Heinner HSJ-600RD User manual
www.heinner.com 150W, 50-60Hz, 220-240V
1
Thank you for purchasing this product!
I. INTRODUCTION
Before using the appliance, please read carefully this instruction manual and keep it for future
reference.
This instruction manual is designed to provide you with all required instructions related to the
installation, use and maintenance of the appliance.
In order to operate the unit correctly and safety, please read this instruction manual carefully before
installation and usage.
II. CONTENT OF YOUR PACKAGE
Slow juicer
User manual
Warranty card
Cleaning brush
www.heinner.com 150W, 50-60Hz, 220-240V
2
III. SAFETY PRECAUTIONS
IV. PRODUCT DESCRIPTION
When using electrical appliances,basic safety precautions should always be followed
Including the following:
1. Read all instructions
2. To protect against risk of electrical shock do not put motor or base of unit in water
or other liquid.
3. Close supervision is necessary when any appliance is used by or near children
4. Unplug from outlet when not in use,before putting on or taking off parts ,and before
cleaning.
5. Avoid contacting moving parts
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions ,or is dropped or damaged in any manner,Return appliance to the
nearest authorized service facility for examination,repair or electrical or mechanical
adjustment
7. The use of attachments not recommended or sold by the manufacturer may cause
fire,electric shock or injury
8. Do not use outdoors
9. Do not let cord hang over edge of table or counter
10. Always make sure juicer cover is clamped securely in place before motor is turned
on.Do not unfasten clamps while juicer is in operation
11. Be sure to turn switch to OFF position after each use of your juicer.Make sure the
motor stops completely before disassembling.
12. Do not put your fingers or other objects into the juicer opening while it is in
operation.If food become lodged in opening,use food pusher or another piece of
fruit or vegetable to push it down.When this method is not possible tum the motor
off and disassemble juicer to remove the remaining food.
13. Do not use the appliance if the rotation sieve is damaged.
14. When a separable pulp container is provided,Do not operate without the pulp
container in place.
The following information is critical to prevent any injuries or damage to the appliance.
Please read the following instructions and use the appliance properly.
Warning: This sign warns risk of death or severe injuries
Caution: This sign warns risk of injuries or product damage
Prohibited Do not disassemble Must take action
www.heinner.com 150W, 50-60Hz, 220-240V
3
Safety warning
Unplug the power cord when not in use
Do not keep or operate the appliance near Infants or toddlers.
*It may injure them
Use a dry towel to clean he power cord.
*It may cause an explosion or electric shock
Do not put the juicer parts in the dishwasher or extremely hot water.
*The pars may war faster
Do not use the appliance on an uneven surface.
*It may cause a malfunction if the appliance tips over
Do not use any hazardous chemicals to the appliance
*It may change the color of the appliance or could result in fire.
Do not repair ,disassemble the base, or customize the appliance may not operate properly
causing fire ,electric shock, or injury.
www.heinner.com 150W, 50-60Hz, 220-240V
4
IV. FEATURES
Do not spray water flammable sprays near the appliance.
It may cause an explosion or electrical shock.
Low speed Extraction method
The juicer extracts instead of grinding retaining all the nutrients and enzymes for a
healthier natural juice
Multi-propose for food preparation and cooking
Extract a variety of ingredients including vegetable, nuts, beans, and fruits making the food
preparation convenient, quick and easy.
Two-step safety start system
All parts must be assembled properly and the lid must be securely locked to star the juicer.
This assure safe operation
Handle for easy handing
Handle makes it easier to use and move.
Powerful motor-no overheating
The powerful and efficient low speed motor processes high fiber fruits and vegetables
effortlessly without overheating.
Quiet Operation
The motor operates quietly, extracting juice quickly with a higher yield.
Convenient rinsing
Simply pour water into the juicer between each recipe to rinse without disassembly during
and extended juicing session of up to 30 minutes.
www.heinner.com 150W, 50-60Hz, 220-240V
7
VI. ASSEMBLING
-Two-step Safety Device - the base and the juicing bowl unit must be assembled properly
before turning the switch ON.
-Power Switch-
1. Place the juicing screw into the center of strainer, and place the set into the rotation
wiper.
*Turn and push in the juicing screw until it clicks into place
www.heinner.com 150W, 50-60Hz, 220-240V
8
2. Align the white doton the strainer with the red doton the juicing bowl and push
down the strainer until it click into place.
CAUTION
Check that the compression silicone is assembled properly in the unit. The juice may leak if
the compression silicone is not assembled properly
3. Assemble the entire top set onto the base ensuring the arrow symbol the drum lid is
aligned with the arrow symbol on the base.
4. Align the red dots and place the drum lid on the juicing bowl.
www.heinner.com 150W, 50-60Hz, 220-240V
9
5. Turn The drum lid clockwise ensuring the double linemark II and red dot are aligned.
TIP
If the juicing screw is assembled incorrectly, the lid will not close property, ensure the
juicing screw is fitted securely inside the juicing bowl.(turn and push in the juicing screw
until it clicks into place)
6. Turn the top set clockwise ensuring the arrow symbol is aligned with the arrow symbol
7. Place the provided juice cup and pulp cup into position.
www.heinner.com 150W, 50-60Hz, 220-240V
10
VII. USING INSTRUCTIONS
1. Ensure the power switch is OFF position before plugging the power cord into a wall
outlet.
