Hunter Products ZP3999B User manual

Styles and colours may vary.
SUITABLE FOR AGES 3 YEARS +
MAXIMUM USER WEIGHT 30KG
ONLY 1 RIDER AT A TIME
FORWARD GEAR ONLY
For after sales service, replacement parts or
general enquiries please contact:
Web: www.electricrideon.com.au
Toll Free Service Phone: [phone]
Email: [email protected]
Item No.: 55180
Model No.: ZP3999B
INSTRUCTION MANUAL
Spider-Man 6 volt Motorbike

Contents
Before First Use: .................................................................................... 2.
Product Specifications: ........................................................................ 3.
Safety Precautions & Warnings: ....................................................... 4-7.
Parts List: ............................................................................................ 8-9.
Parts Diagram: ..................................................................................... 10.
Assembly Instructions: ........................................................................11.
Important Information: .........................................................................12.
Charging Instructions: ........................................................................ 13 .
Reset Fuse: .......................................................................................... 14.
Maintenance: ....................................................................................... 15.
General Care: ........................................................................................16.
Troubleshooting: ............................................................................17- 18.
Customer Service Information: .......................................................... 19.
Warranty: .............................................................................................. 20.

This Instruction Manual contains important safety information as well as assembly,
use and maintenance instructions. This bike must be assembled by an adult who
has read and understands the instructions in this manual. Keep the packaging
away from children and dispose of properly before use.
Keep this manual for future reference.
Before First Use: 2

3 Product Specifications:
For after sales service, replacement parts or general enquiries please contact:
Web: www.electricrideon.com.au
Toll Free Service Phone: [phone]
Email: [email protected]
SPEED
BATTERY
SPEC.
CHARGING SPEC
30 kg
2.5-3 km/hr
6V, 4.5AH
8V 0.5A
POWER MODE
CHARGING TIME
FUSE SPEC
Rechargeable
8-12 hours.
EXTERNAL
DIMENSIONS
MAX WEIGHT
LIMIT
5 amp Thermal FuseAGES
107x53x70 cm
suitable for children
3+ years

Safety Precautions & Warnings 4
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
WARNING!
The following safety hazards may result in serious injury or death to the user of the
vehicle Spider-Man 6v Motorbike Ride-on:
This product contains small parts that are for adult assembly only. Keep small
children away when assembling. Remove and dispose of all protective material and
poly bags before assembly. Be sure to remove all packaging materials and parts
from underneath the car body.
complies with Australian Standard AS/NZS 2063:2008.
Battery posts, terminals and related accessories contain lead and lead compounds
(acid) chemicals that are toxic and corrosive. Never open the battery.
Body parts such as hands, legs, hair and clothing can get caught in moving parts.
Never place a body part near a moving part or wear loose clothing while using the
vehicle. Always wear shoes when using the vehicle.
Using the vehicle near streets, motor vehicles, drop-offs such as: steps, water
(swimming pools) or other bodies of water, sloped surfaces, hills, wet areas,
accident.
Always use the vehicle in a safe, secure environment with continuous adult
supervision. Never leave the child unattended.
Using the vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand or
Using the vehicle in an unsafe manner. Examples include but are not limited to:
Pulling the vehicle with another vehicle or similar device
Allowing more than one rider
Pushing the user from the back
Traveling at an unsafe speed
Always use common sense and safe practices when using the vehicle. Different type
of batteries or new and old batteries are not to be mixed.
This toy is unsuitable for children under 3 years due to its maximum speed.
Battery charger, electric wire plug enclosure and other parts should be periodically.
•There are additional hazards of using the toy in areas other than private grounds.
check for damage, if have damage, need to repair before use.
Not to be used in trafc
•

