Home Styles 88 9100 001 C User manual

HARDWARE LIST
Head Cap Bolt
14 pcs. (+1 extra)
Hex Wrench
1 pc.
Pull Handle
2 pcs.
Machine Screw
for Pull Handle
4 pcs.
Wood Screw
for Caster
16 pcs. (+2 extra)
Adjustable Pin
8 pcs. (+2 extra)
Wood Plug
10 pcs.
(+2 extra)
Thai Patent Pending Numbers 077214
88 9100 001 C
Kitchen Cart (Natural Finish)
A.
Side Panel
1 pc.
PART LIST
B.
Side Panel
1 pc.
H.
Back Panel
3 pcs.
F.
Back Post
2 pcs.
E.
Front Post
2 pcs.
I.
Back Stretcher
1 pc.
J.
Front Stretcher
1 pc.
K.
Front Rail
3 pcs.
G.
Base
1 pc.
R.
Shelf
2 pcs.
L.
Side Rack
1 pc.
M.
Side Rack
1 pc.
O
Brush Chrome Pipes
3 pcs.
Q.
Round Arm
1 pc.
P.
Handle Arm
2 pcs.
D.
Middle Panel
1 pc.
C.
Middle Panel
1 pc.
N.
Base Rack
1 pc.
Tools Required For Assembly : Philips screwdriver
T.
Door
1pc.
S.
Door
1pc.
U.
KD. Drawer
3 pcs.
V.
KD. Drawer
1 pc.
(For Drawer U&V packed in
separate carton with hardware
and assembly instructions.)
Caster
two lock
two non-lock
4 pcs.
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed. Casual Attire For Today's Home

Assembly Instructions 2/3
STEP 1
STEP 2
STEP 3
G
D
G
HHH
K
K
K
CD
A
C
Attach 4 Casters to the underside of the
Base (G), put the 2 Casters with
lock in front as you first need to lock the
cart from moving. (See sticker in the bottom indicating front side)
Put the Front Rail (K) in between the
Middle Frame (C) and (D).
Attach the Side Panel (A) to the
side of the unit with Head Cap Bolts.
Slide the Back Panels (H) into place.
Attach the Back Post (F) and
Front Post (E) to the Middle Panel
(C) and (D).
Attach the assembled Middle Panel
(C) and (D) to the Base (G).
IMPORTANT
Do not tighten up all the screws until each part is properly assembled.
You should keep Hex Wrench in the safe place as you may need to
tighten up the Head Cap Bolts in the future.
F
C
E

STEP 5
STEP 4
STEP 6
STEP 7
Attach the Handle Arm (P) to the
Side Panel (B) with Head Cap Bolts.
Slide the Round Arm (Q) into place.
Attach the Back and Front
Stretcher (I), (J) to the
assembled unit with Head Cap Bolts.
Attach the Side Panel (B) to the other side
of the unit with Head Cap Bolts.
Assembly Instructions 3/3
J
B
I
N
O
O
O
P
A
CD
R
R
B
PQ
B
L
A
M
Attach the Side Rack (L) to the Side Panel (A)
with the Head Cap Bolts.
Attach the Brush Chrome Pipes (O) to the pre-drilled
holes of Side Rack (L).
Attach the Base Rack (N) to the Side Rack (L).
Attach the Side Rack (M) to the Side Panel (A),
using Head Cap Bolts.
Insert the Adjustable Pins into the Side
Panel (A), Middle Panel (C) and Side
Panel (B), Middle Panel (D) at the
desired level.
Place Shelf (R) into place.

Assembly Instructions
Unit Part List
U3.
Side Part
1 pc. for each
drawer.
U4.
Side Part
1 pc. for each
drawer.
U5.
Base Part
1 pc. for each
drawer.
U2.
Back Part
1 pc. for each
drawer.
U2
U2
U5
U5
U3
U4
U4
U4
U3
U3
U1
U1
U1
(Fig) 2
(Fig) 3
(Fig) 4
Assemble the Pull Handle
with Machine Screw on
the Front Part(U1).
(Fig)1
(Fig)2
(Fig)3
(Fig)4
Turn the assembled drawer over and slide the
Plywood Base Part (U5) into the grooves
on Side Parts (U3) and (U4). Be sure to push
the plywood all the way forward so it meets the
Front Part (U1).
HARDWARE LIST
Pull Handle
3 pcs.
Machine Screw
for Pull Handle
6 pcs.
1
Wood Screw /”
2
(for Bottom Part)
18 pcs.(+1 Extra)
Wood Screw 1”
(for Side Part)
24 pcs.(+1 Extra)
(Fig) 1
Insert the remaining (6) 1/2” screws
into the pre-drilled holes in Base Part
(U5), then tighten all screws
MAKE SURE ROLLER
IS ON THE BACK
* If you are missing any of these
parts, please contact our DMI
Customer Service Department
at 1-877-831-0319 or fax us at
1-800-755-2878.
U1.
Front Part
1 pc. for each
drawer.
88 9100 001 C
Drawer (U)
Assemble the Front Part (U1), Side Part (U3),
(U4) and Back Part (U2).
Using a Philips screw driver, insert 1” screws
into each of the 4 pre-drilled holes Side Part
of the (U3) and (U4), then tighten half way.

Assembly Instructions
Unit Part List
V3.
Side Part
1 pc.
V4.
Side Part
1 pc.
V5.
Base Part
1 pc.
V2.
Back Part
1 pc.
V2
V2
V5
V5
V3
V4
V4
V4
V3
V3
V1
V1
V1
(Fig) 2
(Fig) 3
(Fig) 4
Assemble the Pull Handle
with Machine Screw on
the Front Part(V1).
(Fig)1
(Fig)2
(Fig)3 (Fig)4
Turn the assembled drawer over and slide the
Plywood Base Part (V5) into the grooves
on Side Parts (V3) and (V4). Be sure to push
the plywood all the way forward so it meets the
Front Part (V1).
HARDWARE LIST
Pull Handle
1 pc.
Machine Screw
for Pull Handle
2 pcs.
1
Wood Screw /”
2
(for Bottom Part)
6 pcs.(+1 Extra)
Wood Screw 1”
(for Side Part)
8 pcs.(+1 Extra)
(Fig) 1
Insert the remaining (6) 1/2” screws
into the pre-drilled holes in Base Part
(V5), then tighten all screws
MAKE SURE ROLLER
IS ON THE BACK
* If you are missing any of these
parts, please contact our DMI
Customer Service Department
at 1-877-831-0319 or fax us at
1-800-755-2878.
V1.
Front Part
1 pc.
Assemble the Front Part (V1), Side Part (V3),
(V4) and Back Part (V2).
Using a Philips screw driver, insert 1” screws
into each of the 4 pre-drilled holes Side Part
of the (V3) and (V4), then tighten half way.
88 9100 001 C
Drawer (V)
