Hioki Memory HiCorder MR6000 User manual

MR6000
MR6000-01
Instruction Manual
MEMORY HiCORDER
EN
Apr. 2021 Revised edition 3
MR6000A966-03 21-04H
MR6000MR6000-01 MEMORY HiCORDER Instruction Manual
HIOKI MR6000A966-03

HIOKI MR6000A966-03

i
3 Advanced Functions 51
3.1 Overlaying New Waveforms With
Previously Acquired Waveforms.........52
3.2 Converting Input Values
(Scaling Function) ................................54
When using Model U8969 Strain Unit ........59
3.3 Adjusting the Waveform Display
Positions (Variable Function)..............60
3.4 Fine-Adjusting Input Values
(Vernier Function).................................62
3.5 Inverting a Waveform
(Invert Function)....................................63
3.6 Copying Settings (Copy Function) .....64
3.7 ConguringModule-Specic
Settings ..................................................65
ConguringModel8968HighResolution
Unit settings..............................................65
ConguringModel8967TempUnit
settings.....................................................66
ConguringModelU8969StrainUnit
settings.....................................................68
ConguringModel8970FreqUnit
settings.....................................................70
ConguringModel8971CurrentUnit
settings.....................................................73
ConguringModel8972DC/RMSUnit
settings.....................................................75
ConguringModelMR8990Digital
Voltmeter Unit settings ..............................76
ConguringModelU8974HighVoltage
Unit settings..............................................78
ConguringModelU89773CHCurrent
Unit Settings .............................................79
CongureModelU8979ChargeUnit
Settings ....................................................81
Generating signals from Model U8793
Arbitrary Waveform Generator Unit............84
ConguringModelU8793Arbitrary
Waveform Generator Unit..........................86
Registeringarbitrarywaveformsinthe
U8793 Arbitrary Waveform Generator
Unit ..........................................................89
Editing programs of the U8793 Arbitrary
Waveform Generator Unit..........................94
Contents
Introduction........................................................1
HowtoUseThisDocument ............................2
1 Measurement Method 3
1.1 Measurement Procedure.......................3
1.2 Setting Measurement Conditions.........5
Sampling rate setting guideline....................7
Using the envelope .....................................9
1.3 ConguringtheInputChannel
Settings ..................................................11
Analog channels .......................................13
Logic channels..........................................17
1.4 ConguringtheSheetSettings...........19
Switching sheets on the waveform
screen ......................................................24
Generating XY composite waveforms........25
1.5 Starting/StoppingaMeasurement .....28
2 Operating the
Waveform Screen and
Analyzing Data 29
2.1 ReadingMeasuredValues
(TraceCursors,Horizontal
Cursors) .................................................30
2.2 SpecifyingtheWaveformRange
(Section Cursor)....................................34
Changingthedisplaymagnicationof
the waveforms while moving the section
cursor.......................................................35
2.3 Displaying Vertical Scales
(Gauge Function)..................................36
2.4 ScrollingThroughWaveforms ............38
Scrolling through waveforms .....................38
Checking a position of waveforms with
the scroll bar.............................................39
2.5 Changing the Display Position
andDisplayMagnicationof
Waveforms ............................................40
Differentiating a waveform display
positionanddisplaymagnicationfrom
those of other analog channels..................41
2.6 OperatingtheRotaryKnobs ...............44
2.7 Enlarging a Part of the Waveform
(Zoom Function) ...................................45
2.8 Generating XY Composite
Waveforms (XY Composite) ...............46
2.9 Displaying Measured Values ..............48
MR6000A966-03
HIOKI MR6000A966-03

