HumanTechnik earis xs User manual

ES
Instrucciones de servicio
Página 23
EN
User manual
Page 2

2 Deutsch
Important safety notices ..........................................................................3
Safety notes on the lithium-polymer rechargeable battery ........................4
Introduction .............................................................................................4
Contents of package ...............................................................................5
Product overview.....................................................................................6
Connecting the transmitter to an audio source.........................................9
Connecting the transmitter to digital-out (S/PDIF / Toslink).......................9
Connecting the transmitter to RCA sockets ...........................................10
Connecting the transmitter to a headphone jack socket ........................10
Connecting the transmitter to a SCART socket......................................11
Powering the transmitter........................................................................12
Using the rechargeable battery ..............................................................12
Earbuds.................................................................................................13
Using “earis XS” ....................................................................................14
Using the “earis XS” underchin receiver .................................................14
Audio source selection ..........................................................................15
Adjusting the volume .............................................................................15
Adjusting the balance ............................................................................15
Set listening profile for sound improvement............................................16
Pairing transmitter and receiver..............................................................18
Important notes .....................................................................................18
Warranty................................................................................................19
Environmental information / disposal......................................................19
Troubleshooting.....................................................................................20
Specifications ........................................................................................22
Index Page

English 3
Important safety notices
Before setting up and using the device, please read these instructions care-
fully and thoroughly.
• Keep this user manual in a safe place so that it can be accessed by
other users at all times.
• Do not use the device if it is obviously damaged.
• Only use the device in locations where 2.4 GHz radio technology is
permitted.
• The device and in particular the power supply unit are only intended
for operation in dry indoor areas. Operation is only guaranteed within
room temperatures of 5°C to 35 °C.
• Keep the product, packaging and accessories away from children
and pets to avoid accidents.
• Always handle the device and accessories carefully and do not place
them in dirty or dusty areas.
• Clean the transmitter and receiver regularly. For hygienic reasons,
also clean the soft silicone earbuds regularly. Replace the earbuds for
the ones available as accessories.
• Paints and furniture polishes can chemically attack the transmitter‘s
rubber feet and cause surface damage to your furniture.
• Use only the provided power supply unit to power the transmitter.
• In the event of several days‘ absence, we recommend unplugging the
power supply unit from the mains electricity socket.
Attention:
Your receiver can be set to a very high volume. To protect your own hear-
ing or the hearing of people with regular hearing capabilities, especially
children, from damage caused by excessive volume, please observe the
following instructions:
1. Set the receiver to a low volume level before using it.
2. During use, adjust the volume to a level that is comfortable for you.
3. If you have a pacemaker, please check with your physician or the man-
ufacturer of the pacemaker before using this product.
4. If you use other medical devices, use the device only in accordance
with the safety instructions of your physician or the manufacturer.

4 English
Safety notes on the lithium-ions rechargeable
battery
The battery used in the “earis XS” is a lithium-ions battery manufactured in
accordance with the latest standards and safety regulations. Misuse or im-
proper treatment can damage the battery, in which case the Humantechnik
Group assumes no liability.
In extreme cases there is a risk of:
- development of heat
- development of fire
- explosion
- smoke or gas emission
• Do not expose the battery to temperatures above 70°C, e.g. by sun-
light or throwing it into fire.
• Do not expose the battery to water and condensation.
• Do not short-circuit the battery.
• Do not disassemble or deform the battery.
• Store the device / battery in a cool and dry place at room tempera-
ture.
• Only use the chargers provided for the battery.
• When not in use for a prolonged time, recharge the battery in the unit
regularly (every 6 months for approx. 1 hour).
• Charge the battery only at an ambient temperature of 10 °C to 40 °C.
• If the device is obviously defective, do not recharge the battery.
• Refer to the information regarding warranty and disposal.
Introduction
This digital wireless headset uses the latest digital radio technology and
enables sound amplification.
Enjoy crystal clear stereo- and TV sound anywhere in the house.
This digital wireless headset is intended to be used as assistive listening
that can be used help the hearing impared.
Please read this user manual carefully in order to set up the device correctly
and to become familiar with all the possibilities it offers.

