HOLT ADK-5200 User manual

QSG-5200 Rev. A Holt Integrated Circuits
ADK-5200
Quick Start Guide:
HI-5200 10Base-T/100Base-TX
Physical Layer Transceiver
April 2018

QSG-5200
2 Holt Integrated Circuits
REVISION HISTORY
Revision
Date
Description of Change
QSG-5200, Rev. New
02-09-18
Initial Release
Rev. A
04-23-18
Remove HI-5201 option

QSG-5200
3 Holt Integrated Circuits
Introduction
The Holt HI-5200 is a 10Base-T/100Base-TX physical layer transceiver with both MII and RMII MAC
interfaces. It utilizes a unique mixed-signal design to extend signaling distance while reducing power
consumption, and offers HP Auto MDI/MDI-X for reliable detection of and correction for crossover and
straight-through cables. The device comes in a 32-pin, lead-free QFN package and provides an ideal
solution for 10Base-T/100Base-TX applications that have limited PCB board space.
The HI-5200 ADK evaluation board, ADK-5200, provides a convenient platform to evaluate HI-5200
features. All device configuration pins are accessible either by jumpers, test points or interface
connectors on the board.
Figure 1. HI-5200 ADK Evaluation Board, ADK-5200

QSG-5200
4 Holt Integrated Circuits
Features
●Holt 10Base-T/100Base-TX Physical Layer Transceiver
●RJ-45 Jack for Fast Ethernet cable interface
●HP Auto-MDIX for automatic detection and correction for straight-through and crossover cables
●MII (Media Independent Interface) connector to interface with a MAC controller
●RMII (Reduced MII) option with external 50MHz system clock
●2 LED Indicators for status and activity
●Jumpers to configure strapping pins
●Manual Reset Button for quick reboot after re-configuration of strapping pins
Hardware Design Overview
Figure 2 shows a block diagram of the HI-5200 ADK evaluation board. It plugs into any industry standard
“Fast Ethernet” board with Ethernet MACs that expose the MII interface. Configuration of the HI-5200 is
accomplished through on-board jumper selections and/or by PHY register access via the MDC/MDIO
management pins of the MII Interface.
Other features include a RJ-45 Jack for “Fast Ethernet” cable connection, programmable LEDs for
reporting link status and activity, and a manual reset button for quick reboot after reconfiguration of
strapping pins.
The HI-5200 evaluation board receives +5V DC input power through its MII connector.
Figure 2. ADK-5200 Evaluation Board Block Diagram
10Base-T
100Base-TX
RJ45 Jack
Single Port
Magnetic
Module
TX / RX
Pairs
HI-5200PC
Config
Headers
Port
Status
LEDs
Config
Headers
Reset
Button
MII / RMII Port Connector
MII / RMII
Signals
Port
Status
LEDs
25 MHz
Crystal
Oscillator
MII Mode Only
RMII 50 MHz REF_CLK
LDO 3.3V
Regulator
5 VDC
Input
RMII Mode Only (From MAC)

QSG-5200
5 Holt Integrated Circuits
MII (Media Independent Interface) Default Configuration
The MII interface is defined by Clause 22 of the IEEE 802.3 Specification. The HI-5200 PHY evaluation
board receives power and accesses MII data and management information from the MII connector J1. In
MII mode, the PHY is clocked at 25 MHz. A crystal oscillator on the board provides the clock, or an
external 25MHz clock can be connected to the XI pin.
MII Management (MIIM) is conducted thru pins MDC (clock line) and MDIO (data line). MIIM allows
upper-layer devices to monitor and control the states of the HI-5200. An external device with
MDC/MDIO capability can read the PHY status or configure/write the PHY registers. The MIIM frame
format and timing information can be found in the HI-5200 Datasheet and in Clause 22 of the IEEE 802.3
Specification.
The HI-5200 PHY board has a bottom-side 50-pin connector J1 for MII connection. Table 1 lists the pin-
outs for the MII interface on connector J1.
Table 1. Connector J1 Fast Ethernet Port MII Pin Definition.
J1 Pin #
Signal
J1 Pin #
Signal
1
--
2
--
3
--
4
--
5
+5V
6
+5V
7
MDIO
8
GND
9
MDC
10
GND
11
RXD3
12
GND
13
RXS2
14
GND
15
RXD1
16
GND
17
RXD0
18
GND
19
RXDV
20
GND
21
RXCLK
22
GND
23
RXER
24
GND
25
TXER
26
GND
27
TXCLK
28
GND

