Home Styles 20 05100 0002 User manual

Part List
Hardware List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8” Drill Bit
Refer to later page(s) of these
instructions for drawer assembly.
A.
Side Panel
1 pc.
B.
Side Panel
1 pc.
E.
Back Panel
3 pcs.
C.
Middle Panel
1 pc.
D.
Middle Panel
1 pc.
F.
Back Upright
2 pcs.
G.
Back Stretcher
1 pc.
H.
Back Stretcher
1 pc.
I.
Front Stretcher
1 pc.
K.
Front Upright
2 pcs.
Q.
Shelf
2 pcs.
L.
Fixed Shelf
1 pc.
M.
Base
1 pc.
O.
Wine Grid
2 pcs.
P.
Wine Grid
2 pcs.
R.
Door
1 pc.
S.
Door
1 pc.
N.
Leg
2 pcs.
T.
Drawer
3 pcs.
IMPORTANT
20 05100 Top carton is also needed for assembly.
20 05100 0002
Buffet
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Cam Lock
14 pcs. (+2 extra)
Cross Dowel
8 pcs. (+1 extra)
Cam Lock Screw
14 pcs. (+1 extra)
M3.5x25
Wood Screw (long)
24 pcs. (+1 extra)
M3.5x13
Wood Screw (short)
12 pcs. (+1 extra)
Adjustable Pin
8 pcs. (+2 extra)
M3.5x16
Wood Screw
for Back Panel
12 pcs. (+1 extra)
Handle
3 pcs.
Knob
2 pcs.
M6x35
Head Cap Bolt
4 pcs. (+1 extra)
M6x50
Head Cap Bolt (long)
8 pcs. (+1 extra)
M4x25
Machine Screw
8 pcs.
J.
Front Stretcher
1 pc.

Assembly Instructions 2/8
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench as the bolts may need to be tightened in the future.
Figure 1
Cam Lock Screw
LC
D
Cam Lock
STEP 2
Attach Middle Panels (C) and (D)
to Fixed Shelf (L) with Cam Locks.
(See Figure 2)
Figure 2
C
D
A
B
STEP 1
Insert Cam Lock Screws into pre-drilled holes
in Side Panels (A), (B) and Middle Panels (C), (D),
then tighten. (See Figure 1)

Assembly Instructions 3/8
G
H
E
F
Cross Dowel
Head Cap Bolt (long)
STEP 4
Attach Back Stretcher (G) to
unit with Cross Dowels
and Head Cap Bolts (long).
Figure 3
I
K
K
J
E
E
F
STEP 3
Attach Back Stretcher (H) to unit with Cross Dowels
and Head Cap Bolts (long). (See Figure 3)
Attach Back Uprights (F) to Back Stretcher (H).
Slide Back Panels (E) into position.
STEP 5
Attach Front Stretcher (J) to unit.
Attach Front Uprights (K) to unit.
Attach Front Stretcher (I) to unit.
Cross Dowel
Head Cap Bolt (long)

Assembly Instructions 4/8
A
B
Cam Lock
STEP 6
Attach Side Panels (A) and (B) to
unit with Cam Locks.
STEP 7
Attach Base (M) to unit with Cross Dowels
and Head Cap Bolts (long).
Attach Legs (N) to Base (M)
with Head Cap Bolts.
STEP 8
Place Top (U) upside down on a soft cloth.
Insert Cam Lock Screws into pre-drilled holes in Top (U), then tighten.
Cam Lock Screw
Head Cap Bolt (long)
Head Cap Bolt
N
U
N
Arrow label
Cam Lock
Cross Dowel
M

Assembly Instructions 5/8
Figure 4 Figure 5
Q
Q
R
S
Cam Lock
Adjustable Pin
STEP 10
Attach Top (U) to unit with Cam Locks.
Note: Arrow label indicates front of Top (U).
U
STEP 9
Turn unit to its’ upright position.
Insert Adjustable Pins into
side panels and middle panels
at desired level.
Place Shelves (Q) into position.
Attach Doors (R) and (S) to unit by
sliding door hinges into side panel
hinges. (See Figure 4)
Attach Knobs to Doors (R) and (S)
with Machine Screws. (See Figure 5)
Machine Screw
Knob

Assembly Instructions 6/8
STEP 13
Attach Handle with Machine Screws.
STEP 12
Slide Drawer Bottom (T5) into groove.
Attach Drawer Bottom (T5) to unit
with Wood Screws (short).
T5
T1.
Drawer Front
3 pcs.
T2.
Drawer Back
3 pcs.
T5.
Drawer Bottom
3 pcs.
Drawer (T)
STEP 11
Attach Drawer Front (T1) and Drawer
Back (T2) to Drawer Side (T3) with
Wood Screws (long).
Attach Drawer Side (T4) to unit with
Wood Screws (long).
Handle
T1
T2
T3
T4
Bottom
Roller at back
Wood Screw (long)
Machine Screw
Part List
T3.
Drawer Side
3 pcs.
T4.
Drawer Side
3 pcs.
Wood Screw (short)

Assembly Instructions 7/8
T
P
O
O
STEP 14
Slide Drawers (T) into position.
Slide Wine Grids (P) into
grooves of Fixed Shelf (L).
Slide Wine Grids (O) into unit.
STEP 15
Level unit by adjusting the adjustable
levelers on bottom of unit.
(See Figure 6)
Insert Wood Screws for Back Panel
into pre-drilled holes in unit,
then tighten.
Note: Unit must be level before
tightening these screws.
Wood Screw for Back Panel
P
T
T
Figure 6
L

Assembly Instructions 8/8
Hardware List
STEP 16
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
Pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at pre-drilled hole
at top of unit with Wood Screw.
Move unit back into place.
Slide Tip-over Restraint through
Bracket on wall and Bracket on unit.
(See Figure 7)
Put tie end of Tip-over Restraint into lock
end of Tip-over Restraint and pull until tight.
Figure 7
IMPORTANT
To help reduce the risk of the unit tipping over, the Tip-over Restraint must be installed following these instructions exactly.
Drill 3/8” hole in wall
Top of unit
Wood Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
Pre-drilled hole
at top of unit
Tie end
Lock end
Bracket at
top of unit
Tip-over
Restraint
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tip-over Restraint
1 pc. (+1 extra)
M3.5x40
Wall Screw
1 pc. (+1 extra)
M3.5x16
Wood Screw
1 pc. (+1 extra)

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319

U.
Top
1 pc.
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
IMPORTANT
For assembly see instructions in carton 20 05100 Buffet carton.
20 05100 0101
Solid Wood Top
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
