Home Styles Hutch User manual

Part List
Home Styles ConsumerAssistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tools required for assembly : Phillips screwdriver Tools recommended for assembly : Level
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Hardware List
Cam Lock Screw
29 pcs. (+1 extra)
Cam Lock
29 pcs. (+1 extra)
M3x13
Wood Screw
for Magnet
8 pcs. (+1 extra)
M5x40
Panel Screw
9 pcs. (+1 extra)
Magnet
4 pcs.
Washer
9 pcs. (+1 extra)
Machine Screw
2 pcs.
Knob
2 pcs.
E.
Back Rail
1 pc.
F.
Front Rail
1 pc.
C.
Side Panel
1 pc.
D.
Middle Panel
1 pc.
G.
Back Rail
1 pc.
H.
Back Rail
1 pc.
K.
Front Post
1 pc.
I.
Door
1 pc.
J.
Door
1 pc.
N.
Shelf
1 pc.
P.
Back Panel
2 pcs.
88 5002 307
Hutch
Steel Plate
Connector
2 pcs.
.
D
oor
.
oor
o
nt Rail
pc.
c
k Rai
l
c
.
ck
R
ai
l
c.
a
ck Rai
l
p
c.
B.
Side Panel
1 pc.
L.
Front Post
1 pc. O.
Shelf
4 pcs.
M.
Shelf
1 pc.
A.
Top
1 pc.
Adjustable Pin
16 pcs. (+1 extra)
M3.5x16
Wood Screw
24 pcs. (+2 extra)

IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* Use a soft cloth between these parts and the floor.
*After assembly, item must be level to work properly. Use the included adjustable levelers to level.
Assembly Instruction 2 / 6
STEP 2
Insert Cam Lock Screws into the pre-drilled holes in
Middle Panel (D).
Attach Magnets to Middle Panel (D) with Wood Screws
for Magnet. (see Figure 2)
Figure 2
C
C
STEP 1
Insert Cam Lock Screws into the pre-drilled
holes in Side Panels (B), (C), Front Posts
(K), (L) and Front Rail (F). (see Figure 1)
L
L
K
K
F
F
D
D
B
B
Cam Lock Screw
Cam Lock Screw
Cam Lock Screw
Wood Screw
for Magnet
Magnet
Figure 1

Assembly Instruction 3 / 6
STEP 3
Attach Back Rails (E), (G) and (H) to
Side Panel (C) with Cam Locks.
(see Figure 3)
Slide Back Panel (P) into the grooves in
Side Panel (C) and Back Rails (E), (G),
(H).
STEP 4
Attach Shelf (N) to unit with Cam
Locks.
Attach Middle Panel (D) to unit
with Cam Locks, Washer and
Panel Screw. ( see Figure 4)
G
G
Cam Lock
Figure 3
P
P
N
N
D
D
C
C
Cam Lock
P
P
H
H
E
E
Washer
Panel Screw
Figure 4

STEP 5
Attach Shelf (M) to unit with Cam Locks.
Attach Side Panel (B) to unit with Cam
Locks.
Assembly Instruction 4 / 6
STEP 6
Attach Front Posts (K) and (L) to
Front Rail (F) with Cam Locks.
M
M
L
L
F
F
K
K
Cam Lock
B
B
Cam Lock

Washer
Panel Screw
Assembly Instruction 5 / 6
Figure 5
STEP 8
Place Top (A) onto the unit and attach with
Washers and Panel Screws.
Insert Adjustable Pins into the side panels
at the desired level.
Place Shelves (O) into position.
Attach Doors (I) and (J) to the side panels
by sliding the door lift hinges into the side
panel lift hinges. (see Figure 5)
Assemble Knobs to Door (I) and (J) with
Machine Screws. (see Figure 6 )
O
O
Cam Lock
Adjustable Pin
Figure 6
STEP 7
Attach unit from Step 5 to unit
with Cam Locks.
A
A
I
I
J
J
O
O
O
O
O
O

Wood Screw
Assembly Instruction 6 / 6
Figure 8
Figure 7
Wood Screw
Steel Plate
Connector
STEP 9
Insert 16X Wood Screws from the back
of the unit. (see Figure 7)
Note: Please make sure unit is level
before tightening these screws.
STEP 10
Place the Hutch unit onto the Buffet unit.
Attach Steel Plate Connectors with Wood
Screws. (see Figure 8)
