HIK VISION DS-K1T607 Series User manual

DS-K1T607 Series Face Recognion
Terminal
User Manual
UD12808B-B

Legal Informaon
User Manual
©2019 Hangzhou Hikvision Digital Technology Co., Ltd.
About this Manual
This Manual is subject to domesc and internaonal copyright
protecon. Hangzhou Hikvision Digital Technology Co., Ltd.
("Hikvision") reserves all rights to this manual. This manual
cannot be reproduced, changed, translated, or distributed,
parally or wholly, by any means, without the prior wrien
permission of Hikvision.
Please use this user manual under the guidance of professionals.
Trademarks
and other Hikvision marks are the
property of Hikvision and are registered trademarks or the
subject of applicaons for the same by Hikvision and/or its
aliates. Other trademarks menoned in this manual are the
properes of their respecve owners. No right of license is given
to use such trademarks without express permission.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
REGARDING THIS MANUAL. HIKVISION DOES NOT WARRANT,
GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE
USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR
RELIABILITY OF INFORMATION CONTAINED HEREIN. YOUR USE OF
THIS MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE
WHOLLY AT YOUR OWN RISK AND RESPONSIBILITY.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE
OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION
SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL
OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING
FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR
OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL
PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND
THE APPLICABLE LAW, THE LATER PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored
and processed. To protect data, the development of Hikvision
i

devices incorporates privacy by design principles. For example,
for device with facial recognion features, biometrics data is
stored in your device with encrypon method; for ngerprint
device, only ngerprint template will be saved, which is
impossible to reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and
transfer data in accordance with the applicable data protecon
laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as,
implemenng reasonable administrave and physical security
controls, conduct periodic reviews and assessments of the
eecveness of your security controls.
ii

Symbol Convenons
The symbols that may be found in this document are dened as
follows.
Symbol Descripon
Danger Indicates a hazardous situaon which, if not avoided,
will or could result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if
not avoided, could result in equipment damage, data
loss, performance degradaon, or unexpected
results.
Note Provides addional informaon to emphasize or
supplement important points of the main text.
iii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a
residenal installaon. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instrucons, may cause harmful interference
to radio communicaons. However, there is no guarantee that
interference will not occur in a parcular installaon. If this
equipment does cause harmful interference to radio or television
recepon, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help
This equipment should be installed and operated with a minimum
distance 20cm between the radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is
subject to the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and
comply therefore with the applicable
harmonized European standards listed under
iv

the EMC Direcve 2014/30/EU, RE Direcve
2014/53/EU,the RoHS Direcve 2011/65/EU
2012/19/EU (WEEE direcve): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European
Union. For proper recycling, return this product
to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collecon points. For more
informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product
contains a baery that cannot be disposed of as
unsorted municipal waste in the European
Union. See the product documentaon for
specic baery informaon. The baery is
marked with this symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon
see:www.recyclethis.info
v

Safety Instrucon
These instrucons are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury
or death.
Cauons: Neglecng any of the cauons may cause injury or
equipment damage.
Dangers: Follow these safeguards
to prevent serious injury or death.
Cauons: Follow these precauons
to prevent potenal injury or
material damage.
Danger:
•All the electronic operaon should be strictly compliance with
the electrical safety regulaons, re prevenon regulaons and
other related regulaons in your local region.
•Please use the power adapter, which is provided by normal
company. This equipment is intended to be supplied from the
Class 2 surge protected power source rated DC 12V, 3A.
•Do not connect several devices to one power adapter as
adapter overload may cause over-heat or re hazard.
•Please make sure that the power has been disconnected
before you wire, install or dismantle the device.
•When the product is installed on wall or ceiling, the device
shall be rmly xed.
•If smoke, odors or noise rise from the device, turn o the
power at once and unplug the power cable, and then please
contact the service center.
•Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/
buon cell baery is swallowed, it can cause severe internal
burns in just 2 hours and can lead to death.
Keep new and used baeries away from children. If the baery
compartment does not close securely, stop using the product
and keep it away from children. If you think baeries might
have been swallowed or placed inside any part of the body,
seek immediate medical aenon.
•If the product does not work properly, please contact your
dealer or the nearest service center. Never aempt to
disassemble the device yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)
Cauons:
•Do not drop the device or subject it to physical shock, and do
not expose it to high electromagnesm radiaon. Avoid the
vi

