Home Styles 20 08001 0095 Quick start guide

Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver
20 08001 0095
Kitchen Cart
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
A.
Base
1 pc.
B.
Front Rail
1 pc.
C.
Front Rail
2 pcs.
D.
Back Rail
1 pc.
F.
Side Panel
1 pc.
G.
Middle Panel
1 pc.
H.
Middle Panel
1 pc.
I.
Side Panel
1 pc.
E.
Back Rail
1 pc.
J.
Back Upright
2 pcs.
K.
Back Panel
3 pcs.
L.
Door
2 pcs.
Refer to later page(s) of these
instructions for drawer assembly.
Q.
Drawer
3 pcs.
O.
Tower Bar
2 pcs.
M.
Arm
2 pcs.
N.
Arm
2 pcs.
P.
Shelf
4 pcs.
20 09100 Top carton is also need for assembly.

Hardware List
Cam Lock Screw
38 pcs. (+2 extra)
Cam Lock
26 pcs. (+6 extra)
Dowel
28 pcs. (+1 extra)
Adjustable Pin
16 pcs. (+1 extra)
Hinge
6 pcs.
Cam Lock (small)
12 pcs. (+2 extra)
M3x38
Wood Screw (long)
10 pcs. (+1 extra)
M3x25
Wood Screw (short)
12 pcs. (+1 extra)
M4x16
Wood Screw for Hinge
36 pcs. (+1 extra)
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Flat Washer
24 pcs. (+1 extra)
Spring Washer
24 pcs. (+1 extra)
M6x15
Head Cap Bolt (short)
20 pcs. (+1 extra)
Bracket
4 pcs.
Locking Caster
2 pcs.
M6x30
Head Cap Bolt (long)
8 pcs. (+1 extra)
M6x20
Head Cap Bolt
4 pcs. (+1 extra)
Assembly Instructions 2/9
Non-Locking Caster
3 pcs.

Assembly Instructions 3/9
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
Keep Hex Wrench as the bolts may need to be tightened in the future.
Figure 1
A
F
I
G
H
D
E
J
J
Cam Lock Screw
Cam Lock Screw
STEP 1
Insert Cam Lock Screws into pre-drilled
holes in Base (A), Back Rails (D), (E),
Side Panels (F), (I), Middle Panels (G), (H)
and Back Uprights (J), then tighten.
(See Figure 1)

Assembly Instructions 4/9
STEP 2
Insert Dowels into pre-drilled
holes in Back Uprights (J),
then attach Back Rail (D) to
Back Uprights (J) with Cam Locks.
(See Figure 2)
Slide Back Panel (K) into position.
Attach Back Rail (E) to unit
with Cam Locks.
Slide Back Panels (K) into position.
K
K
K
D
E
J
J
Cam Lock
Dowel
STEP 3
Insert Dowels into pre-drilled
holes in Front Rails (C).
Attach Middle Panels (G) and (H)
to Front Rails (C) with Cam Locks.
Figure 2 G
H
Dowel
Cam Lock
C
C
STEP 4
Insert Dowels into pre-drilled
holes in units from Steps 2 and 3.
Attach unit from Step 3 to unit
from Step 2 with Cam Locks.
Attach Front Rail (B) to unit
with Wood Screws (long).
(See Figure 3)
Figure 3
B
Wood Screw (long)
Cam Lock
Dowel

Assembly Instructions 5/9
Cam Lock
Dowel
STEP 5
Insert Dowels into
pre-drilled holes in unit.
Attach Side Panels (F) and (I)
to unit with Cam Locks.
F
I
Wood Screw (long)
Cam Lock
Dowel
STEP 6
Turn unit upside down.
Insert Dowels into pre-drilled
holes in unit.
Attach Base (A) to unit with
Cam Locks and Wood Screws (long).
A

Assembly Instructions 6/9
N
M
M
N
O
O
Head Cap Bolt (long)
STEP 8
Turn unit over to
its upright position.
Attach Arms (M) to unit
with Head Cap Bolts (long).
Slide Towel Bars (O) into
pre-drilled holes in Arms (M).
Attach Arms (N) to unit
with Head Cap Bolts (long).
Figure 4
STEP 7
Attach Casters to unit
with Flat Washers, Spring Washers
and Head Cap Bolts (short),
with Locking Casters at front,
tightening bolts only halfway.
(See Figure 4)
Tighten all Head Cap Bolts (short).
Flat Washer
Spring Washer
Head Cap Bolt (short)
Non-Locking Caster
Locking Caster

Assembly Instructions 7/9
STEP 9
Attach Hinges to Doors (L)
with Wood Screws for Hinge
into pre-drilled holes, then tighten.
(See Figure 5)
Wood Screw for Hinge
Hinge
Figure 5
STEP 10
Attach Doors (L) to unit with
Wood Screws for Hinge.
(See Figure 6)
Insert Adjustable Pins into
side panels and middle panels
at desired level.
(See Figure 7)
Place Shelves (P) into position.
Figure 6
Figure 7
Hinge
Wood Screw for Hinge
Adjustable Pin
L
L
L
L
P
P
P
P

Assembly Instructions 8/9
Q1.
Drawer Front
3 pcs.
Q2.
Drawer Back
3 pcs.
Q3.
Drawer Side
3 pcs.
Q4.
Drawer Side
3 pcs.
Q5.
Drawer Bottom
3 pcs.
Drawer (Q)
STEP 11
Attach Drawer Sides (Q3) and
(Q4) to Drawer Back (Q2) with
Wood Screws (short).
Wood Screw (short)
Q2
Q3
Q4
Cam Lock (small)
Cam Lock Screw
STEP 12
Slide Drawer Bottom (Q5) into groove. Q5
Part List
STEP 13
Insert Cam Lock Screws into pre-drilled
holes in Drawer Front (Q1), then tighten.
Attach Drawer Front (Q1) to
unit with Cam Locks (small).
Q1

Assembly Instructions 9/9
Figure 9 Figure 10
UP Front Back
Down
Figure 11
Left
Right
STEP 16
If needed, adjust doors up or down by removing the front Wood Screws for Hinge and
loosening slightly the back Wood Screws for Hinge from side panel, adjusting doors up
or down and re-installing screws. (See Figure 9).
If needed, adjust doors left to right. (See Figure 10)
If needed, adjust doors front to back. (See Figure 11)
Q
Figure 8
STEP 15
Slide Drawers (Q) into position.
Note: Supports (V) and Head Cap Bolts (middle)
from 20 09100 Top carton are not used in
this assembly.
Q
Q
W
Flat Washer
Spring Washer
Head Cap Bolt
Bracket
STEP 14
Attach Top (W) to unit with Brackets,
Flat Washers, Spring Washer
and Head Cap Bolts,
tightening bolts only halfway.
(See Figure 8)
Tighten all Head Cap Bolts.

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