Contents
ii
6 Search Function 147
6.1 Searching For Peak Values ..............148
6.2 Searching For Positions Where a
TriggerConditionIsSatised............151
6.3 Searching For Differences from
a Fundamental Wave
(MemoryHiConcierge).......................156
6.4 JumpingtotheSpeciedPosition....159
7 Numerical Calculation
Function 161
7.1 Numerical Calculation Procedure ....162
7.2 ConguringtheNumerical
Calculation Settings ...........................164
Displaying numerical calculation
results ....................................................175
7.3 EvaluatingCalculationResultson
aPass/FailBasis................................177
Displaying evaluation results and
externally outputting signals ....................180
7.4 NumericalCalculationTypesand
Descriptions.........................................181
8 Waveform Calculation
Function 189
8.1 Waveform Calculation Procedure ....190
8.2 ConguringtheWaveform
Calculation Settings ...........................192
8.3 DeningConstants.............................199
8.4 Operators of the Waveform
Calculation and Calculation
Results .................................................201
8.5 ExamplesofConguring
Waveform Calculation Settings ........209
ObtaininganRMSwaveformfroman
instantaneous waveform .........................209
FIRlter .................................................212
IIRlter...................................................216
8.6 Explanations of Filter Calculation ....221
Filter type ...............................................221
Filterconguration ..................................222
4 Saving/Loading Data
and Managing Files 97
4.1 DataThatCanBeSavedand
Loaded ...................................................98
4.2 Saving Data.........................................100
Saving types and setting procedure.........100
Structure of the save destination
folders ....................................................101
Automatically saving waveform data........102
Real-timesaving.....................................106
Freely choosing data items to be saved
andsaveles(SAVEkey) .......................109
4.3 Loading Data.......................................113
Data loading procedure...........................113
Loading waveform data in a batch ...........115
Automatically loading the settings
(Automatic setup function).......................115
4.4 Managing Files ...................................116
5 Conguring the Trigger
Settings 117
5.1 TriggerSettingProcedure .................118
5.2 EnablingtheTriggerFunction...........119
5.3 ConguringtheTriggerTiming
Setting ..................................................120
5.4 ConguringthePre-triggerand
Post-trigger Settings ..........................122
Toobserveaninputwaveformwhilethe
instrument is waiting for a trigger.............126
5.5 SettingtheTriggerSatisfaction
Conditions(AND/OROperation)
AmongTriggerSources.....................127
5.6 TriggeringtheInstrumentUsing
AnalogSignals(AnalogTrigger) ......129
5.7 TriggeringtheInstrumentUsing
LogicSignals(LogicTrigger) ............138
5.8 TriggeringtheInstrumentat
RegularIntervals
(IntervalTrigger) .................................140
5.9 ExternallyTriggeringthe
Instrument(ExternalTrigger)............142
5.10 ManuallyTriggeringtheInstrument
(ForcibleTrigger) ................................142
5.11 TriggeringtheInstrumentUsing
CANSignals(CANTrigger) ..............143
HIOKI MR6000A966-03

Contents
iii
12 CAN/LIN Measurement
Function 277
12.1 CAN/LINMeasurement
Procedure ............................................278
12.2 ConnectingCAN/LINInterfaces .......280
12.3 ConguringtheCAN/LINInterface
Settings ................................................285
12.4 ConguringtheCAN/LINDenition
Data Settings.......................................291
ChoosingCANdenitiondata .................297
12.5 ConguringtheTransmission
Function Settings
(CreatingaTransmissionList)..........299
12.6 ChoosingDataSetstoBe
Displayed as Waveforms
(When Displaying Waveforms
During Measurement) ........................304
12.7 ChoosingDataToBeDisplayed
as Waveforms (When Using the
Waveform Calculation Function) ......305
12.8 Saving Data.........................................308
13 Conguring the System
Environment Settings 309
14 Connecting the
Instrument to
Computers 315
14.1 ConguringtheLANSettingsand
Connecting the Instrument to the
Network................................................317
ConguringtheLANsettingswiththe
instrument ..............................................317
14.2 Managing Data in the Instrument
WiththeFTPServerFunction ..........322
ConguringtheFTPseversettingwith
the instrument.........................................323
Operating the instrument with your
computer(FTPserverfunction) ...............324
14.3 Sending Data to a Computer With
theFTPClientFunction.....................325
ConguringanFTPserversettingona
computer ................................................326
ConguringtheFTPclientsettingwith
the instrument.........................................331
9 FFT Calculation
Function 223
9.1 Operating Procedure..........................224
9.2 EnablingtheFFTCalculation
Settings ................................................226
9.3 SettingFFTCalculation
Conditions............................................228
Specifying the number of calculation
points .....................................................228
Conguringthewindowfunction
settings...................................................231
Conguringthecalculationresultpeak
value settings .........................................233
Averaging calculation results...................234
FFTcalculationadvancedsettings...........238
9.4 Performing Calculations on the
Waveform Screen...............................242
Tospecifyarangebeforecalculation.......242
9.5 FFTCalculationTypes.......................245
Calculation types and display
examples................................................245
Calculation types and internal
calculation formulas ................................254
10 Memory Division
Function 255
10.1 ConguringtheMemoryDivision
Settings ................................................256
10.2 ConguringtheDisplaySettings......257
11 Dual Sampling 261
11.1 Dual Sampling Procedure .................262
11.2 ConguringDualSampling
Settings ................................................263
11.3 Operating the Waveform Screen
forAnalyzingWaveforms...................267
11.4 Calculation Function ..........................272
11.5 Files ......................................................274
Automatically saving waveform data........275
Freely choosing data items to be saved
andsaveles(SAVEkey) .......................276
Loading waveform data...........................276
HIOKI MR6000A966-03

