Home Styles 88 9001 002C User manual

PART LIST
88 9001 002C
Cuisine Cart
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
D.
Back Piece
1 pc.
E.
Back Panel
2 pcs.
F.
Back
Stretcher
1 pc.
G.
Front Rail
1 pc.
HARDWARE LIST
A.
Side Panel
1 pc.
B.
Side Panel
1 pc.
C.
Base
1 pc.
M.
Shelf
1 pc.
P.
Drawer
1 pc.
Head Cap Bolt (Middle)
for top
4 pcs.(+ 1 extra)
Head Cap Bolt
(long)
12 pcs.(+ 1 extra)
Head Cap Bolt (short)
for Side Towel Bar
2 pcs.
(+ 1 extra)
Hex Wrench
1 pc.
Pull Handle
2 pcs.
Machine Screw
for Pull Handle
4 pcs.
Wood Screw
16 pcs.
(+ 1 extra)
Adjustable Pin
4 pcs. (+ 1 extra)
H.
Side Rack
1 pc.
I.
Side Rack
1 pc. J.
Brush Chrome Pipes
3 pcs.
K.
Base Rack
1 pc.
L.
Side Towel Bar
1 pc.
N.
Door.
1 pc.
O.
Door.
1 pc.
Caster
two lock
two non-lock
4 pcs.
Wood Plug
8 pcs.
(+2 extra)
Tools Required For Assembly : Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
[email protected]
Small
Hex Wrench
1 pc.
Revised date : 23Mar2011

Assembly Instructions 2/4
IMPORTANT
Do not tighten up all the screws until each part is properly assembled.
You should keep Hex Wrench in the safe place as you may need to
tighten up the Head Cap Bolts in the future.
STEP 1
STEP 2
Attach the Side Panel (B) to the
Base (C).
Tighten up the Head Cap Bolts.
Attach the Back Piece (D) on the Base rear.
Tighten Head
Cap Bolt by
Hex Wrench.
B
D
C
C
Attach four Casters to
the underneath of the Base (C).
Locking Caster
Locking Caster
Head Cap Bolt
Wood Screw

Assembly Instructions 3/4
L
B
B
STEP 5
STEP 4
K
J
J
H
A
I
Attach the Side Rack (H) to the Side Panel (A)
with the Head Cap Bolts.
Attach the Brush Chrome Pipes (J) to the pre-drilled
holes of Side Rack (H).
Attach the Base Rack (K) to the Side Rack (H).
Attach the Side Rack (I) to the Side Panel (A),
using Head Cap Bolts.
Attach the Side Towel Bar (L)
to the Side Panel (B) with
Head Cap Bolts.
Head Cap Bolt
Head Cap Bolt
(for Side Towel Bar)
STEP 3
EE
A
B
F
G
Slide the Back Panel (E) in place.
Attach the Back Stretcher (F) on the unit
with the Head Cap Bolt.
Attach the Front Rail (G) to the
Side Panel (B) with Head Cap Bolt.
Attach the Side Panel (A) to the unit with
Head Cap Bolts.
Head Cap Bolt
Head Cap Bolt

STEP 7
STEP 6
N
P
O
M
Now, you’ll be able to create your own kitchen cart.
Make your own choice of the ‘Top’, wood or stainless
steel or granite.
Place the Top on the unit, then tighten
the Head Cap Bolts.
Attach the Pull Handles to the
Door (N) and (O) using the
Machine Screws. (See figure 1)
Attach the Door (N) and (O) to both
side panels, slide the door lift hinges
into the side frame lift hinges.
(See figure 2)
Slide the Drawer (P) into place.
(Drawer is packed in separated
carton).
STEP 8
Cover up all holes
with Wood Plugs
Head Cap Bolt
(for Top)
Head Cap Bolt
(for Top)
Adjustable pin
Insert the Adjustable Pins into both side
panels at the desired level.
Place Shelf (M) into place.
Figure 2
Figure 1
Assembly Instructions 4/4

Assembly Instructions
Unit Part List
P3.
Side Part
1 pc.
P4.
Side Part
1 pc.
P5.
Base
1 pc.
P2.
Back Part
1 pc.
P2
P2
P5
P5
P3
P4
P4
P4
P3
P3
P1
P1
P1
(Fig) 2
(Fig) 3
(Fig) 4
(Fig)1
(Fig)2
(Fig)3
(Fig)4
HARDWARE LIST
Pull Handle
1 pc.
Machine Screw
for Pull Handle
2 pc.
Wood Screw
(for Base)
6 pcs.(+1 extra)
Wood Screw
(for Side Part)
8 pcs.(+1 extra)
(Fig) 1
P1.
Front Part
1 pc.
88 9001 002C
Drawer (P)
* If you are missing any of these
parts, please contact our DMI
Customer Service Department
at 1-877-831-0319 or fax us at
1-800-755-2878.
Slide the Plywood Base (P5) into the grooves
on side parts. Be sure to push the Base all the
way forward so it meets the Front Part.
Insert the remaining ½” screws (6 pcs.)
into the pre-drilled holes at the Base,
then tighten up all screws.
Assemble the Pull Handle
with
Machine Screw.
to the Front Part
Assemble the Front Part (P1), Back Part
(P2) and Side Part (P3) and (P4).
Using a , insert 1”
screw into the pre-drilled holes at the
side parts, tighten half way.
Phillips screw driver
