HIK VISION DS-K281 Series User manual

DS-K281X Series Access Controller
User Manual

Legal Informaon
©2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-K281X Series Access Controller User Manual
i

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
DS-K281X Series Access Controller User Manual
ii

Available Model
Product Name Model
Access Controller DS-K2811
DS-K2812
DS-K2814
DS-K281X Series Access Controller User Manual
iii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K281X Series Access Controller User Manual
iv

under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitaon est autorisée aux deux condions suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2. l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est suscepble d'en compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmier by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des
autres ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
DS-K281X Series Access Controller User Manual
v

Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
DS-K281X Series Access Controller User Manual
vi

Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
●Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
●Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●When the product is installed on wall or ceiling, the device shall be rmly xed.
●If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children. If you think baeries might have
been swallowed or placed inside any part of the body, seek immediate medical aenon.
●If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
DS-K281X Series Access Controller User Manual
vii

Cauons:
●Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●The device cover for indoor use shall be kept from rain and moisture.
●Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
●Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
●Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
●Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
DS-K281X Series Access Controller User Manual
viii

Contents
Chapter 1 Prevenve and Cauonary Tips .................................................................................. 1
Chapter 2 Product Descripon .................................................................................................... 2
Chapter 3 Main Board Descripon .............................................................................................. 3
3.1 Single-Door Access Controller Main Board Descripon ......................................................... 3
3.2 Two-Door Access Controller Main Board Descripon ............................................................ 4
3.2.1 Four-Door Access Controller Main Board Descripon .................................................. 5
3.3 Component Descripon ......................................................................................................... 5
3.4 Baery Charging Board .......................................................................................................... 7
Chapter 4 Terminal Descripon .................................................................................................. 8
4.1 Single-Door Access Controller Terminal Descripon .............................................................. 8
4.2 Two-Door Access Controller Terminal Descripon ............................................................... 10
4.3 Four-Door Access Controller Terminal Descripon .............................................................. 13
Chapter 5 Installaon ............................................................................................................... 17
5.1 Wall Mounng ..................................................................................................................... 17
Chapter 6 Terminal Wiring ........................................................................................................ 19
6.1 Main Board Wiring ............................................................................................................... 19
6.2 Wiegand Card Reader Wiring ............................................................................................... 20
6.3 RS-485 Card Reader Wiring .................................................................................................. 20
6.4 Cathode Lock Wiring ............................................................................................................ 21
6.5 Anode Lock Wiring ............................................................................................................... 22
6.6 Alarm Output Wiring ........................................................................................................... 23
6.7 Exit Buon Wiring ................................................................................................................ 23
6.8 Door Contact Wiring ............................................................................................................ 24
6.9 Power Supply Wiring ............................................................................................................ 24
Chapter 7 Sengs .................................................................................................................... 26
7.1 Inializaon (Opon 1) ........................................................................................................ 26
DS-K281X Series Access Controller User Manual
ix

7.2 Inializaon (Opon 2) ........................................................................................................ 26
7.3 Relay Output NO/NC Sengs .............................................................................................. 27
7.3.1 Lock Relay Output Sengs ......................................................................................... 27
7.3.2 Alarm Relay Output Sengs ....................................................................................... 28
Chapter 8 Acvaon ................................................................................................................. 30
8.1 Acvate via SADP ................................................................................................................. 30
8.2 Acvate Device via Client Soware ...................................................................................... 31
Chapter 9 Client Soware Conguraon ................................................................................... 33
9.1 Conguraon Flow of Client Soware ................................................................................. 33
9.2 Device Management ............................................................................................................ 34
9.2.1 Add Device .................................................................................................................. 34
9.2.2 Reset Device Password ................................................................................................ 37
9.2.3 Manage Added Devices .............................................................................................. 38
9.3 Group Management ............................................................................................................. 39
9.3.1 Add Group ................................................................................................................... 39
9.3.2 Import Resources to Group ......................................................................................... 40
9.4 Person Management ............................................................................................................ 40
9.4.1 Add Organizaon ........................................................................................................ 40
9.4.2 Import and Export Person Idenfy Informaon .......................................................... 41
9.4.3 Get Person Informaon from Access Control Device .................................................. 43
9.4.4 Issue Cards to Persons in Batch ................................................................................... 44
9.4.5 Report Card Loss ......................................................................................................... 45
9.4.6 Set Card Issuing Parameters ........................................................................................ 45
9.5 Congure Schedule and Template ....................................................................................... 46
9.5.1 Add Holiday ................................................................................................................. 46
9.5.2 Add Template .............................................................................................................. 47
9.6 Set Access Group to Assign Access Authorizaon to Persons .............................................. 49
9.7 Congure Advanced Funcons ............................................................................................ 50
DS-K281X Series Access Controller User Manual
x

