
HARNESS WHERE IT CAN NOT
BE SNAGGED BY ROAD DEBRIS
NEVER ATTEMPT
TO CONNECT
THE HARNESS
TO A SECONDARY
POWER SOURCE.
ALWAYS CONNECT
BOTH LEADS
DIRECTLY TO THE
BATTERY
TO BATTERY
END
CONNECTOR
20 AMP SELF
RESETTING
CIRCUIT
BREAKER
SEALS
LOCATED IN THE HARDWARE PACK IS THE VEHICLE WIRING
HARNESS. THE HARNESS IS MANUFACTURED TO, AND COMPLIES
WITH, THE SAE J1128 REQUIREMENTS. THE WIRE HARNESS IS
APPROXIMATELY 23 ft LONG AND WILL ACCOMMODATE MOST VEHICLES.
YOUR WIRING HARNESS HAS BEEN LEFT UN-ASSEMBLED
FOR EASE OF INSTALLATION. THE END CONNECTOR HAS BEEN
INCLUDED SEPARATELY FROM THE HARNESS TO ALLOW
THE INSTALLER TO THE RUN THE WIRE UNDER AND THROUGH
THE VEHICLE WITH THE SMALLEST HOLE POSSIBLE. FOLLOW
THESE INSTRUCTIONS TO ASSURE PROPER INSTALLATION.
DO NOT CONNECT RED WIRE UNTIL THE VERY END.
UNWIND THE HARNESS AND LAY IT FLAT.
ONE END OF THE HARNESS HAS 2 COVERED PINS.
THIS IS THE LIFT END OF THE HARNESS AND
GOES TO THE REAR CARGO AREA WHERE THE LIFT
WILL MOUNT.
BEGIN ROUTING THE WIRING HARNESS AT THE VEHICLE BATTERY.
ATTACH THE BLACK WIRE TO THE NEGATIVE TERMINAL ON THE BATTERY.
DO NOT ATTACH THE RED WIRE UNTIL THE END.
RUN THE WIRING HARNESS UNDER OR WHEN POSSIBLE THROUGH
THE VEHICLE, BACK TO THE REAR CARGO AREA / TRUNK. ALWAYS
LOCATE THE WIRING WHERE IT CAN NOT BE SNAGGED BY ROAD
DEBRIS AND AWAY FROM THE GAS TANK. THROUGH THE VEHICLE
IS BEST, GAINING ENTRY INTO THE VEHICLE THROUGH THE FIREWALL.
HOWEVER IF YOU WISH TO RUN THE HARNESS UNDER THE VEHICLE,
A HOLE WILL MOST LIKELY NEED TO BE DRILLED TO GET THE WIRE
INTO THE REAR CARGO AREA / TRUNK. IF THE HARNESS IS TOO LONG
FOR THE VEHICLE, COIL THE EXCESS WIRE AND SECURE IT TO THE
VEHICLE FRAME WITH SUPPLIED TIE WRAPS.
DO NOT CUT OR SHORTEN THE HARNESS.
ONCE THE HARNESS IS RUN INTO
THE VEHICLE, REMOVE PIN’S
PROTECTIVE TUBING.
INSPECT THE PIN’S RETAINING FLANGES.
THE MAY HAVE BECOME DEFORMED
WHILE RUNNING THEM THROUGH THE VEHICLE.
THESE ARE CRITICAL TO SECURE THE PINS INSIDE
THE END CONNECTOR. ADJUST AS NEEDED.
FLIP OPEN END CONNECTOR’S HINGED RETAINER.
INSERT PINS AS SHOWN:
WIRING THE VEHICLE
RED WIRE
RED WIRE
OR
LAST
SIDE MOUNT TOP MOUNT
11
2
2
3
3
4
4
5
5
6
6
AL055, AL065 Install and Owner's Manual
4

