Henny Penny KFC Velocity Open Series User manual

FM06-070C
SERVICE
MANUAL
OXE-100
KKFFCC VVeelloocciittyy
SSeerriieess™™
OOppeenn

Contents
i
Table of Contents
Safety and Compliance............................................................................................... vii
Chapter 1 Annual Inspections ..........................................................................................1
1.1 Inspect Castors and Frame.....................................................................................1
1.2 Inspect Counterweight Cables.................................................................................2
1.3 Inspect and Lubricate the Carriage Wheels ..............................................................3
1.4 Oil Migration ..........................................................................................................4
1.5 Inspect Fry Pot for Leaking .....................................................................................5
1.6 Temperature and Level Probe Inspection .................................................................6
1.7 Inspect the Power Cable.........................................................................................8
1.7.1 Electrical Requirements....................................................................................8
1.7.2 International Requirements...............................................................................9
1.8 High Limit and Module Inspection ............................................................................9
1.9 Measuring AMP Draw...........................................................................................10
1.10 Drain Pan Component Inspection ........................................................................ 11
1.11 ATO Reservoir Inspection and pump test..............................................................12
1.12 Testing the Drain Valve .......................................................................................14
1.12.1 Service Procedure Guidance ........................................................................15
1.13 Bulk Dispose Test...............................................................................................16
1.14 Heating Element Spreader Bars Tightening and Inspection ...................................17
1.15 Oil Return Diverters and Pressure Outlet Inspection..............................................18
1.16 Inspect for Plumbing Leaks in the Filtration System...............................................19
1.17 Inspect Cam Slide Fillers ....................................................................................21
1.18 Replacement Maintenance Parts.........................................................................22
1.18.1 Ordering Parts .............................................................................................22
1.18.2 Parts List .....................................................................................................22
Chapter 2 Programming ................................................................................................23
2.1 Program Menu.....................................................................................................23
2.2 Tech Mode Menu .................................................................................................23
Chapter 3 Troubleshooting ............................................................................................29
3.1 Troubleshooting Guide .........................................................................................29
3.2 Error Codes.........................................................................................................29
Chapter 4 Software Updates..........................................................................................37
4.1 Software Updates ................................................................................................37
4.1.1 Control Board Updates ...................................................................................37
4.1.1.1 USB Port Overview.....................................................................................37
4.1.1.2 SanDisk USB Flash Drive ...........................................................................37
4.1.1.3 Version Updates.........................................................................................38
4.1.1.3.1 Access the Extranet .............................................................................38
4.1.1.3.2 Locate and Download the Latest Version of Software .............................. 38
4.1.1.4 Loading the Software..................................................................................39
4.2 Download a Report ..............................................................................................39
Chapter 5 Repair and Replacement Procedures..............................................................41
5.1 Maintenance Hints ...............................................................................................41
5.2 Control Board Replacement..................................................................................41

