Home Styles 5050-13 User manual

M6x19
Head Cap Bolt
14 pcs. (+1 extra)
Hex Wrench
1 pc.
M4x32
Wood Screw (long)
16 pcs. (+1 extra)
M6x45
Headless Bolt
2 pcs. (+1 extra)
M4x12
Wood Screw (short)
12 pcs. (+1 extra)
Flat Washer
12 pcs. (+1 extra )
Spring Washer
12 pcs. (+1 extra )
M6x45
Tapered Head Cap Bolt
4 pcs. (+1 extra)
Bracket
2 pcs.
Hardware List
Part List
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8” Drill Bit
5050-13
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Media Tower
C.
Side Frame
2 pcs.
B.
Rail
4 pcs.
A.
Cabinet
1 pc.
E.
Shelf
2 pcs.
D.
Shelf
2 pcs.
G.
Back Frame
1 pc.
Small Hex Wrench
1 pc.
F.
Side Frame
2 pcs.
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460

Assembly Instructions 2/7
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench as the bolts may need to be tightened in the future.
STEP 1
Attach Rails (B) to Side Frames (C) with Flat Washers, Spring Washers and Head Cap Bolts,
tightening bolts only halfway. (See Figure 1)
Tighten all bolts.
Flat Washer
Spring Washer
Head Cap Bolt
CBFigure 1
STEP 2
Slide Shelf (D) into unit.
Attach Shelf (D) to unit
with Wood Screws (long).
Wood Screw (long)
C
C
B
B
B
B
D

Assembly Instructions /37
STEP 3
Slide Shelf (D) into unit.
Attach Shelf (D) to unit
with Wood Screws (long). D
Wood Screw (long)
STEP 4
Remove drawer from Cabinet (A).
Rotate drawer stop into position.
(See Figure 2)
Figure 2
Drawer Stop
A

Assembly Instructions /47
STEP 6
Turn unit over to its upright position.
Remove handle on inside of drawer
and attach to outside of drawer with
machine screws.
Slide drawer into position.
A
STEP 5
Place Cabinet (A) upside down
on a soft cloth.
Attach unit to Cabinet (A) with
Flat Washers, Spring Washers and
Head Cap Bolts.
Insert Wood Screws (long) into
pre-drilled holes unit.I
Head Cap Bolt
Spring Washer
Flat Washer
Machine Screw
Handle
Wood Screw (long)

STEP 7
Attach Side Frame (F) and Shelves (E)
to Back Frame (G) with
Tapered Head Cap Bolts
and Wood Screws (short).
Assembly Instructions /57
Wood Screw (short)
E
E
STEP 8
Attach Side Frame (F) to unit
with Tapered Head Cap Bolts
and Wood Screws (short).
Insert Headless Bolts into
pre-drilled holes in unit.
Tapered Head Cap Bolt
Wood Screw (short)
Tapered Head Cap Bolt
Headless Bolt
G
F
F

STEP 9
Place upper unit onto base unit.
Attach Brackets to unit with Head Cap Bolts, Tapered Head Cap Bolts and Wood Screws (short).
(See Figure 3)
Level unit by adjusting the adjustable levelers on bottom of unit.
(See Figure 4)
Bracket
Head Cap Bolt
Tapered Head Cap Bolt
Wood Screw (short)
Figure 4
Figure 3
Assembly Instructions /67

Assembly Instructions /77
STEP 10
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at pre-drilled hole
at top of unit with Machine Screw.
Move unit back into place.
Slide Tipover Restraint through
Bracket on wall and Bracket on unit.
(See Figure 5)
Put tie end of Tipover Restraint into lock
end of Tipover Restraint and pull until tight.
Figure 5
IMPORTANT
To help reduce the risk of the unit tipping over, the Tipover Restraint must be installed following these instructions exactly.
Machine Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
Pre-drilled hole
at top of unit
Tie end
Lock end
Bracket at
top of unit
Tipover
Restraint
Hardware List
M3.5x40
Wall Screw
1 pc. (+1 extra)
M4x10
Machine Screw
1 pc. (+1 extra)
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tipover Restraint
1 pc. (+1 extra)
Drill 3/8” hole in wall
Top of unit
Drill 3/8” hole in wall