equipment installaon on vibraons surface or places subject
to shock (ignorance can cause equipment damage).
•Do not place the device in extremely hot (refer to the
specicaon of the device for the detailed operang
temperature), cold, dusty or damp locaons, and do not
expose it to high electromagnec radiaon.
•The device cover for indoor use shall be kept from rain and
moisture.
•Exposing the equipment to direct sun light, low venlaon or
heat source such as heater or radiator is forbidden (ignorance
can cause re danger).
•Do not aim the device at the sun or extra bright places. A
blooming or smear may occur otherwise (which is not a
malfuncon however), and aecng the endurance of sensor
at the same me.
•Please use the provided glove when open up the device cover,
avoid direct contact with the device cover, because the acidic
sweat of the ngers may erode the surface coang of the
device cover.
•Please use a so and dry cloth when clean inside and outside
surfaces of the device cover, do not use alkaline detergents.
•Please keep all wrappers aer unpack them for future use. In
case of any failure occurred, you need to return the device to
the factory with the original wrapper. Transportaon without
the original wrapper may result in damage on the device and
lead to addional costs.
•Improper use or replacement of the baery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used baeries according to the instrucons
provided by the baery manufacturer.
•Biometric recognion products are not 100% applicable to
an-spoong environments. If you require a higher security
level, use mulple authencaon modes.
•Working temperature: -30 °C to +60 °C
•Indoor and outdoor use. If installing the device indoors, the
device should be at least 2 meters away from the light, and at
least 3 meters away from the window or the door. If installing
the device outdoors, you should apply Sililcone sealant among
the cable wiring area to keep the raindrop from entering.
•Protecon level: IP65
vii

Available Models
Product Name Model
Face Recognion Terminal
DS-K1T607M
DS-K1T607MF
DS-K1T607E
DS-K1T607EF
DS-K1T607MW
DS-K1T607MFW
DS-K1T607PE
DS-K1T607PEF
DS-K1T607PMW
DS-K1T607PMFW
DS-K1T607TM
DS-K1T607TMF
DS-K1T607TE
DS-K1T607TEF
DS-K1T607TMW
DS-K1T607TMFWW
Use only power supplies listed in the user instrucons:
Model Manufacturer Standard
C2000IC12.0-24P-DE MOSO Power Supply
Technology Co., Ltd. CEE
C2000IC12.0-24P-GB MOSO Power Supply
Technology Co., Ltd. BS
KPL-040F-VI Channel Well
Technology Co Ltd. CEE
viii

Contents
1 Overview .................................................................. 1
1.1 Overview ............................................................... 1
1.2 Features ................................................................ 1
1.2.1 Features (Normal Series) ............................. 1
1.2.2 Features (P Series) ....................................... 2
1.2.3 Features (T Series) ....................................... 2
2 Appearance .............................................................. 3
3 Installaon ............................................................... 5
3.1 Installaon Environment ....................................... 5
3.2 Install with Gang Box ............................................ 5
3.3 Install without Gang Box ....................................... 7
4 Wiring ..................................................................... 10
4.1 Terminal Descripon ........................................... 11
4.2 Wire Device ......................................................... 13
4.3 Wire Secure Door Control Unit ........................... 13
5 Acvaon ............................................................... 14
5.1 Acvate via Device .............................................. 14
5.2 Acvate via SADP ................................................ 15
5.3 Acvate Device via Client Soware .................... 15
6 Basic Operaon ...................................................... 16
6.1 Set Applicaon Mode ......................................... 16
6.2 Set Recognion Mode ......................................... 17
6.3 Login ................................................................... 18
6.3.1 Login For First Login ................................... 18
6.3.2 Login by Administrator .............................. 19
6.4 Communicaon Sengs ..................................... 20
6.4.1 Set Network Parameters ............................ 20
6.4.2 Set Wi-Fi Parameters ................................. 21
ix

