Hunter Products TR1302 User manual

Mod e l N o .: TR1 3 0 2
Item No.: 5187
V e hicle m us t b e ch a rge d fully b e fore u se .
F ailure to d o so void s w arrant y .
- M
WARNING:
- M
-Maximu m u ser w eight i s 3 0KG.
-Suitablefor a ge s 3+ years .
-Please r e a d manualcarefullybefore u se .
-Adultassembl y require d .
-Thi s toyhave no b rake.
-Not t o b e u se d i n traffic.
-Always w e a r a helme t an d protective c l othin g when r i ding .
-Continuous adult s u pervisionrequire d when u singthis product.
-Chargingthe b a ttery ca n only b e d o n e b y adult at a ll time s .
-Before f i rst u s e , charg e thebattery fo r at leas t 8 - 1 2 hours,no more t h a n 2 0 hours .
-Neverdriving in t he road,street n e a r motor vehicles,ramps,ste e p inclines,stairs ,
s wimmingpools,other sourcesofwate r andany e l s e place dangerously.
-The to y shoul d b e used w it h caution s i nceskil l i s required t o a v oid f alls o r
c ollisions causinginjurytothe u s e r o r third parties.
-The transformers o r b a tter y charger u se d with t he t oy ar e t o b e r egularl y examined
f or d amage to th e cord, plug, e nclosure a nd other p arts, an d in th e even t of such
d amage , t hey m u s t no t b e used u ntil t h a t damagehad b e e n repaired .
-Please k e e p themanual a nd p a ckaging fo r futu r e referenc e a s i t contains i mportant
i nformation.

- 1-
1. SPECI FI CATI ONS
2. LI ST OF PARTS
3. Expl oded dr awi ng and ASSEMBLY STEP WI TH PI CTURE
4. FUNCTI ON OF VEHI CLE AND CI RCUI T DI AGRAM
5. CHARGI NG FOR THE VEHI CLE
6. FUSE
7. SAFETY PRECAUTI ONS
8. MAI NTAI NI NG VEHI CLE
9. TROUBLE- SHOOTI NG
10. DI SPOSAL OF BATTERY
1. SPECI FI CATI ONS
Sui t abl e age
Max. Load
Speed
Mat er i al
Char ger
PP
2. 5- 3Km/h
30kg
3+ year s Bat t er y
Si ze of t he car
Car t on s i ze
Char gi ng t i me
Fus e
Oper at i ng l i f e 300 charges
1000*600*500mm
DC 6V 4. 5AH
8- 12 hour s, at most 20 hour s
Temper at ur e
Opt i mum
Avoi d t o use under bur ni ng s un
Bel ow 40°C
F 5A, Sel f - r es et t i ng
980*540*360mm
I nput : Shown on t he char ger
Out put : 6V500mA

-2-
2．LIST OF PARTS
1
x 1
2
x1
4 5
x 1 x 4
x1
Rearview mirrors
(left&right)
Side board of the body
(left&right)
Wheel hub
(4pcs)
Driving wheel
(1pc)
Gear box
Back bumper fram
Body Dashboard cove
x1
Steering whee
x 1
x 1 x 1
6 7
9 1 0
8
1 1
1 2 1 3 1 4
x 1
3
x 1
Rear axle
Seat
x2
x 1
Steering rod
Flat head screw
(M3.5X16)
Flat head screw
(M4X16)
x 13

-3-
1
(1)Exploded drawing and part name
3．Exploded drawing and ASSEMBLY STEP WITH PICTURE
x3
x 4 x7
(3pcs)
Hub cap
(4pcs)
Axle sleeve
(7pcs)
1 8 1 9 2 0
1 5 1 6
x4
1 7
x 2
Washer
(4pcs)
Nut
(2pcs)
Charger
x 1
2
3
4
56
7
Wheel

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Body
Dashboard cover
Steering rod
Steering wheel
Seat
Flat head screw
Rearview mirrors
(left&right)
Flat head screw
(M3.5X16)
S id e bo ar d o f t he b od y
Back bumper frame
Rear axle
Gear box
Wheel hub
Hu b cap
Axle sleeve
Washer
Nut
-4-
(left&right)
(M4X16)
9
10
1 1
12 13
14
1 5
1 6
17
19
1 8
8
Wheel
Driving wheel

