Honeywell BW Icon User manual

Honeywell BW ™ Icon & BW ™ Icon +
M05-4002-002 EN-A ©2020
Portable Multiple Gas Detector
USER
MANUAL
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

Table of Contents
Introduction 5
Product Description 5
Safety 5
Standards and Certifications 5
What's in the Box 7
Overview 7
Operations 9
Activate the Detector 9
Self Test 9
Deactivate the Detector 9
Common Button Operations 10
Bluetooth Pairing 10
Calibration 11
Bump Test 19
Zero Calibration 25
Capture Real Time Reading 25
Set the Detector via Device Configurator 25
Maintenance 27
Charge the Battery 27
Firmware Update 30
Additional Information 31
Sensor Poisons and Contaminants 31
Sensor Specifications 32
General Specifications 33
Time Out Events 34
Troubleshooting 34
DataLogs and Event Logs 37
Alarms 38
Replacement Parts 40
BW Icon 2 User Manual
41
Security Information
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

CHAPTER
1Introduction
Learn what you need to know about the Honeywell BW™ Icon Gas Detector before operating.
Product Description
The Honeywell BW™ Icon & Honeywell BW™ Icon+ gas detectors warns of hazardous gas at levels
above user-defined alarm setpoints. The detector can monitor up to four gases at a time.
Safety
CAUTION
• The detector is a personal safety device. It is your responsibility to respond properly to
the alarm.
• For safety reasons, this equipment must be operated and serviced by qualified personnel only.
• The lithium battery in this product presents a risk of fire, explosion, and chemical burn if
misused. Do not disassemble, incinerate, or heat above 212°F (100°C). Batteries exposed to heat
at 266°F (130°C) for 10 minutes can cause fire and explosion. Batteries must only be charged in a
safe area free of hazardous gas.
• Deactivating the detector by removing the battery pack may cause improper operation and harm
the detector.
• Use only Honeywell approved battery chargers such as the vehicle Charger.
• Do not use the apparatus if it is damaged. Inspect the apparatus before use. Look for cracks and
missing parts.
Standards and Certifications
IECEx: IECEx SIR 20.0020X
Ex ia op is I Ma Ex ia op is IIC T4 Ga, -40°C≤ Tamb ≤ 60°C (with IR sensor installed)
Ex ia I Ma Ex ia IIC T4 Ga, -40°C≤ Tamb ≤ 60°C
BW Icon 5 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

North America: CSA 20CA80028223X CSA C22.2 No.60079-29-1 UL60079-29-1
Class I, Division 1, Group A,B,C,D, T4;
Class I, Zone 0, AEx ia op is IIC T4 Ga; Ex ia op is IIC T4 Ga (With IR sensor installed)
Class I, Division 1, Group A,B,C,D, T4;
Class I, Zone 0, AEx ia IIC T4 Ga; Ex ia IIC T4 Ga
ATEX: Sira 20ATEX2012X
I M1 Ex ia op is I Ma, -40°C ≤ Tamb ≤ 60°C (with IR sensor installed)
II 1G Ex ia op is IIC T4 Ga, -40°C ≤ Tamb ≤ 60°C (with IR sensor installed)
I M1 Ex ia I Ma, -40°C ≤ Tamb ≤ 60°C
II 1G Ex ia IIC T4 Ga, -40°C ≤ Tamb ≤ 60°C
RE-D Directive 2014/53/EU
EMC Directive 2014/30/EU
ROHS Directive (EU) 2015/863 amending 2011/65/EU
IP: IP66, IP68 (1.2 meters for 45 minutes)
Contains FCC ID: SU3RMBLED
Contains IC: 20969-RMBLED
CAN ICES-3(A)/NMB-3(A)
FCC Compliance statement
This device complies with part 15 of the FCC Rules. operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his
own expense.
BW Icon 6 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

What's in the Box
1 Honeywell BW™ Icon gas detector
1 Battery (factory-installed)
1 USB charger
1 Calibration cap
1 Klick Fast stud
1 Quick Reference Guide
1 Tubing
Overview
1 LED Alarm 6 Sensor
2 IntelliFlash 7 Clip
3 Display 8 Battery
4 Button 9 Charging Port
5 Beeper
BW Icon 7 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

User Interface
Alarm One — Shows when alarm one is breached and gas highlighted next to
sensor
Alarm Two — Shows when alarm two is breached. Alarm two will over write any
alarm one status.
Time Weighted Average — Settable in Safety Suite DC for each toxic sensor.
Short Term Exposure Limit — Settable in Safety Suite DC for each toxic
sensor.
Bump — Shows when bump is due and you can configure to have a count
down.
Calibration — Shows when calibration is due and you can configure to have a
count down.
Battery status — Shows battery status and when on charge will show charging
status.
Bluetooth — All devices have Bluetooth – double click to enter menu. for
search mode
BW Icon 8 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