Contents
iv
14.4 Operating the Instrument With a
BrowserInstalledinaComputer......333
Connecting your computer to the
instrument with a web browser ................334
Remotelyoperatingtheinstrument .........335
Starting/Stoppingmeasurement ..............336
Conguringthecommentsetting .............337
Acquiring data from the instrument ..........338
Setting the clock .....................................339
Handlingles..........................................339
14.5 Sending Email messages..................340
Conguringthebasicsettingforsending
email messages......................................341
Conguringtheemailcontents
settings...................................................342
Conguringtheauthentication,
compression,andencryptionsettings
for email messages to be sent.................343
14.6 Controlling the Instrument With
Command Communications
(LAN)....................................................345
15 Externally Controlling
the Instrument 347
15.1 External Input and Output .................348
Externalinput(IN1),(IN2) .......................348
Externaloutput(OUT1),(OUT2)..............349
Triggeroutput(TRIG.OUT)......................351
Externaltriggerterminal(EXT.TRIG) .......353
15.2 ExternalSampling(EXT.SMPL) .......356
16 Appendix 357
16.1 InformationforReference
Purposes..............................................357
Waveformlesize
(values for reference purposes)...............357
Maximum recordable time when the
real-time saving is enabled
(values for reference purposes)...............361
Scaling method for strain gauges ............367
Exampleofawaveformtextle...............369
File saving rates
(values for reference purposes)...............370
16.2 FFTDenitions....................................371
16.3 Dual Sampling.....................................380
Index 381
HIOKI MR6000A966-03

1
Introduction
Introduction
Thank you for choosing the Hioki MR6000, MR6000-01 Memory HiCorder. Preserve this manual
carefully and keep it handy to make full use of this instrument for a long time.
Model MR6000-01 Memory HiCorder is an upper model of Model MR6000, which is equipped with
the following calculation functions:
• Digital lter calculation
• Real-time waveform calculation
Following manuals are provided along with these models. See manuals relevant to your purpose.
Type Contents Printed CD-stored
le name
Operating Precautions Information on the instrument for
safe operation –
Quick Start Manual Basic instructions and specications
of the instrument 
MR6000A965-XX.pdf
Instruction Manual (this
document)
Functions and instructions for the
instrument –
MR6000A966-XX.pdf
MR6000-01 Dedicated
Functions
Method to use functions including
the calculation available with Model
MR6000-01
–
MR6000A968-XX.pdf
8793, MR8790, MR8791
Instruction Manual
Functions, specications, and
instructions of Model U8793 –
U8793A980-XX.pdf
Notations
*Additional information is presented below.
Indicates the initial setting values of the items. Initializing the instrument restores
settings to each of these values.
(p. ) Indicates the location of reference information.
START
(Bold-faced) Names and keys on the screen are indicated in boldface.
[ ] Menus, dialog boxes, buttons in a dialog box, and other names on the screen are
indicated in blue brackets.
Windows Unless otherwise specied, “Windows” represents Windows 7, Windows 8, and
Windows 10.
Current sensor Sensors measuring current are referred to as “current sensor.”
S/s
The number of times per second the analog input signals are digitized by the
instrument is expressed in terms of “samples per second (S/s).”
Example: “20 MS/s” (20 megasamples per second) indicates that the signal is digitized
20 × 106times per second.
Introduction
HIOKI MR6000A966-03

