HealTech Electronics iLogger easy Instructions and recipes

iLogger easy
Supplementary Manual
Yamaha YZF-R125 2008-2013 (iLE-1-KIT)
www.healtech-electronics.com 1/5
Secure the bike on a stand.
Remove the seats.
Remove the black plastic covers below
the fuel tank.
Remove the fuel tank cover and remove
the fuel tank.
Connect the iLE-H-PWR Red wire to the
Red/White wire of the ignition coil
connector.(Switched +12V)
Connect the iLE-H-PWR White wire to
the Orange wire of the ignition coil
connector.(RPM)

iLogger easy
Supplementary Manual
Yamaha YZF-R125 2008-2013 (iLE-1-KIT)
www.healtech-electronics.com 2/5
Connect the iLE Black wire terminal to
the battery negative terminal.
Connect the Red, Black and White wires
to the green terminal block as show on
the photo.
If the iLE is used together with the iQSE
quickshifter, plug the iLE-H-iQSE
connectors in-line with the 4-pole iQSE
connectors, then connect the Red, Black
and White wires to the green terminal
block as show on the photo.

iLogger easy
Supplementary Manual
Yamaha YZF-R125 2008-2013 (iLE-1-KIT)
www.healtech-electronics.com 3/5
Connect the green terminal block to the
iLE modul.
Optional:
Connect the iLE Black/Green wire to the
Green/Yellow wire of the Front Brake
switch.
(Transparent, 2-pole connector under the
fuel tank)
Optional:
Connect the iLE Black/White wire to the
Gren/Red wire of the Engine coolant
temperature sensor.

iLogger easy
Supplementary Manual
Yamaha YZF-R125 2008-2013 (iLE-1-KIT)
www.healtech-electronics.com 4/5
Optional:
Connect the iLE Pink wire to the Yellow
wire of the Throttle position sensor.
(Black, 5-pole connector under the fuel
tank)
Optional:
Connect the iLE White wire to the
Brown/White wire of the Intake air
temperature sensor.
(Black, 5-pole connector under the fuel
tank)
Optional:
Connect the iLE Green wire to the
Green/Yellow wire of the Rear Brake
switch.
(Transparent, 2-pole connector under the
fuel tank)

iLogger easy
Supplementary Manual
Yamaha YZF-R125 2008-2013 (iLE-1-KIT)
www.healtech-electronics.com 5/5
Mount the GPS receiver.
Connect the GPS connector to the iLE
module.
Typical position for the iLE module.
Secure the unit properly.