5 Safety Precautions & Warnings (cont.)
WARNING!
Age Range 3 to 7 years
Weight Range No more than 30kg
Before using the vehicle the child should understand the vehicle controls and safety
issues. They must also demonstrate the capability to handle the vehicle and
operate its controls. It is the responsibility of the adult to educate the child and
supervise use of the vehicle.
Read the following safety warnings to any child using the vehicle Ride-on:
•
•
•
•
•
•
•
•
Only use the vehicle when an adult is present to watch (supervise).
Adult assembly requited.
• Always sit in the seat when using the vehicle.
• Keep your hands, hair and clothes away from moving parts.
• Always wear shoes when using the vehicle.
• Only one rider is allowed at a time on the vehicle Ride-on.
• Children under three years old cannot use the vehicle.
• Only drive on level ground.
• Do not go near water, drop-offs or up and down steep slopes.
• gravel.
• Do not drive the vehicle on streets or near cars.
PREVENT INJURIES AND DEATHS:
NEVER LEAVE CHILD UNATTENDED. ALWAYSkeep child in view when
child is in vehicle. Direct adult supervision is REQUIRED.
NEVER use in roadways, near cars, on or near steep inclines or steps,
swimming pools or other bodies of water.
ALWAYS wear shoes.
ALWAYS sit on the seat.
RISK OF FIRE. Do not bypass.
NEVER allow more than one (1) rider in the vehicle Ride on.

Safety Precautions & Warnings (cont.) 6
• Contact or exposure to battery leakage (lead acid) may cause serious injury.
If contact or exposure occurs immediately call your physician. If the chemical is
on the skin or in the eyes, flush with cool water for 15 minutes. If the chemical
was swallowed, immediately give the person water or milk. Do not give water or
milk if the patient is vomiting or has a decreased level of alertness. Do not induce
vomiting.
The following safety hazards may result in serious injury or death to the user of the
vehicle:
WARNING!
•
•
• Explosive gases are created during charging. Charge the battery in a well
ventilated area. Do not charge the battery near heat or flammable materials.
• Contact between the positive and negative terminals may result in fire or explosion.
vehicle direct contact between the terminals. Picking up the battery by the wires or
charger can cause damage to the battery and may result in a fire. Always pick up
the battery by its case or handles.
• Liquids on the battery may cause fire or electric shock. Always keep all liquids
away from the battery and keep the battery dry.
Use of a battery or charger other than the supplied 6v rechargeable battery and
charger may cause a fire or explosion. Only use the supplied 6v rechargeable
battery and charger with the vehicle.
Using the 6v rechargeable battery and charger for any other product may result in
over heating, fire or explosion. Never use the 6v rechargeable battery and charger
with another product.

7 Safety Precautions & Warnings (cont.)
WARNING!
WARNING!
•
Important! Before using the vehicle for the time the battery needs to be charged for
a full twenty-four hours (no more than thirty hours). Only an adult who has read and
understands the following safety warnings should handle, charge or recharge of the
battery (see Maintenance).
Note: It is not necessary to remove the battery from the vehicle for charging. However,
if the adapter cord will not safely reach a 240V wall outlet, the battery can be removed
for charging.
• Tampering or modifying the electric circuit system may cause
or explosion and permanently damage the system. Exposed wiring, circuitry
in the charger may cause electric shock. Always keep the charger housing
closed.
Battery posts, terminals and related accessories contain lead and lead
compounds (acid), chemicals and are toxic and corrosive. Never open the
battery.
• Non-rechargeable batteries are not to be recharged;
• Batteries are to be inserted with the correct polarity;
• Exhausted batteries are to be removed from the toy;
• The supply terminals are not to be short-circuited.
• Rechargeable batteries are only to be charged under adult supervision;

Parts List 8
PART
NO
REMARKS
PART
NO
REMARKS
1121
3241
5 6 2
7181
9110 1
11 112 1
13 114 1
Handle bar
Decorative
front fork
cover
Front axle
Mask
Body
Front
panel
Pedal
plate(1)
Training
wheel
Pedal
plate(2)
Dashboard Dashboard
cover
Bushing
Front
fender
Front wheel
(no gear
attachment)