(2) ASSEMBLY STEP WITH PICTURE
1. Assemble the dashboard cover and the frame
1.2. Turn over the body, connect the plug under the body.
1.3. Fix the board on both side of the body with screws.
Join the back bumper frame together with the back bumper by screws.
1.1. Insert the plug of the dashboard cover into the body. Lock the dashboard
cover on the suitable place,then tighten the screws.
2. Assemble the black wheel
Axl e sl e ev e
Rea r ax l e
Washer
W ashe r
Axle sleeve
Washer
Nut
Hubcap
W hee l h ub
Axle sleeve
Gearbox
Nu t
Wheel hub
Hub c a p
Washer
-5-
Wheel
Driving wheel

2.1. Put the axle sleeve on both side of the wheel. (just 1pc axle sleeve for
the driving wheel).
2.2. Take the parts away from the rear axle,then put the axle through the body
and put the gear box through the rear axle on the right side(when reverse
side up).
2.3. Put the driving wheel through the back axle and fix it with washer,nut and
the hub cap in turn.
4. Assemble the steering wheel and the rearview mirror
wheel washer
3.2 The other side is same as above
Frontaxle
washer
axle sleeve
nut
axle sleeve wheel hub
Hub cap
3. Assemble the front wheel
-6-
3.1 Take one piece of nut and one piece of washer away from one side of the
bogie.Put a wheel through the front axle,then fix it with washer,nut and hub
cap in turn.
2.4. Put the washer,wheel and another washer through the back axle onthe other
side in turn,then fix them with nut and hub cap.

4.1 Turn over the vehicle again,now it is right side.Put the steering rod
through the dashboard cover and hookup the bogie.
4.2 Take away the bolt and the nut in the steering wheel, connect the plug as
picture,then put the steering wheel on the steering rod. Place the bolt
through the steering wheel and fix it with nut.
-7-
4.3 Lock the rearview mirrors(left&right) on both sides of the body.
5．Plug in the battery,assemble the seat
5.1. Plug in the battery first, red to red,then connect the plug of the gear box
with the plug of the body.

-8-
5.2. Take away the two screws from the body of the vehicle,then place the seat ,
a nd f ix i t by t ho s e t w o s c re ws .
WARNING
Before using the vehicle,confirm the following has been done:
The battery has been fixed and inserted correctly and the vehicle has been
charged for at least 8-12 hours,no more than 20 hours.
That all screws are tightened.
The vehicle has been assembled strictly according to the steps that the
manual described.
Let your children know necessary safety rules before allowing them to use
the product.
Reduce the risk of injury:
Always wear shoes.
Please don't overweight,the maximum weight is 30kg.
Most of the material is plastic,so please always keep far away from fire
source.
dangerously.
driving.
Direct adult supervision required,without leaving children alone when
stairs ,swimming pools,other sources of water and any else place
Never driving in the road,street near motor vehicles,ramps,steep inclines,

1. Introduction of the functions
-9-
ForwardandReversesSwitch
Pedal Switch
General Power Switch
4．FUNCTION OF VEHICLE AND CIRCUIT DIAGRAM
(1) Turn on the general power switch first,the vehicle can move .
(2) Forward
Press the "Forward and Reverse switch" to the "Forward" position.
Press the pedal.
The vehicle drives forward.
(3) Stop
Remove foot from the accelerator pedal to stop the car.
(4) Reverse
Press the "Forward and Reverse switch" to the "Reverse" position.
Press the pedal.
The vehicle drives backward.

2 . C ircu i t d ia g r a m
-1 0 -
5A
D
M o tor
C h a rg in g
S o ck et
B a tte r y 6V
P o we r S w i tc h
P e d al S w itc h
F o r wa rd &R e v e rse
S w itc h
5 . C HARGINGTHEVEHICLE
●PressthepowerswitchtoOFFpositiontoturnthepoweroff.
●Plugthechargerintothechargingsocketwhichundertheseat.
Plugthechargerintoa240Vmains p o werwalloutlet.
Beforefirstuse,youshouldcharge t h e batteryfor8-12hours,attentivelynomore
than20hour s t o avoiddamagethebatteryandthecharger.
●Neverdrainbatterycompletely or t oacrawlingspeed,rechargethebattery
whenadecreaseinspeedandpowerisnoticedwarranty w illbevoided if
misusehasoccurred.

