Honeywell HCE870 Series User manual

HCE870 SERIES
HCE870C SERIES
Air Purifier
Heater
Fan
Humidifier
Filter
Air Purifier
THERMAWAVE
TM 6
Ceramic Heater
Owner’s Manual
If you have any questions about the operation of this
product, please call us toll-free at 1-800-477-0457,
e-mail us at [email protected],
or visit our website at: www.HoneywellPluggedIn.com

2
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE SAFETY INSTRUCTIONS BEFORE
USING THIS HEATER
WARNING – READ AND SAVE THESE OPERATING AND SAFETY INSTRUCTIONS BEFORE USING
THIS HEATER. IF YOU DO NOT UNDERSTAND THESE INSTRUCTIONS OR PRODUCT LABELS
PLEASE CALL OUR CUSTOMER REPRESENTATIVES AT (800) 4770457 FOR ASSISTANCE
BEFORE USING THIS PRODUCT
Warning – Failure to follow any of these safety instructions could result in fire, injury or death.
YOUR RESPONSIBILITIES
Electrical appliances may expose people to hazards
that can cause severe injury as well as death. The
use of electrical products may create hazards
that include, but are not limited to, injury, fire,
electric shock and electrical system damage. These
instructions are intended to provide you with the
information you need to use the product correctly
and to help avoid hazards.
When using electrical appliances, basic
precautions should always be followed to reduce
risk of fire, electric shock, and injury to persons
including the following:
1. Warning – Read all instructions before using
this heater.
2. Warning – This heater is hot when in use. To
avoid burns, DO NOT let bare skin touch hot
surfaces. Use handles when moving this heater.
Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains
at least 3 feet (0.9 m) away.
3. Warning – Extreme caution is necessary
when any heater is used by or near children
or invalids. DO NOT leave operating and
unattended.
4. Warning – ALWAYS unplug heater when not
in use.
5. Warning – DO NOT operate any heater with
a damaged cord or plug, any heater that
malfunctions, or any heater that has been
dropped or damaged in any manner.
6. Warning – For residential use only.
7. Warning – DO NOT use outdoors.
8. Warning – This heater is not intended for use
in bathrooms, laundry areas and similar indoor
locations. NEVER locate heater where it may
fall into a bathtub or other water container.
9. Warning – DO NOT run cord under carpeting.
DO NOT cover cord with throw rugs, runners, or
similar coverings. DO NOT route cord under
furniture or appliances. Arrange cord away
from traffic area and where it will not be a
tripping hazard.
10. Warning – This appliance has a polarized plug
(one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended
to fit in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified
electrician. DO NOT attempt to defeat this
safety feature.
11. Warning – This heater draws 12.5 amps
during operation. To prevent overloading a
circuit, DO NOT plug the heater into a circuit
that already has other appliances working.
12. Warning – It is normal for the plug to feel
warm to the touch; however, a loose fit between
the AC outlet (receptacle) and plug may cause
overheating and distortion of the plug. Contact
a qualified electrician to replace loose or worn
outlet.
13. Warning – To disconnect the heater, first turn
off the product, then grip the plug body and
pull it from the wall outlet. NEVER pull by the
cord.
14. Warning – DO NOT insert or allow foreign
objects to enter any ventilation or exhaust
opening as this may cause an electric shock or
fire, or damage the heater.
15. Warning – To prevent a possible fire, DO NOT
block air intakes or exhaust in any manner. DO
NOT use on soft surfaces, like a bed, or where
openings may become blocked.
16. Warning – A heater has hot and arcing or
sparking parts inside. DO NOT use it in areas
where gasoline, paint or flammable liquids are
used or stored.

3
17. Warning – Use this heater only as described in
this manual. Any other use not recommended
by the manufacturer may cause fire, electric
shock, or injury to persons.
18. Warning – ALWAYS plug heater directly into
a wall outlet/receptacle. NEVER use with
an extension cord or relocatable power tap
(outlet/power strip).
19. Warning – NEVER tamper with this product
or attempt to fix it. Any tampering with, or
modification of this product can result in
serious injury, death, or fire. DO NOT open. Risk
of electric shock. There are no user serviceable
parts inside.
20. Warning – DO NOT remove product labels that
contain warnings or safety instruction.
21. Caution – The output of this heater may vary
and its temperature may become intense
enough to burn exposed skin. Use of this
heater is not recommended for persons with
reduced sensitivity to heat or an inability to
react to avoid burns.
22. Caution – Before cleaning, or storage, or when
not in use, turn the product’s controls to the
OFF position and unplug the heater from the
electrical outlet and allow to cool.
23. Caution – Place the heater on a firm, level,
open surface free from obstructions and at
least 3 feet (0.9 m) away from any combustible
materials. DO NOT use on an unstable surface
such as bedding or deep carpeting. Be sure the
heater is not in a position where it may be a
tripping hazard.
24. Caution – If your home has aluminum
wiring have a licensed electrician check your
receptacle’s connections. When using a 1500
watt heater, aluminum wire connections can
cause a safety issue.
25. SAVE THESE
INSTRUCTIONS