PART
NO
REMARKS
PART
NO
REMARKS
15 116 2
17 418 2
19 20
21
24
22
23
2
1
2
2
8mm×1 6mm×2
OPERATION MANUAL
6V Dirt Bike
SUITABLE FOR AGES 3 YEARS +
MADE IN CHINA
MAXIMUN USE WEIGHT: 25kgs
Item No.: 55180
Screw
M10*140mm
Screw
4*12mm
Bolt
M5*25mm
Washer
6mm
1
Charger
Included
Tools:
Washer
8mm
Bolt
M6*16mm
Nut
8mm
Instruction
manual
9 Parts List

Parts Diagram 10
NOTE: Some Parts Shown are assembled
on both sides of vehicle
Screwdriver(not included)
ToolsRequired
Spanner
1
11
2
12
33
13
4
14
5
15
15
6
6
16
16
7
17
8
18
18
9
19
19
20 20
10
11
12
13
14
15
Screw
M10*140mm
Pedal plate(2)
Training wheel
Dashboard
Dashboard cover
1
2
3
4
5
Handle bar
Decorative front
fork cover
Front axle
Front fender
Front wheel (no
gear attachment)
16
17
18
19
20
Screw 4*12mm
Bolt M5*25mm
Washer 8mm
Nut 8mm
Nut 5mm
6
7
8
9
10
Mask
Body
Front panel
Pedal plate(1)
Bushing

11 Assembly Instructions
①
②
B type has no A and B plug-ins
③
B type helmet shield
⑤
⑦
⑧
⑥
④
STEPS:
BIKE ASSEMBLY:
Step 1: Install handle bar over front fender and into front fork covers in the same order as diagram 1.
Step 2: Install the front wheel with axle rod and nuts, pay attention to diagram 2 for order of parts
assembly.
Step 3: Loop the supplied tape through rear of mask and into webbing on the plastic handlebar plate to
fix the mask in place
Step 4: Fit part # 8 handlebar plate to front of bike using 4 x screws.
Step 5: Connect the plugs on handle bar with main body of the bike. Attach front wheel & handlebar
assembly to the main body of the bike using part # 15 - M10x140 Bolt & Nut.
Step 6: Slide the foot pedal axle rod through bike and fit plastic foot plates either side of the bike.
Step 7: Fit the training wheel assembly over the 2 bolts underneath the bike as per diagram 7. Fix and
tighten in place using M5 nuts.
Step 8: Fit dashboard onto the handlebar face plate and fix in place using M5 x 25 screws. Clip wind-
shield into place once dashboard is fitted.

（2）
A
Charging hole
1
Start switch
A
Important Information 12
1: Before using the bike for the first time locate the plugs on the right hand side of the handlebars as
per image 1 below. Ensure these plugs are connected together.
2: Charging Information.
Refer to image 2 below. Round charge port located on right side of bike is indicated with an arrow.
3: Add the Batteries (NOT PROVIDED) of dashboard
a. With a screwdriver remove the screw on the dashboard cover located in the center of
the steering wheel.
b. Remove the dashboard cover from the top of the battery compartment.
c. Insert two AA batteries in their correct polarities.
d. Place the dashboard cover over the battery compartment and fasten with the screw
you removed in step one.
4: Operating Instructions.
Start/Go switch is located on right hand handle. To operate press this button. To stop release the button.
AA1.5V
AA1.5V
Horn Engine sounds

13 Charging Instructions
To Charge the Battery:
1: Ensure the bike is stopped and turned off.
2: Plug the round charge pin into the charge port on the right side of the bike. As per image below.
3: Plug transformer into a 240 V outlet.
NOTE: First time charge should be for 10-14 hours
Subsequent charges should be 8-10 hours.
Do not charge for more than 15 hours.

Reset Fuse 14
Thermal Overload Fuse:
This bike is fitted with a thermal overload fuse. If the bike is overloaded the fuse will cut off
power to the bike for 10-20 seconds before resetting itself.
To avoid the fuse activating please
follow the below guidelines.
1: Maximum user weight is 30kg
2: Do not tow or overload bike with weight.
3: Do not get the bike or its electric components wet.
4: Do not alter the bikes circuitry or construction.