6.4.3 Set RS-485 Parameters .............................. 21
6.4.4 Set Wiegand Parameters ........................... 22
6.5 User Management .............................................. 22
6.5.1 Add Administrator ..................................... 22
6.5.2 Add Face Picture ........................................ 23
6.5.3 Add Fingerprint .......................................... 25
6.5.4 Add Card .................................................... 26
6.5.5 Add Password ............................................ 27
6.5.6 Set Authencaon Mode .......................... 28
6.5.7 Search and Edit User .................................. 28
6.6 Import and Export Data ...................................... 28
6.6.1 Export Data ................................................ 28
6.6.2 Import Data ............................................... 29
6.7 Identy Authencaon ....................................... 30
6.7.1 Authencate via 1:1 Matching .................. 30
6.7.2 Authencate via 1:N Matching .................. 31
6.7.3 Authencate via 1:1 Matching and 1:N
Matching ............................................................. 31
6.8 System Sengs ................................................... 31
6.8.1 Set Basic Parameters ................................. 31
6.8.2 Set Face Picture Parameters ...................... 32
6.8.3 Set Fingerprint Parameters ........................ 35
6.8.4 Set Time ..................................................... 36
6.9 Time and Aendance Status Sengs ................. 36
6.9.1 Disable Aendance Mode ......................... 36
6.9.2 Set Manual Aendance ............................. 37
6.9.3 Set Auto Aendance .................................. 37
6.9.4 Set Manual and Auto Aendance ............. 38
6.10 Set Access Control Parameters ......................... 39
6.11 Maintenance ..................................................... 40
x

6.11.1 Upgrade Firmware ................................... 40
6.11.2 Data Management ................................... 41
6.11.3 Log Query ................................................ 41
6.12 View System Informaon .................................. 42
6.13 Two-Way Audio ................................................. 43
6.13.1 Call Client Soware from Device ............. 43
6.13.2 Call Master Staon from Device .............. 43
6.13.3 Call Device from Client Soware ............. 44
6.13.4 Call Indoor Staon from Device ............... 44
7 Client Soware Conguraon ................................. 45
7.1 Device Management ........................................... 45
7.1.1 Add Device ................................................. 45
7.1.2 Reset Device Password .............................. 52
7.2 Person Management ........................................... 53
7.2.1 Add Organizaon ....................................... 53
7.2.2 Congure Basic Informaon ...................... 54
7.2.3 Issue a Card to One Person ........................ 54
7.2.4 Upload a Face Photo from Local PC ........... 55
7.2.5 Take a Photo via Client ............................... 56
7.2.6 Collect Face via Access Control Device ...... 56
7.2.7 Collect Fingerprint via Client ..................... 57
7.2.8 Collect Fingerprint via Access Control Device
............................................................................. 58
7.2.9 Congure Access Control Informaon ....... 58
7.2.10 Customize Person Informaon ................ 59
7.2.11 Congure Resident Informaon .............. 60
7.2.12 Congure Addional Informaon ............ 60
7.2.13 Import and Export Person Idenfy
Informaon ......................................................... 61
7.2.14 Import Person Informaon ...................... 61
xi

7.2.15 Import Person Pictures ............................ 61
7.2.16 Export Person Informaon ...................... 62
7.2.17 Export Person Pictures ............................. 62
7.2.18 Get Person Informaon from Access Control
Device ................................................................. 63
7.2.19 Move Persons to Another Organizaon
............................................................................. 63
7.2.20 Issue Cards to Persons in Batch ............... 64
7.2.21 Report Card Loss ...................................... 64
7.2.22 Set Card Issuing Parameters .................... 64
7.3 Congure Schedule and Template ...................... 65
7.3.1 Add Holiday ............................................... 66
7.3.2 Add Template ............................................. 66
7.4 Set Access Group to Assign Access Authorizaon to
Persons ..................................................................... 68
7.5 Congure Advanced Funcons ........................... 69
7.5.1 Congure Device Parameters .................... 69
7.5.2 Congure Remaining Open/Closed ........... 74
7.5.3 Congure Mul-Factor Authencaon ...... 75
7.5.4 Congure Custom Wiegand Rule ............... 77
7.5.5 Congure Card Reader Authencaon Mode
and Schedule ...................................................... 78
7.5.6 Congure First Person In ............................ 79
7.5.7 Congure An-Passback ............................ 80
7.5.8 Congure Other Parameters ...................... 81
7.6 Congure Linkage Acons for Access Control ..... 90
7.6.1 Congure Client Acons for Access Event
............................................................................. 90
7.6.2 Congure Device Acons for Access Event
............................................................................. 91
7.6.3 Congure Device Acons for Card Swiping
............................................................................. 92
7.6.4 Congure Device Acons for Person ID ..... 93
xii

