Herman Miller Exclave Meeting Table Installation instructions

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 1
YExclave™Meeting Table Installation and Disassembly for
Recycling Instructions
Parts Included:
Work Surface EXTD.T042
Work Surface EXTD.T072
Work Surface EXTT.T060
Work Surface EXTT.T084 Work Surface EXTD.T092 Work Surface EXTD.T114
Foot Assembly(2)
AA
A
AAA
G
Spider
Column
B
F
Draw Rod
C
M5 x 16 Socket
Button Flange Head
Screw(4)
4 Way Base Plate
EXTD.T042 Retainer Cup
M8 x 18 Hex Socket
Head Screw(4)
M12 Hex Nut
Flat Washer
DE
HJ
K
M
L
Power Pass-
Through Kit
Biscuit (6)
Grommet
P
N
Cable Clamp
AK M4 x 12 Pan Hd
Machine Screw
AL

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 2
#8-15 x 5/8 Pan
Hd Tapping Screw
#10-12 X 3/4 Pan
Hd Tapping Screw
M10 x 70 Hex
Socket HD Screw
V
AF
Z
Joint Fastener (6) Stiffener
Stiffener End Cap
Spanner Footrest
Spanner Mounting
Block
Footrest Connector
RS
T
UWX
YM4 x 25 Pan Hd
Tapping Screw
AA 3 Way Base Plate
EXTT.060, EXTD.072,
EXTD.096
AB
4 Way Base Plate
EXTD.T084, T114
AC Retainer Cup Ganging Plate
Column Column Column
1BD219 or
1BDBT3 1BCZGT or
1BCZDM 1BDGW0
AD AE
AG AH AJ

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 3
1. Put Arm Filler piece (D) into spider arm with pan head screw (AA).
2. Insert Draw Rod Assembly (C) into Spider (B).
3. Attach spider to Work Surface (A) with 4 socket button flange head
screws (E).
4. Insert power pass through part (D) into slot on column (F).
5. Place column (F) over tie rod and into spider as shown. Make sure
notches in column engage over ribs in spider.
EA
EXTD.T042
C
B
B
D
AA
F
F
D
#2 Phillips Bit Small Allen Wrench Level
Tools Needed:
Power Driver Torque Wrench M12 Socket8mm Metric Hex Bit 3mm Metric Hex Bit6mm Metric Hex Bit

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 4
6. Position Leg Assemblies (G) onto column.
7. Capture legs with Retainer Cup (J).
8. Position 4-Way Base Plate (H) onto assembly. Make sure notch in Base
Plate aligns with notch in Retainer Cup.
9. Secure in place with 4 Hex Socket Screws (K).
G
GG
G
M
AK
L
AL
N
K
10. Attach flat washer (M) hex nut (L) to end of Draw Rod. Torque to 45 ft. lbs.
11. Press grommet (N) into opening in work surface.
12. Use Cable Clamp (AK) when routing cabling
through base. Secure clamp to base plate with pan
head machine screw (AL).
H
J
Notch

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 5
EXTT.T060, EXTD.T072, EXTT.T084, EXTD.T114
1. Place Work Surface (A) face down on clean padded surface.
For EXTT.T084 and EXTD.T114:
2. Insert biscuits (P) into grooves in mating edge.
3. Fit surface halves together.
4. Insert Joint Fasteners (R) into cutouts in surface halves.
5. Tighten fasteners with small allen wrench.
P
R
A
Allen Wrench

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 6
7. Position stiffener (S) across surface
halves.
8. Assemble Stiffener End Covers (T)
at end of stiffeners.
9. Secure stiffener and end covers in
place with pan head screws (V).
Note: See next page for stiffener
locations.
6. Secure surfaces together with ganging plates (AE) and pan head tapping
screws (AF)
V
AF
AE
VS
S
S
S
T
T
AE
AE
AE AE

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 7
EXTD.T096
EXTD.T072
EXTD.T114
EXTT.T060
EXTT.T084

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 8
11. Put Arm Filler (D) into spider arm with pan head screw (AA). Note: Power
pass through part not needed or included with tables other than EXTD.T042.
12. Place spiders on work surface, rotating until arm with arm filler align with slot
in work surface.
Slot
Arm Filler
D
AA
10. Insert Draw Rod Assembly (C) into spider (B),
engaging plate notches with ribs on spider.
CB