CAUTION
Do not operate the juice without inputting any food for more than 30 seconds
(It may cause a malfunction)
place juice cup and pulp cup into position to prevent any spill or to minimize clean
up
During the operation ,the juicer may produce a squeaking noise,It will disappear
after inserting ingredients into the juicer
2. Press the power switch to operate
*forward: pulls down the ingredients to extract
*Reverse: pushes up the ingredients to unjam
CAUTION
Do not operate with wet hands, (It may cause an explosion or electric shock)
3. Wash and prepare your selection of fruits And vegetables
*cut to 4-5 inches long and 1 in wide stringy vegetables like celery should be chopped fine
*For the best result, insert one piece of ingredients at a time when extracting different
types of ingredients.
Wait until the juicer finishes extracting one type before inserting another one.
www.heinner.com 150W, 50-60Hz, 220-240V
11
CAUTION
Use the push only when needed.
Do not push down food using spoons, spatulas, fingers, or any other utensils.
4. Turn Off the juicer after ensuring the extraction process is complete
*The drum lid may not open easily if there is a lot of remaining pup in the juicer-see in the
instruction on “how to disassemble” on page 12 for details.
If the juicer stops during operation....
Press the REVERSE switch for a few seconds to push up the ingredients that are stuck
between the juicing screw and the strainer. Press the FORWARD switch to continue
(Repeat the process if necessary)
*REVERSE switch: Pushes the ingredients back up. (REVERSE switch only works while
holding down the switch).
CAUTION
Let the juicer stop completely before using the REVERSE switch.(It may cause the juicer to
malfunction if the juicer is not completely stopped before changing operation direction.)
While operation the juicer on REVERSE switch, lightly hold the hopper with one hand while
pressing the RESERS switch.(The Drum lid may come loose while operation in REVERSE
without holding the hopper.)
If the juicer still does not work, disassemble and clean the parts before operation the juicer
again.
www.heinner.com 150W, 50-60Hz, 220-240V
12
HOW TO DISASSEMBLE
1. Turn the drum lid counter clockwise to open.
CAUTION
If the drum lid does not open easily, put the juicer in FORWARD operation and pour some
water to get the remaining pulp out.
Cycle the juicer between REVER and FORWARD operation to loosen pulps stuck between
the juicing screw and the strainer, repeat if needed.
2. Turn the Juicing bowl counter clockwise and lift the juicing bowl off the base.
3. Remove the juicing screw, strainer and rotation wiper unit form the juicing bowl.
4. Disassemble the juicing screw strainer and rotation wiper.
www.heinner.com 150W, 50-60Hz, 220-240V
13
VIII. CLEANING AND MAINTENANACE
1. Ensure the power switch is in OFF position and unplug the power cord from the wall
outlet.
*Ensure all the pulp is cleaned out of the juicer.
2. Disassemble following the above instruction.
3. Immediately after each use, wash the disassembled parts under running water.
*Use the provided brush with a mild soap to clean the holes of the strainer thoroughly.
4. Clean the base with soft damp towel and dry.
TIPS
*clean the juicer after each use to make the cleaning more manageable and to achieve the
best extracting results
*if the top set does not disassemble easily, wash it under running water.
*Ensure all the metal parts are cleaned thoroughly and completely dried before storing.
www.heinner.com 150W, 50-60Hz, 220-240V
14
THE SILICONE PARTS
The silicone parts can be removed and cleaned separately, Dry thoroughly after cleaning
and assemble the silicone parts following the instructions below.
*Juice may leak if the silicone parts are not assembled correctly.
<Silicone Brush>
Gently Pull out the silicone brush from the rotation wiper, after cleaning, with the tail of the
silicone brush pointing down, insert into the slot in the order as shown in the illustration
<Compression silicone>
Unplug before cleaning, after cleaning, plug the compression silicone back in until it is fitted
securely.
<Silicone Ring>
Remove the silicone ring from the juicing bowl, after cleaning, push in the silicone ring until
it is fitted securely.
*Position the silicone ring as shown in the illustration.
www.heinner.com 150W, 50-60Hz, 220-240V
15
Problem
Possible Reasons & Solution
Motor is stuck or
has stopped
.check that the cord is plugged in properly
.check all parts are assembled correctly
.The juicer may stop if the ingredients are fed into the hopper too quickly
. Turn the switch to off position and press down REVERSE switch to pull the
Ingredients down.(repeat if needed)
.Turn the switch to off position and unplug the power cord from the wall outlet. Let
the juicer rest to cool off from overheating
.when using the ingredients with hard seeds, pit before extraction, Seeds may damage
the strainer if not pitted from the ingredients
Juice Yield is low
.Every ingredient yields different amounts of juice.