CHAIR’S WIDTH,
HEIGHT,
ETC...
HEIGHT,
ETC...
½ WIDTH,
PRIOR TO ANY HOLES BEING DRILLED, IT IS HIGHLY RECOMMENDED THAT
THE LIFT BE RUN THROUGH ITS RANGE OF MOTION IN A “TRIAL FIT.”.
WITH THE HELP OF AN ASSISTANT, ASSEMBLE THE LIFT, AND PLACE IT IN THE
MOST REAR CORNER OF THE CARGO SPACE CLOSEST TO THE BUMBER.
(THIS WILL YIELD THE GREATEST AVAILABLE LOADING AREA)
( PASSENGER SIDE SHOWN. DRIVER’S
SIDE IDENTICAL BUT MIRRORED )
THE AlL-055 WILL REQUIRE 3 HOLES TO BE DRILLED
INTO THE VEHICLE, TO BOLT THE LIFT’S BASE TO THE FLOOR.
THE POSITIONING OF THE BASE IS VERY IMPORTANT
TO A SUCCESSFUL INSTALLATION AND OPERATION OF THIS LIFT.
ONCE IT HAS BEEN VERIFIED EACH OF THE HELD MEASUREMENTS DOES NOT
INTERFERE WITH THE VEHICLE’S CARGO AREA / OPENING,
MARK THE 3 LOCATIONS IN WHICH TO DRILL
TRIAL FIT PROCEDURE
FOLD THE CHAIR OR SCOOTER’S SEAT BACK ( or REMOVE SEAT ) PREFERABLY
WITH DOCKING DEVICE INSTALLED TO ROUGHLY OBSERVE THE CHAIR’S
TRANSPORTABLE DIMENSIONS.
MEASURE LENGTH, WIDTH, AND HEIGHT
SIMULATE EACH OF THE CHAIR’S DIMENSIONS
( LENGTH, WIDTH, and HEIGHT ) WHILE RUNNING
THE LIFT THROUGH ITS FULL RANGE OF MOTION
IN AND OUT OF THE VEHICLE’S CARGO AREA
WIDTH
LENGTH
HEIGHT
5

ONCE CONFIDENCE HAS BEEN GAINED ON THE POSITION OF THE LIFT,
AND THE “TRIAL FIT” PROCEDURE HAS BEEN COMPLETED, THREE 3/8”
HOLES WILL NEED TO BE DRILLED IN THE MARKED LOCATIONS
ONCE HOLES ARE DRILLED, FASTEN BASE TO VEHICLE
FLOOR USING SUPPLIED HARDWARE IN THE HARDWARE
PACK. BE SURE TO TIGHTEN ALL FASTENERS.
AL-055 INSTALLATION
ALL THREAD KIT MAY BE REQUIREDALL THREAD KIT MAY BE REQUIRED
SOME VEHICLES HAVE STORAGE
COMPARTMENTS IN THE REAR CARGO
AREA, POTENTIALLY EFFECTING LIFT
PLACEMENT. MOST OF THESE CAN BE
OVERCOME WITH THE AID OF AN
ALL THREAD KIT. SHOWN ABOVE IS THE
TYPICAL APPLICATION FOR
OVERCOMING THESE STORAGE
COMPARTMENTS OR WELLS.
SPARE TIRE STORAGE:
SOME VEHICLES STORE
THE SPARE TIRE UNDER
THE FLOOR OF THE VEHICLE.
MAKE SURE THAT THE BASE
CAN BE BOLTED THROUGH
A STEEL FLOOR OR FRAME.
AT-01
STORAGE
WELL
LID
Vehicle
Floor
Vehicle
Floor
Vehicle
Floor
INSTALLATION TIP:
CHOOSE A SAFE LOCATION IN WHICH TO
DRILL A SINGLE PILOT HOLE FROM ABOVE
IN ONE OF THE 3 MARKED LOCATIONS.
LOOK UNDERNEATH THE VEHICLE
AND MEASURE OUT THE SPECIFIED
DISTANCE FROM THE PILOT HOLE.
IF ALL IS CLEAR IN THAT AREA, CONTINUE
TO DRILL PILOT HOLES IN REMAINING
LOCATIONS.
INSPECT ALL THREE PILOT HOLES FROM
UNDER THE VEHICLE. IF ALL CLEAR, DRILL
3/8” HOLES IN PILOT LOCATIONS
CAUTION! AVOID THE VEHICLE
WIRING, FUEL LINES, FUEL TANKS
SPARE TIRES, ETC. WHEN DRILLING
CAUTION! AVOID THE VEHICLE
WIRING, FUEL LINES, FUEL TANKS
SPARE TIRES, ETC. WHEN DRILLING
PLACE POST INTO BASE.
SLIDE SHAFT COLLAR OVER POST
TIGHTEN SET SCREW.
SLIP-ON ARM ASSEMBLY ONTO BASE..
ADJUST ARM HEIGHT WITH SET SCREW
AS NEEDED (POST MAY BE
CUT IF REQUIRED).
ONCE REQUIRED HEIGHT IS
DETERMINED, DRILL 1/4” HOLE
THRU POST USING SHAFT COLLAR
AS A GUIDE.
BOLT SHAFT COLLAR TO POST
USING SUPPLIED 1/4” BOLT AND NUT.
ARM ASSEMBLY
COLLAR
SET
SCREW
POST
BASE
BUSHINGS
6

