Hioki FT6031-50 User manual

EN
FT6031-50
EARTH TESTER
Instruction Manual
July 2020 Edition 1
FT6031B961-00 20-07H
EN
FT6031-50
EARTH TESTER
Instruction Manual
July 2020 Edition 1
FT6031B961-00 20-07H
HIOKI FT6031B961-00

HIOKI FT6031B961-00

i
Contents
Introduction.........................................................................1
Verifying Package Contents ..............................................5
Options (sold separately) ..................................................6
Safety Notes........................................................................7
Usage Notes......................................................................10
1 Overview 15
1.1 Overview and Features.................................15
Overview................................................................... 15
Features.................................................................... 15
1.2 Part Names and Functions...........................17
1.3 How to Use Carrying Case ...........................24
2 Preparing for Measurement 25
2.1 Attaching/Removing Protector ....................25
2.2 Inserting/Replacing Batteries ......................26
Procedure .................................................................28
2.3 Connecting the Z3210 Wireless Adapter
(Option) ..........................................................29
Procedure .................................................................30
3 Making Measurements 31
3.1 Measurement Procedure ..............................31
3.2 Inspecting Before Use ..................................32
3.3 Setting Up Comparator (PASS/FAIL Test) ...36
How to set up comparator......................................... 37
How to disable comparator .......................................37
FT6031B961-00
HIOKI FT6031B961-00

ii
Contents
3.4 Precise Measurement for Earth
Resistance
(Precise Measurement Method,
3-pole Method)..............................................38
Performing zero adjustment...................................... 40
Connecting measurement cables ............................. 41
Measuring earth resistance ......................................45
Stowing .....................................................................48
Continuous measurement function ...........................49
3.5 SimpliedMeasurementforEarth
Resistance
(SimpliedMeasurementMethod,
2-pole Method)...............................................51
Performing zero adjustment...................................... 54
Connecting test leads ...............................................55
Measuring earth resistance ......................................57
Stowing .....................................................................57
3.6 Cautions and Tips for Measurement ...........58
Distance between earthing electrodes...................... 58
Location to install auxiliary earthing rod.................... 59
How to insert/pull out auxiliary earthing rod.............. 60
3.7 Auto Power Save
(Power-saving Function) ..............................62
3.8 Wireless Communications F unction
(GENNECT Cross) ...........................................63
3.9 Activating the LCD All-on Display ...............65
3.10 Displaying the Serial Number ......................66
4 Specications 67
4.1 GeneralSpecications .................................67
4.2 Input, Output, and Measurement
Specications................................................69
HIOKI FT6031B961-00

iii
Contents
5 Maintenance and Service 77
5.1 Repair, Inspection, and Cleaning.................77
5.2 Troubleshooting ............................................79
5.3 Error Display..................................................83
6 Appendix 85
6.1 Earth Resistance ...........................................85
6.2 Measurement Principle.................................87
WarrantyCerticate
HIOKI FT6031B961-00

iv
Contents
HIOKI FT6031B961-00

1
Introduction
Introduction
Thank you for choosing the HIOKI FT6031-50 Earth Tester. To
ensure your ability to get the most out of this instrument over the
long term, please read this manual carefully and keep it available for
future reference.
Carefully read the separate document entitled “Operating
Precautions” before use.
Intended audience
This manual has been written for use by individuals who use the
instrument or provide information about how to use the instrument.
In explaining how to use the instrument, it assumes electrical
knowledge (equivalent of the knowledge possessed by a graduate
of an electrical program at a technical high school).
HIOKI FT6031B961-00

2
Introduction
Notations
Safety notations
In this document, the severity levels of risk and hazard are classied
as follows:
DANGER
Indicates an imminently hazardous situation
that will result in death of or serious injury to the
operator.
WARNING
Indicates a potentially hazardous situation that
may result in death of or serious injury to the
operator.
CAUTION
Indicates a potentially hazardous situation
that may result in minor or moderate injury to
the operator or damage to the instrument or
malfunction.
IMPORTANT
Indicates information or content that is particularly
important from the standpoint of operating or
maintaining the instrument.
Indicates a high-voltage hazard. Failure to verify
safety or improper handling of the instrument
could lead to an electric shock, burn, or death.
Indicates an action that must not be performed.
Indicates an action that must be performed.
HIOKI FT6031B961-00

3
Introduction
Symbols afxed to the instrument
Indicates the need for caution or the presence of danger. For
more information about locations where this symbol appears
on instrument components, see the "Usage Notes" section
(p. 10), warning messages listed at the beginning of operating
instructions , and accompanying the document entitled
"Operating Precautions."
Indicates a double-insulated device.
Indicates DC (Direct Current).
Indicates AC (Alternating Current).
Indicates the power button that switches the instrument between
on and off states.
Symbols for various standards
Indicates the Waste Electrical and Electronic Equipment
Directive (WEEE Directive) in EU member states.
Indicates that the product conforms to regulations required by
the EU Directive.
Other notations
*Instructs the reader to see below for additional information.
(p.) Indicates the page number to reference.
Fn Operation key names are highlighted in bold.
HIOKI FT6031B961-00

