Honeywell PW6K1R1E Operator's manual

September 2011 © 2011 Honeywell. All rights reserved. 800-07986V1, Revision A
PW6K1R1E Input/Output Module
Installation and Configuration Guide

Copyright © 2011 Honeywell. All rights reserved.
Honeywell Integrated Security is a registered trademark of Honeywell International.
All other product and brand names are the service marks, trademarks, registered
trademarks, or registered service marks of their respective owners. Printed in the
United States of America. Honeywell Integrated Security reserves the right to change
any information in this document at any time without prior notice.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Windows Server is a trademark of Microsoft Corporation.
Ordering Information
Please contact your local Honeywell Integrated Security representative or visit us on
the web at www.honeywellintegrated.com for information about ordering.
Feedback
Honeywell Integrated Security appreciates your comments about this manual. Please
visit us on the web at www.honeywellintegrated.com to post your comments.

PW6K1R1E Configuration and Installation Guide, Document 800-07986V1, Revision A iii
CONTENTS
Chapter 1 Introduction
1.1 Overview ................................................................................................. 2
1.2 General UL-Compliance ......................................................................... 2
1.3 Card Readers ........................................................................................... 3
1.4 Warranty................................................................................................. 4
1.5 Liability ................................................................................................... 4
1.6 FCC Compliance ..................................................................................... 4
Chapter 2 PW6K1R1E Wiring and Setup
2.1 PW6K1R1E Hardware ............................................................................ 6
2.2 Terminal Connections ............................................................................. 7
2.3 Jumper Configuration.............................................................................. 8
2.4 DIP Switch Configuration....................................................................... 8
2.5 Input Power ............................................................................................. 8
2.6 Communication Wiring........................................................................... 9
2.7 Reader Wiring ......................................................................................... 9
2.8 Input Circuit Wiring .............................................................................. 10
2.9 Relay Circuit Wiring ............................................................................. 10
2.10 Status LEDs......................................................................................... 11
2.11 Specifications ...................................................................................... 12
2.12 Additional Mounting Information....................................................... 15

iv www.honeywell.com

PW6K1R1E Configuration and Installation Guide, Document 800-07986V1, Revision A 1
1
Introduction
In this chapter...
1.1 Overview 2
1.4 Warranty 4
1.5 Liability 4
1.6 FCC Compliance 4

2www.honeywell.com
Introduction
Overview
1.1 Overview
The PW6K1R1E reader interface provides a network connected, single door with
paired reader, PoE based solution to the OEM integrator for interfacing TTL/
Wiegand/RS-485 type readers to door hardware. The on-board twisted pair Ethernet
jack with PoE support enables easy installation.
A maximum of 16 PW6K1R1E downstream boards can be connected to PW6K1ICE
controller board.
You can control one physical barrier with PW6K1R1E, using single or paired readers.
The first reader port can accommodate a read head that utilizes Wiegand, magnetic
stripe, or 2-wire RS-485 electrical signaling standards, one or two wire LED controls,
and buzzer control (one wire LED mode only).
The second reader port can accommodate a read head that utilizes Wiegand or
magnetic stripe signaling, one or two wire LED controls, and buzzer control (one wire
LED mode only).
You can use two form-C relay outputs for door strike control or alarm signaling.The
relay contacts are rated at 5A @ 30VAC/DC, dry contact configuration. Four inputs
are provided for monitoring the door contacts, exit push buttons, and alarm contacts.
The PW6K1R1E requires power from PoE or local 12VDC. The reader power should
be based on peak reader power consumption.
The PW6K1R1E may be mounted in a 3-gang switch box; a mounting plate is
supplied with the unit. The PW6K1R1E may be mounted in an enclosure; the supplied
mounting plate has mounting holes that match the MR50 mounting footprint. Refer to
Additional Mounting Information (p. -15) for UL enclosure requirements.
The PW6K1R1E has to be installed on the same subnet as PW6101 (i.e., PW6K1ICE)
or PW6000. The encryption between both PW6000 and PW6K1ICE, and, PW6101
and PW6K1ICE, is built-in and automatic.
1.2 General UL-Compliance
A UL-compliant installation requires the following:
• The PW6K1R1E board must be installed within the protected area.
• The PW6K1R1E board is installed for indoor use only.
• The PW6K1R1E board must be installed with a tamper switch mounted to the
enclosure cover.
• The fail secure locking mechanism shall only be installed where is is allowed
by the local authority having jurisdiction (AHJ), and it shall not impair the
operation of panic hardware and emergency egress.
Note: The PW6K1R1E board is not UL Listed for burglary installations.