AL-065 INSTALLATION
OR
OR
OR
HIGHER TO
GROUND
LOWER TO
GROUND
FLIP
FLIP
ASSEMBLE HITCH ADAPTER
TO MOUNTING FLANGE AND
BOLT ARM / BASE TO MOUNTING FLANGE
(LEAVE LOOSE FOR ADJUSTMENT)
ARM / BASE
MOUNTING
FLANGE
CLASS 3
HITCH
ADAPTER
CLASS 2
HITCH
ADAPTER
PINCH BOLT
TUBE
(CLASS 3 ONLY)
(ADJUST AS NECESSARY)
PLACE POST INTO BASE
SLIP FRAME ONTO POST
ADJUST ARM HEIGHT WITH SET SCREW
AS NECESSARY..
ONCE REQUIRED HEIGHT AND ROTATION IS
DETERMINED, DRILL 1/4” HOLE
THRU POST USING SHAFT COLLAR
AS A GUIDE.
(ADJUST AS NECESSARY)
POST
ARM ASSEMBLY
BASE
(ADJUST AS NECESSARY)
HITCH
STABILIZER
TIGHTEN HITCH STABILIZER
ON HITCH LIP AND BOTTOM
OF HITCH ADAPTER
FOR DRIVER’S SIDE:
FLIP MOUNT BASE,
SO ARM IS ON
OPPOSING SIDE.
COLLAR
BOLT SHAFT COLLAR TO POST
USING SUPPLIED 1/4” BOLT AND NUT.
ONCE ALL ADJUSTMENTS
ARE COMPLETE,
TIGHTEN ALL FASTENERSTIGHTEN ALL FASTENERS
7

DOCKING DEVICES
DD-21
Spreader Bar &
Bridles
DD-19
C-Arm
The Docking Device is the interface between the lift and the Chair / Scooter.
Most chairs / scooters can be lifted either by the center seat post
or the 4 post seat frame.
Although most chairs / scooters can be lifted by the above Docking Devices,
Many specific devices exist making the application even easier.
Please consult the instruction provided with your Docking Device, or contact our technical
service department to find out exactly how this device is right for you.
8

AL-055 OPERATION
POST
ARM ASSEMBLY
TO MOTOR
TO VEHICLE
HARNESS
ROTATE ARM OUT
OF VEHICLE
INSPECT LIFTING STRAP
BEFORE EACH USE
INSPECT LIFTING STRAP
BEFORE EACH USE
CONNECT POWER
TO LIFTING MOTOR
OPEN TRUNK OR
CARGO DOOR
PLACE POST
INTO BASE
PLACE ARM
ASSEMBLY
ONTO POST
PARK CHAIR
CLOSE TO
VEHICLE
LOWER
STRAP
TO CHAIR’S
HEIGHT
KEEP HANDS AND FEET FROM UNDER THE SCOOTER
OR POWER CHAIR AS IT IS BEING LIFTED
FOLD SEAT
BACK DOWN /
TAKE SEAT OFF
ATTACH
DOCKING DEVICE
OR
ATTACH LIFTING
HOOK TO DOCKING
DEVICE
RAISE CHAIR
ABOVE BUMPER
MANUALLY ROTATE
ARM INTO VEHICLE
ENSURE THE LIFTING STRAP IS SECURE AND THAT IT
POINTS STRAIGHT DOWN. FAILURE TO DO SO COULD
RESULT IN THE SCOOTER OR CHAIR SWINGING
CAUSING DAMAGE TO OPERATOR OR VEHICLE
STOP LIFTING BEFORE THE STRAP HOOK CONTACTS THE STRAP ROLLER MOUNTED ON THE
LIFTING ARM. CONTACT WILL DAMAGE THE LIFT. A PROPERLY ADJUSTED LIFT WILL AVOID THIS
ELIMINATE EXCESS STRAP BY PRESSING THE “UP” BUTTON
UNTIL THE HOOK IS ABOUT 1 INCH FROM THE TOP OF THE LIFTING
ARM, MAKING DIS-ASSEMBLY EASIER.
IF PREPARATIONS ARE NEEDED TO SECURE THE SCOOTER OR CHAIR
FOR TRANSPORT SUCH AS PARKING BRAKES OR WHEEL CHOCKS,
THE DEALER SHOULD INSTRUCT OPERATORS ON HOW.
DUE TO THE WIDE VARIETY OF SCOOTERS, POWER CHAIRS, AND VEHICLES,
YOUR DEALER MAY OFFER A DIFFERENT METHOD FOR LOADING AND UNLOADING
YOUR MOBILITY DEVICE. PLEASE FOLLOW THE GUIDELINES THEY HAVE OFFERED.
UNLOADING IS THE REVERSE OF LOADING.
REMOVE ARM & POST ASSEMBLIES
AND STORE INSIDE TRUNK OR
CARGO AREA
CLOSE TRUNK / CARGO DOOR
DISCONNECT POWER
TO LIFTING MOTOR
LOWER CHAIR
INTO VEHICLE
REMOVE HOOK
FROM DOCKING
DEVICE
9