English 5
Contents of package
1 “earis XS” receiver
1 “earis XS” transmitter
2 rechargeable batteries
1 power supply
1 pair of small earbuds
1 Toslink optical (digital) cable
1 audio connection lead with 3.5 mm
stereo jack plugs
1 audio-adapter RCA to 3.5mm stereo jack
1 quick guide
1 user manual

6 English
Product overview
Overview: Underchin receiver
1. Volume control
2. Speaker earbuds
3. Battery compartment
4. Status-LED / function button
5. Balance adjuster
6. Volume indicator
7. Charging contacts
8. Battery status
7
6
2
1
4
5
3
8

English 7
Overview: Transmitter
1. Charging dock
2. Status LED for receiver in charging dock
3. Charging compartment for spare rechargeable battery
4. Status LED for spare rechargeable battery
5. Charging contacts with support magnet
6. Status LED
7. Tone control / pairing button
8. Tone profile setting indicator
9. Connection socket for power supply
10. Optical-digital Toslink connector
11. Jack socket for connecting analogue audio sources (blue)
12. Analogue / digital selector switch
12
7
5
2
4
6
8
3
911
10
1

8 English
Overview: Status LED on transmitter
Status LED Transmitter.....
dark ... is switched off
white light ... is switched on and transmitting
white light flashes fast ... is in pairing mode
flashes 4x in white ....has no PCM signal at digital input
white light flashes 4x slow Connection to receiver lost
Overview: Status LED on receiver
Status LED Receiver.....
dark ... is switched off
constant green light ... is switched on and receiving
red LED on top ....Battery is empty soon
volume indicator bar flashes
rapidly ... is in pairing mode
Overview of audible alerts
Audible alert Signification
during use: 1 beep
every 30 seconds battery is almost depleted
when altering the volume:
1 beep maximum volume reached
when altering the volume:
2 beeps minimum volume reached
during use: 5 beep
every 20 seconds receiver is out of transmission range of
the transmitter

English 9
Connecting the transmitter to an audio source
Turn off the audio source before connecting the transmitter. Place the
transmitter near the audio source. Do not place the transmitter in the imme-
diate vicinity of thick reinforced concrete walls and other radio-transmitting
devices, as the transmission range could be reduced.
You have several possibilities to connect “earis XS” to a sound source (e.g.
TV, stereo set etc.).
Check the options of connection of your audio source.
Connecting options:
DIGITAL AUDIO OUT
-S/PDIF digital output (Toslink)
AUDIO OUT
LR
- RCA sockets
- Headphone jack
))
)
)
- Loudspeaker
AV
- SCART socket
Connecting the transmitter to digital-out
(S/PDIF / Toslink)
For best audio quality, connect the transmitter to your audio source using
the Toslink optical (digital) cable.
Please note that the digital input can only transmit audio sources in PCM /
Stereo standard.
Refer to the manual of the connected audio source to learn how to set up
the digital output.

10 English
Audio playback is not possible if a combined digital signal (bitstream) is
used. The status LED on the transmitter will flash twice, with a pause in
between, if there is no usable digital signal input.
Remove the protective caps on the two Toslink connectors on the cable.
Plug the Toslink optical cable into the transmitter‘s Digital In connector and
connect it to your audio source. The analog/digital switch on the transmit-
ter‘s left side must be set to “Digital”.
Connecting the transmitter to RCA sockets
Good audio quality can be achieved by connecting the transmitter to your
audio source using the analogue audio connection lead.
Plug the supplied audio connection cable into the transmitter‘s blue “An-
alog In” socket. Connect the RCA adapter cable audio connection lead.
Plug the RCA connectors into the RCA sockets of your audio source. Make
sure that the white connector is connected to the white socket of the audio
source and the red connector is connected to the red socket of the audio
source.
The analogue/digital switch on the transmitter‘s left side must be set to
“Analog”
Connecting the transmitter to a headphone jack
socket
Plug the supplied audio connection lead into the transmitter‘s blue “Analog
In” socket. Plug the audio connection lead into the headphone jack of your
audio source.
Set the volume of your sound source to a medium level, where possible.
There are TV sets that mute the speakers when devices are connected to
their headphone jack. On some television sets, this automatic muting can
be turned off via the TV settings menu. Alternatively, use another option for

English 11
connection. The analog/digital switch on the transmitter‘s left side must be
set to “Analog”.
Connecting the transmitter to a SCART socket
The SCART adapter is not included in the scope of delivery and can be
purchased from a specialist dealer.
Plug the supplied audio connection lead into the transmitter‘s blue “Analog
In” socket. Connect the SCART adapter with the audio connection lead.
Plug the SCART adapter into the SCART socket of your audio source. The
analog/digital switch on the transmitter‘s left side must be set to “Analog”.

12 English
Powering the transmitter
Connect the power supply unit to the transmitter with the yellow “5V DC
1.5A” power socket. Then plug the power supply unit into an electrical
mains outlet.
Using the rechargeable battery
Insert the supplied battery into the receiver, until it clicks into place (the
battery only fits one way)
Charge the receiver completely and without interruption before first use. A
complete charge will take about 2 hours.
The battery status on the receiver lights up red when the battery level is low.
When system is in use and the battery in the receiver is low, the status LED
on the receiver flashes RED constantly, and you will hear a beep every 30
seconds. After a few minutes, the receiver will automatically switch off.
To charge the battery, place the receiver in the charging dock of the Trans-
mitter. The LED bar must point upwards, magnets keep the receiver in the
correct charging position.
The charging status LED on the front of the receiver will illuminate red, the
charging status LED will switch to green when the battery is fully charged.