Introduction
Card Readers
PW6K1R1E Configuration and Installation Guide, Document 800-07986V1, Revision A 3
1.3 Card Readers
The Pro-Watch PW6K1ICE controller and PW6K1R1E input/output board have been
tested for use with the following Listed (ALVY) card readers:
Manufacturer Model Part Number
HID ProxPro HU/5355AGN00
ProxPro II HU/5455BGN00
ProxPro K HU/5355AGK00
MiniProx HU/5365EGP00
ThinLine II HU5395CB100
HU/5395CG100
HU/5395CK100
Honeywell OM40 OM40BHONC
OM40GHONC
OM41 OM41BHONC
OM41GHONC
OM55 OM55BHONB
OM55GHONB
OP-10 OP10GENR
OP10HONR
OP-30 OP30GENR
OP30HONR
OP-40 OP40GENR
OP40HONR

4www.honeywell.com
Introduction
Warranty
1.4 Warranty
Honeywell Security Access warrants that the product is free from defects in material
and workmanship under normal use and service with proper maintenance for one year
from the date of factory shipment.
Honeywell Security Access assumes no responsibility for products damaged by
improper handling or installation. This warranty is limited to the repair or replacement
of the defective unit.
There are no expressed warranties other than set forth herein. Honeywell Security
Access does not make, nor intends, nor does it authorize any agent or representative to
make any other warranties, or implied warranties, and expressly excludes and
disclaims all implied warranties of merchantability or fitness for a particular purpose.
Returned units are repaired or replaced from a stock of reconditioned units. Returns
must be accompanied by a Returned Merchandise Authorization (RMA) number
obtained from customer service, and prepaid postage and insurance.
1.5 Liability
You should use the Interface only to control exits from areas where an alternative
method for exit is available.
This product is not intended for, nor is rated for operation in life-critical control
applications.
Honeywell Security Access is not liable under any circumstances for loss or damage
caused by or partially caused by the misapplication or malfunction of the product.
Honeywell Security Access's liability does not extend beyond the purchase price of
the product.
1.6 FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

PW6K1R1E Configuration and Installation Guide, Document 800-07986V1, Revision A 5
2
PW6K1R1E Wiring and Setup
In this chapter...
2.1 PW6K1R1E Hardware 6
2.2 Terminal Connections 7
2.3 Jumper Configuration 8
2.4 DIP Switch Configuration 8
2.5 Input Power 8
2.6 Communication Wiring 9
2.7 Reader Wiring 9
2.8 Input Circuit Wiring 10
2.9 Relay Circuit Wiring 10
2.10 Status LEDs 11
2.11 Specifications 12
2.12 Additional Mounting Information 15

6www.honeywell.com
PW6K1R1E Wiring and Setup
PW6K1R1E Hardware
2.1 PW6K1R1E Hardware
Figure 2-1: PW6K1R1E Control Board
Figure 2-2: PW6K1R1E Control Board Solder Side
2
3
41
S1
S2
123456
ON
J3J7
K1
K2
12V
J5
PoE
J6
TB1 TB2 TB3 TB4 TB5 TB6
111111
IN1 IN2 IN3 IN4 VO LED BZR CLK DAT GND VO GNDDATCLKBZRLED GNDVIN NO NC2-CNONC1-C
J2
0.2 [5.08] 2.35 [59.69]
0.15 [3.81]
2.55 [64.77] 2.55 [64.77]
5.4 [137.16]
STATUS LEDs
2.75 [69.85]
DIP SWITCH
RESET SWITCH
PoE/12Vdc
POWER SELECTOR
JUMPER
ETHERNET RJ45
CONNECTOR
ACTIVITY
(YELLOW)
LINK
(GRREN)
123456
VO
VO IN2 IN1
IN3
IN4
LED
BZR
CLK
DAT
GND
LED
BZR
CLK
DAT
NC GNDGND
VIN
NO
RLY 1
NO
RLY 2
NC CC
TB6
TB5
TB4
TB3
TB2
TB1
J1
6V
5V
3.3V
LNK
ACT
(K1)
(K2)
J4
D24
D19
ETHERNET
STATUS
LEDs
RELAY K1
LED
RELAY K2
LED
STATUS LEDs
SOLDER SIDE