The charger and the battery are not a toy. Do not allow children to play with the
charger and the battery.
Only operate the battery and charger specified according to the manual instructions.
● Please don't open the battery and the charger.
● Please don't connect the wires to a short circuit.
● Battery charging must be done by adults only.Never allow children to charge
the battery. A child could be injured by the electricity involved in charging
the battery.
● After using or at least once a month,recharge for 8 to 12 hours,no more than
20 hours, if not used regularly.
● Always secure the battery with the bracket.Or battery can be fall out and
injure children if vehicle tips over.
● The battery must be handled and operated by adults only.The battery is heavy
and contains sulfuric acid(electrolyte).Dropping the battery could result in
serious injury.
● Before charging the battery check if wear or damage to the battery,charger,the
connectors and other parts.Any damage is found,the charger should be repaired
or replace immediately.Do not use a damaged charger.
● It is normal for the adaptor to feel warm during charging,but if the chargr
feels too hot,stop charging right now and check the battery and adaptor.
6．FUSE
The self-resetting fuse is under the seat(Refer to the picture.)
The vehicle is equipped with a self-resetting fuse. When the vehicle is
overloaded or operated incorrectly, the self-restting fuse will be cut off for
about 5-20 seconds before resuming.
To avoid electric shock,follow these guidelines:
PLEASE DON'T overload the vehicle. The maximum load is 30 Kg.
5A
-11-

PLEASE DON'T
PLEASE DON'T
PLEASE DON'T
tow anything behind the vehicle.
drive the vehicle up the steep slope.
drive into rugged objects,which may cause the wheels to spin,
causing the motor to overheat.
PLEASE DON'T
PLEASE DON'T
drive in very hot weather,components may overheat.
allow water or any other liquids to come in contact with the
battery or other electric components.
PLEASE DON'T tamper with the electric system.Or maybe create a short circuit ,
causing the fuse to trip.
01. While riding,adult supervision is required all the time.
02. Always wear a helmet when driving.
03. Please don't drive near road or on the footpath.
04. It is not recommended to drive the vehicle on wet surface or on slope
greater than 15-degree.
05. It is recommended to drive this vehicle on smooth surface only,
06. Please don't driving this vehicle outdoors when it is raining.
07. Make sure that the vehicle stop completely before changing direction from
orward to reverse.
08. Please don't allow children to operate the charger or play with the battery
09. Clean the vehicle with a dry cloth only.
10. Please follow the correct weight and age limits allowed to drive this
vehicle.
11. It is prohibited to change th e circuit or add other electric parts.
12. Adults must teach their children about safe driving procedures.
13. Please turn the power off when not in use.
14. Check the seat to ensure it has been fitted and secured with a bolt before
driving.
15. Inspect all wires and connections of the vehicle periodically.
16. Charging the battery should only be done by adults.
17. Charging plug is located underneath the seat.
18. In order to avoid accidents,please ensure the vehicle is safe before driving.
7. SAFETY PRECAUTIONS
-12-

19. Please don't let any child touch the wheels or be near them when the car is
moving.
8．MAINTAINING VEHICLE
● Use a soft,dry cloth to clean the vehicle.
● ADULTS ONLY:recharge the battery after each use,Recharge the battery at least
once a month when the vehicle is not being used.
● This toy should be kept away from fire,Keep the vehicle away from sources of
heat,such as stoves and heaters,or plastic parts may melt.While charging
ensure all flammable liquids are well away from the vehicle.
● Keep the vehicle in an upturned position,do not overturn or incline it. It is
recommended to store the vehicle indoors when not in use,If stored outdoors,
the vehicle needs to be covered by a tarp for protection against weather
elements.
● Occasionally use a lightweight oil to lubricate moving parts such as wheels
and steering linkages.
● It is parent's responsibility to check main parts of the vehicle before using.
Regularly examine the vehicle for potential hazards,such as:the battery,
charge cable and cord,plug and ensure screws are tightened,If there are any
damages,the vehicle must not be used until these damages have been properly
repaired or replaced.
● Please don't use chemical liquid to clean the plastic surface of the vehicle.
● Please don't wash the vehicle with soap and water.
● Please don't drive the vehicle in rainy or snowy weather.Water will damage the
motor,electric system and the battery.
● When not in use all the electrical source should be turned off.Press the power
switch to OFF position to turn the power off,and disconnect the battery
connection under the seat.
● Please don't change the structure of this product and circuit system.
● Please don't use the vehicle for other purposes except riding.
-13-

