Home Styles 20 05436 0923 User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/16” Drill Bit, 3/8” Drill Bit
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
20 05436 0923
Storage Island
Cartons 20 05436 0921 and 0922 are also needed for assembly.
Refer to later page(s) of these
instructions for drawer assembly.
D.
Bottom
1 pc.
J.
Drawer
2 pcs.
I.
Drawer
1 pc.
G.
Rail
2 pcs.
H.
Plinth
2 pcs.
E.
Shelf
3 pcs.
Cam Lock Screw
24 pcs. (+2 extra)
Cam Lock
24 pcs. (+6 extra)
M4x25
Machine Screw
6 pcs.
Knob
6 pcs.
Adjustable Pin
12 pcs. (+1 extra)
M6x32
Head Cap Bolt
12 pcs. (+1 extra)
M3.5x32
Wood Screw
4 pcs. (+1 extra)
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Flat Washer
12 pcs. (+1 extra)
Spring Washer
12 pcs. (+1 extra)

Assembly Instructions 2/8
B
C
A
D
H
H
Cam Lock Screw
Cam Lock Screw
Cam Lock Screw
STEP 1
Insert Cam Lock Screws into pre-drilled holes in Top (A), Side Panels (B), (C),
Bottom (D) and Plinths (H), then tighten. (See Figure 1)
Figure 1
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the screws until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench as the bolts may need to be tightened in the future.

STEP 3
Attach Plinths (H) to unit with Cam Locks.
H
H
Cam Lock
Assembly Instructions 3/8
F
D
STEP 2
Attach Back Panel (F) to Bottom (D) with Cam Locks. (See Figure 2)
Note: Arrow label indicates front of Bottom (D).
Cam Lock
Figure 2
Arrow label at front

Assembly Instructions 4/8
STEP 4
Attach unit to Side Panel (C) with Cam Locks,
Flat Washers, Spring Washers and
Head Cap Bolts, tightening bolts only halfway.
(See Figure 3)
Attach Rails (G) to unit with Wood Screws,
into pre-drilled holes. (See Figure 4) G
G
Wood Screw
C
Cam Lock
STEP 5
Attach Side Panel (B) to unit with
Cam Locks, Wood Screws, Flat Washers,
Spring Washers and Head Cap Bolts,
tightening bolts only halfway.
Tighten all bolts used in Steps 4 and 5.
Turn unit to its’ upright position.
Cam Lock
Flat Washer
Spring Washer
Head Cap Bolt
Wood Screw
Head Cap Bolt
Spring Washer
Flat Washer
Figure 3
Figure 4
B

Part List
Assembly Instructions 5/8
I1.
Drawer Front
1 pc.
I2.
Drawer Back
1 pc.
I3.
Drawer Side
1 pc.
I4.
Drawer Side
1 pc.
I5.
Drawer Bottom
1 pc.
Drawer (I)
STEP 6
Attach Drawer Sides (I3) and (I4) to
Drawer Back (I2), then flip Locks.
(See Figures 5 and 6)
I2
I3
I4
Lock
STEP 8
Attach Knobs with Machine Screws.
I5
Lock
I1
STEP 7
Slide Drawer Bottom (I5) into grooves in unit.
Attach Drawer Front (I1) to unit, then flip Locks.
Machine Screw
Knob
Figure 5 Figure 6

Part List
Assembly Instructions 6/8
J1.
Drawer Front
2 pcs.
J2.
Drawer Back
2 pcs.
J3.
Drawer Side
2 pcs.
J4.
Drawer Side
2 pcs.
J5.
Drawer Bottom
2 pcs.
Drawer (J)
STEP 9
Attach Drawer Sides (J3) and (J4) to
Drawer Back (J2), then flip Locks.
J2 J3
J4
Lock
STEP 10
Slide Drawer Bottom (J5) into grooves in unit.
Attach Drawer Front (J1) to unit, then flip Locks.
J1
STEP 11
Attach Knobs with Machine Screws.
J5
Machine Screw
Knob Lock

Assembly Instructions 7/8
Figure 8Figure 7
E
E
E
Adjustable Pin
STEP 12
Level unit by adjusting the adjustable
levelers on bottom of unit from Step 5
(See Figure 7)
Insert Adjustable Pins into side panels
at desired level. (See Figure 8)
Place Shelves (E) into position.
Cam Lock
ASTEP 13
Attach Top (A) to unit with Cam Locks,
Flat Washers, Spring Washers and
Head Cap Bolts, tightening
bolts only halfway.
Tighten all bolts use in this step.
STEP 14
Slide Drawers (I) and (J) into position.
Flat Washer
Spring Washer
Head Cap Bolt
I
J
J

Assembly Instructions 8/8
Drill 3/8” hole in wall
Side Panel of unit
Figure 9
Wood Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
Tie end
Lock end
Bracket at
top of unit
Tip-over
Restraint
Per regulatory requirements, a Tip-over Restraint is included. Follow Step 15 to install it.
3/16” hole in
side panel of unit
STEP 15
Drill a 3/16” hole 1/2” deep 1” below top
of unit in middle of side panel that is
against a wall.
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at pre-drilled hole
at top of unit with Wood Screw.
Move unit back into place.
Slide Tip-over Restraint through
Bracket on wall and Bracket on unit.
(See Figure 9)
Put tie end of Tip-over Restraint into lock
end of Tip-over Restraint and pull until tight.
Hardware List
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tip-over Restraint
1 pc. (+1 extra)
M3.5x40
Wall Screw
1 pc. (+1 extra)
M3.5x16
Wood Screw
1 pc. (+1 extra)

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