AL-065 OPERATION
POST
ARM
ASSEMBLY
MOUNTING FLANGE
& ARM / BASE
OPEN TRUNK OR CARGO DOOR
INSERT POST INTO ARM / BASE
PLACE ARM ASSEMBLY ONTO POST
MANUALLY ROTATE
FRAME ARM TO
OUTSIDE OF VEHICLE
INSPECT LIFTING STRAP
PRIOR TO EACH USE
CONNECT POWER
TO LIFTING MOTOR
LOWER
STRAP
TO CHAIR’S
HEIGHT
PARK CHAIR
CLOSE TO
VEHICLE
KEEP HANDS AND FEET FROM UNDER THE SCOOTER
OR POWER CHAIR AS IT IS BEING LIFTED FOLD SEAT
BACK DOWN /
TAKE SEAT OFF
ATTACH
DOCKING DEVICE
OR
ATTACH LIFTING
HOOK TO DOCKING
DEVICE
ENSURE THE LIFTING STRAP IS SECURE AND THAT IT
POINTS STRAIGHT DOWN. FAILURE TO DO SO COULD
RESULT IN THE SCOOTER OR CHAIR SWINGING
CAUSING DAMAGE TO OPERATOR OR VEHICLE
STOP LIFTING BEFORE THE STRAP HOOK CONTACTS THE STRAP
ROLLER MOUNTED ON THE LIFTING ARM. CONTACT WILL DAMAGE
THE LIFT. A PROPERLY ADJUSTED LIFT WILL AVOID THIS
MANUALLY
ROTATE
ARM INTO
VEHICLE
LOWER CHAIR
INTO VEHICLE
RAISE CHAIR
ABOVE BUMPER
REMOVE HOOK
FROM DOCKING
DEVICE
ELIMINATE EXCESS STRAP BY PRESSING THE “UP” BUTTON
UNTIL THE HOOK IS ABOUT 1 INCH FROM THE TOP OF THE LIFTING ARM
IF PREPARATIONS ARE NEEDED TO SECURE THE SCOOTER OR CHAIR
FOR TRANSPORT SUCH AS PARKING BRAKES OR WHEEL CHOCKS,
THE DEALER SHOULD INSTRUCT OPERATORS ON HOW.
DUE TO THE WIDE VARIETY OF SCOOTERS, POWER CHAIRS, AND VEHICLES,
YOUR DEALER MAY OFFER A DIFFERENT METHOD FOR LOADING AND UNLOADING
YOUR SCOOTER. PLEASE FOLLOW THE GUIDELINES THEY HAVE OFFERED
UNLOADING IS THE REVERSE OF LOADING
TRAVEL w/ LIFT ASSEMBLEDTRAVEL w/ LIFT ASSEMBLED UN-ASSEMBLE / STORE INSIDEUN-ASSEMBLE / STORE INSIDE
ALWAYS DISCONNECT POWER
TO LIFTING MOTOR BEFORE TRAVEL
OR
STRAP HOOK
TO MOUNT FLANGE
RUN STRAP UP TILL TIGHT
REMOVE ARM
ASSEMBLY &
POST AND STORE
TRUNK OR
CARGO
AREA
10

