HULALA HOME NSBSD0390 User manual

NOTE:
ITEM NO. NSBSD0390
This brochure contains IMPORTANT safty info. Please read and keep for
future reference.
1/16

MAINTAINANCE
AND WARNING
Keep furniture away from heat.
Do not clean furniture with harsh cleansers
or polish. Do not use detergents, Solvents,
abrasives, spray packs or leather cleaner. Use
non-color mild soap with warm water clean
spills(Mix 1:10 soap to water)
Do not place furniture under direct sunlight,
material will possibly fade over time.
Do not use on site dry Cleaning machine.
Children should not climb or jump on the
furniture.
Do not write on furniture without a padded
barrier to protect the surface.
Not for commercial use, For residential use
only.
Weight Limitation
80LBS
2/16

PARTS
LIST
3/16
13 x1
3 x1
12 x2
2 x1
1 x1
11 x1
10 x2
9 x2
8 x2
7 x2
6 x2
5 x1
4 x1

OVERVIEW
6
11
13
12
12
10
10
9
6
98
8
7
7
6
4
5
3
2
1

HARDWARE
LIST
Be sure to check all packing material carefully for
small parts, which may have come loose inside the
carton during shipment.
6
SPARE
x2
M4*18mm
Q
13
x2
x1
L
M4
M6*50mmM6*40mm
x6 x16x6 O
4*35mm
Px4K x2 x1N
x2 M
x10
3.5*14mm
M7*50mm
IJ
B G
x16
15mm
HF x4E x6 Dx8 C x4
8*30mm
Ax16
M6*35mm
18

ASSEMBLY
INSTRUCTIONS
x2
M4*18mm
Jx4O Ax8
M6*35mm
4*35mm
Gx8
O
G
6
X2 X2
O*2
A
A*4
J
6
G*4
8
9
7X2
Preparing the part 6.
1) Aligh the hole in part 6;
2) Screw in the cam bolt A and tighten by screwdriver.
3) Align the hole in part J to the hole in part 6 as the picture show, then screw in the
screw O from the part 6 towards part J, tighten by screwdriver.
4) Repeat the same way to finish another part 6
with part J.
Connect part 7,8 to the part 9.
1) Aligh the hole in part 7 to the hole in part 9;
2) Screw in the screw G and tighten by screwdriver;
3) Repeat the same way to finish the connnection of part 8 with part 9.

7
10
X2
10
7
Nx8 Bx8
15mm
8
9
8
9
Installing the part 10
1) Align the grooves in part 7,8 and 9; then
2) Insert and slide the part 10 into the grooves completely.
Connect the part 6 to the finished part in step 3, and preparing the part 1 after .
1) Align the hole in part 7, 8; then
2) Insert the nut B into the hole in part 7,8 as the picture show.Be sure the arrow on
the nut B towards the hole where the cam bolt A will come in!
3) Insert the cam bolt A into the nut B fully and tighten the nut B by screwdriver.
4) Cover the nut B hole by part N

8 6
N x8
B x8
15mm
B*4
2.
N
N*4
B
1.
1
3
4
A
M6*35mm
x8
A
D*4
A*4
1
Preparing the part 1.
1) Aligh the hole in part 1.
2) Insert the wooden towel D into the pre-drilled hole by hand;
3) Screw in the cam bolt A and tighten by screwdriver.
Connecting part 3,4 to the part 11.
Align the hole in part 3 and 4, screw in the cam bolt A and
tighten by screwdriver
1)Insert the nut B into the hole in part 11;
2)Insert the cam bolt A in part 3,4 into the nut B in part 11 fully;
3)Screw and fully tighten the nut B by screwdriver.
4)Cover the nut B hole by part N.
Connect the part 1 to the finished part in step 5.
1) Insert the nut B into the hole in part 3 and 4 as the picture show;
2) Insert the wooden dowel into the hole in part 3, 4; insert the
cam bolt A into the nut B at the same time; then tighten the but
B by screwdriver.
N
2.
1.
B
4
3
N*4
B*4
11
4
3
A
A*4
Dx4
8*30mm
Preparing the part 3 and 4.

9 16
3
5
5
4
4
3
C*4
2
P
5
C
D*4
P
M7*50mm
x4
M4
x1
8*30mm
C
D
x4
Install part 5
1) Align the groove in part 1, 3,4.
2) Insert and slide the part 5 into
the above groove completely
Install the part 2
1) Align the hole in part 3, 4,insert the wooden dowel D into
the predrilled hole by hand aspicture show.
2) Align the hole in part 2, insertwooden dowel D in part 3,4 into
the part 2, then
3) Align the hole and screw in thescrew C and tighten by AllenkeyP.

10 16
M6*40mm
x1P
M4
K x2
13* 6.5*1
M6*50mm
Mx6
L
P
M4
x6
x1
K
70%
K
P
K
13
12
12
12
2
12 M
L*6
P
M*6
100%
L
1.
2.
100%
P
K
Preparing the legs.
1) Align the hole between part 12 and part 13 as the picture show.
2) Screw in the screw K and fully tighten by Allenkey P.
Install the leg to the finished part in step 8
1) Align the hole in part 12 to the hole in part 2,
2) Screw in the screw L with washer M and fully
tighten by Allenkey P

EE
E
2.
1.
6
6
Install the drawer into the cabinet.
1)Move the slider-part in female metal slider to the open-end of
cabinet as above middle picture show; then
2) Align the male metal slider in part 7, 8 to the female metal slider
in part 3,4, insert the male metal slider into the slider-part of
female metal slider slowly for both at the same time, then push
forward when be sure they are all in position.
3) IN CASE the drawer doesn't fit the canibet frame, you can adjust
the female metal slider to make the drawer fit by loose the screw E
and move female metal slider up or down (according to your
situation), then tighten the screw E by screwdriver.

12 6
12
x6
3.5*14mm
F x4 Q E x1
1
E
5
E*6
Q
E
F*4
Q
F
E
Installing part F and Q
1) Insert the part F into the position between 1,2,3,4 and part 5 as the picture
show, then screw in the screw E and tighten by screwdriver.
2)Align the hole in part Q to the part 1 as the picture show, then screw in the
screw E and fully tighten byscrewdriver.

13 6
13
x1 IH x2x1
4*35mm
Q
Gx2
1
1.
I
X2
I
G
3.
I
G
Q
2.
QH
Installing the ANTI-COLLAPSE DEVICE
1) Mark the position on the wall( the height must be same to the height of
part Q on the back of cabinet, part Q finished in step 12);
2) Use driller dig a hole(driller must be 0.315in), then push the part I into the
wall by hammer(not provided) till it even with wall;
3) Align the hole in part Q to the hole in part I, and screw in the screw G
and fully tighten by screwdriver.
4) Iet the belt H go through the part Q in cabinet back and on the wall,
tighten them to secure safe.

14 6
Assembly completed
your cabinet is ready to use.
STEP 14

WARRANTY
We strive to offer high-quality products, and we also try our
best to satisfy each and every customer that orders from us
with product or service as needed. We provide 30 days
warranty starting from the time you receive the item. Each
customer must provide a record of their order such as the
order number, or item receipt for any items that are out of
the warranty period you may also still receive replacement
parts by purchasing them with our company if they are
available.
15/16

Are you having difficulty
with assembly? Missing parts?
Please send email with your order No
[email protected]
For return, Please check the return policy with
the retailer or MarketPlace you bought from.
Appreciated your purchasing from us.
Pop up your life by our furniture piece!
