HealTech Electronics iLogger easy iLE-1-KIT Instructions and recipes

iLogger easy
Supplementary Manual
Kawasaki ZX-6R ABS TC 2019- (iLE-1-KIT)
www.healtech-electronics.com 1/5
Secure the bike on a stand.
Remove the seat.
Remove the covers from the fuel tank.
Remove the fuel tank and the airbox.
Connect the iLE-H-PWR Red wire to the
Red wire of the ignition coil
connector.(Switched +12V)
Connect the iLE-H-PWR White wire to
the Black/Green wire of the ignition coil
connector.(RPM)

iLogger easy
Supplementary Manual
Kawasaki ZX-6R ABS TC 2019- (iLE-1-KIT)
www.healtech-electronics.com 2/5
Connect the iLE Black wire terminal to
the battery negative terminal.
Connect the Red, Black and White wires
to the green terminal block as show on
the photo.
Connect the green terminal block to the
iLE modul.

iLogger easy
Supplementary Manual
Kawasaki ZX-6R ABS TC 2019- (iLE-1-KIT)
www.healtech-electronics.com 3/5
Splice the iLE Blue VSS wire to the
Red/Yellow wire of the ABS connector.
Optional:
Connect the iLE Black/Green wire to the
Green/Yellow wire of the Front Brake
switch.
(Gray, 6-pole connector under the airbox)
Optional:
Connect the iLE Black/White wire to the
Yellow/White wire of the Throttle
position sensor.
(Black, 3-pole connector under the airbox)

iLogger easy
Supplementary Manual
Kawasaki ZX-6R ABS TC 2019- (iLE-1-KIT)
www.healtech-electronics.com 4/5
Optional:
Connect the iLE Pink wire to the
Green/Red wire of the Gear position
sensor.
(Black, 6-pole connector under the fuel
tank)
Optional:
Connect the iLE White wire to the
White/Green wire of the Engine coolant
temperature sensor.
(Black, 2-pole connector under the airbox)
Optional:
Connect the iLE Green wire to the
Blue/Red wire of the Oil pressure switch.
(Black, 4-pole connector under the airbox)

iLogger easy
Supplementary Manual
Kawasaki ZX-6R ABS TC 2019- (iLE-1-KIT)
www.healtech-electronics.com 5/5
Mount the GPS receiver on the tail frame.
Connect the GPS connector to the iLE
module.
Typical position for the iLE module.
Secure the unit properly.