4
Introduction
Screen display
The instrument screen displays the alphanumeric characters as
follows:
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
Accuracy
Hioki expresses accuracy as error limit values specied in terms of
percentages relative to reading and full scale, and digits.
Reading
(Displayed value)
Refers to the displayed value of the measuring instrument.
The limit values of reading errors are expressed in percent
of reading (% of reading, % rdg).
Full scale
(Maximum displayable value)
Refers to the maximum displayable value of each
measurement range. The instrument has measurement
ranges whose values are equal to the maximum displayable
values. The limit values of full-scale errors are expressed in
percent of full scale (% of full scale, % f.s.).
Digits
(Resolution)
Refers to the smallest change in the indication on the digital
measuring instrument, i.e., the numeral one in the rightmost
place. The limit values of digit errors are expressed in terms
of digits (dgt).
HIOKI FT6031B961-00

5
Verifying Package Contents
Verifying Package Contents
When you open the package, carefully inspect the instrument to
ensure that everything is in good condition, and that no damage
occurred during shipping. Carefully check the accessories, panel
keys, and connectors. If the instrument seems to have been
damaged or does not work as specied, contact your authorized
Hioki distributor or reseller.
Check the package contents as follows.
FT6031-50
Accessories
L9840 Auxiliary Earthing Rod
(2 piece set) ×1
L9841 Measurement Cable
(alligator clip, black 4 m) ×1
L9842-11 Measurement Cable
(yellow 10 m, equipped with winder)
×1
L9842-22 Measurement Cable
(red 20 m, equipped with winder) ×1
C0106 Carrying Case ×1
Protector
AA alkaline battery (LR6) ×4
Instruction Manual
Operating Precautions (0990A907)
HIOKI FT6031B961-00

6
Options (sold separately)
Options (sold separately)
The options listed below are available for the instrument. To order an
option, please contact your authorized Hioki distributor or reseller.
Options are subject to change. Please check Hioki's website for the
latest information.
L9787 Test Lead
(for simplied measurement method,
indoor use only, red and black 1.2 m each)
L9840 Auxiliary Earthing Rod
(for precision measurement method, 2 pcs in 1 set)
(φ6 mm, entire length of 270 mm, straight
section 235 mm, material: stainless SUS304)
L9841 Measurement Cable
(for precision measurement method,
alligator clip, black 4 m)
L9842-11 Measurement Cable
(for precision measurement method,
yellow 10 m, equipped with winder)
L9842-22 Measurement Cable
(for precision measurement method,
red 20 m, equipped with winder)
L9843-51
Measurement Cable
(for precision measurement method,
yellow 50 m, equipped with at cable winder)
L9843-52
Measurement Cable
(for precision measurement method,
red 50 m, equipped with at cable winder)
L9844 Measurement Cable
(for earthing terminal board, alligator clip,
3 cables in 1 set, red/yellow/black 1.2 m each)
9050 Earth Nets
(2 sheets in 1 set, 300 mm × 300 mm)
C0106 Carrying Case
Z3210 Wireless Adapter
HIOKI FT6031B961-00

7
Safety Notes
Safety Notes
This instrument is designed to conform to IEC 61010 Safety
Standards, and has been thoroughly tested for safety prior to
shipment. However, using the instrument in a way not described in
this manual may negate the provided safety features.
Carefully read the following safety notes before using the
instrument.
DANGER
Mishandling during use could result in injury or death,
as well as damage to the instrument. Familiarize
yourself with the instructions and precautions in this
manual before use.
WARNING
Electricity can potentially cause serious events such
as an electric shock, heat generation, re, and an arc
ash due to a short-circuit. If you have not used any
electrical measuring instruments before, you should
be supervised by a technician who has experience in
electrical measurement.
HIOKI FT6031B961-00

8
Safety Notes
Measurement categories
To ensure safe operation of measuring instruments, IEC 61010
species the measurement categories, which classies testing and
measuring circuits into three categories according to the types of
mains circuits to which they are intended to be connected.
DANGER
•Do not use a measuring instrument for
measurements on a mains circuit that exceeds the
range of the measurement category rated for the
instrument. Failure to observe this can cause a
severe accident.
•Do not use a measuring instrument without a
measurement category rating for measurements on
a mains circuit. Failure to observe this can cause a
severe accident.
This instrument conforms to the safety requirements for CAT II 300 V,
CAT III 150 V, CAT IV 100 V measuring instruments.
Measurement category II (CAT II)
Applicable to test and measuring circuits connected directly to
utilization points (socket outlets and similar points) of the low-
voltage mains installation.
Example: Measurements on household appliances, portable tools,
and similar equipment, and on the consumer side only
of socket-outlets in the xed installation.
HIOKI FT6031B961-00