Contents
ii
5.3 Power Switch Replacement ..................................................................................43
5.4 USB Port Replacement.........................................................................................43
5.5 Nylatron Vertical Strip Replacement Procedure .....................................................44
5.5.1 Estimated Resource and Time ........................................................................44
5.5.2 Required Tools...............................................................................................45
5.5.3 Kit Parts ........................................................................................................45
5.5.4 Technician Training ........................................................................................46
5.5.5 Remove the Counterweights and Secure Carriage Assembly ............................46
5.5.6 Remove the Tilt Stop......................................................................................47
5.5.7 Remove the Retaining Rod.............................................................................47
5.5.8 Remove the Front Shroud...............................................................................48
5.5.9 Clean the Nylatron Filler Strip Channels...........................................................48
5.5.10 Install the New Nylatron Filler Strip ................................................................48
5.5.11 Reconnect the Retaining Rod........................................................................49
5.5.12 Install the Tilt Stop........................................................................................49
5.5.13 Install the Cover Panels................................................................................49
5.5.14 Test the Nylatron Strips.................................................................................50
5.5.15 Install the Rack Carrier .................................................................................50
5.6 High Limit Thermocouples Replacement................................................................51
5.6.1 Troubleshooting.............................................................................................51
5.6.2 Replacement .................................................................................................51
5.7 High Limit Module Replacement............................................................................53
5.8 Primary Contactor Replacement............................................................................54
5.9 Heat Contactor Replacement ................................................................................54
5.10 AIF Multi-Tab Transformer Replacement ..............................................................55
5.11 Control Transformer Replacement .......................................................................56
5.12 Drain Valve and Actuator Replacement ................................................................ 57
5.12.1 Prepare the Fryer.........................................................................................57
5.12.2 Remove the Drain Valve Extension................................................................57
5.12.3 Remove the Actuator and Drain Valve............................................................58
5.12.4 Install the Drain Valve and Actuator ...............................................................58
5.12.5 Install the Drain Valve Extension ...................................................................58
5.12.6 Install the Drain Valve Actuator......................................................................58
5.12.7 Test the Drain Valve and Actuator Operation ..................................................59
5.13 Filter Pump Motor Replacement ..........................................................................59
5.14 Filter Pump Motor Seal Replacement...................................................................61
5.15 Filter Pump Motor Roller Replacement.................................................................62
5.16 Flex Tube Replacement......................................................................................63
5.17 Lid Cable Replacement ......................................................................................63
5.18 Label Replacement ............................................................................................65
Chapter 6 Zigbee Radio ................................................................................................67
6.1 Overview.............................................................................................................67
6.1.1 Online Projection System (OPS) and Quality and Production Management
(QPM).....................................................................................................67
6.1.1.1 What is OPS/QPM......................................................................................67
6.1.1.2 Data Tracking.............................................................................................67
6.1.2 Communication Architecture ...........................................................................67
6.1.2.1 Digi ZigBee Radio ......................................................................................67
6.1.2.1.1 Digi Radio............................................................................................68
6.1.2.1.2 ZigBee Protocol ...................................................................................68
6.1.2.2 Mesh Network............................................................................................68
6.1.2.2.1 Practical Application .............................................................................68

Contents
iii
6.2 Installation...........................................................................................................69
6.2.1 Install the Hardware .......................................................................................69
6.2.2 Configure the OPS/QPM Settings ...................................................................73
6.2.2.1 Overview ...................................................................................................73
6.2.2.2 Enable OPS/QPM ......................................................................................73
6.2.2.3 Verify Communication.................................................................................76
6.2.3 Cook ID Code................................................................................................79
6.2.3.1 Verifying the Cook ID Code .........................................................................79
6.2.4 ZigBee Identify Response...............................................................................81
6.2.4.1 Identify Overview........................................................................................81
6.2.4.2 Configuring the Identify Response ...............................................................81
6.3 Troubleshooting ...................................................................................................81
6.3.1 Overview.......................................................................................................81
6.3.2 Digi ZigBee Radio Basics ...............................................................................82
6.3.2.1 Network Connectivity..................................................................................82
6.3.2.2 Joining a Network.......................................................................................82
6.3.3 Data Communication......................................................................................82
6.3.3.1 Verify Power ..............................................................................................83
6.3.3.2 Communication Cables...............................................................................83
6.3.3.2.1 Check the Wires...................................................................................83
6.3.3.2.2 Check Data Communication..................................................................83
6.3.3.2.3 Join or Re-Join the Network ..................................................................84
6.3.4 ZigBee Radio Info Display ..............................................................................84
6.3.4.1 Access the Display .....................................................................................84
6.3.4.2 JOIN Screen ..............................................................................................84
6.3.4.3 CHANNEL Screen......................................................................................85
6.3.4.4 PAN ID Screen...........................................................................................85
6.3.4.5 RADIO SHORT ID Screen ..........................................................................86
6.3.4.6 Reset / Unjoin Command ............................................................................86
6.3.4.7 Modbus Packet Statistics ............................................................................87
6.3.4.8 Modbus Character RX/TX Statistics ............................................................. 88
Chapter 7 Replaceable Parts .........................................................................................91
7.1 Parts ...................................................................................................................91
7.1.1 Introduction ...................................................................................................91
7.1.2 Genuine Parts ...............................................................................................91
7.1.3 When Ordering Parts......................................................................................91
7.1.4 Prices ...........................................................................................................91
7.1.5 Delivery.........................................................................................................91
7.1.6 Warranty .......................................................................................................91
7.1.7 Recommended Spare Parts For Distributors ....................................................91
7.1.8 Lasered Acrylic Labels .................................................................................103
Chapter 8 Wiring and Plumbing Diagrams..................................................................... 109
8.1 208-240V 3PH 3+G 24V Controls........................................................................ 109
8.2 480V 3PH 3+G 24V Controls .............................................................................. 110
8.3 380-415V 3PH 3+G 24V Controls........................................................................ 111
8.4 Oil Line Connections for Bulk Disposal................................................................. 112
8.5 Oil Line Connections for Non-Bulk Disposal ......................................................... 113
Chapter 9 Annual Inspection Checklist Form ................................................................. 115
9.1 Required Tools................................................................................................... 118
9.2 Required Parts................................................................................................... 118