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
homestyles will provide replacements free of charge for missing or damaged parts within 1 year of purchase.
Digital images of the defective parts may be required. If the product was not purchased from an authorized retailer,
homestyles is under no obligation to provide replacement parts. Parts are not available for fully assembled items nor
are parts available for sale. Replacements for missing or damaged parts may be requested via contact info below.
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460

Flat Washer
24 pcs. (+1 extra)
Spring Washer
24 pcs. (+1 extra)
Hardware List
Part List
5050-06
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Media Console
D.
Side Frame
2 pcs.
B1.
Stretcher
1 pc.
B.
Stretcher
3 pcs.
C.
Stretcher
1 pc.
A.
Cabinet
1 pc.
F.
Drawer Front
2 pcs.
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8” Drill Bit
Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
M6x19
Head Cap Bolt
24 pcs. (+1 extra)
Handle
2 pcs.
M4x28
Machine Screw
4 pcs. (+1 extra)
Dowel
4 pcs. (+1 extra)
M3x25
Wood Screw for drawer
12 pcs. (+1 extra)
E.
Shelf
2 pcs.
G.
Drawer Box
2 pcs.
M4x32
Wood Screw
27 pcs. (+1 extra)
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460

IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench in a safe place as the bolts may need to be tightened up in the future.
Figure 2Figure 1
Flat Washer
Spring Washer
Head Cap Bolt
Assembly Instructions 2/5
Wood Screw
STEP 1
Attach Stretchers (B), (B1) and (C) to
Side Frame (D) with Flat Washers,
Spring Washers and Head Cap Bolts,
tightening bolts only halfway.
(See Figure 1)
Attach Side Frame (D) to unit with
Flat Washers, Spring Washers and
Head Cap Bolts, tightening bolts only
halfway.
Tighten all Head Cap Bolts.
STEP 2
Slide upper Shelf (E) into unit.
Attach upper Shelf (E) to unit with Flat Washers, Spring Washers,
Head Cap Bolts and Wood Screws. (See Figure 2)
Flat Washer
Spring Washer
Head Cap Bolt
E
D
D
B
B
B
B1
C

Flat Washer
Spring Washer
Head Cap Bolt
Wood Screw
Assembly Instructions 3/5
STEP 3
Slide lower Shelf (E) into unit.
Attach lower Shelf (E) with Flat Washers, Spring Washers, Head Cap Bolts and Wood Screws.
STEP 4
Place Cabinet (A) upside down on a soft cloth.
Attach unit to Cabinet (A) with Flat Washers,
Spring Washers, Head Cap Bolts and Wood Screws.
E
Head Cap Bolt
Spring Washer
Flat Washer
Wood Screw
A

Assembly Instructions 4/5
Figure 3
Machine Screw
Handle
STEP 6
Turn unit over to its upright position.
Attach Handles to drawers with Machine Screws.
Slide drawers into position.
Level unit by adjusting the adjustable levelers on bottom of unit.
(See Figure 3)
STEP 5
Place Drawer Fronts (F) face down on a soft cloth.
Insert Dowels into Drawer Fronts (F).
Attach Drawer Fronts (F) to Drawer Boxes (G) with Wood Screws for drawer.
G
F
Dowel
Wood Screw for drawer
G
F

Assembly Instructions 5/5
Hardware List
STEP 7
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at pre-drilled hole
at top of unit with Machine Screw.
Move unit back into place.
Slide Tip-over Restraint through
Bracket on wall and Bracket on unit.
(See Figure 4)
Put tie end of Tip-over Restraint into lock
end of Tip-over Restraint and pull until tight.
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tip-over Restraint
1 pc. (+1 extra)
M3.5x40
Wall Screw
1 pc. (+1 extra)
M4x10
Machine Screw
1 pc. (+1 extra)
Drill 3/8” hole in wall
Top of unit
IMPORTANT
To help reduce the risk of the unit tipping over, the Tip-over Restraint must be installed following these instructions exactly.
Figure 4
Machine Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
Pre-drilled hole
at top of unit
Tie end
Lock end
Bracket at
top of unit
Tipover
Restraint

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
homestyles will provide replacements free of charge for missing or damaged parts within 1 year of purchase.
Digital images of the defective parts may be required. If the product was not purchased from an authorized retailer,
homestyles is under no obligation to provide replacement parts. Parts are not available for fully assembled items nor
are parts available for sale. Replacements for missing or damaged parts may be requested via contact info below.
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460
