HIK VISION DS-19S08N-04F/K Series User manual

Video Security Control Panel User Manual
--1--
Video Security Control Panel
User Manual
UD.6L0206D1028A01

Video Security Control Panel User Manual
--2--
User Manual
COPYRIGHT © 2015 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou
Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual
(hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or
wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision
does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.
About this Manual
This Manual is applicable to Video Security Control Panel
The Manual includes instructions for using and managing the product. Pictures, charts, images and all other
information hereinafter are for description and explanation only. The information contained in the Manual is
subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the
company website (http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the properties of Hikvision in various jurisdictions.
Other trademarks and logos mentioned below are the properties of their respective owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE,
SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND HIKVISION MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY
QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL
HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT,
EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN
RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR
OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE
USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL

Video Security Control Panel User Manual
--3--
NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.
0200001050505

Video Security Control Panel User Manual
--4--
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the limits for a digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and comply
therefore with the applicable harmonized European standards listed under the EMC Directive
2004/108/EC, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union. See the product documentation for specific
battery information. The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to
your supplier or to a designated collection point. For more information see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

Video Security Control Panel User Manual
--5--
Safety Instruction
These instructions are intended to ensure that the user can use the product correctly to avoid danger or property
loss.
The precaution measure is divided into ‘Warnings’ and ‘Cautions’:
Warnings: Serious injury or death may be caused if any of these warnings are neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
Warnings Follow these safeguards to prevent serious
injury or death.
Cautions Follow these precautions to prevent potential
injury or material damage.
Warnings:
Please adopt the power adapter which can meet the safety extra low voltage (SELV) standard. The power
consumption cannot be less than the required value.
Do not connect several devices to one power adapter as an adapter overload may cause over-heating and
can be a fire hazard.
When the product is installed on a wall or ceiling, the device should be firmly fixed.
To reduce the risk of fire or electrical shock, do not expose the indoor used product to rain or moisture.
This installation should be made by a qualified service person and should conform to all the local codes.
Please install blackouts equipment into the power supply circuit for convenient supply interruption.
If the product does not work properly, please contact your dealer or the nearest service center. Never
attempt to disassemble the product yourself. (We shall not assume any responsibility for problems caused
by unauthorized repair or maintenance.)
Please do not look directly into the laser light within 6 meters because laser is hazardous to humans.

Video Security Control Panel User Manual
--6--
Cautions:
Make sure the power supply voltage is correct before using the product.
Do not drop the product or subject it to physical shock. Do not install the product on vibratory surface or
places.
Do not expose it to high electromagnetic radiating environment.
Do not aim the lens at the strong light such as sun or incandescent lamp. The strong light can cause fatal
damage to the product.
The sensor may be burned out by a laser beam, so when any laser equipment is being used, make sure that
the surface of the sensor not be exposed to the laser beam.
For working temperature, please refer to the specification manual for details.
To avoid heat accumulation, good ventilation is required for a proper operating environment.
While shipping, the product should be packed in its original packing.
Please use the provided glove when open up the product cover. Do not touch the product cover with fingers
directly, because the acidic sweat of the fingers may erode the surface coating of the product cover.
Please use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use
alkaline detergents.
Improper use or replacement of the battery may result in hazard of explosion. Please use the manufacturer
recommended battery type.

Video Security Control Panel User Manual
--7--
Content
Chapter 1 Introduction ______________________________________________ 11
1.1 Overview ___________________________________________________________11
1.2 Feature ____________________________________________________________11
Chapter 2 Installation and Wiring _____________________________________ 13
2.1 Main Board Overview_________________________________________________13
Main Board Description ________________________________________________________ 15
2.2 Wiring Device _______________________________________________________16
Wiring Detector _______________________________________________________ 162.2.1
Wiring Alarm Output ___________________________________________________ 172.2.2
Wiring Keypad ________________________________________________________ 192.2.3
Wiring Video/Audio Input _______________________________________________ 192.2.4
Wiring Video/Audio Output ______________________________________________ 202.2.5
2.3 System Start-up _____________________________________________________22
Video Security Control Panel Start-up ______________________________________ 222.3.1
Alarm Keypad Start-up__________________________________________________ 222.3.2
Keypad Address _______________________________________________________ 242.3.3
Factory Settings _______________________________________________________ 252.3.4
Activating the Control Panel _____________________________________________ 272.3.5
Chapter 3 Keypad Operation (Local Operation ） _________________________ 32
3.1 Alarm Keypad Settings ________________________________________________32
Installer Password Settings ______________________________________________ 323.1.1
Operator Settings ______________________________________________________ 333.1.2
Zone Parameters Settings _______________________________________________ 343.1.3
Zone Linked Trigger Settings _____________________________________________ 373.1.4
Trigger Event Linkage Settings ____________________________________________ 373.1.5
Trigger Time Settings ___________________________________________________ 393.1.6
Siren Settings _________________________________________________________ 393.1.7
Control Panel Time Settings______________________________________________ 403.1.8
Control Panel IP Settings ________________________________________________ 403.1.9
Local Port Number Settings ______________________________________________ 413.1.10
Sub-net Mask Settings __________________________________________________ 413.1.11