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 9
Note: Front refers to one column end of table. Back refers to two column end.
13. Place 2 of the same columns (AG) and 1 different (AH) column over Tie Rod
and into spiders as shown. Make sure notches in column engage over ribs in
spider. See chart below for column types.
Notch
Rib
EXTD.
AG AG
AH
PART NUMBER DESCRIPTION
1BCZHN COLUMN-STANDING-6' & 8' TABLE FRONT
1BCZHM COLUMN-SEATED-6' & 8' TABLE FRONT
1BCZHL COLUMN-STANDING-6' TABLE BACK
1BCZHK COLUMN-SEATED-6' TABLE BACK
1BCZHF COLUMN-STANDING-5' TABLE
1BCZHD COLUMN-SEATED-5' TABLE
1BDLP8 COLUMN-STANDING-8' TABLE BACK
1BDLP6 COLUMN-SEATED-8' TABLE BACK
PART NUMBER DESCRIPTION
1BD219 COLUMN-STANDING-9.5' TABLE BACK
1BDBT3 COLUMN-SEATED-9.5' TABLE BACK
1BDGW0 COLUMN-STANDING-7' TABLE
1BDGVZ COLUMN-SEATED-7' TABLE
1BCZGV COLUMN-SEATED-9.5' TABLE FRONT
1BCZGT COLUMN-STANDING-9.5' TABLE FRONT
1BCZDM COLUMN-SEATED-4' TABLE
1BCZDL COLUMN-STANDING-4' TABLE

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 10
15. Place footrest (W) onto work surface.
16. Assemble each foot (G) to
footrest with footrest connector (Y),
flatwasher (M) and hex socket
head screw (Z). See product foot
configuration on next page.
AJ
AJ
AJ
GG
G
14. Place 3 equal columns (AJ) over Tie Rods and into spiders as shown. Make
sure notches in column engage over ribs in spider. Use notch that makes the
thinest tab face outward.
Thin Tab
Thin Tab
Thin Tab
EXTT.
Z
M
Y

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 11
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
Foot
EXTD.114
EXTD.096
EXTD.072
EXTT.084
EXTT.060
Foot

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 12
17. Lift footrest. Engage feet into columns.
(EXTT.T060, EXTD.T072, EXT.T096)
18. Insert Spanner Mounting Blocks (X) into
ends of spanners (U).
19. Secure blocks to spanner with 1 hex
socket head screw (K).
20. Position spanners onto
columns. Make sure
blocks fully engage onto
columns.
K
U
K
X
X

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 13
24. Install 4 socket head screws (K) through 4 way base plates or 3 socket head
screws (K) through 3 way base plates.
21. Place Retainer Cup (AD) onto ends of legs and blocks.
22. Place 4-way or 3-way Base Plate (AC) or (AB) over cup. Make sure part
number on 4-way plate faces inside of table.
23. Attach hex nut (L) to end of draw rod. Torque to 45 ft. lbs.
AB
AD
EXTT.T060, EXTD.T072, EXTD.T096
EXTT.T084, EXTD.T114 L
K
L
K
AC
AD
Part Number

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 14
26. Go back now and tighten all screws and nuts.
27. Turn table right side up. Level table by adjusting glides on feet.
25. Secure legs to top with 4 socket button flange screws (E).
Glide
E
28. Use Cable Clamp (AK) when
routing cabling under work
surface. Secure clamp to bottom
of work surface with pan head
tapping screw (V).
AK V

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 15
29. To install Umbilical Riser (Y1430.WFCG or Y1430.WFSG) to table (if
available):
- Determine proper location for riser.
- Using Mounting Bracket as template, mark screw hole locations Drill pilot
holes.
- Remove screw from riser.
- Position riser to bracket. Re-install screw.
- Attach mounting bracket to work surface with 2 supplied screws.
- Run wires and cabling through riser. Secure to work surface with cable
clamps as described in step 28.
Supplied
Screw
Umbilical Riser
Screw
Mark and Drill
Pilot Holes
Mounting
Bracket

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 16
Cut out size and location for retrofitting Electrical Distibutor into tops.
Note: Herman Miller not responsible for any damages done to tops during this
process.
9.5’ (EXTD.114)Table
Note: 9.5’, 8’ & 6’ tables
have this size cut out
8’ (EXTD.096) Table
7’ (EXTD.084) Table
6’ (EXTD.072) Table 5’ (EXTD.060) Table
4’ (EXTD.042) Table
273.05mm
10.75”
316.24mm
12.45”
83.57mm
3.29”
809.17mm
31.86”
914.40mm
36.00”
596.27mm
23.48” 663.14mm
26.11”
415.42mm
16.36”
1197.37mm
47.14”
1984.83mm
78.14”
1117.60mm
44.00”
163.83mm
6.45”
163.83mm
78.14”
83.57mm
3.29”

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 17
316.23mm
12.45”
163.83mm
6.45”
4X R.7.95mm
4X R. .313”
273.05mm
10.75”
163.83mm
6.45”
4X R.7.95mm
4X R. .313”
183.13mm
7.21”
163.83mm
6.45”
4X R.7.95mm
4X R. .313”
Logic Cutout Dimensions
3-Outlet Logic cutout dimensions:
5-Outlet Logic cutout dimensions:
6-Outlet Logic cutout dimensions:

Z
© 2015 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
Part no. 1BF6T1 rev D.
TM Y, L, Exclave are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products. 18
Disassembly for Recycling:
Materials Identification and Segregation:
Where possible, plastic components are marked with ASTM recycling codes.
Use these codes to identify material type for recycling. Non marked components
should be treated as mixed plastic. Ferrous metals can be identified using a
small magnet for recycling. Non-ferrous metals should be separated and recycled
separately.
To disassemble product, reverse the above installation steps.