PW6K1R1E Wiring and Setup
Terminal Connections
PW6K1R1E Configuration and Installation Guide, Document 800-07986V1, Revision A 7
2.2 Terminal Connections
Table 1: PW6K1R1E Terminal Connections
Terminal Acronym Description
TB1-1 IN1 Input 1
TB1-2 IN1
TB1-3 IN2 Input 2
TB1-4 IN2
TB2-1 IN3 Input 3
TB2-2 IN3
TB2-3 IN4 Input 4
TB2-4 IN4
TB3-1 VO Reader 1 Power Output - 12VDC
TB3-2 LED Reader 1 LED Output
TB3-3 BZR Reader 1 Buzzer Output
TB3-4 CLK Reader 1 CLK/Data 1/TR+
TB3-5 DAT Reader 1 DAT/Data 0/TR-
TB3-6 GND Reader 1 Ground
TB4-1 LED Reader 2 LED Output
TB4-2 BZR Reader 2 Buzzer Output
TB4-3 CLK Reader 2 CLK/Data 1 Input
TB4-4 DAT Reader 2 DAT/Data 0 Input
TB5-1 VO Auxiliary Power Output - 12VDC
TB5-2 GND Auxiliary Power Output Ground
TB5-3 VIN Input Power - 12VDC (from local power supply)
TB5-4 GND Input Power Ground
TB6-1 NO Relay K1 - Normally Open Contact
TB6-2 1-C Relay K1 - Common Contact
TB6-3 NC Relay K1 - Normally Closed Contact
TB6-4 NO Relay K2 - Normally Open Contact
TB6-5 2-C Relay K2 - Common Contact
TB6-6 NC Relay K2 - Normally Closed Contact

8www.honeywell.com
PW6K1R1E Wiring and Setup
Jumper Configuration
2.3 Jumper Configuration
Figure 2-3: J5 Jumper Location
2.4 DIP Switch Configuration
All S1 switch settings are unassigned and are reserved for future use. Set all switches
to the OFF position.
2.5 Input Power
The PW6K1R1E is powered by one of the following two ways (jumper selected):
1. The Ethernet connection using PoE, fully compliant to IEEE 802.3af.
2. Local 12VDC power supply, TB5-3 (VIN), TB5-4 (GND).
J5 Jumper hidden under TB5
Table 2: Jumper Settings
Jumper Set at Description
J1 N/A Factory Use Only
J2 N/A Factory Use Only
J3 N/A Factory Use Only
J4 N/A Factory Use Only
J5 PoE PW6K1R1E powered from the Ethernet connection
12V PW6K1R1E powered from an external 12VDC power source
connected to TB5-3 (VIN), TB5-4 (GND)
J6 N/A Ethernet connection with PoE support
J7 N/A Factory Use Only

PW6K1R1E Wiring and Setup
Communication Wiring
PW6K1R1E Configuration and Installation Guide, Document 800-07986V1, Revision A 9
2.6 Communication Wiring
The PW6K1ICE communicates with PW6K1R1E through the Ethernet. In the event
of communication loss, all readers connected to the PW6K1R1E must be programmed
to the “locked” option in the Offline mode menu.
2.7 Reader Wiring
The first reader port supports Wiegand, magnetic stripe, or 2-wire RS-485 electrical
interfaces.
The second reader port supports Wiegand or magnetic stripe electrical interfaces.
Power to the first reader is 12VDC and its current is limited to 150mA. The second
reader may be powered from the auxiliary power output on TB5-1 and TB5-2.
Readers that require different voltage or have high current requirements should be
powered separately. Refer to the manufacturer’s specifications for cabling
requirements. In the 2-wire LED mode, the Buzzer output is used to drive the second
LED. Reader port configuration is set via the host software.
Figure 2-4: First Reader Port Wiring
Figure 2-5: Second Reader Port Wiring
MR-10/20 READER
TB3
FIRST READER PORT
DATA1/DATA0 OR CLOCK/DATA
WHT (3)
BLK (6)
GRN (2)
ORG (5)
BRN (4)
RED (1)
CLK/D1
GND
DAT/D0
LED
BZR
VO
1
TB4 TB5
SECOND READER PORT
DATA1/DATA0 OR CLOCK/DATA
WHT (3)
RED (1)
GRN (2)
ORG (5)
BRN (4)
BLK (6)
CLK/D1
GND
VO
DAT/D0
LED
BZR
11
MR-10/20 READER

