Preparation
1. AX Series Wireless Security Control Panel,V1.0.2 or above
2. Wireless output Expander DS-PM-WO2 or DS-PM-WO8
DS-PWA32 How to Add Wireless output Expander and Configure
1. Add by Panel function button.
1) Click the function button of the Hub, enter Adding Detector Mode.
2) Press the registration key once and add the expander according to the voice
prompt.

Title:
DS-PWA32 How to Add Wireless output Expander and
Configure
Version:
v1.0
Date:
05/05/2019
Product:
AX Series Wireless Security Control Panel
Page:
2 of 5
© Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved.
No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: [phone] • Fax: [phone]
E-Mail: [e-mail] •www.hikvision.com
2. Configure Wireless output Expander.
1) Open Hik-connect--- Device, Click Wireless Device

Title:
DS-PWA32 How to Add Wireless output Expander and
Configure
Version:
v1.0
Date:
05/05/2019
Product:
AX Series Wireless Security Control Panel
Page:
3 of 5
© Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved.
No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: [phone] • Fax: [phone]
E-Mail: [e-mail] •www.hikvision.com
2) Select Wireless Outputs Expander---Relay 1, default Manual, you can open or
close by manual.

Title:
DS-PWA32 How to Add Wireless output Expander and
Configure
Version:
v1.0
Date:
05/05/2019
Product:
AX Series Wireless Security Control Panel
Page:
4 of 5
© Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved.
No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: [phone] • Fax: [phone]
E-Mail: [e-mail] •www.hikvision.com
3) Link the relay to Alarm/Away Arming/Disarming/Manual Event, and you can
configure output delay time from 5s~600s.
4) Connect Wire and route cables.