7.7 Door Control ....................................................... 94
7.7.1 Control Door Status ................................... 95
7.7.2 Check Real-Time Access Records ............... 95
7.8 Event Center ....................................................... 96
7.8.1 Enable Receiving Event Nocaon from
Devices ............................................................... 96
7.8.2 View Real-Time Events ............................... 96
7.8.3 Search Historical Events ............................. 98
7.9 Time and Aendance ........................................ 100
7.9.1 Congure Aendance Parameters ........... 100
7.9.2 Add Timetable ......................................... 105
7.9.3 Add Shi .................................................. 107
7.9.4 Manage Shi Schedule ............................ 108
7.9.5 Manually Correct Check-in/out Record ... 111
7.9.6 Add Leave and Business Trip .................... 112
7.9.7 Calculate Aendance Data ...................... 113
7.9.8 Aendance Stascs ............................... 114
7.10 Remote Conguraon (Web) .......................... 116
7.10.1 Check Device Informaon ...................... 116
7.10.2 Edit Device Name .................................. 116
7.10.3 Edit Time ................................................ 116
7.10.4 Set System Maintenance ....................... 117
7.10.5 Congure RS-485 Parameters ................ 118
7.10.6 Manage User ......................................... 118
7.10.7 Set Security ............................................ 118
7.10.8 Congure Network Parameters ............. 119
7.10.9 Congure Advanced Network ................ 119
7.10.10 Congure Wi-Fi .................................... 119
7.10.11 Congure SIP Parameters .................... 119
7.10.12 Congure Face Picture Parameters ...... 120
xiii

7.10.13 Congure Supplement Light Parameters
........................................................................... 121
7.10.14 Set Room No. ....................................... 122
7.10.15 Congure Video and Audio Parameters
........................................................................... 122
7.10.16 Congure Volume Input or Output ...... 122
7.10.17 View Relay Status ................................. 122
A. Tips for Scanning Fingerprint ............................... 123
B. Tips When Collecng/Comparing Face Picture ..... 124
C. Tips for Installaon Environment ......................... 125
D. Relaonship between Wake-up Distance and
Environment ............................................................ 126
E. Dimension ........................................................... 127
xiv

1 Overview
1.1 Overview
Face recognion terminal is a kind of access control device for
face recognion, which is mainly applied in security access
control systems, such as logisc centers, airports, university
campuses, alarm centrals, dwellings, etc.
1.2 Features
1.2.1 Features (Normal Series)
•7-inch LCD touch screen
•2 MP wide-angle dual-lens
•Adjusts supplement light brightness manually
•Face recognion distance: 0.3 m to 1.5 m
•Suggested height for face recognion: between 1.4 m and 1.9
m
•Deep learning algorithm
•6,000 face capacity, 5,000 ngerprint capacity, and 10,000
event capacity
•Mulple authencaon modes
•Face recognion duraon ≤ 0.5 s/User; face recognion
accuracy rate ≥ 99%
•Device parameters management, search, and sengs
•Imports card and user data to the device via TCP/IP
communicaon or USB ash drive
•Stand-alone operaon
•Transmits data to the client soware via TCP/IP communicaon
and saves the data on the client soware
•Capture linkage and captured pictures saving
•Imports data to the device from the client soware
•Manage, search and set device data aer logging in the device
locally
•Connects to one external card reader or access controller via
RS-485 protocol
•Connects to external access controller or Wiegand card reader
via Wiegand protocol
•Connects to secure door control unit via RS-485 protocol to
avoid the door opening when the terminal is destroyed
•Two-way audio with client soware, door staon, indoor
staon, and master staon
•Automac network replenishment (ANR)
•Remote live view via RTSP protocol; encoding mode: H.264
•NTP, manually me synchronizaon, and auto synchronizaon
•Audio prompt
1