English 13
We recommend that you always place the receiver in the charging dock of
the transmitter when the system is not in use, this will always keep the bat-
tery in optimum condition. The intelligent charging circuit within the system
will prevent overcharging of the battery.
The second battery can be charged in the transmitter, additional batteries
are available from your dealer.
The replacement battery can be inserted into the charging slot on the right
side of the transmitter, please remove the cover over the charging slot.
The battery only fits one-way, extreme force is not required to insert it into
the transmitter.
During charging, the charging status LED for the spare battery lights up red
when the battery is fully charged this indicator changes to green.
We recommend that you swap the batteries once a week, this exercises
the batteries and allows them to reach their maximum lifespan.
Earbuds
As supplied, the larger silicone earbuds are fitted to the receiver‘s speaker
arms. If these buds are not comfortable for you, you will find a pair of small-
er earbuds in the delivery.
To change the earbuds, gently pull them off the speaker arms.
Then carefully insert the other two earbuds. Make sure that the earbuds fit
well and firmly.
From time to time, remove the earbuds from the receiver and clean them
with mild soapy water. Dry the earbuds thoroughly before replacing them.
In case of heavy soiling or damage, you should replace the earbuds. Re-
placements are available from your specialist dealer.

14 English
Using “earis XS”
Attention:
Your receiver can be set to a very high volume. To protect your own hear-
ing or the hearing of people with regular hearing capabilities, especially
children, from damage caused by excessive volume, please observe the
following instructions:
1. Set the receiver to a low volume level before using it.
2. During use, adjust the volume to a level that is comfortable for you.
3. Do not expose yourself to high volume for an extended amount of time.
Using the “earis XS” underchin receiver
To use “earis XS”, proceed as follows:
1. Switch your audio source on (e.g. TV). If “earis XS” is connected via
the headphone jack, you should set the volume of the sound source
to a medium level. This is not necessary if “earis XS” is connected via
Toslink or RCA.
2. The receiver switches on automatically when spreading the speaker
arms. Use the volume control on the receiver to adjust the volume to
a low level to protect your hearing. A low level of volume is indicated
when only a few LEDs on the volume indicator are lit. The more LEDs
on the volume indicator light up, the higher the set volume.
3. Adjust the earbuds so that they sit comfortably and without pressure
directly in front of your auditory canals. Look for the markings “L” and
“R” on the top of the speaker arms. The large silver volume wheel
should face forward for easy operation. Put the receiver on. The green
status LED at the top of the receiver indicates whether the receiver is
switched on.
4. The white status LED on the transmitter lights up white as soon as
the transmitter is in contact with the receiver and a transmission is
established.
5. Adjust to the desired volume.
6. When you remove the receiver, it is automatically switched off. We
recommend to always return the receiver to the transmitter‘s charging
dock so that the battery is always charged. If no audio signal reaches
the transmitter for more than 15 minutes, it will switch off automatically.

English 15
Audio source selection
You have the possibility to connecting a maximum of 2 audio sources to
the transmitter, for example an analogue stereo system and a digital TV
set. Use the “Analog/Digital” input selection switch on the left side of the
receiver to select the desired audio source.
Adjusting the volume
Use the silver volume control on the front of the receiver to easily adjust the
desired volume by turning it. The LED bar indicates the set volume. A low
level of volume is indicated when only a few LEDs on the volume indicator
bar are lit. The more LEDs on the volume indicator light up, the higher the
set volume.
Adjusting the balance
The balance control allows the volume distribution between the right and
left ear. Adjust the balance so that you hear equally well in both ears.
The balance control is located on the rear side of the receiver and can be
turned with the help of a coin.

16 English
Set listening profile for sound improvement
With our hearing profiles you have the possibility to find an optimal setting
for your hearing sensation. You can choose the most comfortable profile for
you from 5 sound profiles. The set profile is saved.
The following profiles can be selected:
1. strong sound alteration in the low frequency range
2. minor sound alteration in the low frequency range
3. no change
4. minor sound alteration in the high frequency range
5. strong sound alteration in the high frequency range
1. Press the tone control button on the top of the transmitter to select the
desired profile. You can identify the set profile on the transmitter by the 5
sound profile indicator LEDs.
You can connect a maximum of two receivers to one “earis XS” transmitter.
The transmitter calculates the sound profile, while the adjusted sound pro-
files are stored in the receiver.
The transmitter always calculates the set sound profile of the receiver that
is switched on first.

