Home Styles Barnside TV Console 88 5516 06 User manual

IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
Home Styles ConsumerAssistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Hardware List
88 5516 06
Barnside
TV Console
C.
Side Frame
1 Pc.
B.
Side Frame
1 Pc.
F.
Back Stretcher
1 Pc.
E.
Divider
1 Pc.
D.
Front Rail
1 Pc.
A.
Top
1 Pc.
G.
Shelf
2 Pcs.
Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
H.
Drawer
2 Pcs.
(Knock-Down Construction, please refer to the last page
of instructions for steps to complete assembly)
Machine Screw
4 Pcs.
Pull Handle
2 Pcs.
Head Cap Bolt
8 Pcs.(+1 extra)
Cam Lock Screw
18 Pcs.(+1 extra) Wood Screw (long) for Side Drawer
16 Pcs.(+1 extra)
Wood Screw (short)
for Bottom Drawer
12 Pcs.(+1 extra)
Cam Lock
18 Pcs.(+4 extra)
Tools required for assembly : Phillips screwdriver Tools recommended for assembly : Level

Assembly Instructions 2
IMPORTANT
* Please keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Do not tighten up all the screws until each part is properly assembled.
* Use a soft cloth between these parts and the floor.
* After assembly, item must be level to work properly.
Use the included adjustable levelers to level.
STEP 1
Insert Cam Lock Screws
into the pre-drilled holes
of Top (A) and
Side Frames (B) and (C).
(see Figure 1)
B
E
B
F
B
C
B
B
B
A
C
B
D
STEP 2
Attach Front Rail (D) and Back Stretcher (F) to Divider (E)
with Cam Locks. (see Figure 2)
Attach Side Frame (C) to unit with Cam Locks.
Cam Lock Screw
/4
Figure 1
Figure 2

Assembly Instructions 3
STEP 4
Attach Top (A) to unit with Cam Locks.
Slide Drawers (H) into position.
To level the unit, adjust the adjustable levelers on the bottom of the legs.
(See figure 4)
Note: Unit must be level to work properly.
B
A
B
HB
H
STEP 3
Attach Shelves (G) to unit with Head Cap Bolts. (see Figure 3)
Attach Side Frame (B) to unit with Cam Locks and Head Cap Bolts.
E
G
E
G
B
B
Head Cap Bolt
/4
Figure 3
Figure 4

Assembly Instructions 4
H1.
Front Part
2 Pcs.
H2.
Back Part
2 Pcs.
H3.
Side Part
2 Pcs.
H4.
Side Part
2 Pcs.
H5.
Side Part
2 Pcs.
Part List
STEP 2
Slide H5 into the grooves in H3 and H4.
Be sure to push H5 all the way forward so it meets H1.
(see Figure 2)
STEP 3
Insert short wood screws (4X) into the
pre-drilled holes in H5 and tighten.
(see Figure 3)
STEP 4
Assemble Pull Handle with machine screws.
(see Figure 4)
Tighten all screws used in drawer assembly.
STEP 1
Attach H1 to H3 and H4, using a Phillips screwdriver and long wood screws (4X), tighten halfway.
Attach H2 to H3 and H4 using long wood screws (4X), tighten
halfway. (see Figure 1)
Drawer (H)
B
H1
B
H1
B
H1
B
H2
B
H2
B
H2
B
H3
B
H3
B
H3
B
H4
B
H4
B
H4
B
H5
B
H5
/4
(Figure 1)
(Figure 2)
(Figure 3)
(Figure 4)