•Watchdog design and tamper funcon
•NFC tag an-cloning
1.2.2 Features (P Series)
•7-inch LCD touch screen
•2 MP wide-angle dual-lens
•Adjusts supplement light brightness manually
•Face recognion in dark environment
•Face recognion distance: 0.3 m to 1.5 m
•Suggested height for face recognion: between 1.4 m and 1.9
m
•Deep learning algorithm
•10,000 face capacity, 5,000 ngerprint capacity, and 50,000
event capacity
•Mulple authencaon modes
•Face recognion duraon ≤ 0.5 s/User; face recognion
accuracy rate ≥ 99%
•Device parameters management, search, and sengs
•Stand-alone operaon
•Transmits data to the client soware via TCP/IP communicaon
and saves the data on the client soware
•Capture linkage and captured pictures saving
•Imports data to the device from the client soware
•Manage, search and set device data aer logging in the device
locally
•Connects to one external card reader or access controller via
RS-485 protocol
•Connects to external access controller or Wiegand card reader
via Wiegand protocol
•Connects to secure door control unit via RS-485 protocol to
avoid the door opening when the terminal is destroyed
•Two-way audio with client soware, door staon, indoor
staon, and master staon
•Automac network replenishment (ANR)
•Remote live view via RTSP protocol; encoding mode: H.264
•NTP, manually me synchronizaon, and auto synchronizaon
•Audio prompt
•Watchdog design and tamper funcon
•NFC tag an-cloning
1.2.3 Features (T Series)
•7-inch LCD touch screen
•2 MP wide-angle dual-lens
•Adjusts supplement light brightness manually
•Face recognion in dark environment
•Face recognion distance: 0.3 m to 1.5 m
2

•Suggested height for face recognion: between 1.4 m and 1.9
m
•Deep learning algorithm
•50,000 face capacity, 5,000 ngerprint capacity, and 50,000
event capacity
•Mulple authencaon modes
•Face recognion duraon ≤ 0.5 s/User; face recognion
accuracy rate ≥ 99%
•Device parameters management, search, and sengs
•Imports card and user data to the device via TCP/IP
communicaon or USB ash drive
•Stand-alone operaon
•Transmits data to the client soware via TCP/IP communicaon
and saves the data on the client soware
•Capture linkage and captured pictures saving
•Imports data to the device from the client soware
•Manage, search and set device data aer logging in the device
locally
•Connects to one external card reader or access controller via
RS-485 protocol
•Connects to external access controller or Wiegand card reader
via Wiegand protocol
•Connects to secure door control unit via RS-485 protocol to
avoid the door opening when the terminal is destroyed
•Two-way audio with client soware, door staon, indoor
staon, and master staon
•Automac network replenishment (ANR)
•Remote live view via RTSP protocol; encoding mode: H.264
•NTP, manually me synchronizaon, and auto synchronizaon
•Audio prompt
•Watchdog design and tamper funcon
•NFC tag an-cloning
2 Appearance
Refer to the following contents for detailed informaon of the
face recognion terminal:
Figure 2-1 Face Recognion Terminal Diagram
3

Table 2-1 Descripon of Face Recognion Terminal
No. Name Descripon
1Fingerprint
Module
For ngerprint
recognion.
Note
Only parts of models
support ngerprint
recognion funcon.
2Card Swiping
Area
Swipe card within this
area.
3 Display Screen 7-inch LCD touch screen.
4 Camera (IR Light)
IR light camera for
recording or capturing
videos or pictures in IR
light.
5Camera (White
Light)
White light camera for
recording or capturing
white light videos or
pictures.
6
Supplement
Light (White
Light)
Supplement light for white
light camera.
7Supplement
Light (IR Light)
Supplement light for IR
camera.
8Supplement
Light (IR Light)
Supplement light for IR
camera.
9 USB Interface Connect to USB ash
drive.
10 Network
Interface Connect to Ethernet.
11 SIM Card Slot Reserved
12 Debugging Port The debug terminal is
used for debugging only.
13 Power Interface Connect to power supply.
14 Wiring Terminals
Connect to other external
devices, including RS-485
card reader, Wiegand card
reader, door lock, alarm
input, alarm output, etc.
15 PSAM Card Slot Reserved
4

3 Installaon
3.1 Installaon Environment
•If installing the device indoors, the device should be at least 2
meters away from the light, and at least 3 meters away from
the window or the door.
•If installing the device outdoors, you should apply Sililcone
sealant among the cable wiring area to keep the raindrop from
entering.
•Make sure the environment illuminaon is more than 100 Lux.
Note
•For details about installaon environment, see Tips for
Installaon Environment.
•Make sure the output of external power supply fulls LPS.
3.2 Install with Gang Box
Steps
1. According to the datum line on the mounng template, sck
the mounng template on the wall or other surface, 1.4 meters
higher than the ground.
Figure 3-1 Mounng Template
2. Drill holes on the wall or other surface according to the
mounng template and install the gang box.
5
