HealTech Electronics iLogger easy Instructions and recipes

iLogger easy
Supplementary Manual
KTM SMR 450 2018- (iLE-1-KIT)
www.healtech-electronics.com 1/4
Secure the bike on a stand.
Remove the seat.
Remove the side fairings.
Remove the fuel tank.
Connect the iLE-H-PWR Red wire to the
Orange wire of the fuel injector
connector.(Switched +12V)
Connect the iLE-H-PWR White wire to
the Black/White wire of the fuel injector
connector.(RPM)

iLogger easy
Supplementary Manual
KTM SMR 450 2018- (iLE-1-KIT)
www.healtech-electronics.com 2/4
Connect the iLE Black wire terminal to
the battery negative terminal.
Connect the Red, Black and White wires
to the green terminal block as show on
the photo.
Connect the green terminal block to the
iLE modul.

iLogger easy
Supplementary Manual
KTM SMR 450 2018- (iLE-1-KIT)
www.healtech-electronics.com 3/4
Optional:
Connect the iLE White wire to the
Black/Yellow wire of the Engine coolant
temperature sensor.
Optional:
Connect the iLE Pink wire to the Orange
/Yellow wire of the Throttle position
sensor.
Mount the GPS receiver.
Connect the GPS connector to the iLE
module.

iLogger easy
Supplementary Manual
KTM SMR 450 2018- (iLE-1-KIT)
www.healtech-electronics.com 4/4
Typical position for the iLE module.
Secure the unit properly.