QSG-5200
6 Holt Integrated Circuits
J1 Pin #
Signal
J1 Pin #
Signal
29
TXEN
30
GND
31
TXD0
32
GND
33
TXD1
34
GND
35
TXD2
36
GND
37
TXD3
38
GND
39
COL
40
GND
41
CRS
42
GND
43
+5V
44
+5V
45
--
46
--
47
--
48
--
49
--
50
--
RMII (Reduced Media Independent Interface) Configuration Option
The HI-5200 ADK PHY evaluation board can use its 50-pin male edge connector (J1) with some minor
board population changes to interface with RMII MACs. Like MII mode, the HI-5200 ADK PHY evaluation
board, ADK-5200, receives power and accesses RMII data and management information via connector J1
in RMII mode. In RMII mode, the 50MHz clock (from the MAC) is connected to the XI pin.
The HI-5200 ADK PHY evaluation board and MAC hardware devices can be configured to RMII mode and
interface with each other using the same J1 connector interface. The board changes to support RMII
mode are as follows:
1. Remove crystal circuit (Y1, C16, C17) and TXC clock termination (R6).
2. Populate R14 with 0 Ohm and R19 with 33 Ohm to connect HI-5200 RMII 50MHz reference clock
(provided by MAC side via J1 pin 27) to U1 pin 9 (XI input).
3. Select RMII mode by setting strapping pins CONFIG[2:0] to ‘001’.
These board changes can also be found in the HI-5200 ADK PHY evaluation board schematic diagram.

QSG-5200
7 Holt Integrated Circuits
Table 2 lists the pin outs for the RMII interface on connector J1.
Table 2. Connector J1 Fast Ethernet Port RMII Pin Definition.
J1 Pin #
Signal
J1 Pin #
Signal
1
--
2
--
3
--
4
--
5
+5V
6
+5V
7
MDIO
8
GND
9
MDC
10
GND
11
not used
12
GND
13
not used
14
GND
15
RXD1
16
GND
17
RXD0
18
GND
19
RXDV
20
GND
21
not used
22
GND
23
RXER
24
GND
25
not used
26
GND
27
REFCLK
28
GND
29
TXEN
30
GND
31
TXD0
32
GND
33
TXD1
34
GND
35
not used
36
GND
37
not used
38
GND
39
not used
40
GND
41
not used
42
GND

QSG-5200
8 Holt Integrated Circuits
J1 Pin #
Signal
J1 Pin #
Signal
43
+5V
44
+5V
45
--
46
--
47
--
48
--
49
--
50
--

QSG-5200
9 Holt Integrated Circuits
Jumper Setting & Definition
The HI-5200 ADK PHY evaluation board does not require any jumper for normal operation. At power-up,
the HI-5200 ADK PHY is configured using the chip’s internal pull-up and pull-down resistors with its
default strapping pin values. Jumpers are provided to override the default settings, allowing for quick
configuration and re-configuration of the board. To override the default settings, simply select and close
the desired jumper setting(s) and toggle the on-board manual reset button (S1) for the new setting(s) to
take effect.
The HI-5200 ADK PHY evaluation board jumper settings are defined in Table 3 below.
Table 3. HI-5200PC Evaluation Board Jumper Definitions.
Jumper
Definition
Open (default)
Closed
JP1
PHYAD0
1
0
JP2
PHYAD1
0
1
JP3
PHYAD2
0
1
Jumper
Definition
CONFIG[2:0]
Mode
JP4
CONFIG0
[open, open, open]
MII (default)
JP5
CONFIG1
[open, open, close]
RMII
JP6
CONFIG2
[close, open, open]
PCS Loopback
All other CONFIG[2:0] combinations are reserved, not used.
Jumper
Definition
Open (default)
Closed
JP7
Isolate Mode
Disabled
Enabled
JP8
Auto Negotiation
Enabled
Disabled
JP9
Forced Speed
100Base-TX
10Base-T
JP10
Forced Duplex
Half Duplex
Full Duplex