Contents
iv
List of Tables
Table 1-1 Replacement Maintenance Parts .......................................................................22
Table 2-1 Tech Mode Menu Function.................................................................................23
Table 3-1 Troubleshooting Guide ......................................................................................29
Table 3-2 Error Codes......................................................................................................30
Table 5-1 Required Tools .................................................................................................45
Table 5-2 Required Tools .................................................................................................45
Table 5-3 Required Tools .................................................................................................45
Table 5-4 Kit Parts ...........................................................................................................46
Table 7-1 Flex Lines.......................................................................................................101
Table 7-2 Flex Line ........................................................................................................103
Table 9-1 Annual (12 month) Inspection Checklist ............................................................ 115
List of Figures
Figure 5-1 Pump Seal Kit Placement.................................................................................61
Figure 5-2 Pump Rollers ..................................................................................................62
Figure 6-1 Connecting Wires to Terminal Block..................................................................69
Figure 6-2 Sliding Radio Module on to Studs .....................................................................70
Figure 6-3 Attaching Connector to Radio ........................................................................... 71
Figure 6-4 Securing Radio to Control ................................................................................71
Figure 6-5 Connecting 9-Pin Connector ............................................................................72
Figure 6-6 Gather Wires in Wire Tie ..................................................................................72
Figure 6-7 OP Decal Location...........................................................................................73
Figure 6-8 Menu & Info Button Locations...........................................................................74
Figure 6-9 Second Set of Main Menu Options ....................................................................74
Figure 6-10 Programming Menus .....................................................................................75
Figure 6-11 SP-4 OPS/QPM Enabled................................................................................75
Figure 6-12 SP-4 OPS/QPM Enabled Yes Display .............................................................76
Figure 6-13 Join Status Display ........................................................................................76
Figure 6-14 Channel Status Display..................................................................................77
Figure 6-15 Pan ID Display ..............................................................................................78
Figure 6-16 Radio Short ID Display...................................................................................78
Figure 6-17 Reset/Unjoin Command Display .....................................................................79
Figure 6-18 Number Buttons ............................................................................................80
Figure 6-19 Display .........................................................................................................80
Figure 6-20 Unique Product Number Display .....................................................................80
Figure 6-21 ZigBee ID Display..........................................................................................81
Figure 6-22 Screen 1 .......................................................................................................85
Figure 6-23 Screen 2 .......................................................................................................85
Figure 6-24 Screen 3 .......................................................................................................86
Figure 6-25 Screen 4 .......................................................................................................86
Figure 6-26 Screen 5 .......................................................................................................87

Contents
v
Figure 6-27 Screen 6 .......................................................................................................88
Figure 6-28 Screen 7 .......................................................................................................88
Figure 7-1 Components ...................................................................................................92
Figure 7-2 Drain Pan Assembly ........................................................................................93
Figure 7-3 Heating Elements ............................................................................................95
Figure 7-4 Thermocouple, Heat Contactor & Control Transformer .......................................97
Figure 7-5 Left Side Vat ...................................................................................................98
Figure 7-6 Bottom Of Fryer.............................................................................................100
Figure 7-7 Front Top View ..............................................................................................102
Figure 7-8 Pump and Valve ............................................................................................ 103