9
Safety Notes
Measurement category III (CAT III)
Applicable to test and measuring circuits connected to the
distribution part of the building’s low-voltage mains installation.
Example: Measurements on distribution boards (including
secondary meters), photovoltaic panels, circuit breakers,
wiring, including cables, bus-bars, junction boxes,
switches, socket-outlets in the xed installation, and
equipment for industrial use and some other equipment
such as stationary motors with permanent connection to
the xed installation.
Measurement category IV (CAT IV)
Applicable to test and measuring circuits connected at the source
of the building’s low-voltage mains installation.
Example: Measurements on devices installed before the main fuse
or circuit breaker in the building installation.
T Outlet
CAT II
Internal Wiring
Distribution Panel
Service Entrance
Service Drop
CAT IV
Power Meter
CAT III
Fixed Installation
HIOKI FT6031B961-00

10
Usage Notes
Usage Notes
Observe the following precautionary information to ensure that the
instrument can be used safely and in a manner that allows it to
perform as described in its specications.
Use of the instrument should conrm not only to its specications,
but also to the specications of all accessories, options, batteries,
and other equipment in use.
Verifying before usage
DANGER
If the test lead or the instrument is damaged, there
is a risk of an electric shock. Perform the following
inspection before use:
•Check that the insulation of the test leads are
neither ripped nor torn and that no metal parts
are exposed. Using the instrument under such
conditions could result in an electric shock. Replace
the test leads with those specied by Hioki.
•Check the instrument for any damage that may have
occurred during storage or shipping, and perform
functional checks before use.
HIOKI FT6031B961-00

11
Usage Notes
Use environment of the instrument
WARNING
Installing the instrument in inappropriate locations
may cause a malfunction of instrument or may give
rise to an accident. Avoid the following locations that
are:
•Exposed to direct sunlight or high temperatures
•Exposed to corrosive or combustible gases
•Exposed to strong electromagnetic elds or
electrostatic charges
•Near induction heating systems (such as high-
frequency induction heating systems and IH
cooking equipment)
•Susceptible to vibration
•Exposed to water, oil, chemicals, or solvents
•Exposed to high humidity or condensation
•Exposed to high concentrations of dust particles
CAUTION
• Do not place the instrument on an unstable or uneven
surface. Doing so could cause the instrument to fall
or turn over, causing bodily injury or damage to the
instrument.
• Do not place the instrument on an unstable or uneven
surface. Doing so could cause the instrument to fall
or turn over, causing bodily injury or damage to the
instrument.
HIOKI FT6031B961-00

12
Usage Notes
The protection rating for the enclosure of the instrument (based on
EN60529) is IP65/67*.
CAUTION
Although the instrument has a dust-proof, jet-proof and
waterproof structure, it is not for completely shutting out
the water intrusion into the inside. Please note that it can
be a cause of failure.
*IP65/IP67:
This indicates the degree of protection provided by
the enclosure of the device against use in hazardous
locations, entry of solid foreign objects, and the ingress of
water.
6: Protected against access to hazardous parts with wire
measuring 1.0 mm in diameter. Dust-proof type (Dust shall
not penetrate the enclosure.)
5: The equipment inside the enclosure is protected against
the harmful effects of water projected in jets against the
enclosure from any direction.
7: Watertight (Quantities of water that may harm the enclosure
when it is temporarily immersed in water shall not penetrate
the enclosure.)
For details on the operating temperature and humidity range, see
the specications. (p. 67)
HIOKI FT6031B961-00

13
Usage Notes
Handling the cables
CAUTION
To prevent cable damage, do not step on cables or pinch
them between other objects. Do not bend or pull on cables
at their base.
The ends of the L9787 Test Lead and L9840 Auxiliary
Earthing Rod are sharp. Be careful to avoid injury.
IMPORTANT
Use only the specied auxiliary earthing rod, cables, and test
leads. Using a non-specied cable may result in incorrect
measurements due to poor connection or other reasons.
Precautions during measurement
WARNING
If the instrument is used in locations where the rating
indicated on the instrument or cords is exceeded, the
instrument may be damaged resulting in personal
injury. Do not use the instrument in such locations.
See “Measurement categories” (p.8)
Precautions during shipment
Be sure to follow these precautions when transporting the
instrument:
• Remove accessories and optional equipment from the instrument
in order to avoid damage. Additionally, use the original packing
materials, and be sure to double box the instrument. Accidental
damage suffered in transit is not covered by the warranty.
• Attach a description of the issue when sending out your
instrument for repair.
HIOKI FT6031B961-00

14
Usage Notes
HIOKI FT6031B961-00
