Herman Miller Nelson User manual

2.1
Rotate the top surface upward down and place it in a flat surface. Position X-leg to the top in
a way the X-leg are aligned to the screw holes on the top.
2.2
Using power driver tighten the screws.
Step 2
1.1
Position support leg to the straight in a way the screw holes on the X-leg are aligned to
the screw holes on the support leg.
1.2
Using power driver tighten the screw.
1.3
Follow step 1 to install the another X-Leg and support leg.
Step 1
Power Driver
Parts Included
Tools Required
(4) X-Leg Screw (Qty: 2) (5) Philip Head Screw (Qty: 20)
(2) X-Leg (Qty: 2) (3) Support Leg (Qty: 2)
How to assemble
your table.
HermanMiller
NelsonTM X-Leg Table
For more information about our products and services or to see a list of dealers, please visit us at
hermanmiller.com or call [phone].
© 2013 Herman Miller, Inc., Zeeland, Michigan Printed in U.S.A. Part No. 1bbgg9 - A.
® Yis among the registered trademark of Herman Miller, Inc.
™ Nelson is among the trademark of Herman Miller, Inc.
(1) Top
(5) Philip Head Screw
(2)X-Leg
(3)Support Leg
(4)X-Leg Screw
HermanMiller NelsonTM Table Assembly Instructions1
All manuals and user guides at all-guides.com
all-guides.com

HermanMiller NelsonTM Table Assembly Instructions2
3.1
Repeat step 2 to assemble another leg.
4.1
Rotate the table back to its original position.
Step 3 Step 4