Contents
vi

Preface
vii
SSaaffeettyy aanndd CCoommpplliiaannccee
Henny Penny fryers have many safety features incorporated. However, the only way
to ensure safe operation is to fully understand the proper installation, operation, and
maintenance procedures. The instructions in this manual have been prepared to aid
you in learning the proper procedures. Where information is of particular importance
or is safety related, the words DANGER, WARNING, CAUTION, or NOTICE are used.
Their usage is described as follows:
DDAANNGGEERR!! indicates hazardous situation which, if not
avoided, will result in death or serious injury.
DDAANNGGEERR!!
WWAARRNNIINNGG!! indicates hazardous situation which, if not
avoided, could result in death or serious injury.
WWAARRNNIINNGG!!
CCAAUUTTIIOONN!! indicates hazardous situation which, if not
avoided, could result in moderate or minor injury.
CCAAUUTTIIOONN!!
NOTICE
NOTICE is used for information considered important
regarding property damage.

Preface
viii
These are the original version controlled Henny Penny instructions for Velocity Open
Electric (OXE) model 100 (OXE 100).
This manual is available on the Henny Penny Public website (www.hennypenny.com).
Read these instructions completely prior to installation and operation of this appliance
to ensure compliance to all required installation, operation and safety standards. Read
and obey all safety messages to avoid damage to the appliance and personal injury.
•BBOOIILLOOVVEERR RRIISSKK!! TThhiiss ffrryyeerr mmuusstt bbee iinnssttaalllleedd aanndd
uusseedd iinn aa wwaayy tthhaatt wwaatteerr ddooeess nnoott ccoonnttaacctt tthhee ooiill
wwhhiicchh ccaann ccaauussee ssppllaasshhiinngg aanndd bbooiilliinngg oovveerr ooff ooiill
aanndd sstteeaamm lleeaaddiinngg ttoo ppeerrssoonnaall iinnjjuurryy;; eexxcclluuddeess
nnoorrmmaall pprroodduucctt mmooiissttuurree..
•BBUURRNN RRIISSKK!! DDoo nnoott mmoovvee tthhee ffrryyeerr oorr ffiilltteerr ddrraaiinn
ppaann wwhhiillee ccoonnttaaiinniinngg hhoott ooiill.. PPeerrssoonnaall iinnjjuurryy oorr
sseerriioouuss bbuurrnnss ccaann rreessuulltt ffrroomm ssppllaasshhiinngg hhoott ooiill..
This appliance is intended for commercial use in kitchens of restaurants, bakeries,
hospitals, etc. but not for the continuous mass production of food such as in a factory
setting. During use the units airborne A-weighted emission sound pressure is below
70 db(A). All repairs must be performed by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
Always use strain relief. The provided power cord must be installed with a strain relief
in a way that if the strain relief fails, wires L1, L2, L3 and N must draw taunt and fail
first. If the supplied power cord or an existing one becomes damaged, do not use it;
rather, replace it with a known good power cord. The powercord must be replaced by
the manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
Proper daily, weekly, monthly, quarterly and yearly maintenance must be performed
on this appliance to ensure safe and continuous operation. This appliance must never
be cleaned with a water jet or steam cleaning tool. Cleaning brushes are shipped with
the appliance and proper cleaning instructions are included in this manual.
Proper maintenance also increases the usable life of the appliance and oil, which
reduces lifetime operating costs. Additionally, old oil increases the possibility of surge
boiling and fire due to the reduced flash point of the oil. The oil temperature must
never exceed 450° F (230°C).
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a

Preface
ix
person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
This appliance is not intended to be operated by means of an external timer or a
separate remote control system.

Preface
x

Annual Inspections
1
CChhaapptteerr 11 AAnnnnuuaall
IInnssppeeccttiioonnss
A certified technician should inspect the entire fryer annually (once every 12 months).
Use the Chapter 9
Annual Inspection Checklist Form , page 115 below to ensure all
required maintenance procedures are completed.
11..11 IInnssppeecctt CCaassttoorrss aanndd FFrraammee
AA ccrraacckkeedd ffrraammee ccrreeaatteess aa ttiippppiinngg rriisskk.. IIff ccrraacckkeedd ffrraammee iiss
ffoouunndd,, iimmmmeeddiiaattee aatttteennttiioonn iiss nneeeeddeedd ttoo rreeppaaiirr tthhee ffrraammee
bbyy hhaavviinngg iitt pprrooffeessssiioonnaallllyy rreeppaaiirreedd bbyy aa wweellddeerr,, oorr hhaavviinngg
tthhee ffrryyeerr rreeppllaacceedd..
Ensure the fryer sits level, casters are mechanically sound and able to hold the weight
of the fryer, and that the tube steel frame is not cracked or bent. If the fryer is not level,
inspect the condition of the floor. Repair the floor as necessary, have any missing or
cracked tiles replaced. If there is a slope due to a floor drain, the fryer may need to be
repositioned so the caster is on level flooring. Casters on the fryer ccaannnnoott be adjusted
up or down. Inspect casters and the tube steel frame by removing the side panels and
using a flashlight to look for cracks and/or bent framing. Replaced any damaged or
broken casters by doing the following:

Annual Inspections
2
11.. Raise the lid to lower the fryer’s
center of gravity.
22.. Discard oil from the fry pot.
33.. Remove the racks from the carrier.
44.. Position two floor jacks under the
frame (A), near the casters (B), on
the same side of the fryer.
55.. Block the casters on the opposite
side of the fryer with small wheel
chocks.
66.. Raise the fryer approximately 2.5”
(63mm).
77.. Use an adjustable wrench to remove
the caster (B).
88.. Use an adjustable wrench to install
the new caster. Ensure a snug fit but
do not overtighten.
99.. Continue to the next inspection or
reinstall components as applicable.
11..22 IInnssppeecctt CCoouunntteerrwweeiigghhtt CCaabblleess
This unit uses two cables in the counter-weight mechanism that helps in the raising
and lowering of the lid. Cables should be visually inspected yearly, either as part of a
planned maintenance program or during a routine service call. Cables more than 10
years old should be replaced regardless of inspection results. Call for service to have
both cables replaced.
:
IIff tthhee lliidd bbeeccoommeess ddiiffffiiccuulltt ttoo ooppeerraattee,, ssttoopp uussiinngg tthhee ffrryyeerr
aanndd ccaallll ffoorr sseerrvviiccee bbeeccaauussee tthhee ccaabblleess nneeeedd ttoo bbee
rreeppllaacceedd..

Annual Inspections
3
WWoorrnn CCoouunntteerrwweeiigghhtt CCaabbllee UUssaabbllee CCoouunntteerrwweeiigghhtt CCaabbllee
11.. Use a 3/8” socket, to remove the 6
keps nuts around exterior of rear
cover and remove the back shroud.
22.. Inspect the counter-weight cables. If
cables have cracks in the jacket,
missing pieces in the jacket, or other
obvious signs of wear, replace both
cables.
33.. Continue to the next inspection or
reinstall components as applicable.
11..33 IInnssppeecctt aanndd LLuubbrriiccaattee tthhee CCaarrrriiaaggee WWhheeeellss
The carriage wheels inside the back of the fryer should be lubricated at least once a
year to allow for easy lid movement.

Annual Inspections
4
11.. If necessary, use a 3/8” socket to
remove the 6 keps nuts around
exterior of rear cover and remove
the back shroud.
22.. Inspect the carriage wheels and
ensure proper operation.
33.. Use spindle lube (PN 12124) and
place a small amount on all four (4)
wheels, both top and bottom, left
and right rollers.
44.. Continue to the next inspection or
reinstall components as applicable.
11..44 OOiill MMiiggrraattiioonn
TToo aavvooiidd sseerriioouuss ppeerrssoonnaall iinnjjuurryy::
•UUnnpplluugg ffrryyeerr bbeeffoorree rreemmoovviinngg tthhee lleefftt ssiiddee ppaanneell ttoo
pprreevveenntt eelleeccttrriiccaall sshhoocckk..
•OOnnllyy ppeerrffoorrmm tthhiiss pprroocceedduurree wwhheenn tthhee ffrryyeerr iiss ccooooll oorr
sseevveerree bbuurrnnss mmaayy rreessuulltt..
Inspect behind the left side panel for excessive oil seeping through either the high limit
pot fittings, the temperature probe pot fitting, level probe fitting, pressure transducer
fitting, or the heating element fittings. If oil migration or seepage is found, remove and
clean the fittings, applying pipe thread sealant and then re-install the fitting. If
excessive oil migration is discovered, the insulation on the side of the fryer must be
replaced.
1. If necessary, remove the left side panel.
2. Inspect for oil seepage at the probe
fittings, high limit fittings, pressure
transducer fitting and heating
element fittings.
3. Complete any necessary repairs.
4. Continue to the next inspection or
reinstall components as applicable.