2
How to Use This Document
Accuracy
We dene measurement tolerances in terms of f.s. (full scale) and rdg. (reading) values, with the
following meanings:
f.s. (maximum display value or scale length)
The maximum displayable value or scale length.
rdg. (displayed value)
The value currently being measured and displayed on the measuring instrument.
How to Use This Document
How to open a screen
Indicates the order of tapping the
screens.
The button represents the
setting key.
Procedure numbers
Numbered same as a
corresponding step-by-step
instruction.
Options and explanations
Describes options available
when an item is tapped.
The icon indicates the default
setting of the item.
HIOKI MR6000A966-03

3
1Measurement Method
1.1 Measurement Procedure
Inspecting the instrument before measurement
Conguring the basic settings for measurement
Choose a sampling rate. (p. 5)
Choose a recording length. (p. 6)
Advanced settings
“Using the envelope” (p. 9)
“3.1 Overlaying New Waveforms With Previously Acquired Waveforms” (p. 52)
Conguring the input channel settings (p. 11)
Congure the analog channel settings. (p. 13)
Specify the logic channel settings. (p. 17)
Advanced settings
“3.2 Converting Input Values (Scaling Function)” (p. 54)
“3.3 Adjusting the Waveform Display Positions (Variable Function)” (p. 60)
“3.4 Fine-Adjusting Input Values (Vernier Function)” (p. 62)
“3.5 Inverting a Waveform (Invert Function)” (p. 63)
Conguring the sheet settings
Choose a display format of waveforms. (p. 19)
Conguring the trigger settings (p. 117)
Starting a measurement (p. 28)
Finishing the measurement
Advanced operation
“2.2 Specifying the Waveform Range (Section Cursor)” (p. 34)
“Scrolling through waveforms” (p. 38)
“2.5 Changing the Display Position and Display Magnication of Waveforms” (p. 40)
“4 Saving/Loading Data and Managing Files” (p. 97)
“7 Numerical Calculation Function” (p. 161)
1 Measurement Method
Measurement Method
HIOKI MR6000A966-03

4
Measurement Procedure
To conguring measurement settings automatically
Tapping [Auto range] on the waveform screen automatically species the sampling rate,
measurement range, and zero position of the input waveform and start a measurement.
See “3.7 Measuring Signals With the Auto-range Setting” in the Quick Start Manual.
To load settings registered previously
Load the settings le on the le screen.
See “4.3 Loading Data” (p. 113).
To automatically load saved settings at the time of startup
Congure the setting for the instrument so as to load the le containing the instrument settings at
the time of startup.
See “Automatically loading the settings (Automatic setup function)” (p. 115).
Initializing the instrument (Restoring the basic settings)
Select > [System] > [Initialize] to restore the instrument settings to the factory default.
The setting after the initialization is suitable for simple measurement.
Initialize the instrument when you have found any unexpected or complicated operation.
See “6.2 Initializing the Instrument” in the Quick Start Manual.
HIOKI MR6000A966-03

5
Setting Measurement Conditions
1.2 Setting Measurement Conditions
You have to set conditions required for measurement, such as the sampling rate ([Sampling]) and
recording length ([Shot]).
> [Status] > [Condition]
7
1
3
6
8
5
2
4
1
Enter a comment in the [Title comment] box.
Number of characters that can be entered: up to 40
2
Tap the [Sampling] box, and then choose a sampling rate from the list.
See “Sampling rate setting guideline” (p. 7).
200 MS/s, 100 MS/s, 50 MS/s, 20 MS/s, 10 MS/s, 5 MS/s, 2 MS/s, 1 MS/s,
500 kS/s, 200 kS/s, 100 kS/s, 50 kS/s, 20 kS/s, 10 kS/s, 5 kS/s, 2 kS/s, 1 kS/s,
500 S/s, 200 S/s, 100 S/s, 50 S/s, 20 S/s, 10 S/s, 5 S/s, 2 S/s, 1 S/s
The instrument can measure signals at a sampling rate of 200 MS/s even with several modules other than
Model U8976 installed together. However, the data refresh rate does not exceed the maximum sampling rate
of each module.
When the real-time waveform calculation (Model MR6000-01 only) is set to [On], you cannot choose a
sampling rate of 200 MS/s.
When the real-time saving is set to [On], due to the combination of the number of channels to be used and
save destinations, the maximum sampling rate that can be set varies as follows:
Number of channels to be used
Maximum sampling rate that can be chosen
SSD HDD
USB ash drive
SD Card
FTP transmission
1 channel to 2 channels 20 MS/s 10 MS/s 5 MS/s
3 channel to 4 channels 10 MS/s 5 MS/s 2 MS/s
5 channel to 8 channels 5 MS/s 2 MS/s 1 MS/s
9 channel to 16 channels 2 MS/s 1 MS/s 500 kS/s
17 channel to 32 channels 1 MS/s 500 kS/s 200 kS/s
Only if the following Hioki-designated options are used, the real-time saving operation with the instrument is
guaranteed:
• Model U8332 SSD Unit Model U8333 HD Unit
• Model Z4006 USB Drive Model Z4001 and Model Z4003 SD Memory Card
Measurement Method
HIOKI MR6000A966-03

