TABLE BOX INSTALLATION INSTRUCTIONS
Hubbell Premise Wiring, HUBBELL INCORPORATED (Delaware)
23 Clara Dr Suite 103 Mystic, CT 06355 [phone], Fax [phone]
www.hubbell-premise.com
1ASSEMBLY:
2. MAKE ELECTRICAL CONNECTIONS TO LOW VOLTAGE
DEVICE(S) (PURCHASED SEPERATELY) AS REQUIRED WITH THE
PROVIDED INSTRUCTIONS. USE ONLY THE BOTTOM KNOCKOUTS
TO PASS CABLES THROUGH. SEE FIGURE 1
4. RE-INSTALL GANG PLATE WITH PROVIDED
SCREWS.
This Instruction sheet applies to the following Hubbell catalogs:
WSB985BK : PREWIRED 2 GANG TABLE BOX WITH USB
WSB986BK : PREWIRED 3 GANG TABLE BOX WITH USB
GENERAL INFORMATION:
1. NOTICE: FOR INSTALLATION BY QUALIFIED ELECTRICIAN IN ACCORDANCE WITH THE NATIONAL AND
LOCAL ELECTRICAL CODE AND THE FOLLOWING INSTRUCTIONS.
2. CAUTION: RISK OF ELECTRIC SHOCK. DISCONNECT POWER BEFORE INSTALLING.
3. NOTICE: FOR INDOOR USE ONLY.
4. CHECK THAT THE DEVICE(S) TYPE AND RATING ARE SUITABLE FOR THE APPLICATION.
5. NOTICE: IN ACCORDANCE WITH NEC AND CEC, DATA COMMUNICATIONS MUST BE SEPARATED
FROM POWER CIRCUITS.
6. COMPATIBLE TABLE THICKNESS: 3/4" TO 2.00"
5.THE GREEN (LED) IS "ON" WHEN THE DC SWITCH IS IN
THE "ON" POSITION AND THE USB PORT AND AUXILIARY
DC OUTPUTS ARE POWERED.
1. REMOVE GANG PLATE TO INSTALL
LOW VOLTAGE DEVICES
AVPS15BK
3. CONNECT DC HOOKUP WIRE (UL2468) BETWEEN
LOW VOLTAGE DEVICES (UP TO TWO DEVICES WITH
WSB986BK) AND THE AUX DC WIRES FROM THE
AVPS15BK.
BOTTOM K.O.
FIGURE 1

Control No. Page of
Rev. Date:
Control No. Page of
Rev. Date:
HWS775466 2 4
2 8/21/18
HwS775466 3 4
2 8/21/18
2OUTLET BOX HEIGHT ADJUSTMENT: 4TABLE BOX MOUNTING:
3GFI TEST:
"X" "Y"
WSB985BK 6.00" 6.50"
WSB986BK 7.50" 6.50"
TABLETOPHOLECUTOUTDIMENSIONS
TABLE BOX CHASSIS
1. TEST BEFORE FINAL ASSEMBLY INTO TABLE.
REMOVE THE (4) #6-32 x
1/4" PAN HEAD SCREWS TO
ADJUST THE HEIGHT OF THE
OUTLET BOX INSIDE THE
TABLE BOX CHASSIS
1. DETERMINE LOCATION AND CUT HOLE WITH
1/4 MAX RADIUS CORNERS IN TABLE TOP.
SEE TABLE FOR HOLE SIZE.
FRONT
2. CONFIRM FINAL HEIGHT OF OUTLET BOX ASSEMBLY IN
TABLE BOX CHASSIS BEFORE
INSTALLING IN THE TABLE (SEE STEP 2)
ROTATE LOCKING ARMS CLEAR OF TABLE AND INSERT
TABLE BOX ASSEMBLY INTO HOLE IN TABLE.
3.
FRONT
4. ROTATE LOCKING ARMS TO SECURE ASSEMBLY TO
TABLE WITH ADJUSTMENT SCREW. LOCK ADJUSTMENT
SCREW WITH INTERGRAL NUT WHERE NEEDED. MAKE
ELECTRICAL CONNECTIONS AS REQUIRED.
SHARP TO 1/4 MAX R.
RIM
(2) LOCKING ARM
TABLE
RIM
(2) LOCKING ARM
(2) LOCKING ARM
ADJUSTMENT
SCREW WITH
LOCK NUT
“Y “X”
TABLE THICKNESS
3/4" TO 2.00"
2. THE GFI DEVICE IN THIS PRODUCT WILL IMMEDIATELY
PROVIDE POWER TO THE LOAD WHEN PLUGGED INTO A
POWER OUTLET.
3. PRESS THE "TEST" BUTTON. THE POWER "ON" LIGHT
SHOULD GO OFF.
4. PRESS THE "RESET" BUTTON. THE POWER "ON" LIGHT
SHOULD GO ON
5. DO NOT USE THE DEVICE IF IT FAILS THE ABOVE
TEST. THIS DEVICE DOES NOT PROTECT AGAINST
ELECTRICAL SHOCK DUE TO CONTACT WITH BOTH
CIRCUIT CONDUCTORS AND ALSO DUE TO A FAULT
IN ANY WIRING SUPPLYING THIS DEVICE.
TEST BUTTON
OUTLET BOX
ASSEMBLY