WARNING
YOU MUST HAND WASH
OR USE TOUCHLESS
AUTOMATIC CAR WASH
TO PREVENT LIFT DAMAGE
WARNING
SAFETY:
MAINTENANCE:
WARRANTY:
CAUTION: DO NOT OPERATE THIS LIFT UNTIL YOUR DEALER
HAS SATISFACTORILY INSTRUCTED YOU IN THE PROPER OPERATION OF THE LIFT.
YOUR HARMAR INSIDE LIFT HAS BEEN ENGINEERED AND DESIGNED FOR YEARS OF TROUBLE FREE USE. ALTHOUGH, WITH EVERYDAY USE, SOME
PARTS MAY BECOME LOOSE OR WORN. IMPORTANT! CHECK REGULARLY FOR ANY WORN, LOOSE, OR DAMAGED PARTS OF YOUR LIFT. IF ANYTHING
IS OBSERVED, DO NOT USE THE LIFT ! CONTACT YOUR DEALER OR INSTALLER OF THE LIFT FOR REPAIRS TO BE MADE. FAILURE TO ACT MAY
CAUSE SEVERE INJURY
YOUR HARMAR INSIDE LIFT SHOULD ONLY BE USED FOR THE LOADING AND UNLOADING OF SCOOTERS AND POWER WHEELCHAIRS FOR WHICH IT IS
DESIGNED. IF YOUR PARTICULAR APPLICATION ( VEHICLE & SCOOTER/CHAIR ) CHANGES ( ex. BUY A NEW CAR / UPGRADE TO A NEW POWER CHAIR )
PLEASE CONSULT YOUR INSTALLER OR DEALER, AS THE ORIGINAL EQUIPMENT MAY NOT CONFIGURE THE SAME. DO NOT ADD TO OR MODIFY ANY
PART OF THE LIFT SYSTEM WITHOUT FIRST CONSULTING THE MANUFACTURER OF THE LIFT. ANY MODIFICATIONS MAY VOID ANY WARRANTIES AS
WELL AS THE STRUCTURAL INTEGRITY OF THE LIFT.
IF THERE IS ANY SIGN OF TEARING / LOOSE THREADS / DAMAGE / WEAR
DO NOT USE THE LIFT. SEVERE DAMAGE TO CHAIR / SCOOTER / VEHICLE
AND PERSONAL INJURY MAY OCCUR. PLEASE CONTACT YOUR DEALER OR
INSTALLER, AND HAVE THE STRAP REPLACED IMMEDIATELY.
CAUTION: WHEN ATTACHING THE STRAP HOOK TO YOUR CHAIR / SCOOTER, INSURE THE LIFTING STRAP IS SECURE AND TAUGHT AND THAT IT
POINTS STRAIGHT DOWN BEFORE LIFTING. FAILURE TO DO SO COULD RESULT IN THE SCOOTER OR CHAIR SWINGING TOWARD THE OPERATOR
OR THE VEHICLE.
CAUTION: WHEN USING THE LIFT, KEEP YOUR HANDS AND FEET FROM UNDER THE
CHAIR / SCOOTER AS IT IS BEING LOADED OR UNLOADED.
CAUTION: STOP LIFTING BEFORE THE STRAP HOOK CONTACTS THE STRAP ROLLER
MOUNTED ON THE LIFTING ARM. CONTACT WILL RESULT IN DAMAGE TO THE LIFT.
A PROPERLY ADJUSTED AND OPERATED LIFT WILL AVOID THIS.
CAUTION: INSURE THE CHAIR / SCOOTER IS FIRMLY SITTING ON THE FLOOR OF THE
VEHICLE AND NOT SUSPENDED BY THE LIFT DURING TRANSPORTATION. IF THE
SCOOTER / CHAIR IS NOT FIRMLY ON THE FLOOR OF THE VEHICLE, IT MAY MOVE
DURING TRANSPORTATIONCAUSING DAMAGE TO THE LIFT, TO THE VEHICLE,
TO THE SCOOTER / CHAIR, OR TO THE PASSENGERS.
ALWAYS CHECK
THE LIFTING STRAP
BEFORE EACH USE
FOR DAMAGE
OR WEAR
YOUR HARMAR INSIDE LIFT HAS BEEN DESIGNED AND ENGINEERED TO BE AS TROUBLE FREE AS POSSIBLE TO THE OWNER. BUT, AS WITH ANY
MECHANICAL DEVICE, REGULAR CARE SHOULD BE GIVEN WHILE OWNING AN USING THIS DEVICE.
MAINTENANCE IS NO EXCEPTION.
WE RECOMMEND THAT DEALERS SCHEDULE A PREVENTATIVE MAINTENANCE INSPECTION AT LEAST ONCE A YEAR ON MOTORS, LIFT FRAME,
WIRING HARNESSES, AND ALL MOVING PARTS OF THE LIFT.
CHECK FOR PAINT CHIPS AND TOUCH UP AND BARE METAL WITH A GOOD GLOSS BLACK ENAMEL OR LACQUER TO INHIBIT RUST. THIS MAY BE
NECESSARY MORE FREQUENTLY WHEN SUBJECTED TO SALT AIR OR ROAD SALT.
ALWAYS CHECK THE LIFTING STRAP BEFORE EACH USE. IF ANY WEAR OR DAMAGE IN NOTICED DO NOT USE THE LIFT ! CONTACT THE
DEALER OR INSTALLER FOR REPAIR. FAILURE TO DO SO WILL RESULT SEVERE INJURY OR DAMAGE.
HAND CONTROL UNITS SHOULD BE PROPERLY STORED INSIDE THE VEHICLE WHENEVER POSSIBLE. IF LIFT IS INSTALLED IN THE BACK
OF A PICK-UP TRUCK, WE STRONGLY RECOMMEND UN-PLUGGING THE CONTROL IN BETWEEN USES, AND STORING IN THE CAB. EXPOSURE
TO WEATHER IS OK, BUT RAIN FLOODING THE TRUCK BED, AND THE HAND CONTROLLER BEING SUBMERGED IN WATER, COULD CAUSE THE
CONTROLLER TO FAIL.
THIS LIFT COVERED BY A THREE YEAR FACTORY WARRANTY ON MATERIALS AND WORKMANSHIP. CONTACT YOUR LOCAL DEALER FOR MORE
INFORMATION OR GO TO WWW.HARMAR.COM
SAFETY & MAINTENACE
CAUTIONCAUTION
11