6
Setting Measurement Conditions
3
Tap the [External sampling] button to set it to [On] or [Off].
The external sampling is cannot be set when the envelope is used.
OffDisables the external sampling function.
On Choose this option to sample data at a sampling rate dened by a signal inputted into
the external sampling terminal (EXT.SMPL).
Samples data at rising edges of the input signal.
Samples data at falling edges of the input signal.
&Samples data at both rising and falling edges of the input signal.
4
Tap the [Points] box, and then from the list, choose an option for the number of points to be
measured.
2.5 k, 5 k, 10 k, 20 k, 50 k, 100 k, 200 k, 500 k, 1 M, 2 M, 5 M, 10 M, 20 M, 50 M,100 M,200 M,
500 M,1 G
Tap [Any] to enable it, and then tap [Points], which allows you to enter the number of points in 100
increments.
When the real-time saving is set to [On], you cannot specify the recording length in the [Points] box. Choose
[Save], and enter the recording length in the [Recording time] box. (p. 107)
The maximum recording length you can set varies depending on the number of channels to be measured.
5
Tap the [Mode] box, and then choose a recording mode from the list.
Single Measures waveforms only once. Pressing the START key starts recording waveforms,
and then stops when the specied recording length of the waveforms have been
acquired.
RepeatMeasures waveforms repeatedly. Pressing the STOP key stops the measurement in
progress.
When you choose [Repeat] and set [Count] to [On], measurements repeat the number of times entered in
the [Count] box.
When [Realtime save] is set to [On], you can choose [Single] mode only.
6
Congure the overlay setting.
See “3.1 Overlaying New Waveforms With Previously Acquired Waveforms” (p. 52).
7
Tap the [Realtime save] button to set it to [On].
The instrument can record data in an optional storage device while measuring waveforms.
See “Real-time saving” (p. 106).
8
Conguring the memory division settings
The instrument can divide the internal memory into several blocks and store waveforms into them.
See “10 Memory Division Function” (p. 255).
HIOKI MR6000A966-03

7
Setting Measurement Conditions
Sampling rate setting guideline
Choose a sampling rate using the following table as a guideline.
Maximum display
frequency Sampling rate Maximum display frequency Sampling rate
8 MHz 200 MS/s 400 Hz 10 kS/s
4 MHz 100 MS/s 200 Hz 5 kS/s
2 MHz 50 MS/s 80 Hz 2 kS/s
800 kHz 20 MS/s 40 Hz 1 kS/s
400 kHz 10 MS/s 20 Hz 500 S/s
200 kHz 5 MS/s 8 Hz 200 S/s
80 kHz 2 MS/s 4 Hz 100 S/s
40 kHz 1 MS/s 2 Hz 50 S/s
20 kHz 500 kS/s 0.8 Hz 20 S/s
8 kHz 200 kS/s 0.4 Hz 10 S/s
4 kHz 100 kS/s 0.2 Hz 5 S/s
2 kHz 50 kS/s 0.08 Hz 2 S/s
800 Hz 20 kS/s 0.04 Hz 1 S/s
If the instrument plots false waveforms (aliasing)
If a measured signal oscillates at a higher frequency compared to the sampling rate you chose, the
instrument may plot false waveforms oscillating at a frequency lower than that of the actual signal
once the signal frequency reaches a certain level. This phenomenon is called aliasing.
Actual input
signal
Sampling interval
: Sampled points
Observed
waveform
A sampling interval longer than the cycle of the
input signal causes aliasing.
To plot a sign wave that allows you to observe the peaks without any aliasing, the instrument needs
to sample the waveform at a minimum of 25 points per cycle.
To set the sampling rate automatically
See “3.7 Measuring Signals With the Auto-range Setting” in the Quick Start Manual.
Measurement Method
HIOKI MR6000A966-03