Video Security Control Panel User Manual
--8--
Gateway Settings ______________________________________________________ 423.1.12
Uploading Center IP Settings _____________________________________________ 423.1.13
Uploading Center Port Settings ___________________________________________ 43
3.1.14
Center Protocol and Account Settings ______________________________________ 433.1.15
Printer Parameters Settings ______________________________________________ 443.1.16
Alarm Message Settings_________________________________________________ 453.1.17
Device Information Settings______________________________________________ 453.1.18
Operation Programming Information Settings _______________________________ 463.1.19
Restoring Information of Alarm and Bypass Settings __________________________ 463.1.20
Device Recovering Information Settings ____________________________________ 473.1.21
Siren Linked Event Settings ______________________________________________ 483.1.22
Emergency Alarm Linkage Siren Setting ____________________________________ 493.1.23
Control Panel Tamper-proof Linked Siren Settings ____________________________ 493.1.24
Testing Report Settings _________________________________________________ 503.1.25
Partition Settings ______________________________________________________ 513.1.26
Control Panel System Fault Detection Settings _______________________________ 573.1.27
Partition Fault Display Settings ___________________________________________ 573.1.28
Partition Fault Prompt Sound Settings______________________________________ 583.1.29
DHCP Settings_________________________________________________________ 583.1.30
Delay Zone Time Settings________________________________________________ 593.1.31
Center Group Enabling Settings ___________________________________________ 603.1.32
Center Group Uploading Mode Settings ____________________________________ 603.1.33
Center Group Zone Alarm Report Settings __________________________________ 613.1.34
Center Group Non-zone Alarm Report Settings ______________________________ 623.1.35
White-list Parameters Settings____________________________________________ 633.1.36
Schedule Settings ______________________________________________________ 683.1.37
Wireless User Permission Settings_________________________________________ 763.1.38
Video Live View Settings ________________________________________________ 763.1.39
3.2 Keypad Alarm Operation Code _________________________________________77
Device Initialization ____________________________________________________ 773.2.1
Security control panel Arming and Disarm __________________________________ 773.2.2
Stay Arming __________________________________________________________ 783.2.3
Zone Bypass/Recovery __________________________________________________ 783.2.4
Group Bypass _________________________________________________________ 783.2.5
Group Bypass Recovery _________________________________________________ 783.2.6
Keypad Cancel Alarm ___________________________________________________ 793.2.7
Alarm Output Operation ________________________________________________ 793.2.8

Video Security Control Panel User Manual
--9--
Emergency Alarm ______________________________________________________ 793.2.9
System Status Query ___________________________________________________ 793.2.10
Main Operator Password Changing ________________________________________ 80
3.2.11
Entering Partition System________________________________________________ 803.2.12
Control Panel Programming Operation _____________________________________ 803.2.13
Alarm Center Test______________________________________________________ 813.2.14
Project Mode _________________________________________________________ 813.2.15
Enabling/Disabling Key Tone _____________________________________________ 813.2.16
Connecting Wireless Device and Control Panel_______________________________ 813.2.17
Deleting Connected Wireless Device _______________________________________ 813.2.18
Deleting All Wireless Devices Connected to the Control Panel___________________ 823.2.19
Setting the Schedule ___________________________________________________ 823.2.20
LCD Backlight Control___________________________________________________ 823.2.21
Disabling LCD Backlight _________________________________________________ 823.2.22
Pacing _______________________________________________________________ 823.2.23
Control Panel Soft Recovery______________________________________________ 833.2.24
Current Fault Tone Disabling _____________________________________________ 833.2.25
Test Report Manually Triggering __________________________________________ 833.2.26
Keypad Locking and Unlocking ___________________________________________ 833.2.27
Chapter 4 Accessing by Client Software ________________________________ 84
4.1 Installing the iVMS-4200 ______________________________________________84
4.2 User Registration and Login ____________________________________________88
4.3 Video Security Control Panel Settings ____________________________________89
Adding/Editing/Deleting the Device_______________________________________________ 89
4.4 Remote Settings _____________________________________________________90
System Information Settings _____________________________________________________ 91
Network Settings______________________________________________________________ 97
Alarm Settings _______________________________________________________________ 107
Storage ____________________________________________________________________ 122
Image Settings_______________________________________________________________ 123
Event Settings _______________________________________________________________ 125
Operation __________________________________________________________________ 132
Status______________________________________________________________________ 133
Chapter 5 Trouble Shooting _________________________________________ 135
Appendix1 ： Specifications ___________________________________________ 143

