HealTech Electronics iLE-1-KIT User manual

iLogger easy
Supplementary Manual
Yamaha MT-07 ABS 2014- (iLE-1-KIT)
www.healtech-electronics.com 1/4
Secure the bike on a stand.
Remove the seats.
Remove the plastic covers from the fuel
tank.
Remove the fuel tank.
If the iLE is used together with the iQSE
quickshifter, plug the iLE-H-iQSE
connectors in-line with the 4-pole iQSE
connectors, then connect the Red, Black
and White wires to the green terminal
block as show on the photo.
(Without the iQSE connect the iLE-H-PWR
Red and White wire to the ignition coil
connectors and the iLE Black wire terminal
to the battery negative terminal.)

iLogger easy
Supplementary Manual
Yamaha MT-07 ABS 2014- (iLE-1-KIT)
www.healtech-electronics.com 2/4
Connect the green terminal block to the
iLE modul.
Splice the iLE Blue VSS wire to the
White/Yellow wire of the ABS connector.
Optional:
Connect the iLE Black/Green wire to the
Black/Blue wire of the Front Brake
switch behind the headlight.

iLogger easy
Supplementary Manual
Yamaha MT-07 ABS 2014- (iLE-1-KIT)
www.healtech-electronics.com 3/4
Optional:
Connect the iLE Black/White wire to
White wire of the Throttle position
sensor at the ECU connector.
Optional:
Connect the iLE Pink wire to the
Green/White wire of the Engine coolant
temperature sensor at the ECU
connector.
Optional:
Connect the iLE White wire to the Sky
Blue wire of the Neutral indicator light.
(Black, 14-pole multi connector under the
fuel tank)

iLogger easy
Supplementary Manual
Yamaha MT-07 ABS 2014- (iLE-1-KIT)
www.healtech-electronics.com 4/4
Optional:
Connect the iLE Green wire to the
Green/Red wire of the Oil pressure
switch over the right footpeg.
Mount the GPS receiver on the tail
fairing.
Connect the GPS connector to the iLE
module.
Typical position for the iLE module.
Secure the unit properly.