15 Maintenance
Important Battery and Charger Information
Only an adult who has read and understands the safety warnings may
handle and operate the battery and battery charger. Keep away from
children.
Charge the battery for 10-14 hours before using the vehicle for the first
time.
Charge the battery immediately after each use. Charge for at least 8-12
hours, but no more than 15 hours.
Charge the battery at least once a month, even if the vehicle is not used
or stored.
Never leave the battery in a discharged condition.
Connect the terminal of the battery and charger, then plug the charger
into a 240V AC outlet.
It is normal for the charger to heat slightly. If the charger rises above
71°C / 160°F, disconnect the charger and call Customer Service for
assistance.
Keep the charger away from water or excessive moisture to prevent
short-circuiting.
Only use the charger speci ed with the original item. Do not charge the
battery with any other charger.
Do not attempt to recharge non-rechargeable batteries with the original
charger.
Do not replace the battery with any other battery, or the warranty
will be voided.
Remove damaged batteries from the car immediately. Recycle or
dispose of the used batteries responsibly.
Do not short circuit the supply terminals.
Do not leave the battery connected in the vehicle for extended periods
of time when the vehicle is not being used. Disconnect the battery
connector from the engine connector before storing.
The vehicle is equipped with a thermal fuse to protect the electric
circuit. If the vehicle cuts out, turn the vehicle off and on to reset.

General Care 16
Regularly inspect all vehicle parts to ensure they are in good working
condition.
Regularly inspect the charger, cord, plug, and other related parts for
damage.
Remove any damaged parts and immediately contact Customer Service
for replacement parts.
DO NOT operate the vehicle if there are any damaged parts.
Carefully clean the vehicle with a damp cloth and mild soap. Do not
get water in or near any electrical parts. Do not wash the vehicle with a
hose.
Store the vehicle indoors or use a tarp to cover it. Keep away from
stoves, heaters, or other sources of heat.

17 Troubleshooting Guide
Problem Potential Cause Solution
Vehicle does not run Battery is low Recharge the battery
Thermal fuse tripped Reset fuse
Snap pins are loose Tighten snap pins
Loose wires or loose
connectors
Ensure the battery connectors
are securely attached. If wires
are loose, contact Consumer
Service for repairs
Battery is dead Call Customer Service for
replacement battery
Electrical system is
damaged
Call Customer Service for
repairs
Motor is damaged Call Customer Service for
repairs
Vehicle only runs for a
short time
Undercharged battery Ensure a secure connection
when the battery is
recharging. Recharge for at
least 8-12 hours
Overcharged battery Never charge the battery for
more than 15 hours
Battery is old Replace battery
Vehicle runs slowly Battery is not fully
charged
Ensure a secure connection
when the battery is recharging
Battery is old Call Customer Service to
order replacement battery
Too much weight on
vehicle
Reduce weight on vehicle
(30kg max)
Harsh conditions Operate the vehicle on level
ground and safe surfaces
Completely read through the manual and troubleshooting guide before
contacting Customer Service.

Troubleshooting Guide 18
Problem Potential Cause Solution
Vehicle needs a push to
start
Loose wires or loose
connectors
Ensure the battery connectors
are securely attached. If wires
are loose, contact Consumer
Service for repairs
“Dead spot” on motor A “dead spot” means
electricity is not being
delivered to the terminal.
Contact Consumer Service for
repairs
Dif culty shifting Attempting to shift while
vehicle is moving
Stop the vehicle before
shifting
Motor or gear box
making grinding noises
Motor or gear damage Contact Consumer Service for
repairs
Battery will not recharge Charger is not plugged in Plug in the charger to a
functional wall outlet
Charger is not working Call Consumer Service for a
replacement
Loose connector or loose
adapter
Check that the connectors are
securely plugged in to each
other
Battery makes bubbling
noise while recharging
This is normal No action required
Charger is warm This is normal No action required

19 Service and Repairs
If your product requires service, repairs or replacement parts, please visit
us online at www.electricrideon.com.au
Or contact us at:
Toll Free Service Phone: [phone]
emall: [email protected]
Hours: 9.00 AM - 5.00 PM (AEST), Monday - Friday