CHAPTER
2Operations
Learn what you can do with your Honeywell BW™ Icon Detector, from commissioning to
Calibration.
Activate the Detector
To turn the detector on, press, and hold the button for four seconds. LEDs light and the
instrument vibrates and beeps.
The detector performs a Self Test and Sensors warm-up.
During the Self Test, the icons light and the IntelliFlash flashes in amber.
During the Sensor warm-up, the sensors LEDs flash clockwise.
In the regular mode, the IntelliFlash flashes in green every five seconds.
Self Test
When the detector is activated, it performs several start-up tests.
lBattery
lData Flash
lRTC. Real Time Clock
lTemperature sensor.
lBLE module
lSensors
lBump and Calibration due date
When the detector has passed all the start-up self-tests, it enters the regular operation mode.
Deactivate the Detector
To deactivate your Honeywell BW™ Icon, press the button for four seconds.
The instrument beeps and vibrates, and the alarm LEDs light in red.
BW Icon 9 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

Common Button Operations
Feature Operation
Power On 4-second hold
Power Off 4-second hold
Enter or Exit menu Double-Press
Switch Menu (bump, cal, & BLE) Single-Press
Initiate selected 3-second hold
Acknowledge latched alarm 1-second hold
Bluetooth Pairing
The user can pair the Honeywell BW™ Icon to a mobile device via built-in Bluetooth Low Energy
(BLE). The Honeywell Device Configurator app, installed on the mobile device, can then show
gas readings and alarms from the BW Icon unit that is connected.
Readings and alarms can then be sent to Honeywell remote monitoring software
On the Honeywell BW™ Icon, the Bluetooth connection is on by default.
1. Turn On the BW Icon.
2. In your mobile device, open the Device Configurator app
3. In your BW Icon:
lDouble press to enter the menu
lSingle press until the BLE icon is displayed
lHold press 3 secs to initiate the pairing mode.
4. In the Device list screen from the Device Configurator app, select the BW Icon Serial
Number to start pairing.
BW Icon 10 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

BLE Status Description
Pairing The BLE icon flashes every second, Tee IntelliFlash flashes every
five seconds, and two shot beeps.
Succeed The BLE flashes in blue every 15 seconds. The IntelliFlash
flashes every five seconds in green.
Fail The BLE icon is solid red, and two short beeps.
Calibration
Perform a calibration to adjust the sensitivity levels of sensors and ensure accurate responses to
gases.
The detector can be calibrated in two ways:
• Apply gas from a cylinder to the sensors using the Safety Suite Device Configurator (SSDC)
software or the Device Configurator (DC) app.
• Use an IntelliDoX module. For further reference see the IntelliDox User Manual.
BW Icon 11 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

CAUTION
Move to a normal atmosphere (20.9% v/v O2) that is free of hazardous gas. Use 50% LEL for
test gas.
Details for calibration and maintenance:
lRecommendations for calibration of the equipment on a routine basis including the
maximum time interval between calibrations.
lCalibrate the apparatus before first-time use and then on a regular schedule, depending on
use and sensor exposure to poisons and contaminants. Honeywell recommends that the
sensors be calibrated regularly and at least once every 180 days (6 months).
lThe combustible sensor is factory calibrated to 50% LEL methane. If monitoring a different
combustible gas in the % LEL range, calibrate the sensor using the appropriate gas.
Procedure to calibrate the detector via the calibration cap and the DC app on a
mobile device
1. Turn On the BW Icon. Place the cap over the detector, and then press down on both tabs to
snap it into place. Wait a few minutes to sensors warm up.
BW Icon 12 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

2. Attach the hose.
3. In your mobile device, open the Device Configurator app
4. In your BW Icon:
lDouble press to enter the menu.
lSingle press until the BLE icon is displayed.
lHold press 3 secs to initiate the pairing mode.
5. In the Device list screen from the Device Configurator app, select the BW Icon Serial Number
to start pairing.
6. In your Mobile device, tap on the Menu button and then select Remote Calibration
7. Tap Calibration, the IntelliFlash flashes amber to indicate the calibration process has started.
BW Icon 13 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

8. Enter the Operator Name, and then Tap START. The instrument will start Zero calibration; the
IntelliFlash flashes amber, and the Calibration icon lights in blue.
9. After the Zero calibration is completed, use any of the following three ways to select the gas
cylinder, and then click START.
10. Select the sensor that you want to calibrate and then tap START.
BW Icon 14 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

11. Open the cylinder valve by turning the pressure regulator knob counterclockwise. Follow
onscreen instructions to know when to apply gas. The IntelliFlash lights amber.
BW Icon 15 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

12. After calibration is complete, a report is displayed. Tap the Return Arrow button to exit the
report and go back to the remote calibration main screen.
The detector will start purge, and the slots LEDs will flash in yellow clockwise.
After purge is completed, the instrument will back to the regular mode.
BW Icon 16 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

Procedure to calibrate the detector via the SSDC
Calibrate the BW Icon via the Safety Suite Device Configurator (SSDC).
1. Turn On the BW Icon. Place the cap over the detector, and then press down on both tabs to
snap it into place. Wait a few minutes to sensors warm up.
2. Attach the hose.
BW Icon 17 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

3. Connect the instrument to the PC via the IR link.
4. Log in to SSDC with an authorized user account. For further information, refer to the SSDC
User Manual.
5. Click on the Device List View tab, the SSDC scans for connected devices or you can click
Refresh to browse manually.
6. Select the connected detector and then click Start Bump/Cal.
7. In the Start Bump/Calibration Test window, do the following:
lSelect Calibration;
lSelect the calibration sensor. You can modify the default values;
lClick START TEST
lWait for several seconds. The detector starts ZEROCalibration, and the four slots
LEDs flash blue clockwise. After Zero Calibration is complete, the LEDs are solid blue
if calibration passed, or red if failed.
8. Optional Step. You can either remove or keep the IR link connection, the remaining
operation is in the instrument.
9. Apply span gas when the slot LEDs start flashing. Span calibration starts after the instrument
detects gas. The four slots LEDs flash blue clockwise. After the Span calibration is completed,
the LEDs are solid green if calibration passed, or red if failed.
10. Remove the calibration cap. The detector starts purging, and the slots LEDs flash in yellow
clockwise.
After the purge is complete, the device is back to the regular mode.
BW Icon 18 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

Bump Test
The detector can be tested in four ways:
lApply gas from a cylinder to the sensors manually through the calibration cap, and using the
detector's menu.
lApply gas from a cylinder to the sensors manually through the calibration cap, and using the
Safety Suite Device Configurator (SSDC) software on a computer.
lApply gas from a cylinder to the sensors manually through the calibration cap, and using the
Device Configurator (DC) app on a mobile device.
lUse an IntelliDoX module. For further reference see the IntelliDoX User Manual.
CAUTION
Move to a normal atmosphere (20.9% v/v O2) that is free of hazardous gas. Use 50% LEL for
test gas.
Details for Bump Test and maintenance:
lRecommendations for initial checking of the equipment on a routine basis including the
maximum time interval between calibrations.
lPerform a functional check with gas before each day of use.
lHoneywell recommends bump testing the sensors before each day’s use to confirm their
ability to respond to gas by exposing the apparatus to a gas concentration that exceeds the
alarm setpoints. Manually verify that the audible and visual alarms activate.
lThe combustible sensor is factory calibrated to 50% LEL methane. If monitoring a different
combustible gas in the % LEL range, calibrate the sensor using the appropriate gas.
Bump Test via the menu
Apply gas from a cylinder to the sensors manually through the calibration cap, and using the
detector's menu.
1. Turn On the BW Icon. Place the cap over the detector, and then press down on both tabs to
snap it into place. Wait a few minutes to sensors warm up.
BW Icon 19 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

2. Attach the hose.
3. Double press the button to enter the menu.
4. Hold the button to enter the bump test, then the slot LED starts flashing blue.
5. Apply span gas when the slot LEDs start flashing. The bump test starts after the instrument
detects gas. The four slots LEDs flash blue clockwise. After the bump test is completed, the
LEDs are solid green if calibration passed, or red if failed.
6. Remove the calibration cap; the detector starts purging, and the slots LEDs flash in yellow
clockwise. After the purge is complete, the device is back to the regular mode.
BW Icon 20 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

Bump Test via SSDC
Apply gas from a cylinder to the sensors manually through the calibration cap, and using the
Safety Suite Device Configurator (SSDC) software on a personal computer (PC).
1. Turn On the BW Icon. Place the cap over the detector, and then press down on both tabs to
snap it into place. Wait a few minutes to sensors warm up.
2. Attach the hose.
3. Connect the instrument to the PC via the IR link.
BW Icon 21 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664

4. Log in to SSDC with an authorized user account. For further information, refer to the SSDC
User Manual.
5. Click the Device List View tab, the SSDC scans for connected devices, or you can click
Refresh to browse manually.
6. Select the connected detector and then click Start Bump/Cal.
7. In the Start Bump/Calibration Test window, do the following:
lSelect Bump
lSelect the bump test sensor. You can modify the default values
lClick START TEST
8. Optional Step. You can either remove or keep the IR link connection. The remaining
operation is in the instrument.
9. Apply span gas when the slot LEDs start flashing. The bump test starts after the instrument
detects gas. The four slots LEDs flash blue clockwise. After the bump test is completed, the
LEDs are solid green if calibration passed, or red if failed.
10. Remove the calibration cap. The detector starts purging, and the slots LEDs flash in yellow
clockwise. After the purge is complete, the device is back to the regular mode.
BW Icon 22 User Manual
www.CanarySense.com
Shop for Gas products online at: 1.888.610.7664