Annual Inspections
5
11..55 IInnssppeecctt FFrryy PPoott ffoorr LLeeaakkiinngg
OOiill aaccccuummuullaattiioonn oonn tthhee eexxtteerriioorr ooff tthhee ffrryyppoott ccrreeaatteess aa ffiirree
rriisskk.. TTaakkee tthhee ffrryyeerr oouutt ooff sseerrvviiccee uunnttiill tthhee ooiill aaccccuummuullaattiioonn
iiss rreemmoovveedd,, oorr tthhee ffrryyeerr iiss rreeppllaacceedd..
Excessive oil accumulation on the exterior of the fry pot may indicate the fryer is
having a hardware issue or the operator is not following recommended operating
procedures. With both side panels and the back shroud removed, clean off the oil
accumulation, and then use a flashlight to inspect the fry pot, fry pot welds, fry pot
plumbing and fittings, and the probe and element fittings.
If the fry pot is suspected of leaking, do the following:
• If the oil accumulation is toward the upper half of the fry pot, take the fryer out of
service immediately, and replace the fryer.
• If the oil accumulation is toward the lower half of the fry pot, and it is not evident if
the oil accumulation is due to the store using a drain pan without a cover or other
operator error, do the following:
If necessary, scrape and clean off the existing oil from the fry pot and welds, and then
have the store bread and cook 4 head or greater of bone in chicken. During cooking,
monitor the suspected area for leaking:
• If oil is pushed out of the fry pot or welded areas while the fryer is under pressure,
take the fryer out of service and replace the fryer.

Annual Inspections
6
• If the pot is not leaking, take the fryer out of service until the oil accumulation is
removed and the store operates the fryer with a drain pan cover or the operator
error is corrected.
11..66 TTeemmppeerraattuurree aanndd LLeevveell PPrroobbee IInnssppeeccttiioonn
TToo aavvooiidd sseerriioouuss ppeerrssoonnaall iinnjjuurryy.. UUnnpplluugg ffrryyeerr bbeeffoorree
rreemmoovviinngg tthhee lleefftt ssiiddee ppaanneell ttoo pprreevveenntt eelleeccttrriiccaall sshhoocckk..
OOnnllyy ppeerrffoorrmm tthhiiss pprroocceedduurree wwhheenn tthhee ffrryyeerr iiss ccooooll oorr
sseevveerree bbuurrnnss mmaayy rreessuulltt..
Ensure the temperature and level probes are undamaged and working within
specification by doing the following:

Annual Inspections
7
1. Press and hold the menu button until
*MAIN* appears on the display.
2. Press the number one product button to
enter the filter menu.
3. Press the right arrow until 4. DRAIN ->
displays.
4. Select 44.. DDRRAAIINN -->>, and drain all the oil
in the fry pot into the drain pan.
5. On the inside of the vat, clean off any
build up or debris from the
temperature probe and level probe.
If a probe is bent or damaged,
replace the probe.
6. Check that each probe is inserted into
the fry pot 3/8” into the oil. If a probe
either extends too far into the oil or is
too shallow, do the following:
a) Remove the left side panel.
b) Adjust the probe to the correct depth by
loosening the ½” compression nut
on the temperature probe.
c) Slide the probe to the correct depth
then tighten the compression nut.
7. Select 55.. FFIILLLL <<--. Allow oil to fully fill
the vat. Once filled, cancel the filter
pump motor and exit out of the filter
menu by pressing and holding the
menu button.
8. Continue to the next inspection or
reinstall components as applicable.