8
Setting Measurement Conditions
Update rate of each module
The data refresh rate is not allowed to exceed the maximum sampling rate of each module.
The instrument measures the same data until the data gets updated, causing the instrument to plot
a stair-step waveform.
In addition, even though the instrument measures the same signal simultaneously, values may vary
due to differences in the sampling rate, frequency range, and frequency characteristics of modules.
Modules Maximum sampling rate
or data update rate Reference
Model 8966 Analog Unit 20 MS/s (50 ns) –
Model 8967 Temp Unit Depends on the data refresh setting. p. 66
Model 8968 High Resolution Unit 1 MS/s (1 µs) –
Model U8969 Strain Unit 200 kS/s (5 µs) –
Model 8970 Freq Unit Depends on the setting. p. 70
Model 8971 Current Unit 1 MS/s (1 µs) –
Model 8972 DC/RMS Unit Depends on the response setting. p. 75
Model 8973 Logic Unit 20 MS/s (50 ns) –
MR8990
Digital Voltmeter Unit Depends on the NPLC setting. p. 76
Model U8974 High Voltage Unit Depends on the response setting. p. 78
Model U8975 4ch Analog Unit 5 MS/s (200 ns) –
Model U8976 High Speed Analog Unit 200 MS/s (5 ns) –
Model U8977 3CH Current Unit 5 MS/s (200 ns) –
Model U8978 4CH Analog Unit 5 MS/s (200 ns) –
U8979 Charge Unit 200 kS/s (5 µs) –
HIOKI MR6000A966-03

9
Setting Measurement Conditions
Using the envelope
> [Status] > [Condition]
1
2
3
1
Under [Measurement method], tap [Envelope] to use the envelop.
NormalDoes not use the envelope.
Envelope Uses the envelope.
• What is Normal?
The instrument records data at the specied sampling rate.
• What is Envelope?
At the specied recording interval, the instrument records the maximum and minimum values among data
points sampled within each specied recording interval by sampling an input signal at an over-sampling rate*
of 100 MS/s. Hence, even though a relatively longer recording interval is specied, peaks of uctuations can
be recorded without being missed.
*: Over-sampled data (indicated by blue dots in the gure) are not saved.
• Values to be acquired using the envelope
Maximum
Minimum
Recording interval
Oversampling interval (10 ns)
: Over-sampled data
: Stored data (the maximum and
minimum values)
: Waveform shown on the screen
A set of sampled data acquired using the envelope consists of two values: the maximum value and the
minimum value. These values are taken from the measured values acquired by sampling an input signal at an
over-sampling rate during the recording interval chosen in the [Sampling] box. The screen displays a vertically
wide waveform line. When saved in an external storage device, the data set that consists of the maximum and
minimum values is stored for a single instance of measurement.
Measurement Method
HIOKI MR6000A966-03

10
Setting Measurement Conditions
2
Tap the [Sampling] box, and then choose a sampling rate from the list.
The following are the sampling rates you can choose when the envelope is used.
10 MS/s, 5 MS/s, 2 MS/s, 1 MS/s, 500 kS/s, 200 kS/s, 100 kS/s, 50 kS/s, 20 kS/s, 10 kS/s,
5 kS/s, 2 kS/s, 1 kS/s, 500 S/s, 200 S/s, 100 S/s, 50 S/s, 20 S/s, 10 S/s, 5 S/s, 2 S/s, 1 S/s,
30 S/min, 12 S/min, 6 S/min, 2 S/min, 1 S/min
3
Tap the [Points] box, and then from the list, choose an option for the number of points to be
measured.
2.5 k, 5 k, 10 k, 20 k, 50 k, 100 k, 200 k, 500 k, 1 M, 2 M, 5 M, 10 M, 20 M, 50 M,100 M,200 M,
500 M,1 G
Tap [Any] to enable it, and then tap the [Points] box, which allows you to enter the number of points in 100
increments.
When the real-time saving is set to [On], you cannot specify the recording length in the [Points] box. Choose
[Save], and enter the recording length in the [Recording time] box. (p. 107)
The maximum recording length you can specify varies depending on the number of channels to be measured.
HIOKI MR6000A966-03