CIRCUIT
BREAKER
20 A
SELF
RESTING
BATTERY
12 V
SHOPBATTERY
APPLY KNOWN GOOD POWER
DIRECT TO MOTOR
APPLY KNOWN GOOD
POWER DIRECT
TO PLUG ON LIFT
OPERATE HAND
CONTROLLER
APPLY KNOWN GOOD
POWER DIRECT
THRU VEHICLE HARNESS
OPERATE HAND
CONTROLLER
DID
MOTOR
RUN
?
DID
MOTOR
RUN
?
DID
MOTOR
RUN
?
YES
YES
YES
NO
NO
NO
REPLACE
MOTOR
INSPECT /
REPLACE
LIFT WIRING
INSPECT or
REPLACE
VEHICLE
HARNESS
SHOP BATTERY
BATTERY
12V
WIRING IN LIFT
WIRING IN LIFT
SHOP BATTERY
BATTERY
BATTERY
12V12V
REPLACE
VEHICLE
BATTERY
BATTERY
12 V
HARMAR STRONGLY RECOMMENDS TROUBLESHOOTING
ELECTRICAL PROBLEMS WITH KNOW GOOD / FULLY CHARGED
12 V AUTOMOTIVE BATTERY or KNOW GOOD / FULLY
CHARGED POWER CHAIR/SCOOTER BATTERY
BAD ELECTRICAL CONNECTIONS / CIRCUIT BREAKER
PROCEDURE:
CHECK / CLEAN ALL CONNECTIONS THAT MIGHT BE LOOSE OR DIRTY
THIS IS THE #1 CAUSE OF A POORLY PERFORMING LIFT.
THE MOTOR ON THE LIFT REQUIRES QUALITY ELECTRICAL CONNECTIONS
TO OPERATE AT FULL CAPACITY. ANY BREAK IN THE WIRING WILL
SLOW DOWN THE MOTOR, OR CAUSE IT TO OPERATE INTERMITTENTLY.
WHICH IN TURN WILL PREMATURELY DETERIORATE THE MOTOR.
THE LIFT’S VEHICLE POWER HARNESS RUNNING THROUGH OR UNDER
THE VEHICLE IS SUBJECT TO ROAD DEBRIS, AND RUBBING AGAINST THE
VEHICLE’S FRAME, CAUSING A SHORT. INSPECT THE FULL LENGTH
OF THE HARNESS TO BE SURE THE JACKET OF INSULATION IS NOT TORN.
VOLTAGE
METER
AUTOMOTIVE
TEST LIGHT
THESE INSTRUMENTS WILL DETECT VOLTAGE, BUT MAY NOT
INDICATE A TEAR OR POOR CONNECTION IN THE WIRING
EXAMPLE:
LIFT WILL NOT OPERATE,
OPERATES SLOWLY, or OPERATES INTERMITTENTLY.
PROBLEM:
PROBLEM: LIFTING STRAP OPERATES IN REVERSE
PROBLEM: SCOOTER OR CHAIR TIPS FRONT OR BACK WHILE BEING LIFTED
PROBLEM: LIFTING ARM IS HARD TO ROTATE
REASON:
BE CAREFUL WHEN TROUBLESHOOTING WITH A TEST LIGHT, OR
VOLTAGE METER. THEY MAY GIVE FALSE INDICATION AS SHOWN
ABOVE. THEY WILL ONLY INDICATE THERE IS SOME WIRE
CONNECTION--NOT NECESSARILY--ENOUGH.
BE CAREFUL WHEN TROUBLESHOOTING WITH A TEST LIGHT, OR
VOLTAGE METER. THEY MAY GIVE FALSE INDICATIONS
THE CIRCUIT BREAKER IS LOCATED ABOUT 6”
FROM THE CONNECTIONS TO THE VEHICLE’S
BATTERY. THE BREAKER WILL SELF RESET IF
OVER-LOADED. HOWEVER, VERIFY
(w/ OHM METER or TEST LIGHT )
THE BREAKER IS FUNCTIONING, OR
REPLACE IT WITH A NEW / KNOWN GOOD
CIRCUIT BREAKER, AND
PERFORM THE
FOLLOWING TESTS.
SHOP
SHOP
THIS SECTION IS RESERVED
FOR THE INSTALLER / DEALER
HARMAR DOES NOT RECOMMEND
THESE PROCEDURES BE ATTEMPTED
BY ANYONE WITHOUT PROPER
KNOWLEDGE OF AUTOMOTIVE
ELECTRICAL CIRCUITRY
REASON: BUTTON WAS HELD TOO LONG AND UNWOUND LIFTING STRAP
LIKE A YO-YO, THE LIFTING STRAP WOUND IN REVERSE
REASON: CHAIR or SCOOTER IS BEING LIFTED OFF CENTER
REASON: DRY / DIRTY BUSHINGS
PROCEDURE: PRESS WHICH EVER BUTTON EXTENDS STRAP, AND
CONTINUE TO HOLD UNTIL STRAP RETURNS TO PROPER DIRECTION
PROCEDURE: ADJUST FOR CENTER OF GRAVITY ON DOCKING DEVICE. CHECK TO
SEE IF PROPER DOCKING DEVICE IS BEING USED
PROCEDURE: CLEAN AND LUBRICATE GREY BUSHINGS IN BASE WITH
WHITE/LITHIUM GREASE OR EQUIV.
TROUBLESHOOTING
BATTERY
12 V
EXAGGERATED
TEAR OR CHAFF
MOTOR
DEAD
THE TEST INSTRUMENTS SHOW
VOLTAGE AVAILABLE, BUT WILL
DROP TOO LOW WHEN THE LOAD
OF THE MOTOR IS APPLIED.
BUT
BATTERY
12 V
INSULATION
REMOVED FOR
CLARITY
MOTOR
DEAD
BATTERY
12V
INSULATION
REMOVED FOR
CLARITY
MOTOR
RUNS
12 V READING
( )
0 V READING
12 V READING
OPEN
1
1
1
2
2
2
TEST
FIRST
TEST
FIRST
TEST
FIRST
THEN
CONNECT
TO
POWER
THEN
CONNECT
TO
POWER
THEN
CONNECT
TO
POWER
12