9.7.1 Congure Remaining Unlocked/Locked ...................................................................... 50
9.7.2 Congure An-Passback ............................................................................................. 51
9.7.3 Congure Mul-door Interlocking .............................................................................. 52
9.7.4 Congure First Person In ............................................................................................. 53
9.7.5 Congure Mul-Factor Authencaon ....................................................................... 54
9.7.6 Congure Card Reader Authencaon Mode and Schedule ...................................... 56
9.7.7 Congure Device Parameters ...................................................................................... 58
9.7.8 Congure Device Parameters ...................................................................................... 62
9.8 Door Control ........................................................................................................................ 63
9.8.1 Control Door Status ..................................................................................................... 63
9.8.2 Check Real-Time Access Records ................................................................................ 64
Appendix A. Tips for Scanning Fingerprint ................................................................................ 65
Appendix B. DIP Switch Descripon .......................................................................................... 67
Appendix C. Custom Wiegand Rule Descripons ....................................................................... 68
Appendix D. Communicaon Matrix and Device Command ...................................................... 70
DS-K281X Series Access Controller User Manual
xi

Chapter 1 Prevenve and Cauonary Tips
Before connecng and operang your device, please be advised of the following ps:
●Ensure unit is installed in a well-venlated, dust-free environment.
●Keep all liquids away from the device.
●Ensure environmental condions meet factory specicaons.
●Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of
dropping it may cause damage to the sensive electronics within the unit.
●Use the device in conjuncon with an UPS if possible.
●Power down the unit before connecng and disconnecng accessories and peripherals.
●A factory recommended HDD should be used for this device.
●Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the manufacturer.
●It is recommended to choose a 12 V 7 AH lead-acid baery that meets the IEC 60896 standard.
The baery wiring method is shown in the following gure.
DS-K281X Series Access Controller User Manual
1

Chapter 2 Product Descripon
●32-bit high-speed processor
●Supports TCP/IP communicaon. The communicaon data is specially encrypted to relieve the
concern of privacy leak
●Supports recognion and storage of card No. with maximum length of 20
●Supports up to 10,000 cards and 50,000 card presenng records
●Supports mul-door interlock funcon, inner-device an-passback funcon, mulple
authencaons funcon, open door with rst card funcon, super password funcon, M1 card
encrypon, online upgrade funcon and remote control of the doors
●IP address conict detecon
●Supports RS-485 interface and Wiegand interface for accessing card reader. Wiegand interface
supports W26, W34 and is compable with the third-party card reader with Wiegand interface
●Various indicators to show dierent status
●Supports record storage funcon when the device is oine and insucient storage space
storage alarm funcon
●Data can be permanently saved aer the access controller is powered o
●Supports I/O linkage and event linkage
DS-K281X Series Access Controller User Manual
2

Chapter 3 Main Board Descripon
3.1 Single-Door Access Controller Main Board Descripon
Figure 3-1 Single-Door Access Controller Main Board
DS-K281X Series Access Controller User Manual
3

3.2 Two-Door Access Controller Main Board Descripon
Figure 3-2 Two-Door Access Controller Main Board
DS-K281X Series Access Controller User Manual
4

3.2.1 Four-Door Access Controller Main Board Descripon
Figure 3-3 Four-Door Access Controller Main Board
3.3 Component Descripon
You can view the device's components and their descripons.
Take four-door access controller as an example, the component diagram is shown below.
DS-K281X Series Access Controller User Manual
5

Figure 3-4 Four-Door Access Controller Component Diagram
Table 3-1 Four-Door Access Controller Component Descripon
No. Component Descripon
1 Power Indicator
2 Lock Indicator
3 Hardware Inializaon and Normal Working Choice
4 Network Indicator
5 Running Indicator
6 RS-485 Communicaon Indicator
7 Alarm Output Indicator
8 Door Relay Output Status (NC/NO) Choice
DS-K281X Series Access Controller User Manual
6

3.4 Baery Charging Board
Figure 3-5 Baery Charging Board
Note
The baery charging boards are only for devices that support baery.
DS-K281X Series Access Controller User Manual
7

Chapter 4 Terminal Descripon
4.1 Single-Door Access Controller Terminal Descripon
You can view the single-door access controller's terminal descripon.
Figure 4-1 Single-Door Access Controller Main Board
DS-K281X Series Access Controller User Manual
8