QSG-5200
10 Holt Integrated Circuits
Table 4 lists the pin strapping definitions for the HI-5200 ADK PHY evaluation board jumpers.
Table 4. HI-5200PC Pin Strapping Options on PHY Evaluation Board.
Jumper
U1 Pin #
Pin
Name
Pin Function
JP3
JP2
JP1
15
14
13
PHYAD2
PHYAD1
PHYAD0
The PHY address is latched at power-up / reset
and is configurable to any value from 1 to 7.
The default PHY address is 00001.
PHY address bits [4:3] are always set to 00.
JP6
JP5
JP4
18
29
28
CONFIG2
CONFIG1
CONFIG0
The CONFIG[2:0] pins are latched at power-up / reset and
are defined as follows:
CONFIG[2:0] = 000 MII Mode (default)
CONFIG[2:0] = 001 RMII Mode
CONFIG[2:0] = 100 PCS Loopback
All other CONFIG[2:0] combinations are reserved.
JP7
20
ISO
ISOLATE Mode
Pull-Up = Enable
Pull-Down = Disable (default)
At power-up / reset, the state of this pin is latched into
register 0 bit 10.
JP9
31
SPEED
SPEED Mode
Pull-Up = 100Mbps (default)
Pull-Down = 10Mbps
At power-up / reset, the state of this pin is latched into
register 0 bit 13 as the Speed Select, and is also latched
into register 4 (Auto Negotiation Advertisement) as the
Speed capability support.
JP10
16
DUPLEX
DUPLEX Mode
Pull-Up = Half Duplex (default)
Pull-Down = Full Duplex
At power-up / reset, the state of this pin is latched into
register 0 bit 8 as the Duplex Mode.
JP8
30
NWAYEN
Nway Auto-Negotiation Enable
Pull-Up = Enable Auto-Negotiation (default)
Pull-Down = Disable Auto-Negotiation
At power-up / reset, the state of this pin is latched into
register 0 bit 12.

QSG-5200
11 Holt Integrated Circuits
Test Point Definition
The HI-5200 ADK PHY evaluation board has six test points. They are defined in the following table.
Table 5. HI-5200PC PHY Evaluation Board Test Points.
Test Point
Description
TP1
Interrupt Signal (U1 pin 21) with external pull-up
TP2
Signal Ground
TP3
Signal Ground
TP20
+5VDC input DC voltage check
TP21
+1.8VDC core logic PLL voltage check
TP22
+3.3VDC IC supply voltage check
RJ-45 Ethernet Connector
The RJ-45 Connector (J2) connects to standard CAT-5 Ethernet cable to interface with 10Base-
T/100Base-TX Ethernet devices.
J2 also supports Auto-MDIX and Auto-Negotiation / Forced Modes.

QSG-5200
12 Holt Integrated Circuits
LED Indicators
The board has two LED indicators (LED0 and LED1). LED1 is connected to pin 31 and LED0 is connected
to pin 30 of the HI-5200PC (U1),
The two LEDs are programmable to LED mode ‘00’ or ‘01’ via register 1E (hex), bits [15:14], and are
defined in the following table.
Table 6. Definitions for HI-5200PC PHY Evaluation Board LEDs.
LED Mode
LED1 (U1 pin 31)
LED0 (U1 pin 30)
00
Speed
U1 Pin 31
State
LED State
Link /
Activity
U1 Pin 30
State
LED State
10BT
H
OFF
No Link
H
OFF
100BT
L
ON
Link
L
ON
-----------
-----------
-----------
Activity
Toggle
Blinking
01
Activity
U1 Pin 31
State
LED State
Link
U1 Pin 30
State
LED State
No Activity
H
OFF
No Link
H
OFF
Activity
L
ON
Link
L
ON
10
Reserved –Not Used
Reserved –Not Used
11
Reserved –Not Used
Reserved –Not Used