11
Conguring the Input Channel Settings
1.3 Conguring the Input Channel Settings
Congure the settings of the analog and logic channels.
> [Channel]
Operation available on the [Channel] screen
• Adding a comment to each channel
• Setting measurement conditions for each channel
• Specifying the display method setting for waveforms
• Converting measured values into physical quantities and displaying them
When a CAN/LIN interface is connected, the [UNIT/CAN] selector box appears.
To congure the input channel settings, select [UNIT].
Measurement Method
HIOKI MR6000A966-03

12
Conguring the Input Channel Settings
Channel setting procedure
Analog channels (CH1 through CH32) setting procedure
Conguring the input settings
Choose a measurement mode. (p. 13)
Choose a measurement range for each measurement target. (p. 14)
Convert input values (scaling function). (p. 15)
Choose an input coupling method. (p. 15)
Choose a low-pass lter cutoff frequency (if noise is present). (p. 15)
Conguring the display settings
Choose a waveform display color. (p. 15)
Convert input values (scaling function). (p. 15)
Logic channels (Model 8973 Logic Unit) setting procedure
Conguring the display settings
Choose a logic recording width. (p. 17)
Specify the display position of the waveform. (p. 17)
Choose a waveform display color. (p. 17)
When the sheet display format is set to XY composite waveforms or FFT waveforms, no logic waveforms are
displayed.
HIOKI MR6000A966-03

13
Conguring the Input Channel Settings
Analog channels
For details on conguring each module setting, refer to “3.7 Conguring Module-Specic Settings”
(p. 65).
> [Channel] > each module (UNIT)
4
8
12
3
5
6
The instrument displays the waveform screen during
measurement.
When the instrument does not perform measurement, it
displays the presently inputted waveforms on the monitor.
9
9
9
10
7
8
1
Tap the [Use] button to set it to [On] or [Off].
OnMeasures waveforms through this module.
Off Does not measure any waveform through this module.
Since no data is acquired, the instrument displays or saves nothing.
2
Enter a comment in the [Comment] box.
Number of characters that can be entered: up to 40
3
Tap the [Mode] box, and then choose a measurement mode from the list.
VoltageMeasures a waveform in voltage mode.
Temperature Measures a waveform in temperature mode.
Selectable modes vary depending on the installed modules.
See “3.7 Conguring Module-Specic Settings” (p. 65).
Measurement Method
HIOKI MR6000A966-03

14
Conguring the Input Channel Settings
4
Tap the [Range (f.s.)] box, and then choose a measurement range from the list.
The value of the range represents its maximum displayable value (f.s.).
See the following table for the full-scale resolution of each module.
If the input voltage exceeds the measurable range (overrange occurs), change the measurement range to one
with a lower sensitivity.
After changing measurement ranges, check values including level, upper, lower of the trigger, search, and
numerical calculation functions.
Modules Resolution (LSB)
Model 8966 Analog Unit, Model 8971 Current Unit, Model 8972 DC/RMS Unit 2,000
Model 8967 Temp Unit 20,000
Model 8968 High Resolution Unit, Model U8974 High Voltage Unit, Model U8975 4ch
Analog Unit, Model U8977 3CH Current Unit, Model U8978 4CH Analog Unit 32,000
Model U8976 High Speed Analog Unit 1,600
Model U8969 Strain Unit, Model U8979 Charge Unit 25,000
Model 8970 Freq Unit (Power frequency mode) 2,000
Model 8970 Freq Unit (Count mode) 40,000
Model 8970 Freq Unit (Frequency mode, rotation speed mode, duty ratio mode,
pulse width mode) 10,000
Model MR8990 Digital Voltmeter Unit 1,000,000
*: For the Model 8967 Temp Unit, the valid range varies depending on the thermocouples. For more
information about resolution, refer to “Model 8967 Temp Unit” in “5.2 Specications of the Options” in the
Quick Start Manual.
5
Congure the input coupling, low-pass lter, and probe ratio settings.
Tapping the area that includes [Coupling] allows the setting dialog box to appear.
(1)
(2)
(3)
HIOKI MR6000A966-03