4
SETUP
MOVING THE HEATER
Turn off the heater.
Allow it to cool for ten (10) minutes.
Unplug heater and move. This heater is equipped with a Cool Touch Handle for your convenience.
Place the heater on a firm, level, open surface free from obstructions and at least 3 feet (0.9 m) away from
any wall or combustible material. DO NOT use on an unstable surface such as bedding or deep carpeting.
BE SURE THE HEATER IS NOT IN A POSITION WHERE IT MAY BE A TRIPPING HAZARD.
For best result, place heater on the floor to create warming room convection and allow heater to run for 510
minutes to reach maximum heat output.
ABOUT CERAMIC TECHNOLOGY
ASSEMBLY
Ceramic heaters generate heat by passing electricity through heating wires embedded in ceramic plates.
This type of heating technology provides fast, even heating.
The Thermawave™ 6 Heater was designed for maximum heat output.
This heater requires simple, no tool assembly.
Unpack Main Body and Mounting Base (Fig. 1).
Place Mounting Base on a firm surface. Place ThermaWaveTM 6 Heater Main Body on Mounting
Base so Mounting Tabs are aligned with Base Slots. Press Main Body onto the Base until Tabs snaps secure
into the Slots (Fig. 2).
Fig. 1 Fig. 2

5
OPERATION
NOTE: NEVER LEAVE AN OPERATING UNIT UNATTENDED
With the Power Button in the OFF position, plug the heater into a polarized 120V outlet.
DO NOT FORCE THE POLARIZED PLUG INTO THE OUTLET; it will only fit one way.
The ThermaWaveTM 6 Heater is versatile and designed to be placed in the center of the room or closer to the
wall (at least 3 feet away) for maximum convection room heating.
ThermaWaveTM 6 Heater Operation
Turn heater on by pressing ON ( ) button. The heater will default to the low setting.
Adjust Louver to give directional heat control.
To turn the unit off, press the power until none of the heat settings are illuminated and the red power light is
off. The fan will continue running for 60 seconds after the power is shut off, in order to cool down the heating
element. Unplug the heater when you are finished using it.
The Settings ( ) Button is equipped with three (3) settings: Fan Only ( ) Low Heat ( ), High Heat ( ). The
Low ( ) heat setting uses 900 watts of power and the High ( ) heat setting uses 1500 Watts of power.
The Fan Only ( ) setting uses very low power and does not provide heat. You can select the proper setting
to accommodate your comfort level with the Settings Button ( ). Press the button until the setting you want
is illuminated. The Low ( ) heat setting does not require as much electricity to operate, it is more energy
efficient and may be a better option if you are concerned about amperage draw on a circuit when the heater
is on the High setting.
The Adjustable Thermostat ( ) button is equipped with
4 pre-set Heat Levels. To set Thermostat to one of
these levels, press the Thermostat ( ) button until the
temperature desired is illuminated. The heater will operate
at the High setting until the room reaches the desired
temperature. The heater fan will run for 60 seconds and
turn off until the room temperature goes below desired
temperature it will then turn back on.
The Timer Button ( ) is equipped with three (3) settings:
two hours (2h) four hours (4h) ) and eight hours (8h). The
timer option will illuminate once selected. The timer is not
on if none of those three (3) timer settings are illuminated.
2h
8h
4h
65˚ 70˚
75˚ 80˚
Timer Option
Adjustable
Louver
Adjustable
Thermostat
Power Button
Model 870 Series
3 Settings
Auto/LO/HI