PCB Rev. A
P/N: HV032
Bill of Materials
HI-520X PC PQ
Evaluation Board
Item Qty
Description Reference Digikey P/N Mfg P/N
1 1
PCB, Bare, Evaluation Board N/A JetTech # 42169
2 7 Capacitor Cer 0.1uF 25V 10% X7R 0805
C4,C5,C7,C11, C12,C13,C15 399-1168-1-ND Kemet C0805C104K3RACTU
3 2
Capacitor Cer 22pF 50V COG 0805 SMD C16,C17 399-1113-1-ND Kemet C0805C220J5GACTU
4 1
Capacitor Cer 100pF 50V COG 0805 SMD C19 399-1122-1-ND Kemet C0805C101J5GACTU
5 2
Capacitor Cer 1000pF, 2KV Y5P Radial C14,C18 1252PH-ND Vishay S102K33Y5PP63K5R
6 1
Capacitor Cer 10uF 16V X5R 0805 SMD C8 399-8013-1-ND Kemet C0805C106M4PACTU
7 2
Capacitor Tant 10uF 16V 10% 6032 SMD C6,C9 399-3732-1-ND Kemet T491C106K016AT
8 1
Capacitor Tant 22uF 16V 10% 6032 SMD C3 399-3744-1-ND Kemet T491C226K016AT
9 2
Capacitor Tant 47uF 16V 20% 6032 C1,C2 399-8356-1-ND Kemet T491C476K016AT
10 2
Resistor 0, 1/8W 5% 0805 SMD R54,R55 Optional P0.0ACT-ND Panasonic ERJ-6GEY0R00V
11 10
Resistor 33, 1/8W 5% 0805 SMD R4-R9,R16,R17,R20,R21 P33ACT-ND Panasonic ERJ-6GEYJ330V
12 4
Resistor 49.9, 1/8W 1% 0805 SMD R10-R13 P49.9CCT-ND Panasonic ERJ-6ENF49R9V
13 4
Resistor 75, 1/8W 5% 0805 SMD R50,R51,R52,R53 P75ACT-ND Panasonic ERJ-6GEYJ750V
14 2
Resistor 220, 1/8W 5% 0805 SMD R22,R24 P220ACT-ND Panasonic ERJ-6GEYJ221V
15 4
Resistor 1K, 1/8W 5% 0805 SMD R23,R31,R32,R33, P1.0KACT-ND Panasonic ERJ-6GEYJ102V
16 8
Resistor 4.7K,1/8W 5% 0805 SMD R3,R18,R25-R30, P4.7KACT-ND Panasonic ERJ-6GEYJ472V
17 1
Resistor 6.49K, 1/8W 1% 0805 SMD R15 P6.49KCCT-ND Panasonic ERJ-6ENF6491V
18 2
Resistor 10K, 1/8W 5% 0805 SMD R1,R2 P10KACT-ND Panasonic ERJ-6GEYJ103V
19 1
Diode Gen 100V 300mA SOD 123 D1 1N4148W-FDICT-ND Diode Inc. 1N4148W-7-F
20 1
Ferrite Bead 31 Ohm 1206 SMD FB1 445-6170-1-ND TDK HF50ACB321611-T
21 2
Test Point, Black Insulator, 0.062" GND (TP2, TP3) 36-5011-ND Keystone 5011
22 1
Test Point, Red Insulator, 0.062" 3V3 (TP22) 36-5010-ND Keystone 5012
23 1
Test Point, Orange Insulator, 0.062" 5V (TP20) 36-5013-ND Keystone 5013
24 1
LED Green 0805 SMD LED1 160-1423-1-ND LiteOn LTST-C171GKT
25 1
LED Red 0805 SMD LED2 160-1178-1-ND LiteOn LTST-C171EKT
26 1
Header, Male 2x20, .1" Pitch JP1-JP10 S2012EC-20-ND Sullins PREC020DAAN-RC
27 10
Conn Shunt Gold JP1-JP10 S9001-ND Sullins SPC02SYAN
28 1Switch Tactile SPST-No 0.02A, 15V
S1 P19749CT-ND Panasonic EVP-BFAC1A000
29 1
Socket, 50 pin .8mm Edge Assembly J1 ERF8-025-05.0-L-DV-K Samtec ERF8-025-05.0-L-DV-K
30 1Con Mod 8P8C R/A Shield RJ45
J2 AE10387-ND Assman A-2004-2-4-LPS-N-R
31 110/100Base-T 1:1 Single Port 16Term, Gull SMD
T1 100B-1003X Arrow Pulse 100B-1003X
32 1Crystal 25Mhz 18pF Leaded HC49/US
Y1 XC1927-ND ECS-250-18-4X-DU
33 1IC Reg Linear 3.3V 500mA SOT23-5
U2 576-2756-1-ND Micro Chip MIC5216-3.3YM5-TR
34 1
HI-520X PQ & PC U1 Holt Inc. HI-520X PQ & PC
35 4
Bumper Cylin 0.312" Dia, 0.210" High, Blk Place at four corners SJ5747-0-ND 3M SJ61A11