9．TROUBLE-SHOOTING
PROBLEM POSSIBLE CAUSE
The 6-Volt
battery will
not recharge
The vehicle
d oes n o t r u n
(1) The battery is dead. Have you properly maintained the
battery according to the directions? Is the battery
old? Your battery may need to be replaced. Contact
Customer Sevice or Importer
(2) Electrical system is damaged. Water may have corroded
the system or loose dirt, gravel or sand may have
jammed the switch.
(3) Motor is damaged. Contact Customer Sevice or Importer
(4) Battery connector is loose.
Make sure the battery connector is firmly plugged in.
(5) The 6 Volt battery will not recharge. Make sure the
charger is plugged into a 240 Volt wall outlet and the
power flow to the outlet is turned on.
(6) Charger is not plugged in. Make sure the charger is
plugged into a 240 Volt wall outlet and the power flow
to the outlet is turned on.
(7) Check and replace fuse if necessary.
(1) Battery connector is loose.
Make sure the battery connector is firmly plugged in.
(2) The 6-Volt battery will not recharge.
Make sure the charger is plugged into a 240 Volt wall
outlet and the power flow to the outlet is turned on.
(3) Charger is not plugged in.
Make sure the charger is plugged into a 240 Volt wall
outlet and the power flow to the outlet is turned on.
(4) Check and replace fuse if necessary.
-14-

PROBLEM POSSIBLE CAUSE
The vehicle
d oes n ot ru n
for very long
(1) The battery needs recharging. After each use, or at a
minimum of once a month, charge the battery for a full
10 - 12 hours. DO NOT leave the battery on the charger
for more than 20 hours.
(2) The battery is old. The 6 Volt battery will eventually
lose the ability to hold a charge. Depending on the
amount of use, and varying conditions, the battery
should operate for one to three years. Replace the
battery with a new 6 Volt battery.
(3) The vehicle is overloaded. Maximum weight is 30kg . D O
NOT overload the vehicle. DO NOT tow anything behind the
vehicle.
Battery buzzes
or gurgles when
c har gin g
This is normal and not a cause for concern. It may also be
silent when charging, which is also normal.
(1) The battery may be undercharged. You may not be charging
the battery for long enough. After each use, or at a
minimum of once a month, charge the battery for a full
10 - 12 hours.
leave the battery on the charger for more than
20 hours.
(2) The battery is old. The 6 Volt battery will eventually
lose the ability to hold a charge. Depending on the
amount of use, and varying conditions, the battery
should operate for one to three years.Replace the
battery with a new 6 Volt battery.
(3) A vailable through Customer Sevice or Importer.
D O N OT
T he v eh i cl e
runs sluggishly
occurs
o r b ee p in g
-15-

Disposal Of Battery
Disposal Of Batter y
Your sealed lead-acid battery must be recycled or disposed of in an environmentally
sound manner.
Do not dispose of your lead-acid battery in a fire. The battery may explode or leak.
Do not dispose of a lead-acid battery in your regular, household trash. The incineration,
land filling or mixing of sealed lead-acid batteries with household trash is prohibited by
law.
Return an exhausted battery to your local approved lead-acid battery recycle, such as a
local seller of automotive batteries.
Contact your local waste management officials for other information regarding the
environmentally sound recycling and disposal of lead-acid batteries.
FOR CUSTOMER SERVICE OR PRODUCT ENQUIRIES
PLEASE CONTACT Hunter Products Customer Service
TOLL FREE NUMBER: 1800 224 094
OR VISIT WWW.ELECTRICRIDEON.COM.AU
MADE IN CHINA
-16-

10．DISPOSAL OF BATTERY
Disposal of Battery
● Your sealed lead-acid battery must be recycled or disposed of in an
environmentally sound manner.
● Do not dispose of your lead-acid battery in a fire.The battery may explode or
leak.
● Do not dispose of lead-acid battery in your regular household trash.
The incineration land filling or mixing of sealed lead-acid batteries with
household trash is prohibited by law.
● Return an exhausted battery to your local approved lead-acid battery recycle,
Such as a local seller of automotive batteries.
● Contact your local waste management officials for other information.regarding
the environmentally sound recycling and disposal of lead-acid batteries.
Edition:20140703
FOR CUSTOMER SERVICE OR PRODUCT ENQUIRIES
PLEASE CONTACT Hunter Products Customer Service
TOLL FREE NUMBER: 1800 224 094
OR VISIT WWW.ELECTRICRIDEON.COM.AU
MADE IN CHINA