Soak the ingredients in water before extracting if the ingredients are dry or no fresh
.when extracting ingredients like carrots or beets, extract with a combination of other
fruit and vegetables with more water content to increase the juice yield.
Cut ingredients to 4-5 inches long and 1 in wide for optimal extraction.
.Check that the compression silicone is assembled properly in the unit.
When extracting seeded fruits like tomatoes ,the strainer may get clogged with the
excessive amount of small seeds, Pour water through the hopper to unclog before
IX. EXTRACTING TIPS
Carefully read before extracting
For the best result, insert on piece of ingredients at a time. When extracting different types
of ingredients, wait until the juicer finished extracting one type before inserting another one
When extracting high fiber ingredients like celery and parsley, cut finely in to 1/2 in
segments for optimal extraction.
When extracting ingredients like carrots or beets, extract with a combination of other fruits
and vegetables with more water content to increase the juice yield.
④If the ingredients are not fresh ,the juice yield will be lower due to the decreased water
content in the ingredients ,soak the ingredients in water before extracting to obtain the best
yield.
⑤Some ingredients are not appropriate for juicing, like bananas
⑥During the operation, the juicer may occasionally squeak when juicing ingredients like
carrots or fruits with hard skins, this is normal.
⑦When extracting, juice may spray out of the hopper especially with ingredients like grapes
and cherry tomatoes.
⑧Fruits with pits or hard seeds like peaches, plums, or cherries must be pitted before
extraction .Fruits with hard skins should be peeled before extraction.
X. TROUBLESHOOTING
www.heinner.com 150W, 50-60Hz, 220-240V
16
continuing extraction
Juicing bowl shakes
in the middle of
operation
.It is normal for the juicing bowl to shake a little bit during operation.
Seems like juicing
screw is grinds
.The juicing screw and e strainer are closely aligned with small tolerances.
Do not operate without inputting any ingredients for more than 30 seconds
Juicer is noisy
.The rotation wiper may make a squeaking noise while wiping the juicing bowl. After
inserting ingredients the noise should disappear.
.Turn the switch to OFF position and unplug the power cord from the wall outlet.
Check the parts are assembled properly
.check that the juicer is on a level surface.
.Check that the ingredients are cut to appropriate size.
I see a separation in
the juice extracted
.there may be a separation in the juice due to the ingredients’ density after extraction.
This is different from oxidation that is caused by juicing with a traditional high speed
juicer
The juice leaks out
of top set
.The juice may leak if the compression silicone is not assembled properly.
Disassemble and ensure the compression silicone is assembled properly.
I see discoloration of
the plastic parts
.After use, clean the juicer immediately to prevent discoloration.
.Beta carotene (found in carrots and spinach) pigment may discolor the plastic parts
of the juicer. Rub the parts with a little bit of cooking oil then clean with a mild soup.
.The silicone parts can be removed and cleaned separately
Power
150W
Voltage
220-240V, 50/60Hz
Noise level
≤72 dB
Speed
80 RPM
XI. TECHNICAL FICHE
www.heinner.com 150W, 50-60Hz, 220-240V
17
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working electrical equipment’s to
an appropriate waste disposal center.
HEINNER is a registered trademark of Network One Distribution SRL. Other brands and product
names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from NETWORK
ONE DISTRIBUTION.
Copyright © 2013 Network One Distibution. All rights reserved.
www.heinner.com, http://www.nod.ro
http://www.heinner.com, http://www.nod.ro
This product is in conformity with norms and standards of European Community
Importer: Network One Distribution
Marcel Iancu Street, 3-5, Bucharest, Romania
Tel: +40 21 211 18 56, www.heinner.com , www.nod.ro
www.heinner.com 150W, 50-60Hz, 220-240V
19
Vă mulțumim pentru alegerea acestui produs!
I. INTRODUCERE
Înainte de a utiliza acest aparat, citiți cu atenție manualul de instrucțiuni și păstrați-l pentru
consultări ulterioare.
Acest manual este conceput pentru a vă oferi toate instrucţiunile necesare referitoare la instalarea,
utilizarea şi întreţinerea aparatului.
Pentru utilizarea corectă şi în siguranţă a aparatului, vă rugam să citiţi cu atenţie acest manual de
instrucţiuni înainte de instalare şi utilizare.
II. CONȚINUTUL PACHETULUI DUMNEAVOASTRĂ
Storcător cu ax melcat
Manual de utilizare
Certificat de garanție
Perie de curățare
This manual suits for next models
1
Table of contents
Languages:
Other Heinner Juicer manuals
Heinner
Heinner C300SS User manual
Heinner
Heinner HSJ-200WH User manual
Heinner
Heinner C160SS User manual
Heinner
Heinner HSJ-200X User manual
Heinner
Heinner VitaPlus 400 User manual
Heinner
Heinner HSJ-600GR User manual
Heinner
Heinner HSJ-200WH User manual
Heinner
Heinner HSJ-200X User manual
Heinner
Heinner C250X User manual
Heinner
Heinner C850S User manual
