Herman Miller FT360 Installation instructions

Parts Included
Tools Required
HermanMiller
Canvas Channel Surface Attached
Laminate Screen (FT360, FT361, FG360,
FG361) Installation and Disassembly for
Recycling Instructions
How to assemble your Surface
Attached Laminate Screen
Screen
Cable Trough
RH Screen Bracket
Pan Head Machine Screw Torx Sheet Metal Screw
LH Screen Bracket
Center Screen Bracket
Safety Glasses Phillips Bit Torx Bit Power Driver
Assembly Instructions:
Step 
1.1 Attach LH & RH Screen Brackets and Center screen bracket to
Screen with pan head screws.
1.2 If screen is to be attached to end of table where a wall attached leg is
installed, switch middle bracket with end screen brackets. This will give
clearence between bracket and leg.
1.3 If Cable Trough is to be installed onto screen, place screen flat on
clean surface. Position brackets onto screen. Place Cable Trough over
brackets. Install pan head screws.
Cable Trough
Pan Head
Machine Screw
Center Screen
Bracket
LH Screen
Bracket
RH Screen
Bracket
Assembly Instructions1HermanMiller 1BLY01 rev A

Assembly Instructions2HermanMiller 1BLY01 rev A
Disassembly for Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling
codes. Use these codes to identify material type for recycling. Non
marked components should be treated as mixed plastic. Ferrous metals
can be identied using a small magnet for recycling. Non-ferrous metals
should be separated and recycled separately.
To disassemble product, reverse steps 6 through 1.
For more information about our products and services please visit us at
hermanmiller.com or call [phone].
©2017 Herman Miller, Inc., Zeeland, Michigan Printed in U.S.A. Part No. BLY  B
1.4 Position screen assembly up to table at desired location with 1” gap
between screen and edge of table.
1.5 Mark screw holes. Remove screen assembly. Drill pilot holes. Make
sure not to drill through work surface.
1.6 Return screen to table. Secure in place with sheet metal
screws.
Torx Sheet
Metal Screw
1” Gap
Screen
Work Surface
Screen
Work Surface