6
SAFETY FEATURES
We recommend that the ThermaWave™ 6 Heater be cleaned at least once a month and before
off-season storage.
• Turn the heater OFF ( ) and unplug it. Allow it to cool.
• Use a dry cloth only to clean the external surfaces of the heater. DO NOT USE WATER, WAXES,
POLISHES OR ANY CHEMICAL SOLUTIONS.
• Before storing, clean the ThermaWave™ 6 Heater using the above-mentioned steps. Wrap the cord around
the unit. Place in its original box and store it in a cool, dry place.
If your ThermaWave™ 6 Heater shuts off unexpectedly or fails to operate, one of your heater safety features
may have been activated to prevent overheating.
• Be sure it is plugged in and that the electrical outlet is working.
• Check for any obstructions. If you find an obstruction, turn the heater OFF and unplug it. Allow the heater
to cool completely, then remove the obstruction. Wait at least 20 minutes, then plug the heater back in
and follow the OPERATION instructions.
• Make sure the heater is on a flat level surface so that the tip over switch is not engaged.
The ThermaWave™ 6 Heater is equipped with several devices and features for added protection:
• A 360º tip-over switch that disables the heater if it is tipped in any direction.
• Two high temperature safety sensors prevents overheating. If activated, unplug the device and wait at least
20 minutes or allow the unit to cool completely. Make sure the operating conditions are safe and then plug
the heater back in and follow the OPERATION instructions.
• Thermal insulated wiring for heat resistance and reinforced wire connections to help protect against loose
connections.
• Built using a high temperature plastic and has a cool to touch housing and handle.
• The 8 hour timer auto off is the default setting upon powering the unit on. To select another option, press timer.
STORAGE
TROUBLESHOOTING
CLEANING

7
CONSUMER RELATIONS
We are here to help.
Call us toll-free at: 1-800-477-0457
E-mail: [e-mail];
Or visit our website at: www.HoneywellPluggedIn.com
In Canada visit: www.HoneywellPluggedIn.ca
Please be sure to specify a model number located on the box and the back and bottom of your unit.
NOTE: IF YOU EXPERIENCE A PROBLEM, PLEASE CONTACT CONSUMER RELATIONS FIRST OR SEE YOUR
WARRANTY. DO NOT RETURN TO THE ORIGINAL PLACE OF PURCHASE. DO NOT ATTEMPT TO OPEN THE
MOTOR HOUSING YOURSELF, DOING SO MAY VOID YOUR WARRANTY AND CAUSE DAMAGE TO THE FAN
OR PERSONAL INJURY
Model(s) 870 Series
Unit Dimensions 7.75” L x 17.8” W x 18.31” H (assembled)
Amps 12.5
Unit Voltage 120V, 60Hz
Max Watts 1500
Max BTUs 5118
Operation Cost*
To estimate the cost to operate this heater, multiply the watts used by 0.001 to convert into kilowatts then
multiply the kilowatts used by your local kilowatt hour electric rate for however long you run the heater. For
example, if your electric rate is $0.1326** per kilowatt hour and you ran this heater in constant high mode
(1500 watts) for 4 hours, it would cost you $0.80 cents to run the heater (1500 watts x 4 hours x 0.001) x
$0.1326 kwp = $0.80 cents).
NOTE: The Low setting does not require as much electricity to operate, it is more energy efficient and may
be a better option if you are concerned about the higher power consumption when the heater is on the High
setting.
*Calculation (Total Wattage x 0.001 x hours used) x Cost per Kilowatt Hour.
**Average Retail Price of Electricity to Ultimate Customer by EndUse, US Energy Information
Administration, July 2020.
PRODUCT SPECIFICATIONS

8
3 YEAR LIMITEDWARRANTY
YOU SHOULD FIRST READ ALL INSTRUCTIONS
BEFORE ATTEMPTING TO USE THIS PRODUCT.
A. This 3 year limited warranty applies to repair or
replacement of product found to be defective
in material or workmanship. This warranty does
not apply to damage resulting from commercial,
abusive, unreasonable use or supplemental damage.
Defects that are the result of normal wear and
tear will not be considered manufacturing defects
under this warranty. KAZ IS NOT LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION
OF THIS WARRANTY. Some jurisdictions do not
allow the exclusion or limitation of incidental or
consequential damages or limitations on how long
an implied warranty lasts, so the above limitations
or exclusions may not apply to you. This warranty
gives you specific legal rights, and you also may
have other rights which vary from jurisdiction
to jurisdiction. This warranty applies only to
the original purchaser of this product from the
original date of purchase.
B. At its option, Kaz will repair or replace this
product if it is found to be defective in material
or workmanship.
C. This warranty does not cover damage resulting
from any unauthorized attempts to repair or
from any use not in accordance with the
instruction manual.
Please go to:
www.HoneywellPluggedIn.com/warranty-
registration to register your product and to sign up
to receive new product information updates and new
promotional offers.

9
FCC/ICES COMPLIANCE
ICESCOMPLIANCE
In the USA:
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help. Please note that changes or
modifications of this product not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This device complies with Industry Canada license exempt - RSS210. Operation is subject to the following 2
conditions: (1) This device may not cause interference and (2) This device must accept any interference including
interference which may result in the undesirable operation of this device.

10
