DS-K1800 Series Card Readers Connect
to DS-K2800 Series Access Controllers
Version:
v1.0
Date:
7/15/2017
Product:
Access Control Device
Page:
1 of 5
DS-K1800 Series Card Readers Connect to DS-K2800
Series Access Controllers
Preparation
Connecting card reader to access controller is mainly applied to swiping card to open the door for entrring
or exiting. The models of card reader and access controller in this guide are as below:
Card Reader
Access Controller
DS-K1801M/MK, DS-K1802M/MK,
DS-K1801E/EK, DS-K1802E/EK
DS-K2801,
DS-K2802,
DS-K2804
Notice
1. Please cut off power supply before wiring;
2. DS-K1800 Series Card Readers support standard Wiegand 26/34 protocol , the details about
Wiegand interface about of card reader are as below;
3. Correspondingly, there are wiegand interfaces in DS-K2800 series access controllers;
Color
Description
Red
PWR(+12 VDC)
Black
GND
Green
Wiegand W0
White
Wiegand W1
Blue
Wiegand 26/34
Purple
Beep Control
Brown
OK
Orange
ERR
Cable
Wiring mode
Wiegand Mode
Blue Wiegand
cable
Grounded
Wiegand 26
Not Grounded
Wiegand 34
DS-K2601
DS-K2602
DS-K2604

Title:
DS-K1800 Series Card Readers Connect
to DS-K2800 Series Access Controllers
Version:
v1.0
Date:
7/15/2017
Product:
Access Control Device
Page:
2 of 5
Mothed 1: Wiegand 26 Wiring
DS-K2801:
Please connect card reader to access controller as following picture;
DS-K2802:
Please connect card reader to access controller as following picture, you can also refer to DS-K2801
wiring and get clearer wiring;
Interface
Door
Reader
READER 1
Door 1
Entrance card reader1
READER 2
Exit card reader2
Interface
Door
Reader
READER 1
Door 1
Entrance card reader1
READER 2
Exit card reader2
READER 3
Door 2
Entrance card reader3
READER 4
Exit card reader4
READER1
READER2
G
12V
W0
BEEP
OK
ERR
W1
G
12V
W0
BEEP
OK
ERR
W1
Wiegand26/Blue
BEEP/Purple
ERR/Orange
OK/Brown
GND/Black
+12V/Red
W0/Green
W1/White
Wiegand26/Blue
BEEP/Purple
ERR/Orange
OK/Brown
GND/Black
+12V/Red
W0/Green
W1/White
READER2
READER4
READER1
READER3
Wiegand26/Blue
BEEP/Purple
ERR/Orange
OK/Brown
GND/Black
+12V/Red
W0/Green
W1/White
READER2
READER4
READER1
READER3

Title:
DS-K1800 Series Card Readers Connect
to DS-K2800 Series Access Controllers
Version:
v1.0
Date:
7/15/2017
Product:
Access Control Device
Page:
3 of 5
DS-K2804:
For four-door access controller, there are four wiegand interfaces in mainboard of access cotroller and
these four wiegand interfaces are designed for entrance card reader; And there are no extended wiegand
interfaces because of space limitation.
Please connect card reader to access controller as following picture, you can also refer to DS-K2801
wiring and get clearer wiring;
Mothed 2: Wiegand 34 Wiring
DS-K2801:
Please connect card reader to door station as following picture;
Interface
Door
Reader
READER 1
Door 1
Entrance card reader1
READER 2
Door 2
Entrance card reader3
READER 3
Door 3
Entrance card reader5
READER 4
Door 4
Entrance card reader7
Interface
Door
Reader
READER 1
Door 1
Entrance card reader1
READER 2
Exit card reader2
READER2
READER4
READER1
READER3
Wiegand26/Blue
BEEP/Purple
ERR/Orange
OK/Brown
GND/Black
+12V/Red
W0/Green
W1/White
READER2
READER4
READER1
READER3
READER1
READER2
BEEP/Purple
ERR/Orange
OK/Brown
GND/Black
+12V/Red
W0/Green
W1/White
G
12V
W0
BEEP
OK
ERR
W1
G
12V
W0
BEEP
OK
ERR
W1
BEEP/Purple
ERR/Orange
OK/Brown
GND/Black
+12V/Red
W0/Green
W1/White

Title:
DS-K1800 Series Card Readers Connect
to DS-K2800 Series Access Controllers
Version:
v1.0
Date:
7/15/2017
Product:
Access Control Device
Page:
4 of 5
DS-K2802:
Please connect card reader to access controller as following picture, you can also refer to DS-K2801
wiring and get clearer wiring;
DS-K2804:
For four-door access controller, there are four wiegand interfaces in mainboard of access cotroller and
these four wiegand interfaces are designed for entrance card reader; And there are no extended wiegand
interfaces because of space limitation.Please connect card reader to access controller as following picture,
you can also refer to DS-K2801 wiring and get clearer wiring;
Interface
Door
Reader
READER 1
Door 1
Entrance card reader1
READER 2
Exit card reader2
READER 3
Door 2
Entrance card reader3
READER 4
Exit card reader4
Interface
Door
Reader
READER 1
Door 1
Entrance card reader1
READER 2
Door 2
Entrance card reader3
READER 3
Door 3
Entrance card reader5
READER 4
Door 4
Entrance card reader7
READER2
READER4
READER1
READER3
READER2
READER4
READER1
READER3
READER2
READER4
READER1
READER3
BEEP/Purple
ERR/Orange
OK/Brown
GND/Black
+12V/Red
W0/Green
W1/White
READER1
READER2
READER3
READER4
READER2
READER4
READER1
READER3
BEEP/Purple
ERR/Orange
OK/Brown
GND/Black
+12V/Red
W0/Green
W1/White
READER1
READER2
READER3
READER4
