Herman Miller Intent Installation instructions

Z
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b4z6d rev C.
1
YIntent®Interiors Work Surface Screen and Modesty Panel
Installation and Disassembly for Recycling Instructions
Parts Included:
Tools Needed:
Screen
Modesty Panel
Hardware Pack
Hardware Pack
Screen Support
Bracket (2)
Modesty Support
Bracket (2 or 3)
Thread Cutting
Screw (4)
Thread Cutting
Screw (4)
Tapping
Screw (8)
Tapping
Screw (8)
A
A
B
B
C
C
D
D
Power Driver #18 Drill Bit Phillips Bit Tape Rule
Safety Glass

Z
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b4z6d rev C.
2
Screen:
5.62
Edge
Step
Drill Holes
(Both Sides)
1. Determine where Screen is to be installed onto work surface. Note: Center of
Bracket is 5 5/8” from edge of screen.
2. Position one Screen Bracket (B) onto Work Surface.
3. Using Screen Bracket as template, drill four 1/8” pilot holes 1/2” deep.
4. Remove Bracket and install onto Screen (A) using 2 Thread Cutting Screws (C).
Repeat for remaining Screen Bracket (B). See Bracket locations above.
B
B
C
C
A11.74
FT694._24A FT694._18A FT694._18B
11.74
5.74

Z
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b4z6d rev C.
3
5. Position Screen onto Work Surface. Install 4 Tapping Screws (D) using Pilot
Holes previously drilled.
6. Drill Pilot Holes for other Bracket using Bracket as template and ensuring that
step is against edge of Work Surface.
7. Install 4 Tapping Screws (D).
D
D

Z
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b4z6d rev C.
4
8. Install Modesty Brackets (B) onto Modesty Panel (A) using 2 Thread Cutting
Screws (C) per Bracket.
9. Place Modesty Panel onto bottom of Work Surface at desired location.
10. Attach Panel to Surface with 4 Tapping Screws (D) per Bracket.
Modesty Panel:
A
C
B
D

Z
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b4z6d rev C.
5
Disassembly and Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling codes. Use
these codes to identify material type for recycling. Non marked components should
be treated as mixed plastic. Ferrous metals can be identied using a small magnet
for recycling. Non-ferrous metals should be separated and recycled separately.
To disassemble product, reverse steps 10 through 3.
