Herman Miller Intent Furniture Tackboard Installation instructions

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b57cw rev H.
1
J-Strip
YIntent®Furniture Tackboard Installation and Disassembly
for Recycling Instructions
Parts Included:
Tools Required:
Tackboard
Spacer
Phillips Screw
Driver
1/8” Drill Bit Power Driver
Clip
Velcro adhesive strip
Safety Glass
Note: Cable Management Spacer (FV985) not included. Order separately.

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b57cw rev H.
2
1. Measure 4” down from desired top of tackboard and strike a horizontal chalk line
on the wall.
Note: Cable Management Spacer (FV985) not included with tackboard.
Order separately.
4”
4”4”
3. Attach spacers and clips to wall with customer supplied fasteners. Align center
spacers with existing Velcro on tackboard back.
2. Clip screws should be on this line approximately 4” in from ends and evenly spaced.
Wall Mount:
Cable Management Spacer Installation:

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b57cw rev H.
3
5. Engage J-strip to wall clips and adjust horizontally. Press tackboard at the bottom to
engage velcro adhesive.
J-Strip
Wall
Clip
Tackboard
Spacer
Velcro Adhesive
4. Remove velcro adhesive backer.

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b57cw rev H.
4
Hutch Mount:
6. Measure 5” down for screw location and strike a chalk line.
5”
7. Using 1/8” drill bit, drill pilot holes on the back panel, approximately 1/4” deep, 4”
from each end and evenly spaced between. Take care not to drill through back of
hutch.

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b57cw rev H.
5
8. Attach spacers and clips using customer supplied screws.
Note: Ensure screw length does not protrude through back.
4” 4”
Spacer
Clip

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b57cw rev H.
6
J-Strip
Back Panel
Spacer
Clip
Tackboard
Velcro Adhesive Strip
10. Engage J-strip to wall clips and adjust horizontally. Press tackboard at the bottom
to engage velcro adhesive.
Note: The hutch mount tackboard will have a 1” gap at the top to allow clip engagement.
1”
9. Remove velcro adhesive backer.
11. FV985 cable management spacers not compatible with dual lock only tackboards.
Requires J-strip mounted tackboards.
12. When reinstalling cable management spacers with an existing J-strip mounted
tackboard, order U1B546L Velcro strips.
13. Route cable between spacers and attach tackboard.
14. For 12” high tackboards, cut spacer to length.
15. Install customer supplied fastener through both holes in the spacer.

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Intent are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b57cw rev H.
7
Disassembly and Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling codes. Use
these codes to identify material type for recycling. Non marked components should
be treated as mixed plastic. Ferrous metals can be identied using a small magnet
for recycling. Non-ferrous metals should be separated and recycled separately.
1. Using a straight head screw driver remove J-strip from the tackboard.
To disassemble product, reverse steps 15 through 1 and also do the following:
