Honeywell MultiRAE Series User manual

Honeywell MultiRAE Series™
Portable Multi-gas Monitor

Table of Contents
Honeywell MultiRAE Series™ 1
Safety 1
Features Comparison 8
Standard Contents 11
General Information 14
Key Features 15
User Interface 19
Display Overview 19
Screen Display for Various Numbers of Active Sensors 26
Menus 27
Wireless Control and Submenus 32
Point-To-Point Wired Connection 35
Using Safety Suite Device Configurator (SSDC) to Set P2P Operation 35
Connecting a MultiRAE to a PC to Enable Point-To-Point Operation 39
Charging with the MultiRAE Desktop Cradle 41
Automatic PID Cleaning 42
Charging with The Travel Charger 43
Carrying the MultiRAE In A Vehicle 43
Charging with the AutoRAE 2 46
Replacing a Battery 46
Charging Batteries with A MultiRAE Battery Charger 47
Battery States 49
Alkaline Battery Pack 49
Turning the MultiRAE On and Off 52
Fast Access to Safety Suite Device Configurator (SSDC) 52
Turning the MultiRAE On 52
Turning the MultiRAE Off 53
Honeywell MultiRAE Series™ 2 User Manual

Testing Alarm Indicators 53
Glance Mode 53
Pump Status 54
Calibration Status 55
Bump Status 55
Toggle Display: Alternating Between Correction Factor and Reading 55
Enabling Benzene Operation & Sep-Tube Cartridge Tutorial 56
Modes of Operation 59
Hygiene Operation Mode 59
Search Operation Mode 59
Benzene-Specific Mode 59
Basic User Mode 66
Advanced User Mode 66
Programming 68
Enter Programming in Advanced Mode 68
Enter Programming in Basic Mode 69
Menus and Submenus 70
Policy Enforcement 114
Setting Policy Enforcement 114
Deactivating Policy Enforcement 118
Calibration and Testing 121
Manual Alarms Test 121
Bump Testing and Calibration 121
Zero/Fresh Air Calibration 126
Span Calibration 127
Three-Point Calibration for Enhanced Linearity with Extended- Range And ppb
PID Sensors 128
MultiRAE Pro Normal & Gamma Operation 134
Normal Mode for Simultaneous Radiation & Gaseous Threat Measurements 134
Gamma Radiation-Only Measurement Mode 134
Honeywell MultiRAE Series™ 3 User Manual

Datalog Transfer, Monitor Configuration, and Firmware Upgrades
Via Computer 138
Downloading Datalogs and Performing PC-Based Instrument Configuration and
Firmware Upgrades 139
Maintenance 142
Removing/Installing the Rubber Boot 142
Replacing the Filters 143
Replacing the Gas Inlet Adapter 144
Removing/Cleaning/Replacing Sensor Modules 144
Removing/Cleaning/Replacing A PID (Pumped Versions Only) 145
Replacing the Pump 147
Alarms Overview 149
Alarm Signals 149
Changing the Alarm Mode 149
Alarm Signal Summary 150
Troubleshooting 155
Pump Stall Threshold Adjustment 159
Entering Diagnostic Mode to Set the Pump Stall Threshold 159
Selecting the Pump Stall Threshold Method 160
Setting Pump Stall Threshold Values – Dynamic Method 160
Setting Pump Stall Threshold Values – Static Method 162
Configuring Wi-Fi Communication 166
Setting Wi-Fi Communication Parameters in Safety Suite Device Configurator
(SSDC) 166
Configuring Messaging 171
Configuring BLE 172
BLE Modes 172
Specifications 179
Honeywell MultiRAE Series™ 4 User Manual

Appendix 186
Alarm Limits 186
Sensors’ information 188
Contact Us 190
Honeywell MultiRAE Series™ 5 User Manual

IMPORTANT!
MultiRAE-series instruments use instrument firmware version 1.52/sensor firmware version 1.52.
MultiRAE series device uses instrument FW 1.31/ sensor FW 1.08A
MultiRAE lite with Wi-Fi option uses instrument FW 1.36/ sensor FW 1.36
Note: Fws 1.36 are not compatible with MultiRAE series device not using Wi-Fi module (and vice
and versa).
IMPORTANT! BUMP TEST THE MONITOR BEFORE EACH DAY’S USE
Prior to each day’s use, every gas detection monitor should be bump tested to confirm the
response of all sensors and activation of all alarms by exposing the monitor to a
concentration of target gas that exceeds the low alarm set point. A bump test is also
recommended if the monitor has been subjected to physical impact, liquid immersion, an
Over Limit alarm event, or custody changes, or anytime the monitor’s performance is in
doubt.
To ensure greatest accuracy and safety, only bump test and calibrate in a fresh air
environment.
The monitor should be calibrated every time it does not pass a bump test, but no less
frequently than every six months, depending on use and exposure to gas and contamination,
and its operational mode.
• Calibration intervals and bump test procedures may vary due to national legislation.
• Honeywell recommends using calibration gas cylinders containing the gas that is
appropriate to the sensor you are using, and in the correct concentration.
MultiRAE series device uses instrument FW 1.31/ sensor FW 1.08A
MultiRAE lite with Wi-Fi option uses instrument FW 1.36/ sensor FW 1.36
Honeywell MultiRAE Series™ 1 User Manual
CHAPTER
1Safety

CAUTION! Fws 1.36 are not compatible with MultiRAE series device not using Wi-Fi module
(and vice and versa).
WARNINGS
Read Before Operating
This manual must be carefully read by all individuals who have or will have the responsibility of
using, maintaining, or servicing this product. The product will perform as designed only if it is
used, maintained, and serviced in accordance with the manufacturer’s instructions.
CAUTION!
Never operate the monitor when the cover is removed. Remove the monitor rear cover or battery
only in an area known to be non-hazardous.
ANY RAPID UP-SCALE READING FOLLOWED BY A DECLINING OR ERRATIC READING MAY
INDICATE A GAS CONCENTRATION BEYOND UPPER SCALE LIMIT, WHICH MAY BE
HAZARDOUS.
TOUTE LECTURE RAPIDE ET POSITIVE, SUIVIE D’UNE BAISSE SUBITE AU ERRATIQUE DE LA
VALEUR, PEUT INDIQUER UNE CONCENTRATION DE GAZ HORS GAMME DE DÉTECTION QUI
PEUT ÊTRE DANGEREUSE
ONLY THE COMBUSTIBLE GAS DETECTION PORTION OF THIS INSTRUMENT HAS BEEN
ASSESSED FOR PERFORMANCE.
UNIQUMENT, LA PORTION POUR DÉTECTOR LES GAZ COMBUSTIBLES DE CET INSTRUMENT
A ÉTÉ ÉVALUÉE.
CAUTION: BEFORE EACH DAY’S USAGE, SENSITIVITY OF THE LEL SENSOR MUST BE TESTED
ON A KNOWN CONCENTRATION OF METHANE GAS EQUIVALENT TO 20 TO 50% OF FULL-
SCALE CONCENTRATION. ACCURACY MUST BE WITHIN 0 AND +20% OF ACTUAL.
ACCURACY MAY BE CORRECTED BY CALIBRATION PROCEDURE.
ATTENTION: AVANT CHAQUE UTILISATION JOURNALIERE, VERIFIER LA SENSIBILITE DU
CAPTEUR DE LIE AVEC UNE CONCENTRATION CONNUE DE METHANE EQUIVALENTE DE 20
A 50% DE LA PLEINE ECHELLE. LA PRECISION DOIT ETRE COMPRISE ENTRE 0 ET 20% DE
LA VALEUR VRAIE ET PEUT ETRE CORRIGEE PAR UNE PROCEDURE D’ETALONNAGE.
CAUTION: HIGH OFF-SCALE READINGS MAY INDICATE AN EXPLOSIVE CONCENTRATION.
Honeywell MultiRAE Series™ 2 User Manual

ATTENTION: DES LECTURES HAUTES ET HORS D’ECHELLE PEUVENT INDIQUER DES
CONCENTRATIONS DE GAZ INFLAMMABLES
CAUTION: Substitution of components may impair intrinsic safety.
Note: Users are recommended to refer to ISA-RP12.13, Part II-1987 for general information on
installation, operation, and maintenance of combustible gas detection instruments.
The MultiRAE multi-gas detector must be calibrated if it does not pass a bump test, or at least
once every 180 days, depending on use and sensor exposure to poisons and contaminants.
SPECIAL CONDITIONS FOR SAFE USE
1. The PGM-62xx shall only be fitted with Honeywell Battery Pack type M01-3053-000,
M01-3055-000, or Battery Adapter M01-3054-000 fitted with Duracell MN1500
batteries.
2. The PGM62xx shall only be charged outside hazardous areas.
3. No precautions against electrostatic discharge are necessary for portable equipment
that has an enclosure made of plastic, metal, or a combination of the two, except where
a significant static-generating mechanism has been identified. Activities such as placing
the item in a pocket or on a belt, operating a keypad or cleaning with a damp cloth, do
not present a significant electrostatic risk. However, where a static-generating
mechanism is identified, such as repeated brushing against clothing, then suitable
precautions shall be taken, e.g., the use of anti-static footwear.
The model PGM62xx is certified according to the IECEx scheme, ATEX and cCSAus (for US and
Canada). PGM62xx is intrinsically safe and may be used in hazardous locations.
SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC SAFETY.
MARKING
The product is marked with the following information:
HONEYWELL
700 Mint St.
Charlotte, NC 28202, USA
Type PGM62x0, PGM 62x6, PGM 62x8
Honeywell MultiRAE Series™ 3 User Manual

Serial No/matrix: XXX-XXXX-000
IECEx SIR 11.0069X,
Ex ia IIC T4 Ga
Ex ia I Ma
(PGM62x0/PGM62x6)
Ex ia d IIC T4 Gb
Ex ia I Ma
(PGM62x8)
2460 SIRA
11ATEX2152X
II 1G Ex ia IIC T4
Ga
I M1 Ex ia I Ma
(PGM62x0/PGM62x6)
II 2G Ex ia d IIC T4
Gb
I M1 Ex ia I Ma
(PGM62x8)
Exia Cl I,
Dv 1
Gr. A, B, C, D,
T4;
Cl II, Dv 1 Gr.
E, F, G; T85ºC
C22.2 No
152-1984
ISA-12.13.01-
2000
IECEx TSA 13.0021X /
ANZEx 13.3023X
Ex ia IIC T4 Ga
Ex ia I Ma
(PGM62x0/PGM62x6)
Ex ia d IIC T4 Gb
Ex ia I Ma
(PGM62x8)
Warnings: Understand manual first before operating.
Warning:Do not change batteries in hazardous location.
Do not mix old/new or different type of batteries
PGM62x0: Use only Honeywell battery pack.
PGM62x6/62x8: Use only Honeywell battery pack, PN: M01-3053-000, M01-3055-000, or
M01-3054-000.
Um: 20V
-20º C ≤ Tamb ≤ +50º C
Honeywell MultiRAE Series™ 4 User Manual

FCC Part 15 Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Operation Area and Conditions
Hazardous Areas classified by Zones
PGM62x0/PGM62x6are intended to be used in hazardous areas zone 0, zone 1 or zone 2,and
PGM62x8 in hazardous areas zone 1 or zone 2 within the temperature range of -20º C to +50º
C, where gases of explosion groups IIA, IIB or IIC and T4 may be present.
Hazardous Areas classified by Divisions
PGM62x0/PGM62x6/PGM62x8are intended to be used in hazardous areas classified for Class
I &II Div. 1 or 2, within the temperature range of -20º C to +50º C, where gases of explosion
groups A, B, C, D, T4; Groups E, F, G; T85°C.
WARNINGS:
1. NDIR sensors shall not be installed in PGM62x0 or PGM 62x6 models.
2. NDIR LEL sensors shall not be installed in PGM62x8 diffusion models bearing cCSAus logo.
Proper Product Disposal at End of Life
The EU Directive 2012/19/EU: Waste Electrical and Electronic Equipment (WEEE)
This symbol indicates that the product must not be disposed of as general industrial or
domestic waste. This product should be disposed of through suitable WEEE disposal facilities.
For more information about disposal of this product, contact your local authority, distributor, or
the manufacturer.
Recommended Storage Conditions
Storage Temperature: 0° C to 20° C (32° F to 68° F)
Storage Humidity:15% to 90% RH (relative humidity), non-condensing; preferred 30% to
70% RH
0% RH preferred sealed storage for PID and NDIR sensors
Storage Pressure: 90 to 110kPa
Storage Life: 6 months in sealed container (no air)
Honeywell MultiRAE Series™ 5 User Manual

In order to maximize rechargeable battery life and performance: Fully charge the battery. Then
use up to extend the battery performance because of charge cycle time
Running the instrument while charging is not recommended because it will shorten the battery
life and reduce performance. Operating the instrument while charging is forbidden in non-safe
areas.
If the instrument or battery pack is not used for long periods, we recommend charging every 4
months.
For sensor storage conditions, please refer to Technical Note TN-114.
Sensor Specifications, Cross-Sensitivities, And Calibration Information
For information on sensor specifications, cross-sensitivities, and calibration information, refer
to RAE Systems Technical Note TN-114: Sensor Specifications and Cross-Sensitivities
(available for free download from https://sps.honeywell.com/us/en/products/safety/gas-and-
flame-detection). All specifications presented in this Technical Note reflect the performance of
stand-alone sensors. Actual sensor characteristics may vary when the sensor is installed in
different instruments. As sensor performance may change over time, specifications provided
are for brand-new sensors.
Honeywell MultiRAE Series™ 6 User Manual

Honeywell MultiRAE Series™ 7 User Manual

This chart shows the differences between the various MultiRAE models.
MultiRAE
Pro MultiRAE MultiRAE Lite
Appearance
Gamma Radiation Sensor Yes
ppb PID
(10.6 eV; 0.01 - 2,000 ppm; 10 ppb
resolution)
Yes
High-Range ppm PID
(10.6 eV; 0.1 - 5,000 ppm;
0.1 ppm res.)
Yes Yes
ppm PID
(10.6 eV; 1 - 1,000 ppm;
1 ppm resolution)
Pumped Only
ppm PID (9.8 eV; 0.1 - 2,000 ppm; 0.1
ppm resolution) Yes Yes
20+ Electrochemical Sensors Yes Yes Yes
ETO-C Extended-range Sensor Diffusion Only
Hydrogen (H2) Sensor Diffusion Only
H2S, HR Extended-range Sensor Diffusion Only
Catalytic %LEL Sensor Yes Yes Yes
Combustible NDIR Sensors (%LEL or
%Vol. CH4)Yes Yes Pumped Only
CO2NDIR Sensor Yes Yes Yes
Integrated Wireless Modem (Optional) Yes Yes Yes
Integrated BLE Modem (Optional) Yes Yes Yes
Integrated Wi-Fi Modem (Optional) Yes Yes Yes
Sampling Pumped Pumped Pumped or Diffusion
IP Rating IP-65 IP-65 IP-65 (Pumped)
Honeywell MultiRAE Series™ 8 User Manual
CHAPTER
2Features Comparison

IP-67 (Diffusion)
Default Rubber Boot Color Black Yellow Yellow
Automatic Test and Calibration System AutoRAE
2
AutoRAE
2
AutoRAE 2, pumped
version only
Honeywell MultiRAE Series™ 9 User Manual

Honeywell MultiRAE Series™ 10 User Manual

The MultiRAE is available in four configurations, each with different kits, outlined below.
MultiRAE Lite
Pumped
MultiRAE Lite
Diffusion MultiRAE MultiRAE Pro
Monitor with sampling mode,
sensors, battery, and wireless
options as specified and
protective rubber boot, external
filter, and belt clip installed
Pumped
Yellow Rubber
boot
Diffusion
Yellow Rubber
boot
Pumped
Yellow
Rubber
boot
Pumped
Black
Rubber
boot
Travel Charger/PC
communications adapter Yes Yes Yes Yes
AC adapter Yes Yes Yes Yes
Desktop charging / PC
communications cradle No No No Yes
Alkaline battery adapter
Included with
rechargeable
configurations
only
Included with
rechargeable
configurations
only
Yes Yes
PC communication cable Yes Yes Yes Yes
Calibration adapter Yes Yes Yes Yes
6" flexible probe No No Yes Yes
3 spare external filters Yes No Yes Yes
10 charcoal filters (reduce CO
sensor’s cross-sensitivity to
VOCs)
Yes No Yes Yes
RAE-Sep Tube Cartridges * *
PID sensor cap removal tool Yes No Yes Yes
PID zeroing charcoal filter No No No Yes
Toolkit Yes Yes Yes Yes
QuickStart Guide Yes Yes Yes Yes
Technical Note TN-106 with
ionization energies and
correction factors for 300+
VOCs
Yes No Yes Yes
Calibration and test certificate Yes Yes Yes Yes
Cardboard box with a colorful Yes Yes No No
Honeywell MultiRAE Series™ 11 User Manual
CHAPTER
3Standard Contents

sleeve
Hard transport case No No Yes No
Pelican case Optional Optional Optional Yes
*If ordered with 9.8dV PID Lamp sensor.
Honeywell MultiRAE Series™ 12 User Manual

Honeywell MultiRAE Series™ 13 User Manual

The MultiRAE is a family of multi-threat gas monitors that combine continuous monitoring
capabilities for volatile organic compounds (VOCs), toxic and combustible gases, and radiation,
with Man Down Alarm functionality in one highly portable instrument. MultiRAE monitors offer
an industry-leading selection of interchangeable field-replaceable electrochemical, combustible,
infrared, PID (photoionization detector), and gamma radiation sensors to fit a wide variety of
applications. The MultiRAE family’s wireless capability elevates worker protection to the next level
by providing safety officers real-time access to instrument readings and alarm status from any
location for better visibility and faster response.
Notes:
lNDIR combustible sensors are not supported on the diffusion version with CSA
certification.
lThe PID sensor requires a pumped configuration.
lIf a %Vol. NDIR sensor is installed in an instrument, a catalytic bead %LEL sensor must
also be installed in the instrument for CSA certification.
IMPORTANT!
The benzene-specific cartridge can only be used on MultiRAE and MultiRAE Pro models
equipped with a 9.8eV lamp.
Honeywell MultiRAE Series™ 14 User Manual
CHAPTER
4General Information

Key Features
lAll-in-one continuous monitoring capabilities for gamma radiation, VOCs, oxygen, toxic
and combustible gases, for a total of up to six threats at a time
lHighly customizable with over 25 field-interchangeable intelligent sensor options
lWireless access to real-time instrument readings and alarm status from any location
through ProRAE Guardian Real-Time Wireless Safety System
lUnmistakable five-way local and remote wireless notification of alarm conditions,
including Man Down Alarm
lLarge graphical display with easy-to-use, icon-driven user interface
lSimple maintenance with easily accessible sensors, pump, and plug-and-play battery
lFully automated charging, data management, bump testing and calibration with
AutoRAE 2
MultiRAE With Pump, front view
1 External filter 5 MODE key 9 Alarm LED
2 Gas inlet 6 Y/+ key 10 Alarm buzzer
3 Belt clip (back) 7 LED 11 N/- key
4 Display 8 Charging and comm unication contact 12 Alarm LEDs
Honeywell MultiRAE Series™ 15 User Manual
