Herman Miller Nevi Height Adjustment Table User manual

Parts Included
Full Length (for Tables up to ”)
Independent (for Tables ” or Less)
Tools Required
HermanMiller
Nevi Height Adjustment Table
Installation
How to assemble your Nevi
Height Adjustment Table
Top Support (2)
Top Support (2)
Foot (2)
Foot (2)
Hand Switch
Hand Switch
Control Box
Control Box
M8 x 1.25
12 mm Screw (8)
M8 x 1.25
12 mm Screw (8)
M10 x 1.5
30 mm Screw (4)
M10 x 1.5
30 mm Screw (4)
Power Cord
Power Cord
Safety Information
Important Safety Instructions save these instructions.
DANGER To reduce the risk of electric shock:
Always unplug this furnishing from the electrical outlet before cleaning.
WARNING
To reduce the risk of death, serious injury, or property damage, read
and follow this safety information and the provided instructions when
assembling this product. Do not change or replace components and
accessories provided.
”
”
”
”
KEEP AWAY FROM CHILDREN
This table system is not designed for use in homes or other areas
accessible by small children. For indoor commercial oce use only.
BE CAREFUL WHEN ADJUSTING DESK HEIGHT
Body parts and property can be caught between the moving work surface and
an immobile obstacle (such as shelves, furniture, window sills, or walls). Keep
at least one inch of clearance around desk and make sure nothing is in table’s
path for its entire range of motion.
Before raising or lowering:
• Check surroundings on all sides of desk are clear
• Make sure corded objects will not be pulled o table or cause other
objects to fall
• Make sure desk power cord moves freely as desk moves up and down
Power Driver Phillips Bit Torque Wrench T Torx bit  mm Hex bit
”
Cross Beam
Screw(8)
Column with independent
Beam/Motor (2)
Column with independent
Beam/Motor (2)
Assembly Instructions1HermanMiller 1BNX5K rev E

Assembly Instructions2HermanMiller 1BNX5K rev E
Before proceeding with the table assembly: All electric motors MUST be
initialized before moving the table in the “UP” direction.
Please follow the below instructions for proper initialization:
• All Columns (motors) must be plugged into the Control box.
• Plug the “Up/Down” Hand switch in to the Control box.
• Plug the Control box power cord into a  volt grounded outlet.
• Hold the “Down” button in until the columns bottom out to the lowest
position.
• Please continue to hold until a “clicking” sound is heard and the
columns move “slightly” UP.
• Once this is completed your system is properly initialized and can be
operated without harm to the system.
STOP
Do Not Overload Desk
To prevent table from tipping or collapsing, make sure the desk frame is
not overloaded by the weight of table top and objects on table. Evenly
distribute load; excess loads near edges can reduce stability and lead
to tip over.
• Do not exceed maximum load (including weight of desktop) of
 lb. (Kg) for two-leg conguration.
• Do not exceed edge load of  lb. when positioning monitors or
mounting accessories.
• Do not sit or stand on table
Use Care When Moving Desk
• Clear objects and equipment from table before rolling to reduce
the risk of tipping over.
• Adjust the desk to its lowest height before moving
• To disconnect, turn all controls to the o position, then remove
plug from outlet
• Do not move a loaded desk
• Do not li the desk by the work surface (desktop)
Do Not Open Electrical Components
Keep Table Frame Dry
Do not attempt to service table components. There are no user-
serviceable parts inside the motor control units or table legs. If
your table needs service, contact customer service. Never operate
this furnishing if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged. Return the furnishing to
a service center for examination and repair.
Keep all electrical components away from water and high humidity.
Clean only with a dry or slightly damp cloth. Do not spray cleaning
solutions directly onto table system.
Grounding Instructions
This product is equipped with a cord having an equipment-grounding
conductor and a grounding plug. Use only the cord provided. Make
sure that the product is connected to an outlet having the same
conguration as the plug (as shown in Illustration A) that is properly
installed and grounded in accordance with all local codes and
ordinances.
Do not modify the plug provided with the product - if it will not t the
outlet, have a proper outlet installed by a qualied electrician.
No adapters are to be used with this product. Keep cord away from
heated surfaces.
Grounding Pin Grounded Outlet
Grounded Outlet Box

Assembly Instructions3HermanMiller 1BNX5K rev E
Step : Assemble the Foot to the Column
. Assemble using the M x . x mm length screws ( per
column). When torque wrench is available, tighten fasteners to
maximum of  Nm. ( Ft-Lbs.). If you do not have access to a torque
wrench, then tighten fasteners to snug, plus a ¼ turn. .
Step : Fasten the Table Frame onto the Table Top
. Be sure to use approved screws per the table top supplier.
. Repeat step  and tighten.
Note: Some holes may need to be pre drilled.
Full Length
Independent
Step : Assemble Top Support to the Beam and Column
. Assemble using the M x . x mm length screws
( per column) leave screws loose. When torque wrench is available,
tighten fasteners to maximum of  Nm. ( Ft-Lbs.). If you do not have
access to a torque wrench, then tighten fasteners to snug, plus a ¼
turn. Align top support holes with independent beam assembly. Repeat
as necessary for remaining columns .
Step : Fasten the Cross Beam onto the Table Top
. Secure the Cross Beam with the table top with  screws.
Note: Some holes may need to be pre drilled.

Assembly Instructions4HermanMiller 1BNX5K rev E
Step : Fasten the Control Box and Handswitch to the Table Top
. Make sure the control box and handswitch are fastened in a
location where all the cables will connect without being in tension. Be
sure to use approved screws per the table top supplier.
. Connect the Handswitch (HS) Cable to the Control Box
Step : Connect the Motor Cable to the Control Box
. The motor cable plug-connection has to click into place. If a
control box is used which has more plug-terminals than needed,
you have to connect to M rst. (The extra terminals can be le
open.)
Connections to the control box:
M-M = Connectors for the columns
HS = Connectors for the handset
AC = Connector for the power cord (-pin)
. Connect toe Supplied Powercord (AC) to the Control Box

Assembly Instructions5HermanMiller 1BNX5K rev E
For more information about our products and services please visit us at
hermanmiller.com or call ()  .
© Herman Miller, Inc., Zeeland, Michigan Printed in U.S.A. Part No. BNXK  D
Disassembly for Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM
recycling codes. Use these codes to identify material type for
recycling. Non marked components should be treated as mixed
plastic. Ferrous metals can be identied using a small magnet for
recycling. Non-ferrous metals should be separated and recycled
separately.
To disassemble product, reverse steps.
