HealTech Electronics iLogger easy Instructions and recipes

iLogger easy
Supplementary Manual
Kawasaki Ninja 400 ABS 2018- (iLE-1-KIT)
www.healtech-electronics.com 1/5
Secure the bike on a stand.
Remove the seats.
Remove the black covers from the fuel
tank.
Remove the fuel tank and the airbox.
Connect the iLE-H-PWR Red wire to the
Red wire of the ignition coil
connector.(Switched +12V)
Connect the iLE-H-PWR White wire to
the Black/Orange wire of the ignition coil
connector.(RPM)

iLogger easy
Supplementary Manual
Kawasaki Ninja 400 ABS 2018- (iLE-1-KIT)
www.healtech-electronics.com 2/5
Connect the iLE Black wire terminal to
the battery negative terminal.
Connect the Red, Black and White wires
to the green terminal block as show on
the photo.
Connect the green terminal block to the
iLE modul.

iLogger easy
Supplementary Manual
Kawasaki Ninja 400 ABS 2018- (iLE-1-KIT)
www.healtech-electronics.com 3/5
Splice the iLE Blue VSS wire to the Green
wire of the ABS connector.
Optional:
Connect the iLE Black/Green wire to the
Blue/Red wire of the Front Brake switch.
(Green, 6-pole connector under the airbox)
Optional:
Connect the iLE Pink wire to the
Yellow/White wire of the Throttle
position sensor.
(Grey, 3-pole connector under the airbox)

iLogger easy
Supplementary Manual
Kawasaki Ninja 400 ABS 2018- (iLE-1-KIT)
www.healtech-electronics.com 4/5
Optional:
Connect the iLE White wire to the Orange
wire of the Engine coolant temperature
sensor.
(Black, 2-pole connector under the airbox)
Optional:
Connect the iLE Green wire to the Light
Green wire of the Gear position sensor.
(Black, 3-pole connector under the fuel
tank)
Mount the GPS receiver.
Connect the GPS connector to the iLE
module.

iLogger easy
Supplementary Manual
Kawasaki Ninja 400 ABS 2018- (iLE-1-KIT)
www.healtech-electronics.com 5/5
Typical position for the iLE module.
Secure the unit properly.