English 17
Pairing transmitter and receiver
For “earis XS” to function properly, transmitter and receiver must be paired.
As a rule, this has already been done during production and is carried out
as a standard on delivery.
However, if you want to use another receiver or perhaps have to replace
one later, it must first be paired with the transmitter.
A maximum of 2 receivers can be used simultaneously with one transmitter.
There are 2 possibilities to pair a receiver with the transmitter:
1. When inserting a receiver into the charging dock of the transmitter for at
least 15 seconds, the according receiver and the transmitter will be paired
automatically.
2. Press and hold the tone control button until the status LED on the front
of the transmitter starts flashing rapidly.
Underchin receiver: Wear the underchin receiver to switch it on.
Press the function button on the top of the receiver until the flashing status
LED on the transmitter lights up constantly. This indicates that transmitter
and receiver are now paired.

18 English
Important notes
The equipment is designed for listening within domestic environments.
Other uses are outside the scope of use for this product. Damage or con-
taimination caused to the equipment, caused by use not in accordance
with these instructions, is excluded from the warranty.
The devices are not waterproof and should be kept away from all liquids.
Do not place them near any heat sources. Do not place any items on top
of the devices which may cause them to malfunction.
Warranty
“earis XS” is a highly reliable product. Should a fault occur, contrary to
proper use, please refer to the troubleshooting guide. If this does not re-
solve the problem, please contact your retailer or the manufacturer directly
for further help before returning any items.
The warranty covers free repair as well as free return shipment, where ap-
plicable.
We recommend to return the items in the original packaging, so please
keep it for the length of the warranty period.
This warranty does not cover misuse, improper handling or attempted re-
pair by unauthorised persons (broken device seal). Warranty repairs will
only be carried out if proof of purchase is provided to the retailer or man-
ufacturer.
Always specify the product number in any event.

English 19
Environmental information / disposal
Disposal of used electrical and electronic devices (to be applied in coun-
tries of the European Union and other European countries with a
separate collection system for these devices).
The symbol on the product or on its packing indicates that this
product must not be treated as normal household waste, but that it must
be returned to a recycling point of acceptance for electrical and electronic
devices or that it must be disposed in a Yellow Bin. You protect the envi-
ronment and the health of your fellow man by contributing to the correct
disposal. Environment and health are endangered by incorrect disposal.
Material recycling helps to reduce the consumption of raw materials.
Additional information about recycling of this product can be obtained from
your community, the municipal disposal companies or the shop where you
bought the product.
Battery
The provided batteries can be recycled. Please dispose of the bat-
tery through battery containers or a specialist shop.
Please dispose only discharged batteries to guarantee environmen-
tal protection.
These devices comply to the requirements of the following EC directives:
- 2011/ 65/EU + 2015/863/EU RoHS-directive
- 2012/19/EU WEEE-directive
- 2014/53/EU RED-directive
Conformity with the above-mentioned directives is confirmed by the CE
mark on the device. CE declarations of conformity are available on the
Internet at www.humantechnik.com/service
This devices adheres to the requirements of the
following IC directives:
RSS-247 Issue 2 (2017-2)
Technical changes reserved.

20 English
Troubleshooting
Symptoms Cause Solution
Charging status LEDs
do not light up, de-
spite batteries insert-
ed in the transmitter
charging stations.
The transmitter is with-
out power from the
power supply unit.
Check that the power
supply unit is properly
connected and that
the mains electricity
outlet is working prop-
erly.
Charging status LED
does not light up, de-
spite a battery being
inserted.
No contact between
battery and charging
station in the transmit-
ter.
Insert the batteries cor-
rectly and completely
into the transmitter.
Check if the contact
areas are clean.
Charging status LED
for the receiver does
not light up, despite
the receiver being put
in the charging dock.
No contact between
the receiver battery
and the charging dock
of the transmitter.
Make sure that the
receiver is correctly
placed in the charging
dock.
The receiver does not
work, no sound trans-
mission.
No battery placed in
the receiver.
Insert the battery in the
receiver.
The transmitter is not
or not properly con-
nected to the TV- or
stereo set.
Check the cables and
connectors between
the transmitter and the
audio source.
The TV- or stereo set is
not switched on or the
output has not been
configured properly.
Switch the audio
source on or check the
settings.
The pairing has been
lost
Pair the transmitter
and the receiver again.
The receiver does not
work, no sound trans-
mission.
The receiver is not
switched on.
(Pocket Version)
Switch the receiver
on, using the ON/OFF
switch on the side of
the device.
(Pocket Version)