EXPLODED VIEW
AL 055 / 065 ARM ASSEMBLYAL 055 / 065 ARM ASSEMBLY
13

EXPLODED VIEW
AL-055AL-055
ASSEMBLY PARTSASSEMBLY PARTS
ITEMITEM QTYQTY PART NO.PART NO. DESCRIPTIONDESCRIPTION
1111201-ZB05-C201-ZB05-C BASEBASE
2211260-2B05-A260-2B05-A HOIST ASSEMBLYHOIST ASSEMBLY
3311541-1B05-C541-1B05-C VERTICAL POSTVERTICAL POST
4411542-1B05-C542-1B05-C SHAFT COLLAR TUBESHAFT COLLAR TUBE
5511ALA05010ALA05010 FLANGE BEARING 2 INCHFLANGE BEARING 2 INCH
6611ALA05011ALA05011 BUSHING 2 INCHBUSHING 2 INCH
7711ALA06550ALA06550 HARNESSHARNESS
8811ALA280ALA280 HARDWARE PACKHARDWARE PACK
9911ALA99995ALA99995 LABEL, SERIAL NUMBERLABEL, SERIAL NUMBER
1010 11H20000H20000 2 BUTTON HAND CONTROL2 BUTTON HAND CONTROL
1111 11HHCS-0_25-28--3_00-ZHHCS-0_25-28--3_00-Z HEX HEAD, 1/4-28 X 3.00, ZINCHEX HEAD, 1/4-28 X 3.00, ZINC
1212 11NUT-0_25-28-NYLOCK-ZNUT-0_25-28-NYLOCK-Z NUT, NYLOCK, 1/4-28, ZINCNUT, NYLOCK, 1/4-28, ZINC
1313 11SSCP-0_25-28--0_375SSCP-0_25-28--0_375 SET SCREW, 1/4-28 X 0.375SET SCREW, 1/4-28 X 0.375
ASSEMBLY PARTSASSEMBLY PARTS
QTYQTYITEMITEM PART NO.PART NO. DESCRIPTIONDESCRIPTION
11
11
77
11
88
11
1010
11
22
11
99
11
44
11
55
11
66
11
1111
11
1212
11
1313
11
33
11
14

