Home Styles 88 9001 002C User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver
88 9001 002C
Cuisine Cart
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
M6x35
Head Cap Bolt (long)
12 pcs. (+1 extra)
M6x30
Head Cap Bolt (middle)
for Top
4 pcs. (+1 extra)
M6x25
Head Cap Bolt
for Side Tower Bar
2 pcs. (+1 extra)
M4x16
Wood Screw
for Caster
16 pcs. (+1 extra)
Adjustable Pin
4 pcs. (+1 extra)
Knob
2 pcs.
M4x20
Machine Screw
4 pcs.
Wood Plug
8 pcs. (+1 extra)
Refer to later page(s) of these
instructions for drawer assembly.
P.
Drawer
1 pc.
G.
Front Rail
1 pc.
F.
Back Stretcher
1 pc.
M.
Shelf
1 pc.
D.
Back Upright
1 pc.
E.
Back Panel
2 pcs.
C.
Base
1 pc.
J.
Brush Chrome Pipe
3 pcs.
K.
Base Rack
1 pc.
L.
Side Tower Bar
1 pc.
H.
Side Rack
1 pc. I.
Side Rack
1 pc.
A.
Side Panel
1 pc.
B.
Side Panel
1 pc.
M3.5x13
Wood Screw (short)
6 pcs. (+1 extra)
M3.5x25
Wood Screw (long)
8 pcs. (+1 extra)
Pull Handle
1 pc.
Caster
2 Locking
2 Non-Locking
4 pcs.
N.
Door
1 pc.
O.
Door
1 pc.

IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
Keep Hex Wrench in a safe place as the bolts may need to be tightened up in the future.
Figure 1
Figure 2
Head Cap Bolt
Locking Caster
F
A
B
G
E
E
D
C
STEP 2
Attach Side Panel (A) to Base (C) with Head Cap Bolts.
(See Figure 2)
Attach Back Upright (D) to Base (C).
Slide Back Panels (E) into place.
Attach Back Stretcher (F) and Front Rail (G) to Side Panel (A) with Head Cap Bolts.
Attach Side Panel (B) to unit with Head Cap Bolts.
C
Assembly Instructions 2/5
Non-Locking Caster
Locking Caster
Wood Screw for Caster
C
STEP 1
Attach Casters underneath Base (C)
with Wood Screws for Caster, with
Locking Casters on the front.
(See Figure 1)
Note: The ‘Arrow’ sticker
indicates the front of Base (C).
‘Arrow’ sticker at front
‘Arrow’ sticker at front

Assembly Instructions 3/5
STEP 3
Attach Side Rack (H) to Side Panel (A)
with Head Cap Bolts.
Slide Brush Chrome Pipes (J) and
Base Rack (K) into Side Rack (H).
Attach Side Rack (I) to Side Panel (A)
with Head Cap Bolts.
STEP 5
Attach Top to unit with
Head Cap Bolts for Top.
Insert Adjustable Pins into
side panels at the desired level.
(See Figure 3)
Place Shelf (M) into position.
Head Cap Bolt for Top
Adjustable Pin
M
Figure 3
Head Cap Bolt
A
H
I
J
K
STEP 4
Attach Side Tower Bar (L) to Side Panel (B)
with Head Cap Bolts for Side Tower Bar.
Head Cap Bolt
for Side Tower Bar
L
B

Part List
Assembly Instructions 4/5
STEP 8
Attach Pull Handle with Machine Screws.
P1.
Drawer Front
1 pc.
P2.
Drawer Back
1 pc.
P3.
Drawer Side
1 pc.
P4.
Drawer Side
1 pc.
P5.
Drawer Bottom
1 pc.
P5
P3
P4
P1
P2
STEP 7
Slide Drawer Bottom (P5) into the grooves
of Drawer Sides (P3) and (P4) until it meets
Drawer Front (P1).
Attach Drawer Bottom (P5) to unit with
Wood Screws (short).
Drawer (P)
P1
P2
P3
P4
Roller at back
Bottom
STEP 6
Attach Drawer Front (P1) and Drawer
Back (P2) to Drawer Side (P3) with
Wood Screws (long).
Attach Drawer Side (P4) to unit with
Wood Screws (long).

Assembly Instructions 5/5
Figure 4 Figure 5 Figure 6
STEP 9
Attach Knobs to Doors (N) and (O) with Machine Screws.
(See Figure 4)
Attach Doors (N) and (O) to unit by sliding the door lift hinges into side panel lift hinges.
(See Figure 5)
Slide Drawer (P) into position.
Cover all holes with Wood Plugs.
(See Figure 6)
A
B
N
O
P

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
