Hytera HP70X User manual

QUICK REFERENCE GUIDE
HP
70X/ 78X Digital Portable Radio
Hytera Canada
100 Leek Crescent, Unit 11
Richmond Hill, ON L4B 3E6
[phone]
www.hytera.ca [email protected]
Hytera US Inc.
1363 Shotgun Road,
Sunrise, FL 33326
[phone]
www.hytera.us [email protected]
(C) 2022 Hytera Communications Ltd. All rights reserved.
8 Whatney,
Irvine, CA 92618
[phone]

1
Product Layout
HP78X
1
2
3
4
6
7
8
9
10
11
17
18
15
12 20
14
19
16
13
5
21
23
24
25
26
22
No. Part Name No. Part Name
1Side Key 1 (SK1)
(Programmable) 14 Antenna
2Push-to-Talk (PTT)
Key 15 Microphone
3Side Key 2 (SK2)
(Programmable) 16 Right Key
4Side Key 3 (SK3)
(Programmable) 17 Back/Subgroup Key
5Top Key (TK)
(Programmable) 18 On-Off/P2/End Key
(Programmable)
No. Part Name No. Part Name
6 Smart Knob 19 Up Key
(Programmable)
7 LCD Display 20 Down Key
(Programmable)
8 Left Key 21 Battery Latch
9 OK/Menu Key 22 Strap Hole
10 P1/Answer Key
(Programmable) 23 Accessory
Connector
11 Keypad 24 Belt Clip
12 Speaker 25 Battery
13 LED Indicator 26 Charging Contacts
HP70X
1
2
3
4
6
7
8
9
10
11
17
18
15
12 20
14
19
16
13
5
21
23
24
25
26
22
No. Part Name No. Part Name
1 On-Off Key 10 Antenna
2 PTT Key 11 Microphone
3 SK1 (Programmable) 12 Battery Latch
4 SK2 (Programmable) 13 Strap Hole
5 TK (Programmable) 14 Accessory
Connector
6 Smart Knob 15 Belt Clip
7 OLED Display 16 Battery
8 Speaker 17 Charging Contacts
9 LED Indicator / /
●For details about the programmable keys,
contact your dealer.
●Figures in this guide are only for reference.
Basic Operations
Charging the Battery
●Use the approved charger to charge the
battery.
●Read the Safety Information Booklet before
charging.
●The remaining lithium-ion battery power is
limited to 30% pursuant to the new lithium
battery shipment regulation approved by
the International Air Transport Association
(IATA).

2
Before initial use, charge the battery alone or the battery
attached to the radio. It is recommended to keep the radio
turned off during charging.
The LED indicator on the charger shows the charging
status, as described in the following table.
Status Description
Glows red The battery is being charged.
Glows orange The battery is charged to 90% or
above.
Glows green The battery is fully charged.
Flashes red slowly No battery is placed on the
charger.
Flashes red rapidly The battery fails to be charged.
Turning On or Off the Radio
●To turn on the radio, long press the On-Off key or
reattach the battery.
●To turn off the radio, long press the On-Off key.
Adjusting the Volume
Rotate the Smart Knob clockwise to increase the volume,
or counterclockwise to decrease the volume.
Using the Keypad
This feature is available only for HP78X.
●To lock or unlock the keypad, on the home screen,
press the OK/Menu key, and then press .
●To enter the content or edit messages, do any of the
following:
»To switch the input method between alphabetic
mode and numeric mode, press .
»To enter special characters, press in
alphabetic mode.
» To enter a space, press in alphabetic
mode.
Selecting a Zone
●Press the preprogrammed Zone Up or Zone Down
key.
●Go to Menu > Zone to select a zone. This method
applies only to HP78X.
Selecting a Channel
●Press the Smart Knob, and then rotate the knob
within 5 seconds.
●Press the preprogrammed Channel Up or Channel
Down key.
Call Services
To keep the audio quality, keep your mouth 2.5 centimeters
to 5 centimeters away from the microphone.
Initiating a Call on Digital Channel
●Press and hold the PTT key.
●Go to Menu > Contact to select a contact, and then
press and hold the PTT key. This method applies only
to HP78X.
Initiating a Call on Analog Channel
●Call Without Signaling
Press and hold the PTT key.
●Call with Signaling
» Press and hold the PTT key.
» Press the preprogrammed One Touch Call key.
» Go to Menu > Contact to select a contact, and
then press and hold the PTT key. This method
applies only to HP78X.
Emergency
The Emergency feature is congured and enabled by your
dealer. For details, refer to the User Manual.
Status Indications
LED Indicator
Status Description
Flashes green The radio is being turned on.
Glows green The radio is receiving.
Glows red The radio is transmitting.
Flashes orange
slowly The radio is scanning or roaming.
Flashes orange
rapidly
The radio is operating in emergency
mode.
Glows orange
Call hang time: No voice is being
transmitted or received during a call.
Within such a period, you can press
and hold the PTT key to speak.
Flashes blue once
every 3 seconds
The BT feature is enabled, but no
BT device is connected.
Flashes blue once
every 1.5 seconds A BT device is connected.
Flashes blue once
every 0.1 second The BT feature is being disabled.

3
LCD Icons
Icon Radio Status
More bars indicate more remaining battery
power.
The battery power runs out. Recharge or
replace the battery.
The radio detects no signal.
The number of bars indicates the signal
strength.
The radio operates in low power mode.
The radio operates in high power mode.
The radio is scanning.
The radio is operating in emergency mode.
The BT feature is enabled
A BT device is connected.
The Location feature is enabled, and valid
positioning data has been received.
The Location feature is enabled, but no valid
positioning data has been received.
For details on other icons, refer to the User Manual.