Annual Inspections
8
11..77 IInnssppeecctt tthhee PPoowweerr CCaabbllee
FFiirree RRiisskk aanndd EElleeccttrriiccaall SShhoocckk PPoossssiibbllee.. IIff aannyy ooff tthheessee
ccoonnddiittiioonnss aarree ffoouunndd,, ttaakkee tthhee ffrryyeerr oouutt ooff sseerrvviiccee uunnttiill aa
nneeww ppoowweerr ccoorrdd oorr pplluugg ccaann bbee iinnssttaalllleedd.. AAllwwaayyss aaddhheerree ttoo
llooccaall eelleeccttrriiccaall ccooddee uuppoonn iinnssttaallllaattiioonn ooff tthhee ppoowweerr ccoorrdd..
TThhiiss ffrryyeerr mmuusstt bbee aaddeeqquuaatteellyy aanndd ssaaffeellyy ggrroouunnddeedd
((eeaarrtthheedd)) oorr eelleeccttrriiccaall sshhoocckk ccoouulldd rreessuulltt.. RReeffeerr ttoo llooccaall
eelleeccttrriiccaall ccooddeess ffoorr ccoorrrreecctt ggrroouunnddiinngg ((eeaarrtthhiinngg))
pprroocceedduurreess oorr iinn aabbsseennccee ooff llooccaall ccooddeess,, wwiitthh TThhee NNaattiioonnaall
EElleeccttrriiccaall CCooddee,, AANNSSII//NNFFPPAA NNoo.. 7700--((tthhee ccuurrrreenntt eeddiittiioonn))..
IInn CCaannaaddaa,, aallll eelleeccttrriiccaall ccoonnnneeccttiioonnss aarree ttoo bbee mmaaddee iinn
aaccccoorrddaannccee wwiitthh CCSSAA CC2222..11,, CCaannaaddiiaann EElleeccttrriiccaall CCooddee
PPaarrtt 11,, aanndd//oorr llooccaall ccooddeess..
TToo aavvooiidd eelleeccttrriiccaall sshhoocckk,, tthhiiss aapppplliiaannccee mmuusstt bbee eeqquuiippppeedd
wwiitthh aann eexxtteerrnnaall cciirrccuuiitt bbrreeaakkeerr wwhhiicchh wwiillll ddiissccoonnnneecctt aallll
uunnggrroouunnddeedd ((uunneeaarrtthheedd)) ccoonndduuccttoorrss.. TThhee mmaaiinn ppoowweerr
sswwiittcchh oonn tthhiiss aapppplliiaannccee ddooeess nnoott ddiissccoonnnneecctt aallll lliinnee
ccoonndduuccttoorrss..
FFOORR EEQQUUIIPPMMEENNTT WWIITTHH CCEE MMAARRKK OONNLLYY!! TToo pprreevveenntt
eelleeccttrriicc sshhoocckk hhaazzaarrdd tthhiiss aapppplliiaannccee mmuusstt bbee bboonnddeedd ttoo
ootthheerr aapppplliiaanncceess oorr ttoouucchhaabbllee mmeettaall ssuurrffaacceess iinn cclloossee
pprrooxxiimmiittyy ttoo tthhiiss aapppplliiaannccee wwiitthh aann eeqquuiippootteennttiiaall bboonnddiinngg
ccoonndduuccttoorr.. TThhiiss aapppplliiaannccee iiss eeqquuiippppeedd wwiitthh aann
eeqquuiippootteennttiiaall lluugg ffoorr tthhiiss ppuurrppoossee.. TThhee eeqquuiippootteennttiiaall lluugg iiss
mmaarrkkeedd wwiitthh tthhee ffoolllloowwiinngg ssyymmbbooll..
NOTICE
:
The supply power cords shall be oil-resistant, sheathed flexible
cable, no lighter than ordinary polychloroprene or other
equivalent synthetic elastomer-sheathed cord. It is
recommended that a 30 mA rated protective device such as a
residual current circuit breaker (RCCB), or ground fault circuit
interrupter (GFCI), be used on the fryer circuit.
Replace any power cord with torn or damaged sheathing, any exposed wire, or any
fraying. Replace the plug if there are any signs of damage, loose wires showing, or
burnt connections.
11..77..11 EElleeccttrriiccaall RReeqquuiirreemmeennttss
The electric fryer requires 208 or 240 volt, three phase, 50/60 Hertz service. The
power cord may be already attached to the fryer, or provided at installation. Check the
data plate mounted just above the lid, on the left side of the back shroud, to determine
the correct power supply. A terminal block is mounted inside the fryer for the cable
