HealTech Electronics GIpro DS Series User manual

GPDS-T01_Manual_en.pdf [rev. 002] - 1 -
http://www.gi-pro.net
GIpro DS-series
Installation and Operation Manual
Model GPDS-T01
For use with the following TRIUMPH motorcycles:
Daytona 650 (2005), Rocket III (2004-2010), Speed Triple 1050 (2005-2010),
Sprint ST 1050 (2005-2010), Tiger 1050 (2007-2010), Thunderbird (2010)
Foreword
Congratulations on your purchase of a GIpro-DS gear position indicator.
The GIpro from HealTech Electronics Ltd. is the most advanced gear position
indicator on the market today.
This product will fit all Triumph fuel injected (FI) motorcycles with Keihin ECU.
Unlike other gear indicators available for your bike, this product connects to the
diagnostic connector. It makes the installation very simple. The unit reads data
from the ECU, offering fasterandmorereliablereadings than competitive
products.
The display is auto learning, there are no buttons and no “programming wire”.
Known limitation:Triumph motorcycles are not equipped with Gear Position
Sensor, therefore determining the gear in use is only possible when the engine is
running and the clutch is released.

- 2 -
Installation
Find the 16-pole diagnostic connector. It is in a black dust boot, usually near the
ECU box. It is an “open” connector, there are no other plugs attached to it.
Daytona 650 (2005): under seat near battery
Rocket III (2004-2009): under seat
Speed Triple 1050 (2005-2009): under seat near battery
Sprint ST 1050 (2005-2009): front right of the fairing, in the locker, next to
the fuse box and toolset
Tiger 1050 (2007-2009): under seat
Connect the GIpro plug, andusethelongcabletiesuppliedtosecuretheplugs
together.
SplicetheGIproredwiretoa+12Vpowerlead,whichisswitchedononlywhen
the engine stop switch is in RUN position (you will find such wire in the extension
plug for the optional alarm, hotwireofthelicense plate light, or at the fusebox).
Use the Red quick connector supplied.
Route the cable to the mounting location.
Peel off the green plastic from the back of the unit, and mount the display.
Secure the cable with the cable ties supplied.
Setup
You need to setup this module after installation. When ignition is turned on, the
display counts backwards (6 to 1) indicating that the memory is clear.
-Raise the rear wheel off the ground by using a stand, and start the
engine in Neutral. (If you do not have a stand, you may setup the unit while
riding. Find a long, straight road with light traffic.)
-The display will blink “1”.
Select first gear, release the clutch, and keep the RPM above idle speed.
The display is blinking faster while the unit is learning the gear.
-When the display shows “2”, select second gear.
Repeat this process until all gears are thought (5 or 6).
In top gear, wait until “o” (over) is indicated and the display stops
blinking.
The unit is programmed and should indicate the gears correctly.
Now, when ignition is turned on, the display counts forward (1 to 6) indicating
that it is fully functional.

- 3 –
Reset
If some gears are not indicated correctly, reset the unit and setup it up again.
If you have a SpeedoHealer (or otherspeedometercalibrator)andyouchange
the calibration factor, probably you have to reset the GIpro and set it up again.
Cutoffthepowerof the unit 6timesinarow
, while the GIpro display is
counting up and shows 3, 4 or 5.
You can power on/off the display by flipping the engine RUN switch on/off.
On the next power up, the display will count backwards (6 to 1).
The memory is clear now and you can perform the Setup procedure.
Troubleshooting
Disconnect the GIpro connector and check whether the pins are broken, bent or
pushed out of position. Reconnect the plug,andmakesurethatallconnections
are good and the connector is fully seated.
MakesuretheGIproplugisnotlooseinthediagnosticconnector.Usethelong
cable tie supplied to secure the plugs together.
If youcannotexecutetheSetupprocedure,yourbatterymightbeoldorweak.
Charge the battery or connect another battery using a jumper cable.
Ifsomegearsarenotindicatedproperlywhentheengineisrunningandclutchis
released, reset the unit and setup again.
If the problem persists, your clutch might be slipping.
Warranty
The unit is completely sealed and epoxy encapsulated, which gives extreme
protection for the internal parts from shocks, vibrations and water.
To ensure trouble-freeoperationfromthestart,allunitshavebeenextensively
tested prior to shipment.
Ourdealersareofferinga30-day money-back guarantee on HealTech products,
thusyouwillgetyourmoneybackiftheproductdoesnotfulfillyour
expectations. (All parts must be returned in original condition for full refund.)
Furthermore the product is covered by our 2-year replacement warranty from
the date of purchase.
Web: www.gi-pro.net
Email: [e-mail]