1
1
2
2
3
3
4
4
5
5
D D
C C
B B
A A
TXEN_A
RXD3_A
RXD1_A
TXD2_A
LEDK0
TXD1_A
RXD2_A
RXER_A
RXD0_A
RXD1_A
RXD3_A
RXDV_A
LEDK0
RXD2_A
COL_A
CRS_A
LEDK1
CRS_A
RXDV_A
RSTN
INTRP_A
RXC_A
RXER_A
RXD0_A
COL_A
LEDK1
TXC_A
TXD3_A
TXD0_A
TXP
TXN
XO
XI
TXN
SIGNAL_GND
MDC_A
RXN
TXP
LEDK1
LEDK0
MDIO_A
RXP
TX+
RX+
TX-
RX-
RXN
CHASSIS_GND
TX+
TX-
RX+
RX-
CMR
CMT
CMT
RXP
CMR
1V8PLL
3V3A
3V3
3V3
3V3
3V3
5V03V3
3V3
1V8PLL3V3A
Title
Size Document Number Rev
Date: Sheet of
5200_EVAL.DSN
B
HI-5200PQ Evaluation Board
11Monday, April 23, 2018
Title
Size Document Number Rev
Date: Sheet of
5200_EVAL.DSN
B
HI-5200PQ Evaluation Board
11Monday, April 23, 2018
Title
Size Document Number Rev
Date: Sheet of
5200_EVAL.DSN
B
HI-5200PQ Evaluation Board
11Monday, April 23, 2018
STEWARD
HI1206N101R-00
Push
Button
Reset
9
CRS_DV
REF_CLK
Output
Input
18
TXD[1]
23
Output
24
Input
TX_EN
TXD[0]
External
MAC RMII Signals
RXD[1]
Type
Input
Name
RX_ER
CRSDV
Output
20
15
RXD[0]
RXD[0]
RXD[1] TXD[1]
Type
Input
REFCLK
Output
Output
TX_ER
Output
Input
TXD[0]
Input
25
Name
16
U1 Pin
Input
Output
Output
TX_EN
Input
HI-5200
PHY RMII Signals
Strapping Options (Described in HI-5200 Datasheet)
PHYAD0
ISO
CONFIG0
CONFIG2
CONFIG1
PHYAD1
SPEED
DUPLEX
NWAYEN
PHYAD2
RMII Mode (option)
The RMII signal connections between HI-5200
PHY and external MAC are shown in the table to
the right.
For RMII mode,
1. Remove crystal circuit (Y1, C16, C17) and TXC
termination (R6).
2. Populate R14 with 0 Ohm and R19 with 33
Ohms to connect 50MHz Reference Clock
(provided by the MAC side via J1 pin 27) to U1
pin 9 (XI input).
3. Select RMII mode by setting jumpers JP6:JP4
for signals CONFIG[2:0] to '001'.
4. Connect J2 (RMII Port) to board with RMII MAC .
1. HI-5200 has a Paddle Ground on bottom side of chip.
Refer to datasheet for mechanical dimensions.
3. Place components (Y1, C16, C17, C53, R14, R15) and (R10,
R11, R12, R13, C13, C15) close to respective pins of U1.
2. HI-5200 provides the 1.8V PLL supply at VDDPLL_1.8
(pin 2). Decouple 1V8PLL power rail as shown.
Notes:
Route both traces of each differential pair
as identical to each other as possible at 6mil
width/6mil parallel spacing, and at least 18
mils away from all other signals.
Place SIGNAL_GND return of C14
close to SIGNAL_GND at 5V input
power to board.
[01]
ACT
LED Mode
LINK
LED1
SPEED
[00]
LINK/ACT
LED0
MII / RMII Port
CRS
COL
TD3
TD2
TD1
TD0
TXEN
TXC
TXER
RXER
RXCLK
RXDV
RXD0
