Herman Miller Fuld Installation instructions

HermanMiller
Fuld Disassembly for Recycling Instructions
How to Disassemble your Fuld chair
Step 2
Step 1
Chair Disassembly
Tools Required
Flat head screwdriver T- Torx head
screwdriver
Hammer Torque Wrench
T- Torx
driver
T- Torx
driver
. Remove bolts from underside of rear legs.
. Remove backrest from remaining chair.
. Remove bolts from LH-Leg insert and RH-leg insert.
. Remove LH-Leg insert and RH-leg insert from Bent Tube.
1HermanMiller Fuld chair Installation Instructions1BWJ6Hrev A

2HermanMiller Fuld chair Installation Instructions1BWJ6Hrev A
Step 3 Step 4
. Remove caster from old caster foot . . Using a non-marring hammer, gently tap rear surface of caster foot until it
comes free from leg tube.
Step 6Step 5
. Use T screwdriver to remove bolts.
. Remove U-clip. Retain for later.
. Use flat head screwdriver to remove Clip Cover Retain for later.

3HermanMiller Fuld chair Installation Instructions1BWJ6Hrev A
Step 8Step 7
. Remove dampener from Seat. Retain for later.. Remove seat from tube.
Step 2
Step 1
Glide Chair Disassembly
. Remove bolts from underside of rear legs.
. Remove backrest from remaining chair.
. Remove bolts from LH-Leg insert and RH-leg insert.
. Remove LH-Leg insert and RH-leg insert from Bent Tube.

4HermanMiller Fuld chair Installation Instructions1BWJ6Hrev A
Step 4
Step 3
. Using a non-marring hammer, gently tap rear surface of Front Glide
Assembly until it comes free from leg tube.
. Pull down on Rear Glide Assembly until free from Backrest.
Step 6Step 5
. Use T screwdriver to remove bolts.
. Remove U-clip. Retain for later.
. Use flat head screwdriver to remove Clip Cover Retain for later.

5HermanMiller Fuld chair Installation Instructions1BWJ6Hrev A
For more information about our products and services please visit us at
hermanmiller.com or call ()  .
© Herman Miller, Inc., Zeeland, Michigan Printed in U.S.A. Part No. BWJH A
Step 8Step 7
. Remove dampener from Seat. Retain for later.. Remove seat from tube.