EXPLODED VIEW
AL-065AL-065
ASSEMBLY PARTSASSEMBLY PARTS
ITEMITEM QTYQTY PART NO.PART NO. DESCRIPTIONDESCRIPTION
1111201-1B06-C201-1B06-C MOUNTING ARMMOUNTING ARM
2211210-ZB06-C210-ZB06-C MOUNTING FLANGEMOUNTING FLANGE
3311241-1B06-C241-1B06-C VERTICAL POSTVERTICAL POST
4411245-1B06-C245-1B06-C SHAFT COLLARSHAFT COLLAR
5511260-2B05-A260-2B05-A HOIST ASSEMBLYHOIST ASSEMBLY
6622ALA05010ALA05010 FLANGE BEARING 2 INCHFLANGE BEARING 2 INCH
7711ALA06550ALA06550 HARNESSHARNESS
8811ALA068ALA068 HARDWARE PACKHARDWARE PACK
9911ALA99995ALA99995 LABEL, SERIAL NUMBERLABEL, SERIAL NUMBER
1010 11H065411H065411 AL065 PATENT STICKERAL065 PATENT STICKER
1111 11H20000H20000 2 BUTTON HAND CONTROL2 BUTTON HAND CONTROL
1212 11HHCS-0_25-28--3_00-ZHHCS-0_25-28--3_00-Z HEX HEAD, 1/4-28 X 3.00, ZINCHEX HEAD, 1/4-28 X 3.00, ZINC
1313 44HHCS-0_50-13--3_50-ZHHCS-0_50-13--3_50-Z HEX HEAD, 1/2-13 x 3.50, ZPHEX HEAD, 1/2-13 x 3.50, ZP
1414 11NUT-0_25-28-NYLOCK-ZNUT-0_25-28-NYLOCK-Z NUT, NYLOCK, 1/4-28, ZINCNUT, NYLOCK, 1/4-28, ZINC
1515 44NUT-0_50-13-NYLOCK-ZNUT-0_50-13-NYLOCK-Z NYLOCK NUT, 1/2-13, ZINCNYLOCK NUT, 1/2-13, ZINC
1616 22SHCS-10-24--0_18-NSHCS-10-24--0_18-N SOCKET HEAD, 10-24 X 0.188, NYLONSOCKET HEAD, 10-24 X 0.188, NYLON
1717 11SSCP-0_25-28--0_375SSCP-0_25-28--0_375 SET SCREW, 1/4-28 X 0.375SET SCREW, 1/4-28 X 0.375
QTYQTYITEMITEM
ASSEMBLY PARTSASSEMBLY PARTS
PART NO.PART NO. DESCRIPTIONDESCRIPTION
11
11
22
11
33
11
55
11
66
22
77
11
88
1199
11
1010
11
1111
11
1313
44
1414
11
1515
44
1616
22
1717
11
44
11
1212
11
15

ELECTRICAL
BATTERY IN
VEHICLE
BATTERY
12V
WIRING INLIFT
VEHICLEHARNESS
2 BUTTONHAND CONTROL
20A
SELF RESETTING
CIRCUIT BREAKER
ARM ASSEMBLY
A
B
BLACK WIRE
RED WIRE
BLUE WIRE
RED WIRE
BLACK WIRE
WHITE WIRE
BLACK WIRE
RED WIRE
RED WIRE
BLACK WIRE
RED WIRE
BLACK WIRE
16

SERVICE NOTES
Service Description:
Service Date:
Service Performed By:
Service Description:
Service Date:
Service Performed By:
Service Description:
Service Date:
Service Performed By:
Service Description:
Service Date:
Service Performed By:
17

SERVICE NOTES
Service Description:
Service Date:
Service Performed By:
Service Description:
Service Date:
Service Performed By:
Service Description:
Service Date:
Service Performed By:
Service Description:
Service Date:
Service Performed By:
18

THANK YOU FOR MAKING HARMAR AMERICA’S LEADER IN LIFTS AND RAMPS
P/N: 999-3B05-AA Rev B