10 www.honeywell.com
PW6K1R1E Wiring and Setup
Input Circuit Wiring
2.8 Input Circuit Wiring
Typically, these inputs are used to monitor door position, request to exit, or alarm
contact. Input circuits can be configured as unsupervised or supervised. When
unsupervised, reporting consists of only the open or closed states.
When configured as supervised, the input circuit will report not only open and closed,
but also open circuit, shorted, grounded, and foreign voltage.
Note: Grounded and foreign voltage states are not a requirement of UL 294 and
therefore not verified by UL.
A supervised input circuit requires two resistors be added to the circuit to facilitate
proper reporting.
The standard supervised circuit requires 1K Ohm, 1% resistors and should be located
as close to the sensor as possible. Custom end of line (EOL) resistances may be
configured via the host software.
The input circuit wiring configurations shown below are supported but may not be
typical:
Figure 2-6: Input Circuit Wiring
2.9 Relay Circuit Wiring
Two relays are provided for controlling door lock mechanisms or alarm signaling. The
relay contacts are rated at 5A @ 30VAC/DC, dry contact configuration.
Each relay has a Common pole (C), a Normally Open pole (NO) and a Normally
Closed pole (NC).
• When you are controlling the delivery of power to the door strike, the
Normally Open and Common poles are used.
1K,1%
1K,1%
1K,1%
1K,1%
Standard Supervised Circuit,
Normally Closed Contact
Standard Supervised Circuit,
Normally Open Contact
Unsupervised Circuit,
Normally Open Contact
Unsupervised Circuit,
Normally Closed Contact
TB2
IN4
IN2
IN3
1
IN1
TB1
1
}

PW6K1R1E Wiring and Setup
Status LEDs
PW6K1R1E Configuration and Installation Guide, Document 800-07986V1, Revision A 11
• When you are momentarily removing power to unlock the door, as with a
mag lock, the Normally Closed and Common poles are used.
Check with local building codes for proper egress door installation.
Caution: Door lock mechanisms can generate feedback to the relay circuit which can
cause damage and premature failure of the relay. For this reason, it is recommended
that you should use either a diode or MOV (metal oxide varistor) to protect the relay.
Wire should be of sufficient gauge to avoid voltage loss.
Figure 2-7: Relay Circuit Wiring Diagram
Note: The initial charge of the battery may take up to 24 hours to be fully charged.
2.10 Status LEDs
At power-up, LEDs 2 through 6 are turned ON then OFF in sequence.
After the above sequence has completed successfully, the PW6K1R1E goes to the
“waiting for IP address” mode.
Diode Selection:
• Diode current rating: 1x
strike count
• Diode breakdown voltage:
4x strike voltage
• For 12VDC or 24VDC
strike, diode 1N4002
(100V/1A) typical
MOV Selection:
• Clamp voltage: 1.5x VAC
RMS
• For 24VAC strike,
Panasonic ERZ-
C07DK470 typical
+-
TB6
2-C
NC
NC
NO
1
NO
1-C
O
TB6
1
NO
1-C
NC
NC
NO
2-C
LED DESCRIPTION
1 Off-line: Off-line = 0.2 second ON, 0.8 second OFF
2 Waiting for IP address: 0.5 second ON, 0.5 second OFF
3 Flashes when data is received from either reader
4 Input IN1 Status: OFF = Inactive, ON = Active, Flashing = Trouble

12 www.honeywell.com
PW6K1R1E Wiring and Setup
Specifications
After the PW6K1R1E has received its IP address, the following table describes the
LEDs in the normal running mode. If the communication is lost, the PW6K1R1E
reverts back to the “waiting for IP address” mode:
2.11 Specifications
The interface must be used in low voltage, class 2 circuits only.
The installation of this device must comply with all local fire and electrical codes.
5 Input IN2 Status: OFF = Inactive, ON = Active, Flashing = Trouble
6 Input IN3 Status: OFF = Inactive, ON = Active, Flashing = Trouble
LED DESCRIPTION
1 On-line, encryption disabled = 0.8 second ON, 0.2 second OFF
On-line, encryption enabled = four pulses, 0.1 second ON, 0.1 second OFF per
second
2 Flashes when there is host communication
3 Flashes when data is received from either reader
4 Input IN1 Status: OFF = Inactive, ON = Active, Flashing = Trouble
5 Input IN2 Status: OFF = Inactive, ON = Active, Flashing = Trouble
6 Input IN3 Status: OFF = Inactive, ON = Active, Flashing = Trouble
Power Input • PoE Power Input 12.95W, compliant to IEEE 802.3af
- OR -
•12VDC 10%, 900mA maximum
Notes:
• A +12V power input must be powered by a UL 294/UL 609 Listed power
supply with appropriate ratings (12Vdc, 900mA) and the capability to
provide adequate standby power.
• If the PW6K1ICE is powered by Power-Over_Ethernet (POE), it must be
powered by a Listed (ALVY) Altronix, Model NetWay1 POE Injector.
NetWay1 must be powered by a UL 294/UL 609 Listed power supply with
appropriate ratings (24Vac/dc, 1.2A) that is capable of providing adequate
standby power.
Power Output • 12VDC @ 700mA maximum (reader and AUX outputs combined)
• Reader (TB3) 12 VDC (10.3 through 12.6) @ 150mA maximum
• AUX (TB5) 12 VDC (10.7 through 13.0) @ 700 mA maximum
Output • Form-C Contacts rated at 5A @ 28VDC
Inputs • 4 unsupervised/supervised, End of Line resistors
• 1k/1k - ohm, 1% 1/4W watt standard