Video Security Control Panel User Manual
--10--
Appendix2 ： CID Report ______________________________________________ 148
Appendix3 ： LED Keypad Prompt Sound _________________________________ 150
Appendix4 ： Conversion Table_________________________________________ 150

Video Security Control Panel User Manual
--11--
Chapter 1 Introduction
1.1 Overview
These series of commercial-grade video control panels implement multi-functions of alarm input/output,
scheduled arming/disarming, video signal processing and so on.
It is mainly applied to the security systems of shopping mall, stores, residence, apartments, communities, etc. It
can be used cooperatively with the video surveillance and access control partition through the software
operation.
1.2 Feature
Signal Input/ Output
8 zones alarm input;
4-ch network / analog camera, support dual-stream;
1-ch audio output, 1-ch two-way audio, 1-ch loudspeaker;
1-ch VGA output;
1-ch local alarm output, 8-ch extension alarm output;
Remote Control
32 remote controls;
SMS alarm data-push and remote arming/disarming function (DS-19S08N-04F/KxGx supports message
alarm data-push function);
Report Transmission

Video Security Control Panel User Manual
--12--
2 transmission modes: network transmission, 3G/4G transmission (DS-19S08N-4F/KxGx supports GPRS
transmission);
2 groups of stand-alone Ethernet alarm centers;
2 groups of stand-alone 3G/4G alarm centers (DS-19S08N-4F/KxGx supports 3G/4G alarm center);
External Equipment
8 external alarm keypads are accessible;
External storage battery for power supply;
Various Applications
Equipped with LED/LCD keypad;
Scheduled arming/disarming function;
Tamper-proof alarm and movement prevention alarm for the control panel and tamper-proof alarm for the
detector;
Support post-view function, the duration of post-view can be configured;
Support rechecking of alarm linked live view and capture. Support video motion detection, video loss
detection function;
PTZ control is available;
1-ch siren (12VDC) output.

Video Security Control Panel User Manual
--13--
Chapter 2 Installation and Wiring
2.1 Main Board Overview
DS-19S08-04F/Kx (Gx)

Video Security Control Panel User Manual
--14--
DS-19S08N-04F/Kx (Gx)

Video Security Control Panel User Manual
--15--
Main Board Description
The main board description is shown as follows.
Take the model of DS-19S08-04F/Kx (Gx) as an example.
This module varies depending on the models of control panel.
NO.
Description
NO.
Description
1
Keypad Board Interface
11
Reset Button Switch
2
SATA HDD Interface
12
Tampering Prevention
3
HDD Power Interface
13
Movement Prevention Switch
4
Alarm Input Interface
14
SIM Card Slot
5
Alarm Output (Alarm Lamp)
15
3G Card Slot
6
PTZ Control Interface
16
Video Input Interface
7
Keypad Connection Interface
17
Audio Input Interface
8
Auxiliary Power Interface
18
VGA Interface
9
Power Adapter
19
USB Interface
10
Lead-acid Battery
20
LAN Interface

Video Security Control Panel User Manual
--16--
2.2 Wiring Device
Wiring Detector2.2.1
The alarm input interfaces of the control panel are show as follows.
Take the model of DS-19S08-04F/Kx (Gx) as an example.
The wiring of sensor is shown as follows.
8.2KΩ
NC
C
Z
G
Peripheral Security DetectorAlarm Host
Normal Closed Detector
8.2KΩ
NO
C
Z
G
Alarm Host
Normal Opened Detector
Peripheral Security Detector

Video Security Control Panel User Manual
--17--
The Tamper-proof wiring is shown below.
2.2KΩ
2.2KΩ
ZONE
GND
DETECTOR
N.C.
N.O.
TAMPER
Wiring Alarm Output2.2.2
Take the model of DS-19S08-04F/Kx (Gx) as an example, the alarm output interfaces of the video security control
panel are show as follows.
The resistance of 2.2KΩor 3.3KΩsupports tamper-proof and non-tamper-proof wiring.
The resistance of 4.7KΩonly supports tamper-proof wiring.
The resistance of 5.6KΩor 8.2KΩonly supports non-tamper-proof wiring.

Video Security Control Panel User Manual
--18--
The wiring of alarm output is shown as follows:
External Device
NO/NC
COM
DC12V
Breaker
External DC Load
External Device
NO/NC
COM
DC12V
Breaker
AC220V
External AC Load
Relay
The DC current supplied by the control panel can be used for external devices. The load current cannot be over
1A.

Video Security Control Panel User Manual
--19--
Wiring Keypad2.2.3
The keypad wiring is shown as follows. Take the model of DS-19S08-04F/Kx (Gx) as an example.
Wiring Video/Audio Input2.2.4
The video/audio wiring is shown as follows. Take the model of DS-19S08-04F/Kx (Gx) as an example.

Video Security Control Panel User Manual
--20--
Wiring Video/Audio Output2.2.5
Take the model of DS-19S08-04F/Kx (Gx) as an example
