Hubbell KILLARK MC Series Instruction Manual

Page 1 of 3
3940 Dr. Martin Luther King Drive
St. Louis, MO 63113
KIL00921465 FORM NO. K1465 06/15 ERO-8-029-15
INSTALLATION, OPERATION &
MAINTENANCE DATA SHEET
MC SERIES 45° & 90°CABLE GLANDS FOR USE WITH
TYPE MC, MC-HL, TECK90-HL, RA90, RA90-HL, AC90,
AC90-HL, ACWU90, and ACWU90HL CABLE
MC SERIES 45° & 90°CABLE GLANDS FOR
USE WITH TYPE MC, MC-HL, TECK90-HL,
RA90, RA90-HL, AC90, AC90-HL, ACWU90,
and ACWU90HL CABLE
CAUTION:
Before installing, make sure you are compliant with area classications, failure to do so may result in bodily injury,
death and property damage. Do not attempt installation until you are familiar with the following procedures. All
installation must comply with the applicable Electrical Code.
Make sure that the circuit is de-energized before starting installation or maintenance.
Verify that the installation is grounded. Failure to ground will create electrical shock hazards, which can cause
serious injury and or death.
IMPORTANT;
Please read these instructions carefully before installing or maintaining this equipment. Good electrical practices
should be followed at all times and this data should be used as a guide only.
Technical information, advice and recommendations contained in these documents is based upon information
that Killark believes to be reliable. All the information and advice contained in these documents is intended for
use only by persons having been trained and possessing the requisite skill and know-how and to be used by
such persons only at their own discretion and risk. The nature of these instructions is informative only and does
not cover all of the details, variations or combinations in which this equipment may be used, its storage, delivery,
installation, check out, safe operation and maintenance. Since conditions of use of the product are outside of the
care, custody and control of Killark, the purchaser should determine the suitability of the product for his intended
use, and assumes all risk and liability whatsoever in connection therewith.

Page 2 of 3
3940 Dr. Martin Luther King Drive
St. Louis, MO 63113
KIL00921465 FORM NO. K1465 06/15 ERO-8-029-15
For Class I, Division 2, Groups A, B, C & D
Class II, Division 1, Groups E, F & G; Class III.
Type 3 and 4. IP66. Operating Temperature Range
-50°C +60°C
1. Back Nut
2. Middle Nut
3. Grounding Spring (Captive in the Middle Nut)
4. Armor Stop
5. Elbow
6. Locking Collar
7. Potting Chamber
8. Entry Component
9. O-Ring (Captive in Entry Component)
ASSEMBLY INSTRUCTIONS
STEP A (Refer to Figure A on left)
Strip cable to suit equipment as shown above,
exposing metal armor sheath (I) and insulated
cores (II).
I = 3/4” (19mm) for ½” size glands
I = 13/16” (21mm) for ¾” size glands
I = 1” (25mm) for 1” size glands
I = 1-1/4” (32mm) for1-¼” size glands
II to suit equipment
STEP B (Refer to Figure B on left)
Push the cable through the back nut (1), middle
nut (2), and grounding spring (3). Locate the armor
stop (4) at the end of the armor as shown below. If
the conductors are too large to t through the armor
stop (4) it can be removed from the assembly. The
elbow component (5) has a built in armor stop for
larger cables. Feed the wires through the elbow
and tighten the middle nut (2) and backnut (1) to
the torque shown in Table A (Approximately hand
tight + 1 turn). This will compress the grounding
spring (3) to grip the armor for grounding.
Figure A
Figure B

Page 3 of 3
3940 Dr. Martin Luther King Drive
St. Louis, MO 63113
KIL00921465 FORM NO. K1465 06/15 ERO-8-029-15
Table A
Gland Size
Assembly
Torque (lbf-ft)
1/2” 20
3/4” 20
Figure C1
Figure C2
STEP C (Refer to Figure C on left)
If the gland is to be installed in a threaded opening
rst thread the entry component (8) into the
enclosure to prevent twisting of the cable. When
installing the entry component (8) into a NPT entry
the component should be installed hand tight and
then one additional turn with a wrench.
If the entry component (8) is installed into a thru hole
with a locknut, rst thread the entry component (8)
into the locknut. The entry component (8) should
be tightening to the torque shown in Table A
(Approximately hand tight +1 turn).
Thread the locking collar (6) onto the entry
component (8) to the torque show in Table A. This
is to prevent twisting of the cable during assembly.