PW6K1R1E Wiring and Setup
Specifications
PW6K1R1E Configuration and Installation Guide, Document 95HYLVLRQ$ 13
Reader Interface
Reader Power: • 12VDC @ 700mA maximum (reader and
AUX outputs combined)
Reader LED Output • TTL compatible
• High > 3.0V
• Low < 0.5V
• 5mA source/sink maximum
Buzzer Output • Open collector
• 5VDC open circuit maximum
• 10mA sink maximum
Reader Data Inputs • TTL compatible inputs
or
• 2-wire RS-485
RS-485 Mode • 9600 bps
• Asynchronous
• Half-duplex
• 1 start bit
• 8 data bits
• 1 stop bit
• Maximum cable length 4000' (1,200m)
Cable requirements
Communication • Ethernet
• Category 5 minimum
Power • 18 AWG
• 1 twisted pair
Ethernet • CAT-5 (minimum)
RS-485 • 24AWG
• 120-ohm impedance
• 4,000ft (1,219 m) maximum
• Twisted pair(s) with an overall shield
Alarm Input • 1 twisted pair per input
• 30-ohm maximum loop resistance
Reader data (TTL) • 18AWG
• 6 conductors
• 500-foot (150 m) maximum

14 www.honeywell.com
PW6K1R1E Wiring and Setup
Specifications
Reader data (RS-
485)
•24AWG
• 120-ohm impedance
• Twisted pair with shield
• 4000-foot (1,219 m) maximum
Environmental
Temperature • -55°C to +85°C, storage
• -40°C to +75°C, operating
Humidity • 10 to 95% RHNC
Mechanical
Dimension • 5.5" (140mm) W x 2.75" (70mm) L x 0.96"
(24mm) H without bracket
• 5.5" (140mm) W x 3.63" (92mm) L x 1.33"
(34mm) H with bracket
Weight • 4.2 oz. (120g) without bracket
• 5.3 oz. (150g) with bracket
Enclosure
Box type • The unit must be installed within a UL 514A/UL
514C Listed (QCIT or QCMZ) 3-gang electrical
box.
Box dimensions • The minimum dimensions for the electrical box
are 2.75 inches by 2.75 inches by 5.8 inches, with
a minimum capacity of 44 cubic inches.
Box spacing • Minimum spacings must be enforced of at least 1/
2 inch between the PWB/components and the
enclosure.
Tamper switch • For UL applications, a tamper switch must be
installed.

PW6K1R1E Wiring and Setup
Additional Mounting Information
PW6K1R1E Configuration and Installation Guide, Document 95HYLVLRQ$ 15
2.12 Additional Mounting Information
Sources for the optional items shown below:
• 3-gang stainless steel blank cover: Leviton part number 84033-40.
Available from Graybar, part number 88158404.
• Magnetic switch set: G.R.I. part number: 505.
Figure 2-8: Stainless Steel Blank Cover
FIELD WIRING
PW-6K1R1E WITH INCLUDED
MOUNTING PLATE
TO ETHERNET
NETWORK
OPTIONAL 3-GANG
JUNCTION BOX
OPTIONAL BLANK
COVER W/SCREWS
OPTIONAL MAGNETIC
TAMPER SWITCH

16 www.honeywell.com
PW6K1R1E Wiring and Setup
Additional Mounting Information
Figure 2-9: Mounting Plate Dimensions
3.85 [97.8]
2.35 [59.7]
5.50 [139.7]
3.63 [92.1]
3.30 [83.8]
3.63 [92.1]
Ø0.16 [Ø4.0]
MR50 MGT HOLES
4PL
Ø0.16 [Ø4.0]
3-GANG MGT HOLES
4PL