RXD1
RXD2
RXD3
Place R19 close to J1 pin 12.
DigiKey 399-3443-1-ND 1808
MOUNTED FAR SIDE,
AS SEEN FROM TOP.
(X-RAY VIEW)
+5V DC
Power
Input
Power_ON
Reset
Pulse H1102
HOLT INTEGRATED CIRCUITS
+
C8
10uF
+
C8
10uF
R28 4.7KR28 4.7K
R21 33R21 33
TP17TP17
TP3TP3
JP8 JUMPERJP8 JUMPER
R10
49.9
R10
49.9 R11
49.9
R11
49.9
R1 100KR1 100K
R32 1KR32 1K
S1
SW PUSHBUTTON
S1
SW PUSHBUTTON
1 2
3 4
JP9 JUMPERJP9 JUMPER
R8 33R8 33
C17
22pF
C17
22pF
TP7TP7
R23 1KR23 1K
TP14TP14
R52 75 R52 75
C5
0.1uF
C5
0.1uF
R20 33R20 33
FB1
FBEAD
FB1
FBEAD
12
TP4TP4
R27 4.7KR27 4.7K
C7
0.1uF
C7
0.1uF
JP10 JUMPERJP10 JUMPER
Y1
25MHz
Y1
25MHz
+
C2
47uF
+
C2
47uF
C4
0.1uF
C4
0.1uF
R31 1KR31 1K
J1
ERF8-025-05.0-L-DV-K
J1
ERF8-025-05.0-L-DV-K
VCC
5MDIO
7MDC
9
RX_DV
19 RX_CLK
21 RX_ER
23 TX_ER
25 TX_CLK
27 TX_EN
29 TXD0
31 TXD1
33 TXD2
35 TXD3
37 COL
39 CRS
41 VCC
43
VCC 6
NC 8
NC 10
NC 12
NC 14
NC 16
NC 18
NC 20
NC 22
NC 26
NC 30
NC 32
NC 34
NC 36
NC 38
NC 40
NC 42
VCC 44
VCC
1VCC 2
VCC
3
VCC
45 VCC
47 VCC
49
VCC 4
VCC 46
VCC 48
VCC 50
NC 28
NC 24
RXD0
17
RXD3
11 RXD2
13 RXD1
15
TP11TP11
+
C6
10uF
+
C6
10uF
R5 33R5 33
TP18TP18
TP2TP2
JP1 JUMPERJP1 JUMPER
R2
10K
R2
10K
R30 4.7KR30 4.7K
C14
1nF 2KV
C14
1nF 2KV
R33 1KR33 1K
R9 33R9 33
C53
100pF
C53
100pF
TP8TP8
R17 33R17 33
JP7 JUMPERJP7 JUMPER
R13
49.9
R13
49.9
JP6 JUMPERJP6 JUMPER
TP15TP15
JP2 JUMPERJP2 JUMPER
C12
0.1uF
C12
0.1uF
R29 4.7KR29 4.7K
U2
MIC5216-3.3BM5
U2
MIC5216-3.3BM5
VIN 1
EN 3
GND 2
BYP
4
OUT
5
R3
4.7K
R3
4.7K
+
C3
22uF
+
C3
22uF
TP5TP5
R4 33R4 33
U1
HI-5200PQ
U1
HI-5200PQ
GND
1VDDPLL_1.8
2VDDA_3.3
3RX-
4RX+
5TX-
6TX+
7XO
8
XI
9REXT
10 MDIO 11 MDC 12 RXD3 13 RXD2 14 RXD1 15 RXD0 16
VDDIO_3.3 17
RXDV 18
RXC 19
RXER 20
INTRP 21
TXC 22
TXEN 23
TXD0 24
TXD1 25 TXD2 26 TXD3 27
COL 28
CRS 29
LED0 30 LED1 31
RST# 32
JP4 JUMPERJP4 JUMPER
TP12TP12
R25 4.7KR25 4.7K
R7 33R7 33
R15
6.49K
R15
6.49K
C13
0.1uF
C13
0.1uF
R51 75R51 75
JP3 JUMPERJP3 JUMPER
J2
RJ-45 Jack
J2
RJ-45 Jack
8
7
6
5
4
3
2
1
9
10
TP19TP19
R22 220R22 220
R16 33R16 33
JP5 JUMPERJP5 JUMPER
R6 33R6 33
R53 75 R53 75
TP9TP9
+
C9
10uF
+
C9
10uF
R26 4.7KR26 4.7K
TP16TP16
R19 NCR19 NC
R50 75R50 75
TP1TP1
C16
22pF
C16
22pF
TP6TP6
R18
4.7K
R18
4.7K
D1
1N4148
D1
1N4148
1 2
T1
PM-6102
T1
PM-6102
1
2
3
6
8
7
16
15
14
11
10
9
LED1
Stacked Dual LED
LED1
Stacked Dual LED
1 2
3 4
TP13TP13
R12
49.9
R12
49.9
C15
0.1uF
C15
0.1uF
R24 220R24 220
R14
NC
R14
NC
+
C1
47uF
+
C1
47uF
TP10TP10
C11
0.1uF
C11
0.1uF
